Dometic CFX-WD Manuel utilisateur

The wireless display CFX-WD allows data, such as the

current temperature, power supply or alarm, to be shown

up to 15 m away from the CFX cooler.

Operating and display elements

Operating the wireless display

Selecting the temperature unit

✓Press the “°C/°F” button to switch between °C and °F.

Showing the current temperature/power supply

The display indicates the current temperature of the cooler.

When the cooler is connected to a 100 – 240 V AC mains

supply, the display shows “AC”. When the cooler is

operated with 12/24 V DC, the display shows the input

voltage and the mode set for the battery monitor

(VH – HIGH, VM – MEDIUM, VL – LOW).

Showing the set temperature

➤Press the “SET” button once.

✓The display indicates the set cooling temperature.

Setting the temperature alarm

➤Press the “SET” button twice.

➤Press the “+/–” buttons to set the temperature alarm

(“OFF”: no alarm, “01”: alarm at ± 5 °C/°F, “02”: alarm

at ± 3 °C/°F).

Switching the wireless display on/off

➤Press the “SET” button and hold it down for two

seconds.

✓The display is switched on or off.

The backlight is automatically switched off during battery

operation.

Description Explanation

PLED lights up green:

LED lights up orange:

Compressor is on

Compressor is off

aLED flashes red: Device is switched on but not ready for operation

°C/°F button Switches between °C and °F

SET button

•Show set cooling temperature (SET)

•Set temperature alarm (ALERT)

•Switch wireless display on/off (ON/OFF)

+/– buttons

•The +/– buttons set the temperature alarm.

•The – button switches the backlight on and off.

•The + button turns on/off the alarm sound.

CoolFreeze Accessory

Wireless display CFX-WD

CFX-WD--O-AU.fm Seite 1 Freitag, 7. Oktober 2016 12:48 12

Alarm for temperature, battery and temperature

sensor

When the current temperature is outside the set

temperature, the “ALERT” message appears, the display

flashes and an alarm sounds. Press the “+” button to switch

off the alarm.

When the battery voltage is insufficient, the “P” LED flashes

orange and the mode indicator for the battery monitor

flashes.

The fault messages “E1” (interrupted power circuit) and

“E2” (short circuit) are shown on the display if there is a fault

with the temperature sensor.

Technical data

CFX-WD

Ref. no.: 9105306632

Response time: 5 s

Range: 15 m

Input voltage:

12/24 Vg

(range: 9 V – 31.5 Vg)

(1,8 m lead/cigarette plug included)

3 Vg(2 standard AAA 1.5 V batteries included)

Connected voltage versus batteries:

When connected to 12/24 Vg, batteries are not in use.

HINT: Connection to 12/24 Vg as often as possible will

prolong battery life.

Current consumption:

50 mA (12/24 Vg)

15 mA (batteries)

1 mA (stand-by)

LCD display: Blue backlight with 12/24 Vgconnected

No backlight when battery powered

Dometic Australia Pty. Ltd.

1 John Duncan Court

Varsity Lakes QLD 4227

www.dometic.com

4445101941 10/2016
