Doro FORM 20 Manuel utilisateur

FORM 20/25R

13 15

Phone book

Left menu button/OK

Headset connector

Talk button

Speaker phone

Down/Redial

*and keypad lock

#and ring signal On / Off

RRecall button (PBX features)

End call and on / off button

Right menu button/Back/Internal call

Up / missed call

10.

11.

12.

Only for Form 25r:

Indicators, see Base unit indicators

section

Paging

Answer machine functions. Detailed in

Answer machine section.

Message indication/display

13.

14.

15.

16.

English

Répertoire

Touche menu / OK

Prise casque

Touche de prise de ligne

Touche Mains-libres

Touche délement / Bis

*et Verrouillage du clavier

Touche #et Sonnerie Off/On

Touche R

Touche de raccroché et on/off

Touche menu / Retour / Intercom

Touche délement / Journal des

appelants

10.

11.

12.

Uniquement pour le modèle Form 25r:

Témoins lumineux, voir description.

Touche de recherche du combiné

Fonctions répondeur, voir la section

Répondeur

Compteur de messages

13.

14.

15.

16.

Français

English

Installation

Connection

Connect mains adapter and phone cable to wall sockets.

Insert batteries (1.2V NiMH AAA) in accordance with the markings.

Place the handset into base unit with the keypad facing outwards to charge (24 hours the

rst time).

Press (left menu button).

Scroll {/}to HS SETTINGS.

Press OK (left menu button).

Scroll to LANGUAGE. Press OK.

Scroll to ENGLISH. Press OK.

Press Lor several times to exit the menu screens.

Note!

The mains socket outlet must be located near the equipment and easily accessible.

If the Form 25r base unit’s display is showing -- the answer machine is disconnected, or

time/date is not set.

Date/Time

Press (left menu button).

Scroll {/}to HS SETTINGS. Press OK.

Scroll to HS DISPLAY. Press OK.

Scroll to TIME. Press OK.

Scroll to DATE & TIME. Press OK.

Scroll to SET TIME. Press OK.

Enter time of day (HH-MM). Press OK.

Scroll to SET DATE. Press OK.

Enter date (DD MM YY). Press OK.

Press Lor several times to exit the menu screens.

The format of date/time can also be adjusted in this menu in the same way as other settings.

10.

English

Battery

When the batteries are relatively new (less than 6 months) and fully-charged (10 hours) they

will last for approx 100 hours standby time or approx 10 hours call time. Full battery capacity

will not be reached until the batteries have been charged 4–5 times. It is not possible to

overcharge or damage the batteries by charging them for ”too long”. It may take up to 5

minutes charging before display illuminates, if batteries are totally empty.

Warning!

Risk of explosion if battery is replaced by an incorrect type. Use only original batteries.

The guarantee does not cover any damage caused by using the wrong batteries.

Note!

When the battery is low or when there is too great a distance to the base unit the

telephone will be unable to connect to a line. Do not place the base unit close to other

electrical equipment, in direct sunlight or other strong heat sources! This is to minimize the

risk of any interference. It is normal for the device to become warm during charging and this is

not dangerous.

Dispose of used batteries according to the instructions.

Battery LED

When the batteries are running low, will ash and a warning tone will be heard when a call

is in progress.

Please note that the complete battery indicator in the display will ash as long as the handset is

charging, and when the battery is fully charged only the inner segment will ash.

Base unit indicators

7Steady light while charging.

Only Form 25r:

Steady light during calls and ashes when there is an incoming call or

new message on the answer machine.

English

Range

The telephone’s range depends on whether or not the radio waves carrying the call are

restricted by obstacles in their path, and is usually between 50 and 300 metres. Coverage can

be improved by turning one’s head so that the handset is aligned with the base unit. Sound

quality declines as the limit is reached until the call is nally interrupted.

The 6 symbol is shown when the phone is within range and goes out/ashes when it is out of

range.

Eco Functionality

We have introduced the ECO FUNCTIONALITY label to help customers identify products within

our assortment having a lower impact on the enviornment. Products carrying this label feature:

Reduced power consumption in both operational and standby modes.

Adaptive transmission power depending on range on base unit.

Full Energy Star®compliance and approval (www.energystar.gov)


The base unit is designed to t a photo of your choice. Remove the foto lid by inserting your

nger on the top side recess area. You may use the lid for cutting the photo to correct size.

Replace the photo lid on top of your photo.

•

English

Operation

Making a call

Enter the required number. Delete if necessary with right menu button C.

Press qto make the call. Press Lto end the call.

Note!

To switch between handset/speaker press . In speaker mode, you cannot both speak at

once – you must take it in turns to talk.

When batteries are really low the speaker phone and backlight will not work in order to

save the batteries.

Receiving a call

Wait for the handset to ring.

Press qto answer. Press Lto end the call.

Volume control

The volume may be adjusted during a call with {/}.

Redial

Press r. Scroll among the 5 most recently dialled numbers with {/}. Press q.

Mute button

The microphone can be switched on / off during a call with C (right menu button).

Paging

The handset will ring when J(on the base unit) is pressed. The signal will stop automatically

after a while or if the Lbutton on the handset or the Jbutton on the base unit are

pressed.

Temporary silent mode

When someone calls, you can press C(right menu button) to turn off the handset ring signal.

Softkeys

Note the top two keys just under the menu are “softkeys”. Their function is shown in the Display

directly above them.

English

Phonebook

You can save 20 numbers/names. If you subscribe to a caller ID service, the name allocated to

the caller in the phonebook will be shown for incoming calls. It is possible to choose between

various ringers for the numbers saved in the Phonebook (only functions if you subscribe to a

caller ID service).

Save name/number in handset

Press b. Press .

Scroll to ADD. Press OK.

Press equivalent digit key several times for desired name. Press OK.

Enter the telephone number, including the area code. Delete if necessary with right menu

button C. Press OK.

Scroll to required ringer. Press OK.

Managing the phonebook

Press b. Scroll between entries with {/}. You can quick search the phonebook by

pressing the corresponding number key for the rst letter.

Press qto make a call or press for various options.

Edit number

Press (left menu button).

Scroll {/}to PHONEBOOK, press OK.

Scroll to the name you choose to edit, press .

Scroll to EDIT, press OK.

Check name is correct, press OK.

Number will appear with cursor ashing at the end of the number

Press Cto backspace/delete number

Re-enter correct number, press OK.

Select melody, press OK.

Delete number

Press (left menu button).

Scroll {/}to PHONEBOOK, press OK.

Scroll to the name you choose to delete, press .

Scroll to DELETE, press OK.

English

Incoming numbers/Caller ID

The display shows you who is calling and the 10 most recent missed calls. NEW CALLS will

be shown in standby mode and in the list indicates a missed call. This function requires a

subscription from your service provider!

Retrieving and dialling

Press {. Scroll to the desired entry with }.

Press qto call or press for various options

( = back).

Deleting new calls/number log

Scroll {to new call number, press (left menu button)

Scroll }to DELETE or if more than one number, scroll to DELETE ALL, press OK.

CONFIRM will be displayed on screen, press OK.

Caller identication messages

In addition to number display, the following messages will be shown occasionally:

OUT OF AREA Unknown number, e.g. international call.

WITHHELD Information about the number is blocked. Number cannot be shown.

aMSG indication from your network operator*

*To remove the message indicator: Press {and then hold down 4.
