DSE A2629 Manuel utilisateur

A2629

DVD/VCR Home Theatre Receiver

OPERATING INSTRUCTIONS

Important Safety Instructions

CAUTION

The product shall not be exposed to dripping or

splashing and that no object filled with liquids, such

as vases, shall be placed on the product.

Do not install this equipment in a confined space

such as a book case or similar unit.

CAUTION Regarding Placement

To maintain proper ventilation, be sure to leave a

space around the unit (from the largest outer

dimensions including projections) equal to, or

greater than, shown below.

Left and Right Panels : 10 cm

Rear Panel : 10 cm

Top Panel : 50 cm

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of

uninsulated "dangerous voltage" within the

product’s enclosure that may be of

sufficient magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

This mark means double-insulated equipment.

This mark means the equipment complies with

Australian electromagnetic compatibility

requirements and radiocommunications

standards.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK). NO

USER-SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

PRECAUTIONS

MOISTURE CONDENSATION

DO NOT OPERATE THIS UNIT FOR AT LEAST TWO

HOURS WHEN

MOISTURE IN THE AIR CONDENSES ON IT.

<WHAT IS MOISTURE CONDENSATION?

When a cold liquid is poured into a glass.

For example, water vapor in the air will condense on

the surface of the glass. This is called moisture

condensation.

<MOISTURE WILL CONDENSE ON THE UNIT IN THE

FOLLOWING CASES;

When you move the unit from a cold to a warm place.

After heating a cold room or under extremely humid

conditions.

<WHEN YOU EXPERIENCE THE ABOVE CONDITIONS

(for Head Drum);

Plug the power cord into an AC outlet. Set the power

switch to ON and leave the unit at room temperature

until moisture condensation disapears.

Dpending on the surrounding conditions, this may

take two or three hours.

If you cause a static discharge when touching the UNIT,

and the unit fails to function, simply unplug the unit from

the wall outlet.

Wait a few minutes and plug it back in. The unit should

return to normal operation.

The ventilation holes prevent overheating. Do not block

or cover these holes.

Especially avoid covering the holes with soft materials

such as cloth or paper.

Do not insert fingers or any other objects into the

cassette loading slot. Do not spray cleaner or wax

directly on the unit or use forced all to remove dust.

Avoid places subject to strong vibration. Use in a

horizontal (flat) position only.

Keep the unit away from flower vases sink, etc. If liquids

should be spilled into the unit serious damage will

result. If you spill any liquids into the unit unplug the AC

power cord immediately and consult qualified service

personnel before attempting to use the unit again.

When you finish operating the unit always unload the

cassette and turn off the

power.

When you leave your home for a long time, unplug the

AC power cord.

To protect the unit during a lightning storm, unplug the

AC power cord from the wall outlet. Do not touch the

antenna leads.

Table of Contents

INTRODUCTION

Contents...................................................................................4

Before Use .............................................................................5

Discs.........................................................................................6

Remote Control Unit ............................................................10

Connection............................................................................11

Connecting Antennas..........................................................17

Names of Each Control .......................................................18

DVD PART

DVD Settings.........................................................................23

Surround Mode ....................................................................26

Speaker Configuration ........................................................27

Night Mode ...........................................................................29

Setting a Rating Level and Password ..............................30

Basic Operation ...................................................................31

Playback................................................................................32

Resume Playback ................................................................33

Playback from a specific chapter/track...........................34

Slow-Motion Playback........................................................35

Single Stepping Playback...................................................35

Direct playback ....................................................................35

Repeat Playback .................................................................36

Shuffle Playback of CD, MP3 .............................................37

Programmed playback (CD) ...............................................38

GUI(Graphical User Interface) ..........................................40

Title Select ............................................................................41

Time Select ..........................................................................41

Picture Zoom.........................................................................42

JPEG ....................................................................................42

Change the Angle ................................................................43

Select a Subtitle Language ..............................................43

Select an Audio Language .................................................44

TUNER PART

Tuner .....................................................................................45

Preset Tuning .......................................................................46

VCR PART

Menu Screen Operation .....................................................47

Setting the Clock .................................................................48

Channel Setting ..............................................................49-50

'INITIAL SET' menu ........................................................51-52

Language Selection.............................................................52

Video Cassette ................................................................53-54

Basic Playback.....................................................................55

Special Operation ................................................................56

Digital Shuttle Function.......................................................57

Recording TV Programs ................................................58-59

Duplicating a Video Tape....................................................60

One Touch Timer Recording (OTR) ...................................61

Normal Timer Programming .........................................62-65

Checking and Cancelling Timer Recording ....................66

VISS (VHS Index Search System) ...............................67-68

Clock/Count Display.............................................................68

Copying from DVD to VHS...................................................69

MTS Broadcast / TV Stereo System .................................70

Select Audio Mode for Playback.......................................70

Select Audio Mode for Recording.....................................70

Reference

Glossary ................................................................................71

Remote...................................................................................72

Troubleshooting ...................................................................78

Specifications.......................................................................79

DO NOT MOVE THE UNIT DURING PLAYBACK

During playback, the disc rotates at high speed. Do

NOT lift or move the unit during playback. Doing so

may damage the disc or the unit.

WHEN MOVING THIS UNIT

When changing places of installation or packing the

unit for moving, be sure to remove the disc and

return the disc tray to its closed position in the

player. Then, press the power switch to turn the

power off, and disconnect the power cord. Moving

this unit with the disc loaded may result in damage to

this unit.

Before Use

Conventions about This User Guide

<Instructions in this user guide describe the controls

on the remote control. You can also use the buttons

on the front panel if they have the same or similar

names as those on the remote.

<The types of functions and operations that can be

used for a particular disc vary depending on the

features of that disc. In some cases, these functions

and operations may differ from the descriptions

given in this User Guide. In this event, follow the

instructions given on the screen. This User Guide

only covers basic disc operations.

<For some operations, the PROHIBIT icon "A" may

appear on the screen. This indicates that the

operation described in this User Guide is not

permitted for the current disc.

<The drawings about the TV screen and front panel

display used in this User Guide are purely for the

purposes of explanation. The actual displays may

differ slightly from what are shown here.

Read this before operation

<As the unit may become warm during operation,

always leave sufficient space around the unit for

ventilation.

<The voltage supplied to the unit should match the

voltage as printed on the rear panel. If you are in any

doubt regarding this matter, consult an electrician.

<Choose the installation location of your unit carefully.

Avoid placing it in direct sunlight or close to a source

of heat. Also avoid locations subject to vibrations

and excessive dust, heat, cold or moisture.

<Do not place the unit on an amplifier or receiver.

<Do not open the cabinet as this might result in

damage to the circuitry or electrical shock. If a

foreign object should get into the unit, contact your

dealer or service company.

<When removing the power plug from the wall outlet,

always pull directly on the plug, never yank the cord.

<To keep the laser pickup clean, do not touch it, and

always close the disc tray.

<Do not attempt to clean the unit with chemical

solvents as this might damage the finish. Use a

clean, dry cloth.

<Keep this user guide in a safe place for future

reference.

"DTS" and "DTS Surround" are registered trademarks of Digital

Theater System, Inc.

Manufactured under license from Dolby Laboratories. “Dolby”,

“Pro Logic” and the double-D symbol are trademarks of Dolby

This product incorporates copyright protection technology that

is protected by method claims of certain U.S. patents and other

intellectual property rights owned by Macrovision Corporation

and other rights owners. Use of this copyright protection

technology must be authorized by Macrovision Corporation, and

is intended for home and other limited viewing uses only, unless

otherwise authorized by Macrovision Corporation. Reverse

engineering or disassembly is prohibited.

Discs 1

Type of Discs That Can be Played on

This System

This player can playback discs bearing any of the

following marks:

Note 2

The specific playback functionality for some DVD

and video CD discs is determined by the disc

manufacturer. Because this DVD player plays disc

data in accordance with the disc manufacturer’s

guidelines, some functions may not be available on

some discs. Be sure to read the instructions provided

with the disc.

The PROHIBIT icon "A" displayed during DVD player

operation indicates that such manufacturer imposed

restrictions apply.

Note 1

DVD players and discs are designed with region

numbers that dictate the regions in which a disc can

be played. If the region number on the disc you want

to play does not match the region number of your

DVD player, you will not be able to play the disc. In

that case, an error message will appear on the

screen.

The region code is printed on the rear panel of this

unit. Discs having the following region codes can be

played on this unit :

DVDs

12cm or 8cm disc

See Note 1, 2, 3.

Audio CDs, MP3

12cm or 8cm disc

See Note 4.

Note 3

The audio on a DVD disc recorded in MPEG version

2.0 format cannot be played (MPEG-2 is an image

only format).

Note 4

File names of MP3 should be alphanumeric

characters. This unit cannot display symbols and full-

size or 2 bytes-wide characters (such as Japanese,

Chinese, etc.) correctly.

Also, be sure to use the extension ".mp3".

When more than 200 MP3 files are recorded on the

disc, the unit might not be able to play it correctly.

About CD-R/CD-RW

CD-R/RW discs recorded in Audio CD format and

finalized correctly are playable. But depending on

the quality of the disc and/or the condition of the

recording, some CD-R & CD-RW discs may not be

playable.

Discs 2

The following discs cannot be played

with this unit:

CD-G, CD-EXTRA, PHOTO CD, CD-ROM and DVD-

ROM discs.

Discs recorded in a colour system other than PAL or

NTSC.

Illegally produced discs.

Scratched discs.

Discs that are dusty, soiled or marked with

fingerprints.

Warning:

If you attempt to play back such discs, there is a risk

that a sudden loud noise can blast over the speakers

at full volume and cause damage to the speakers and

your hearing.

<Copy-protected discs and other discs which do not

conform to the CD standard may not play back

correctly in this player. If you use such discs in this

unit, we cannot be responsible for any

consequences or guaranteed quality of playback. If

you experience problems with such non-standard

discs, you should contact the producers of the disc.

Discs 3

Glossary of Disc Terms

Title (DVD)

The longest sections of a picture or a music piece on

a DVD; a movie, etcetera, for a picture piece on a

video software; or an album, etc., for a music piece

on an audio disc. Each title is assigned a title number

enabling you to locate the title you want. On most

DVD movies, there will be only one title.

Chapter (DVD)

Sections of a picture or a music piece that are

smaller than titles. A title is composed of several

chapters. Each chapter is assigned a chapter

number enabling you to locate the chapter you want.

Depending on the disc, there may be only one

chapter per title recorded.

Track (audio CD)

Sections of a music piece on an audio CD. Each track

is assigned a track number enabling you to locate

the track you want. On most audio CD's, one track is

equal to one song.

number of audio tracks recorded

on the disc

number of subtitles recorded on

the disc

screen aspect ratio

disc recorded with multiple

camera angles

region code

Track 1 Track 2 Track 3 Track 4

Piste 1 Piste 2 Piste 3 Piste 4

Pista 1 Pista 2 Pista 3 Pista 4

DVD

Chapter 1 Chapter 2 Chapter 1 Chapter 2

Chapitre 1 Chapitre 2 Chapitre 1 Chapitre 2

Capitulo 1 Capitulo 2 Capitulo 1 Capitulo 2

Title 1

Titre 1

Titulo 1

Title 2

Titre 2

Titulo 2

Example of Icons used on DVD discs:

Notes on Discs

This section shows you how to handle, clean, and store

discs.

<Always place the disc on the disc tray with the label

side up. (Compact discs can be played or recorded

only on one side.)

<To remove a disc from its storage case, press down

on the center of the case and lift the disc out, holding

it carefully by the edges.

How to remove the disc

How to hold the disc

<Should the disc become dirty, wipe the surface

radially (from the center hole outward towards the

outer edge) with a soft, dry cloth :

<Never use such chemicals as record sprays,

antistatic sprays or fluid, benzine or thinner to clean

the discs. Such chemicals will do irreparable

damage to the disc's plastic surface.

<Discs should be returned to their cases after use to

avoid dust and scratches that could cause the laser

pickup to "skip."

<Do not expose discs to direct sunlight or high

humidity and temperature for extended periods. Long

exposure to high temperatures will warp the disc.

<Do not play any disc that is warped, deformed or

damaged. Playing such discs may cause irreparable

harm to the playing mechanisms.

<CD-R and CD-RW discs are more sensitive to the

effects of heat and ultraviolet rays than ordinary CDs.

It is important that they are not stored in a location

where direct sunlight will fall on them, and which is

away from sources of heat such as radiators or heat-

generating electrical devices.

<Printable CD-R and CD-RW discs aren't

recommended, as the label side might be sticky and

damage the unit.

<Do not stick papers or protective sheets on the discs

and do not use any protective coating spray.

<Use a soft oil-based felt-tipped pen to write the

information on the label side. Never use a ball-point

or hard-tipped pen, as this may cause damage to the

recorded side.

<Never use a stabilizer. Using commercially available

CD stabilizers with this unit will damage the

mechanisms and cause them to malfunction.

<Do not use irregular shape CDs (octagonal, heart

shaped, business card size, etc.). CDs of this sort

can damage the unit:

<If you are in any doubt as to the care and handling of

a CD-R/CD-RW disc, read the precautions supplied

with the disc, or contact the disc manufacturer

directly.

Remote Control Unit

Remote Control Battery Installation

Remove the battery compartment cover.

Insert two “AAA“ dry batteries. Make sure that the

batteries are inserted with their positive “+“ and

negative “_“ poles positioned correctly.

Close the cover.

Battery Replacement

If the distance required between the remote control unit

and main unit decreases, the batteries are exhausted. In

this case replace the batteries with new ones.

Precautions concerning batteries

<Be sure to insert the batteries with correct positive

“+“ and negative “_“ polarities.

<Use batteries of the same type. Never use different

types of batteries together.

<Rechargeable and non-rechargeable batteries can

be used. Refer to the precautions on their labels.

<When the remote control unit is not to be used for a

long time (more than a month), remove the batteries

from the remote control unit to prevent them from

leaking. If they leak, wipe away the liquid inside the

battery compartment and replace the batteries with

new ones.

<Do not heat or disassemble batteries and never

dispose of old batteries by throwing them in a fire.

Remote Control Operation Range

The provided Remote Control Unit allows the unit to be

operated from a distance.

When operating the remote control unit, point it towards

the REMOTE SENSOR on the front panel of the unit.

<Even if the remote control unit is operated within the

effective range, remote control operation may be

impossible if there are any obstacles between the

unit and the remote control.

<If the remote control unit is operated near other

products which generate infrared rays, or if other

remote control devices using infrared rays are used

near the unit, it may operate incorrectly. Conversely,

the other products may operate incorrectly.

Table des matières

Autres manuels DSE Récepteur

DSE

DSE RE-HDMI-NET Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
