DOT ECOMPACT Manuel utilisateur

READ THE ENTIRE OWNER’S MANUAL BEFORE USING YOUR DOT BOARD

Owner’s Manual

Transporter model shown here with optional 120 mm wheels and optional four battery configuration

WARNING

THE

USE OF ANY SKATEBOARD PRESENTS RISKS AND DANGERS.

THE

USE

OF THIS PRODUCT HAS INHERENT RISKS AND DANGERS AND

ITS

USE

CAN RESULT IN SERIOUS INJURY OR DEATH EVEN WHEN

SAFETY

EQUIPMENT

IS USED AND OTHER PRECAUTIONS ARE TAKEN.

NOT USE THIS PRODUCT UNTIL YOU READ THE ENTIRE

MANUAL,

WHICH

EXPLAINS HOW TO REDUCE SOME RISKS.

Welcome

Congratulations, and thank you for choosing a Transporter, Cruiser or Compact dot board.

Please take the time to read this owner’s manual and familiarize yourself with and understand all the important information

in this manual before riding your new dot board.

We wish you an enjoyable riding experience.

dot board

For the latest updates to this manual, questions, video tutorials and additional help, please visit www.dotboards.com or

you can email us at info@dotboards.com.

Welcome

UPDATES

TO THIS MANUAL, WARNINGS, BATTERY INFORMATION, QUICK START GUIDE, FIRMWARE, AND OTHER INFORMATION WILL BE POSTED

OUR

WEBSITE.SO PLEASE CHECK OUR WEBSITE PERIODICALLY FOR UPDATES.PLEASE REGISTER YOUR DOT BOARD ON OUR WEBSITE SO THAT WE

CAN

YOU UPDATED INFORMATION.PLEASE NOTIFY US OF ANY CHANGES TO YOUR EMAIL AND OTHER CONTACT DETAILS.

NOTE: Illustrations and photographs that appear in this manual are for demonstration purposes only and do not necessarily

reflect the exact parts and accessories or the dot board you purchased. Product specifications are subject to change

without notice.

Keep this manual with your dot board skateboard as a reference. Should you resell your dot board or give it away , please

pass this manual on to the next owner.

Table of Contents

Safety Warning…….……..……………………….………………………………...... 6

Important Labels.....……………….…..……..……..……………………………... 8

Accessories and Modifications…..………………..………………………….…. 9

Model Details –Transporter………..……….…..………………………….…... 10

Model Details –Cruiser……………….………..…..………………………………. 11

Model Details –Compact….…….………………………..…………..……....... 12

Remote Controller –RC100.……………………..……………..….……………. 13

Main Controller –MC100...………………………..…….…….………………… 14

Battery Module –BM100……………………………..…..……………………... 15

Motorized Truck Assembly and Hub Motor…..………………………….. 16

Parts Diagram……………………….…………………………......................... 17

Unpacking Your Skateboard…..………………................................... 18

Battery Safety……………….……..……………………………………............... 19

Battery Care and Installation..………………………………………………….. 20

Removing or Replacing Batteries..…………….…………….……..……..... 22

Charging the Battery.………….………..…..…………….……....…………….... 24

Table of Contents 5

Remote Controller Pairing......…………………..………………..…............ 26

Remote Controller Menu –Main ….…………………………….……..….... 27

Remote Controller Menu –Info ….…………………………….…………..... 28

Remote Controller Menu –Options………..….………………………….... 29

Remote Controller Menu –Ride…..………..….………………………….... 30

Remote Controller Menu Features………………….……………..……..... 31

Remote Controller Ride Levels………….…………….………………..…..... 32

Remote Warning and Haptic (Vibration) Feedback………………...... 33

Setting Up & Before Riding.……………………………………….…….......... 35

Operating Your dot board….…………………………………………….......... 36

Hub Motor and 120mm Wheel Installation….………….….…........... 37

Transporter –120mm Wheel Installation….…………………..……...... 38

Firmware Updates….…………………..………………..…….…………………… 39

Storing Your dot board..….……………………..…………...………………….. 40

Flying With Your dot board.……………………………..…………………….... 41

Warranty and Insurance Information..………………..………………...... 42

Certifications.………………………………………………………..…………………. 43

Regulations……………...………….…………..…………….…………..………..... 45

Product and Battery Disposal Information…………………….…..…….. 46

Safety Warnings

THE USE OF ANY SKATEBOARD PRESENTS RISKS AND DANGERS. THE USE OF THIS PRODUCT HAS INHERENT RISKS AND DANGERS AND ITS USE CAN RESULT IN

SERIOUS INJURY OR DEATH EVEN WHEN SAFETY EQUIPMENT IS USED AND OTHER PRECAUTIONS ARE TAKEN.

WARNING

READ AND UNDERSTAND THE ENTIRE OWNER’S MANUAL PRIOR TO USE*

WARNING

THIS PRODUCT INCLUDES ONE OR MORE RECHARGEABLE BATTERIES WHICH POWERS ONE OR MORE ELECTRIC MOTORS. MISUSE OF THE BATTERY CAN RESULT

IN SERIOUS INJURY, DEATH, FIRE OR OTHER DAMAGE. READ AND FOLLOW THE SEPARATE WARNINGS AND INSTRUCTIONS REGARDING THE BATTERY.

USE THIS PRODUCT AT YOUR OWN RISK

YOUR SAFETY IS UP TO YOU. Before using your dot board, please read and understand the entire instruction manual, which contains further warnings and information

WARNING

Depending upon the age, skill level and maturity of the user, the dot

board may not be suitable for everyone. This product is not

recommended for riders under the age of 18. The use of this product by

someone who lacks the necessary physical development, skills or

maturity presents an increased risk of serious injury or death. This

product is NOT a toy. NEVER leave this product with unattended children.

WARNING

Under some circumstances, the electric brakes may not work, especially

if the battery is fully charged due to the regenerative braking feature. It

is also possible to lose power and brakes due to radio interference or a

dead Remote control battery. Therefore, only ride this product at speeds,

on slopes, and in situations where you would be comfortable riding the

product without power or brakes.

WARNING

Not wearing a helmet increases the chances of serious injury or death. Be

sure you always wear a helmet and other protective gear when you ride.

WARNING

Once the skateboard starts moving, the Remote control will continue to

respond to the skateboard even if you are not on the skateboard. If you

step off, fall off the skateboard, or are not on the skateboard while the

skateboard is moving, the skateboard will continue to move even if you

are not on it. Therefore, it is important that you use the Remote only

while you are on the skateboard or while the skateboard is in the upside

down position. In the event of a runaway skateboard, attempt to use the

brakes on the Remote to stop the skateboard but be aware that it is

possible that the brakes may not always work.

Safety Warnings

YOU INCREASE THE RISKS IF YOU:

•Fail to wear a helmet

•Ride at speeds, on inclines, or in situations where you are not safely in control

•Attempt tricks or stunts

•Ride at night, in low visibility, in wet or icy conditions, in bad weather such as rain

or fog, or in other risky environments

•Ride if you are impaired (physically or mentally)

•Ride if you are pregnant, have any heart, head, back or neck conditions

YOU MAY DECREASE THE RISKS IF YOU:

•Wear a helmet –ALWAYS WEAR A HELMET TO REDUCE THE RISK OF HEAD

INJURIES

•Wear other protective gear and clothing

•Ride within your capabilities and use common sense and good judgment

•Pay attention to your surroundings and watch for cars, pedestrians, bikes,

other vehicles and other hazards

•Ride on flat, dry, level ground that is clear of debris

Safety Warnings 7

*WARNINGS AND INSTRUCTIONS MAY CHANGE OVER TIME.

FOR THE MOST UPDATED OWNER’S MANUAL PLEASE VISIT www.dotboards.com AND CLICK ON THE SAFETY/MANUAL LINK.

Check laws and regulations that govern the use of the product on public roads, bike paths, sidewalks and other places that you plan to use this product.

You are responsible for knowing and abiding with all applicable laws and regulations

WARNING

While your dot board is equipped with red rear lights, they are not brake

lights and may not always be visible. If you ride in low visibility conditions,

use equipment and clothing that makes you visible to others and that

allows you to see where you are going.

WARNING

Do not disassemble or tamper with or attempt to repair the hub motor(s),

or the Main

Controller Module or battery, or the Remote Control. They

contain chemicals or components that may cause injury.

WARNING

This product is not for riders heavier than 265 pounds (120 kilograms). DO

NOT EXCEED THE WEIGHT LIMIT OF 265 POUNDS (120 KILOGRAMS)

–

including backpacks and other items that the rider might be carrying. This

product is intended to be a single rider use only. DO NOT ride with any

additional passengers. Doing so may exceed the capacity of the product

and result in a loss of control or reduced braking or insufficient power.

WARNING

Do not touch the rear truck or motor after extended use as they may get

hot and may cause burns.

YOUR SAFETY IS UP TO YOU. It is not possible to list all do’s and don’ts. We list only some ways that may help reduce the risk of injury or death

Important Labels

Main Controller Label -MC100

SAFETY LABELS

Safety labels on your skateboard either warn you of potential hazards

that could cause serious injury or provide important safety

information. Read these labels carefully and don’t remove them.

Note: If a label comes off or becomes hard to read, contact us at

info@dotboards.com

Battery Module Label –BM100

Important Labels

When applicable, the battery module label is attached to the

top cover of the battery module case. This faces the

underside of skateboard deck and not visible unless the

battery module is removed or upon first assembly and use.

Remote Label -RC100

Warning Label –On underside of the skateboard deck

Accessories and Modifications

Modifications

Do not remove any original equipment or improperly modify

your dot board in any way that would change its design or

operation. Such changes could seriously impair your

skateboard’s handling, stability, and braking, making it unsafe

to ride.

Risk of Electric Shock

Do not open or tamper with the electrical or electronic

housings, including battery electronics and cells and main

controller module. This is dangerous and can lead to fire or

explosion or malfunctions. Tampering will also void your

warranty.

ACCESSORIES AND MODIFICATIONS

Improperly modifying your dot board or using uncertified accessories can

make your dot board unsafe.

Accessories

•Only use dot board accessories and parts that have been specifically

designed and tested for your dot board. You will be solely personally

responsible for any damage that may result from your use of any

uncertified accessories or improper modifications of your dot board.

•Do not add any electrical equipment to the dot board electrical system. A

blown fuse can cause a loss of lights or motor power. Any interference to

the electrical system can result in erratic behavior of the main controller

module.

•Do not modify, open, or tamper with the battery module. Do not tamper

with the cells contained within the battery module, these have been

specifically designed, programmed and tested to use with your dot

board.

Accessories and Modifications 9

WARNING

USE OF IMPROPER

ACCESSORIES OR IMPROPER MODIFICATIONS

CAN

CAUSE DAMAGE TO YOUR DOT BOARD WHICH CAN LEAD TO

SERIOUS INJURY OR DEATH.

FOLLOW ALL INSTRUCTIONS IN THIS OWNER’S MANUAL REGARDING

ACCESSORIES AND MODIFICATIONS

WARNING

DO NOT use

uncertified batteries, chargers or other parts

with your dot

board. Only use genuine dot board batteries,

chargers, and parts. The use of

uncertified batteries,

chargers or parts with your dot board may pose a fire hazard

and other hazards

which can result in serious injury or

death.

Model Details - Transporter

TRANSPORTER

The Transporter comes standard with two motors and two batteries - you have the

option to upgrade to three or four batteries and larger 120mm comfort wheels.

•Approximate Range:

Two Batteries 12 Miles/20 Km

Three Batteries 18 Miles/30 Km

Four Batteries 24 Miles/40 Km

•Approximate Max Speed:

83mm Wheels: 18 MPH/30 KPH

120mm Wheels: 24 MPH/40 KPH

•Approximate Hill Climb: up to 30% grade

•Approximate Product Weight:

Two Batteries + Two Motors: 16 lbs/ 7 kgs

Three Batteries + Two Motors: 18 lbs/ 8 kgs

Four Batteries + Two Motors: 20 lbs/ 9 kgs

•Dimensions: 11 inches/28 cm (wide), 42 inches/107 cm (length), 5 1/2 inches/ 14 cm

(height)

•Brakes: regenerative braking delivered by the dot Hub Motor

•Deck: 8-ply teak + hard rock maple, eco-resin construction

•Wheels: 83mm 78a or 120mm 78a urethane

•Front Truck: 150mm magnesium reverse kingpin

•Charger: 3.5A 48V DC power adaptor with magnetic cable (standard)

•Approximate Charge Time:

Two Batteries with Standard 3.5A 48V Adaptor - 90 Minutes

Three Battery with Standard 3.5A 48V Adaptor - 135 Minutes

Four Battery with Standard 3.5A 48V Adaptor - 180 Minutes

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels DOT Skateboard et longboard

DOT

DOT Compact Manuel utilisateur

Manuels Skateboard et longboard populaires d'autres marques

Walksmart

Walksmart Fuga Manuel utilisateur

Mattel

Mattel Fisher-Price DYH05 Manuel utilisateur

VOLTAWAY

VOLTAWAY POCKETROCKET 26 Manuel utilisateur

Lycaon Board

Lycaon Board Lycaon GR Manuel utilisateur

Ignite

Ignite ESK02 Manuel utilisateur

YUNEEC

YUNEEC E-GO Cruiser Manuel utilisateur

Miles

Miles Phantom Manuel utilisateur

Hudora

Hudora Skateboard Retro Instructions de montage

fun pro

fun pro Mini Cruiser Manuel utilisateur

Beeper

Beeper RoadBoard SK1 Manuel utilisateur

Backfire

Backfire Ranger X3 Manuel utilisateur

Gyroor

Gyroor R1 Manuel utilisateur

MOOVI

MOOVI EB203A Manuel utilisateur

iSinwheel

iSinwheel V8 Manuel utilisateur

YUNEEC

YUNEEC E- GO Manuel utilisateur

OnlyOne

OnlyOne O-3 Manuel utilisateur

Clas Ohlson

Clas Ohlson 31-9262 Manuel utilisateur

Miles

Miles RAMPAGE Manuel utilisateur

DOT eCOMPACT Manuel utilisateur

Manuels Skateboard et longboard populaires d'autres marques
