DNC(Dmax Network Camera) User's Manual Part1
DNC １Dongyang Unitech Co., Ltd
DNC(Dmax Network Camera) User’s Manual
Part 1
(Product Overview)
Version 4.0
Dongyang Unitech Co., Ltd
www.d-max.co.kr
www.cctvhome.net
DNC(Dmax Network Camera) User's Manual Part1
DNC ２Dongyang Unitech Co., Ltd
Contents
1. Product Overview...............................................................................................................................３
1.1. DNC IP Camera..............................................................................................................................３
1.2. Key Features ..................................................................................................................................４
1.3. Technical Specification of DNC IP Camera....................................................................................５
1.4. DNC IP Camera Packing List .........................................................................................................７
2. Hardware Description.........................................................................................................................８
2.1. DNC IP Camera..............................................................................................................................８
3. DNC IP Camera HW installation and basic setup..............................................................................８
3.1. Before installation ...........................................................................................................................８
3.2. Factory Default Condition ...............................................................................................................８
3.3. Hardware installation ......................................................................................................................９
DNC(Dmax Network Camera) User's Manual Part1
DNC ３Dongyang Unitech Co., Ltd
1. Product Overview
1.1. DNC IP Camera
DNC® IP Camera is a standalone network camera that has a built-in PTZ Analog Camera and is capable
of transmitting the video over the IP Network. IP Camera has built-in web server, so it can transmit the
video at the rate of up to 30fps (NTSC@4CIF) over the network such as LAN, leased line, DSL or Cable
modem. Users can monitor the video transmitted from IP Camera on web browser such as Internet
Explorer or Firefox.
DNC IP Camera supports video compression format of both Motion-JPEG and H.264, and it can encode
the video signal into the two different video formats and transmit them over the network at the same time.
This way, users have the choice which video format to use for their intention. DNC IP Camera supports
both NTSC and PAL standards, and users can select from 5 different video resolutions and 6 levels of
video qualities.
Picture 1 : FW-1177-DE
DNC(Dmax Network Camera) User's Manual Part1
DNC ４Dongyang Unitech Co., Ltd
1.2. Key Features
•Standalone device with built-in web server
•10/100Base-T Auto-Sensing Ethernet
•Configuring and controlling through Web browser
•Up to 30 fps transmission rate on TCP/IP network
•Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264
•Dual Streaming in Motion JPEG and H.264
•1-channel Voice Encoding / 1-channel Voice Decoding
•Built-in 2 way Audio transmission (1ch A-in, 1 A-out)
•Support Dynamic-IP users by IPCCTVDNS server
•Support PTZ (Pan/Tilt/Zoom) functions
•Support Sensor Input, Digital Output
•Support transparent mode
•Encryption on user authentication level
•Support dialup modem (Dial-in, Dial-out)
•Image transmission via FTP and Email
DNC(Dmax Network Camera) User's Manual Part1
DNC ５Dongyang Unitech Co., Ltd
1.3. Technical Specification of DNC IP Camera
Hardware
32bit Embedded CPU
Flash 8Mbytes / SDRAM: 128Mbytes
Linux version 2.6.xx operating system
Battery backed-up real-time clock
Image Sensor
1/4”Sony 410K Super HAD CCD
Resolution: 520 TV Lines
[Detail]
S/N ratio: 50dB or more (AGC OFF)
Electronic shutter speed:
1/60 ~ 1/100,000 sec (NTSC)
1/50 ~ 1/100,000 sec (PAL)
White Balance: ATW (indoor: 3,000K~6,500K / outdoor:
1,800K~10,500K), AWC, MWB
Lens
IRIS control: Auto & Manual
F1.4-30, f=3.3 mm wide to 99.0 mm tele
Angle of view: 2.3~62.0 horizontal
Shutter speed: Auto or 1/120~1/60,000 sec
Minimum Illumination
Color: 0.4 Lux (F1.6)
B/W: 0.1 Lux (F1.6)
DSS( Digital Slow Shutter) : 0.0007 Lux (F1.6)
Video Related
Features
DIS (Digital Image Stabilizer) - protection from variation
AGC (Auto Gain Control)
DSS (Digital Slow Shutter)
BLC (Back Light Compensation)
ICR (Day & Night)
SSNR (Noise Reduction at Low Light)
Video Compression Motion JPEG / H.264
Resolution NTSC: 720x480, 704x480, 704x240, 352x240,176x112
PAL: 720x576, 704x576, 704x288, 352x288,176x144
Frame Rate
(each channel)
Motion JPEG: Up to 30/25 fps @4CIF (Secondary Stream at QCIF)
H.264: Up to 30/25 fps @4CIF (Primary Stream at QCIF)
Video Streaming Motion JPEG and H.264 Dual Streaming (Simultaneously)
Controllable frame rate and bandwidth
Image Setting Compression levels: 6 (Motion JPEG) / 6 (H.264)
Color: color, black & white
Zoom 33x optical zoom, 10x digital zoom
Smart Zoom (Speed control by zoom ratio)
Pan / Tilt
Max Speed: Pan 360°/sec, Tilt 200°/sec@preset mode
Rotation Angle: Pan 360°(endless), Tilt: 92°(auto flip)
32 Preset Positions
Swing, Group, tour, 16 privacy zone
Voice
4 bit ADPCM, Sampling rates 8KHz, Mono Audio
1ch in & 1ch out
Bandwidth: 2KByte/sec (per channel)
Min/Max Audio Freq.: 300Hz ~ 3.4KHz
LAN Interface 10/100Base-T Ethernet auto-sensing
Alarm I/O Interface 1 Photo-coupled inputs and 1 Relay output
DNC(Dmax Network Camera) User's Manual Part1
DNC ６Dongyang Unitech Co., Ltd
Audio Input (MIC)
Input Impedance : 4 KΩ
Phantom Power : 5 Volt
Gain : 20 dB
Jack : 3.5mm Mono
Audio Output (SPK)
Output Impedance : 160 Ω
Output Power : 50 mW
Output Voltage : 1 Volt (peak-to--peak)
Jack : 3.5mm Stereo
Power Over Ethernet Optional
Serial Interface
Two serial ports for console, modem(PSTN & GSM), serial
input/output device, PTZ
COM Port is RS-232,
AUX port connected to Built-In PTZ
Max Baud Rate: 115200 bit/s
Security Features Multi-user level protection for camera access, PTZ, Alarm I/O
Advanced Service
Up to 15.5M memory for Pre/Post alarm buffer
e-mail, FTP, alarm Buffer by event or schedule
IP notification, Alarm Notification to e-mail,
CGI Call by event or schedule
Built-in Motion
Detections
Accuracy: 12x12=144 blocks
Motion Sensitivity: -100 ~ 100 (100 is hypersensitive)
PTZ & UART Control
Support
Built-in PTZ device is controlled through AUX
UART control X10 device
Dial in/out via PSTN or GSM modem
Others Transmit Serial input data transfer with Video
IP notification by e-mail
Management Configurable by serial, web or telnet
Remote system update via telnet, FTP OR web browser.
Developer Support Provides HTTP CGI API
ActiveX control development kit
Power Supply
Power Adaptor included
Input: 100/240 VAC, 1A
Output: AC 24 Volt, 1.5A
Power Consumption AC 24Volt, 1A
Operating
Environment
Temperature: 32°~ 122°F (0°~ 50°C)
Humidity: 20 ~ 80% RH (non-condensing)
Miscellaneous
Free version NDVR Software
Works with IP-Manager( NDVR S/W)
Dynamic IP support through CCTVHOMEDNS Server
Simultaneous Users Live-cast for up to 16 clients
Installation,
Management and
Maintenance
Installation CD and web-based configuration
Firmware upgrades over HTTP or FTP, firmware available at
http://www.d-max.co.kr
Video Access from
Web Browser Supported on Microsoft Internet Explorer or Firefox
Minimum Web
Browsing
Requirements
Pentium III CPU 500 MHz or higher
Windows XP, 2000, NT4.0*,
Internet Explorer 6.x or later
DNC(Dmax Network Camera) User's Manual Part1
DNC ７Dongyang Unitech Co., Ltd
System Integration
Support
Powerful API for software integration available at http://www.d-
max.co.kr, including Simple Viewer API, DNC Control SDK, event
trigger data in video stream, embedded scripting and access to
serial port peripherals over HTTP/TCP
User can be installed user program daemon for event notification or
sending image.
Embedded operating system: Linux 2.6
Supported Protocols HTTP, TCP/IP, FTP, Telnet, RARP, PPP, PAP, CHAP, DHCP,
SMTP client(e- mail), NTP, RTP/RTSP
Applications
(not included) IP-Camera Manager 16/25/32/64/128/256
Included Accessories
Power Adaptor 24 V AC / Power cord
Mounting brackets
Connector kit
Installation Guide (Hard copy)
CD (Installation wizard, user's manual, quick install guide &
software),
Approvals
KCC
FCC : Class A
CE : Class A
IP66
RoHS
Dimensions and
Weight
216.8mm (Diameter) X 289.2mm (Height) (8.53”x 11.38”)
5.5 Kg (12.1lbs) without power supply.
Table 1 : DNC IP Camera Specification
1.4. DNC IP Camera Packing List
DNC IP Camera’s packing box includes the following items
IP Camera 1ea
Power Adaptor Unit
(Power Cable & DC12V, 3A Adapter) 1ea
CD (User’s Manual, installation wizard and Pictures) 1ea
Table 2 : DNC IP Camera Packing List
)Please make sure all the listed items are included in the package. For any missing items, please
contact your local distributor.
DNC(Dmax Network Camera) User's Manual Part1
DNC ８Dongyang Unitech Co., Ltd
2. Hardware Description
2.1. DNC IP Camera
Picture 2. DNC IP Camera with Wall Mount Bracket
3. DNC IP Camera HW installation and basic setup
3.1. Before installation
•Read User's Manual carefully
•Check User’s Network (IP Address, Network Mask and default gateway)
•Secure IP address for IP Camera.
3.2. Factory Default Condition
The table below shows the factory default conditions. Please refer to this when you need to change the
values on admin menu.
Item Factory Default
Admin ID root
Admin password root
IP address 10.20.30.40
Network mask 255.255.255.0
Gateway 10.20.30.1
Table 3 : Factory Default Condition
)Admin ID and Password are case sensitive.
DNC(Dmax Network Camera) User's Manual Part1
DNC ９Dongyang Unitech Co., Ltd
3.3. Hardware installation
Following pictures show the installation steps for DNC IP Camera.
1.
Next, you need to follow the steps below.
1. Network Configuration on IP-installer.
2. Camera Configuration on IP-installer or admin-menu.
3. Service Configuration on IP-installer or admin-menu.
For further details, please refer to the related part in the User’s Manual. Configuring IP Camera is mostly
done on a web browser, so users should set up the network first.
