Dometic RM122 Manuel utilisateur

Absorber refrigerator

Installation and Operating Manual. . . 8

Absorber-Kühlschrank

Montage- und Bedienungsanleitung 27

Réfrigérateur à absorption

Instructions de montage

et de service . . . . . . . . . . . . . . . . . . 49

Nevera con extractor

Instrucciones de montaje y de uso . 70

Frigorifero ad assorbimento

Istruzioni di montaggio e d’uso . . . . 91

Absorptiekoelkast

Montagehandleiding en

gebruiksaanwijzing . . . . . . . . . . . . 111

Absorber-køleskab

Monterings- og

betjeningsvejledning . . . . . . . . . . . 131

Absorptionskylskåp

Monterings- och bruksanvisning . . 150

Absorbsjons-kjøleskap

Monterings- og bruksanvisning . . . 169

Absorptiojääkaappi

Asennus- ja käyttöohje . . . . . . . . . 188

Frigorífico de absorção

Instruções de montagem e manual de

instruções . . . . . . . . . . . . . . . . . . . 207

Абсорбционный

холодильник

Инструкция по монтажу и

эксплуатации . . . . . . . . . . . . . . . . 228

Lodówka absorpcyjna

Instrukcja montażu i obsługi . . . . . 249

Absorpční lednička

Návod k montáži a obsluze. . . . . . 269

Absorpčná chladnička

Návod na montáž a uvedenie do

prevádzky . . . . . . . . . . . . . . . . . . . 289

Abszorberes hűtőszekrény

Szerelési és használati útmutató . 308

RM122, RM123

380 mm

300 mm100 mm

439 mm

510 mm

400 mm39 mm

586 mm

RM122, RM123

662 mm

420 mm

76 mm76 mm

RM122, RM123

RM123

RM122, RM123

RM122

RM123

3 AMP

RM123

RM122, RM123

SW13

SW17

RM123

RM122

RM122, RM123

Please read this operating manual carefully before starting the device.

Keep it in a safe place for future reference. If the device is passed on to

another person, this operating manual must be handed over to the user

along with it.

The manufacturer cannot be held liable for damage resulting from

improper usage or incorrect operation.

Contents

1 Notes on using the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

7 Installing the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

8 Connecting the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

9 Using the refrigerator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

10 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

11 Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

12 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

14 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

RM122, RM123 Notes on using the manual

1 Notes on using the manual

➤Action: This symbol indicates that action is required on your part. The

required action is described step-by-step.

✓This symbol describes the result of an action.

Fig. 15, page 3: This refers to an element in an illustration. In this case,

item 5 in figure 1 on page 3.

2 Safety instructions

2.1 General safety

!WARNING!

Do not operate the device if it is visibly damaged.

If this device's power cable is damaged, it must be replaced by

the manufacturer, customer service or a similarly qualified

person in order to prevent safety hazards.

This device may only be repaired by qualified personnel.

Improper repairs can lead to considerable hazards.

This device can be used by children aged 8 years and above as

well as persons with reduced physical, sensory or mental capa-

bilities or lack of experience and knowledge, if they are super-

vised or have been instructed to safely use the device and if

they understand the hazards resulting out of it.

Cleaning and user maintenance must not be carried out by chil-

dren without supervision.

WARNING!

Safety instruction: Failure to observe this instruction can cause

fatal or serious injury.

NOTICE!

Failure to observe this instruction can cause material damage and

impair the function of the product.

NOTE

Supplementary information for operating the product.

Safety instructions RM122, RM123

Children must not play with the device.

Children must be supervised to ensure that they do not play with

the device.

Always keep and use the device out of the reach of children

under the age of 8 years.

Do not store any explosive substances such as spray cans with

a flammable propellant in the device.

!CAUTION!

Disconnect the device from the mains

– before each cleaning and maintenance

– after every use

Food may only be stored in its original packaging or in suitable

containers.

ANOTICE!

Check that the voltage specification on the type plate

corresponds to that of the energy supply.

Never pull the plug out of the socket by the cable.

The cooling device is not suitable for transporting caustic

materials or materials containing solvents.

2.2 Operating the device safely

ANOTICE!

Do not use electrical devices inside the cooler unless they are

recommended by the manufacturer for the purpose.

Danger of overheating!

Ensure at all times that there is sufficient ventilation so that the

heat that arises during operation does not build up. Provide an

air inlet with a cross-section of at least 250 cm² as well as a vent

hole.

Ensure that the ventilation openings are not covered.

Do not fill the inner container with ice or fluid.

Never immerse the device in water.

Protect the device and the cable against heat and moisture.
