Dometic PLB40 Manuel utilisateur

PLB40

Portable lithium iron phosphate

battery pack

Operating manual . . . . . . . . . . . . . . . . . . . . .4

Batterie lithium fer phosphate

portable

Notice d’utilisation . . . . . . . . . . . . . . . . . . . 17

Batería de litio-ferrofosfato

portátil

Instrucciones de uso . . . . . . . . . . . . . . . . . .30

ENERGY & LIGHTING

BATTERIES

PLB40-O-US.book Seite 1 Donnerstag, 24. Januar 2019 3:23 15

PLB40

13 4 87

5 9

PLB40-O-US.book Seite 2 Donnerstag, 24. Januar 2019 3:23 15

PLB40

211111 3 4 5 6

PLB40-O-US.book Seite 3 Donnerstag, 24. Januar 2019 3:23 15

Explanation of symbols PLB40

Please read this instruction manual carefully before first use, and store it in

a safe place. If you pass on the product to another person, hand over this

instruction manual along with it.

Table of contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

6 Using the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

8 Maintaining and cleaning the product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

9 Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

10 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

1 Explanation of symbols

WARNING!

Safety instruction: Failure to observe this instruction can cause death

or serious injury.

CAUTION!

Safety instruction: Failure to observe this instruction can lead to injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair

the function of the product.

PLB40-O-US.book Seite 4 Donnerstag, 24. Januar 2019 3:23 15

PLB40 General safety instructions

2 General safety instructions

The manufacturer accepts no liability for damage in the following cases:

•Damage to the product resulting from mechanical influences and incorrect

connection voltage

•Alterations to the product without express permission from the manufacturer

•Use for purposes other than those described in the operating manual

The declaration of conformity can be requested from the manufacturer (contact infor-

mation on the back).

Note the following basic safety information when using electrical devices to protect

against:

•Electric shock

•Fire hazards

•Injury

2.1 General safety

!WARNING! INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELEC-

TRIC SHOCK, OR INJURY TO PERSONS.

•Only use the device as intended.

•Disconnect the device from the mains

– Before cleaning and maintenance

–Afteruse

– Before changing a fuse

•To reduce risk of damage to the electric plug and cord, pull the plug

rather than the cord when disconnecting the device.

•Do not use a device that is damaged or modified. Damaged or modi-

fied devices may exhibit unpredictable behavior resulting in fire,

explosion or risk of injury.

•Do not operate the device with a damaged cord or plug, or a dam-

aged output cable.

•Do not disassemble the device, take it to a qualified service person

when service or repair is required. Incorrect reassembly may result in a

risk of fire or electric shock.

NOTE

Supplementary information for operating the product.

PLB40-O-US.book Seite 5 Donnerstag, 24. Januar 2019 3:23 15

General safety instructions PLB40

•To reduce the risk of electric shock, unplug the device from the outlet

before attempting any instructed servicing.

•Do not expose to liquid, vapor, rain, sleet, snow or the like.

•The device shall be stored indoors and protected from the elements.

•Never smoke or allow a spark or flame in vicinity of battery or engine.

•When charging the device, work in a well ventilated area and do not

restrict ventilation in any way.

•Do not expose the device to fire or excessive temperature. Exposure

to fire or temperature above 130°C(266°F)maycauseexplosion.

•Electrical devices are not toys.

Always keep and use the device out of the reach of children.

•Children must be supervised to ensure that they do not play with the

device.

ANOTICE! MATERIAL DAMAGE.

•Do not insert foreign objects into the output or input terminals.

•Do not put fingers or hands into the device.

•Do not attempt to replace the internal battery cells.

•Before using for the first time, charge your battery pack using one of

the methods described in chapter “Charging the lithium iron phos-

phate battery pack” on page 11.

•Before using the device for the first time, check that the voltage speci-

fication on the rating plate matches that of the power supply.

•Never pull on the power cord to unplug the device from the power

socket.

•Store the device in a dry and cool place.

2.2 Operating the device safely

!WARNING! INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELEC-

TRIC SHOCK, OR INJURY TO PERSONS.

•Only use the charger supplied to charge the device. Use of an attach-

ment not recommended or sold by the manufacturer may result in a

risk of fire, electric shock, or injury to persons.

•The power socket to which the device is connected must be close by

and easily accessible.

PLB40-O-US.book Seite 6 Donnerstag, 24. Januar 2019 3:23 15

PLB40 Scope of delivery

!CAUTION! FIRE AND/OR EXPLOSION HAZARD.

•Do not operate the device

– In the vicinity of corrosive fumes

– In the vicinity of combustible materials

– In areas where there is a danger of explosions

•Do not place the device next to heat sources such as fires.

•Place the device in a shady place. Avoid direct sun exposure in hot

and humid surroundings for a proper usage.

ANOTICE! MATERIAL DAMAGE.

•Do not disconnect any cables when the device is still in use.

•Only use the device in upright position.

3Scopeofdelivery

4 Intended use

The portable lithium iron phosphate battery pack is for use in camping application. It

comes with four outlets to power devices like tablet, mobile phone, portable

fridge/freezer etc.

The battery pack is suitable for

•the connection to 12 V appliances with low power consumption e.g. small invert-

ers up to 150 W,

•the connection to a laptop with an additional 150 W inverter connected to the

12 V DC connection socket output.

It is not allowed

•to use the battery pack as a starter battery for a vehicle,

•to use two battery packs in parallel connection.

No. in

fig. 1, page 2 Description

1 Portable lithium iron phosphate battery pack

2 DC charge cable

3 AC power supply unit

4 2x DC Fuse

PLB40-O-US.book Seite 7 Donnerstag, 24. Januar 2019 3:23 15

Technical description PLB40

5 Technical description

The portable lithium iron phosphate battery pack (LiFePO4) enables mobile power

supply for portable refrigeration, USB devices and small inverters up to 150 W con-

tinuous output.

A DC consumer unit (e.g. a portable refrigeration) can be simultaneously supplied

with power while the lithium iron phosphate battery is being charged via the power

supply unit.

The housing is shock, heat and UV resistant.

The lithium iron phosphate battery can be charged in three ways:

•via the supplied AC/DC charger on the AC mains (max. 8 A)

•via DC connection through vehicle alternator (max. 8 A)

•via DC connection through solar panel

The device has the following protective functions:

•Overtemperature, undertemperature protection

•Overvoltage protection

•Undervoltage protection

•Overcurrent protection

•Short circuit protection

•Incorrect polarity protection

PLB40-O-US.book Seite 8 Donnerstag, 24. Januar 2019 3:23 15

PLB40 Technical description

5.1 Connections and display

5.2 Display

No. in

fig. 2, page 2 Description

1 Power button

2 Display (LCD)

3 2 x USB socket (5 V, max. 4.2 A overall)

412Vg 2-pin connection output to portable refrigeration

512Vg heavy duty connection socket output for portable

refrigeration and 12 V applicances

6 Adjustable handle

7 2x fuse holder

8 AC/DC adapter input socket

9 DC/DC Anderson™ SB™ input socket

No. in

fig. 3, page 3 Description

1 A failure occurred (chapter “Troubleshooting” on

page 13).

2 See chapter “Troubleshooting” on page 13.

3 See chapter “Troubleshooting” on page 13.

4 The battery pack supplies energy to an USB device.

5 The battery pack supplies energy to a device connected to

the 2-PIN output.

6 The battery pack supplies energy to a device connected to

the DC output.

7 State of charge as a percentage

PLB40-O-US.book Seite 9 Donnerstag, 24. Januar 2019 3:23 15

Using the appliance PLB40

6 Using the appliance

6.1 Before first use

➤Before first use or storing plug the battery pack into the wall charger until it is fully

charged.

➤Observe the information given in chapter “Charging the lithium iron phosphate

battery pack” on page 11.

6.2 Starting and switching off

Starting the lithium iron phosphate battery pack

➤Press the power button (fig. 21, page 2) for at least 3 seconds to start the

device.

✓The device emits 2 beeps.

✓The display shows the operational status:

: the lithium iron phosphate battery is being charged

: the lithium iron phosphate battery is being discharged

: the lithium iron phosphate battery is on idle mode

✓The display switches off automatically after 1 minute.

Switching the display on

➤Press the power button (fig. 21, page 2) briefly to switch on the display.

8 Battery is being discharged

Battery is being charged

Battery is being charged and discharged at the same time

9 See chapter “Troubleshooting” on page 13.

No. in

fig. 3, page 3 Description

PLB40-O-US.book Seite 10 Donnerstag, 24. Januar 2019 3:23 15
