Dorel Ameriwood 9151202WP Manuel utilisateur
B349151202WP00
9151202WP
STOP
1-800-489-3351
Need Parts or Assistance?
WWW.AMERIWOOD.COM/PARTS
If a part is missing or damaged, visit our website or call our toll-free
customer service line. We will gladly ship your replacement parts
FREE of charge.
For prompt, reliable service please have your assembly manual ready.
DO NOT RETURN PRODUCT TO THE STORE
Individual stores do not stock parts.
or call toll free:
Recommended # of people needed for assembly: 2
(however it is always better to have an extra hand.)
Estimated assembly time is 2 hours.
Spanish translations are located in the center of this manual.
Se localizan las traducciones españolas en el centro de este
manual.
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Date of Purchase
___ / ___ / ___
Please Recycle
Recicle Por Favor
A Dorel Company
MERIWOOD
INDUSTRIES
TM
0 29986 915139
B349151202WP00
3 /28
Parts
left panel
39118202010 right panel
39118202021 left partition
39118202030 right partition
39118202040
modesty panel
39118202101
desk top
39151202110
right fixed shelf
39118202140 left bottom
39118202150 right bottom
39118202160 left kick
39118202170 right kick
39118202180
left apron
39118202190
right apron
39118202200 front crown molding
39118202210 left lower crown molding
39118202220 right lower crown molding
39118202230
left door
39118202280
ABCDJ
O
NPQR
K
S
TUVWBB
B349151202WP00
4 /28
Parts
right door
39118202291
pencil drawer front
39118202300 2 pencil drawer sides
39118302310
pencil drawer back
39118302320 keyboard drawer front
39118202330 left keyboard
drawer side
39118202340
right keyboard
drawer side
39118202350
keyboard drawer back
39118202360 keyboard drawer bottom
39118202370 file drawer front
39118202380 left file drawer side
39118302390 right file drawer side
39118302400
file drawer back
39118302410 pencil drawer bottom
K911830280 file drawer bottom
K911830270
left back panel
K911820230 right back panel
K911820240
cam lock
#A22430
qty: 20
cam bolt
#A22440
qty: 20
shelf support
#A80250
qty: 3
CC DD EE FF GG HH
II JJ KK LL MM NN
OO PP QQ 12
plastic catch
#A30030
qty: 4
3
3a 3b
grommet
#A70040
qty: 2
45
8-32 x 7/8"
machine screw
#A17400
qty: 10
6
flap hinge
#A60500
qty: 2
7
RR SS
B349151202WP00
5 /28
Hardware
angle bracket
#A53600
qty: 12
7/16" flat head
screw
#A11080
qty: 22
1-1/4" flat head screw
#A11600
qty: 8
#4 x 1/2" flat head
screw
#A09130
qty: 10
drawer bracket
#A53760
qty: 8
euro screw
#A15600
qty: 16
hinge
#A60010
qty: 4
file holder
#A82120
qty: 2
extension slide
#A56540
qty: 1
cup pull
#A52416
qty: 5
1-3/4" flat
head screw
#A13410
qty: 11
1" washer head screw
#A12840
qty: 8
nail
#A21110
qty: 36
1/2" pan head
screw
#A12210
qty: 66
8910 11
12
13
14 15 16 17 18
19 20 21
B349151202WP00
6 /28
21
43
This illustration shows how the CAM fastening system works.
Esta ilustracion muestra el sistem de fijacion del tornillo de cerradura.
drawer slide
#A56030
qty: 2
22a 22b
22c
22d
A09130 (X10)
#4 x 1/2" flat
head screw
14
A11080 (X22)
#6 x 7/16" flat
head screw
A21110 (X40)
nail
A53760 (X8)
drawer bracket
15
16
A53600 (X12)
angle bracket
17
18
A15600 (X16)
drawer screw
9
A11600 (X8)
#6 X 1-1/4" FLT
10
A12840 (X8)
#8 X 1" W/H
11
12
A12210 (X66)
#8 X 1/2" pan
head screw
13
A13410 (X11)
#8 X 1-3/4" FLT
5
A80250 (X4)
shelf support
1
A22430 (X20)
12mm cam lock
6
A17400 (X10)
#8-32 X 7/8"
machine screw
7A60500 (X2)
flap hinge
8
A60010 (X2)
hinge
A60010 (X2)
hinge
8
A22440 (X10)
24mm cam bolt
2
2
A22440 (X10)
24mm cam bolt
3
4
A30030 (X2)
plastic catch
A70040 (X2)
50mm grommet
HARDWARE COMPARTMENT LAYOUT
A30030 (X2)
plastic catch
3
1
B349151202WP00
7 /28
-Insert four CAM LOCKS (1) into the RIGHT FIXED SHELF (N), LEFT BOTTOM (O),
and RIGHT BOTTOM (P) as shown.
Proper orientation of CAM LOCK
Orientation propio del tornillo de cerradura
x 12 N
O
P
1
1
1
1
1
1
2
B349151202WP00
8 /28
x 2
x 2
x 3
x 1
A
Proper orientation of CAM LOCK
Orientation propio del tornillo de cerradura
Insert two CAM LOCKS (1) and screw two CAM BOLTS (2) into the LEFT PANEL (A) as shown.
Attach one LEFT CABINET MEMBER (22a) to the LEFT PANEL (A) with three SCREWS (15) as shown.
Fasten one ANGLE BRACKET (18) with one SCREW (12) as shown in the detail.
1
2
15
15
2
1
22a
15
18
12
18
x 1
12
x 1
22a
3
B349151202WP00
9 /28
Proper orientation of CAM LOCK
Orientation propio del tornillo de cerradura
x 2
x 2
x 6
x 2
x 1
x 1
C
C
turn over
de la vuelta
x 1
Attach one LEFT CABINET MEMBER (22a) to the LEFT PARTITION (C) with three SCREWS (15).
Turn the panel over and attach one RIGHT CABINET MEMBER (22b) with three SCREWS (15).
On the same side insert two CAM LOCKS (1), screw two CAM BOLTS (2) and attach one PLASTIC
CATCH (3a) with two SCREWS (12). Fasten one ANGLE BRACKET (18) with one SCREW (12) as
shown in the detail.
1
1
2
15
12
3a
15
15
12
3a
22a
22b 22b
22a
15
15
2
18
12
18
x 1
4
B349151202WP00
10 /28
B
Proper orientation of CAM LOCK
Orientation propio del tornillo de cerradura
Insert two CAM LOCKS (1) and screw four CAM BOLTS (2) into the RIGHT PANEL (B).
Seperate the EXTENSION SLIDE (21) by extending it until it stops, depress the plastic lever and pull apart. Complete this procedure for both slides. Attach
slide to the RIGHT PANEL with three SCREWS (12). Fasten one ANGLE BRACKET (18) with one SCREW (12) as shown in the detail.
USE THESE THREE HOLES WHEN ATTACHING SLIDE.
USE ESTOS TRES AGUJEROS AL ATAR LA DIAPOSITIVA.
PLASTIC LEVER
x 2
x 4
x 4
x 1
1
2
12
21
1
2
21
21
12
18
x 1
12
18
