2044CL-O-EVS, 300 Clip Instant Access System, Odetics Protocol 8
6. LEARN A CLIP OR CLIP COMBINATION
a. ON THE ST400
1) Press VTR [1], [2], [3], [4], [5], or [6] to select the channel to learn.
2) Load a clip on the selected channel. See section LOAD A CLIP.
3) Use the transport functions to view the clip.
Press [IN] to mark an IN point. The IN LED will turn on.
On recall, the clip will cue to the IN time, not the beginning of the clip.
Optional: Press [OUT] to mark an OUT point. The OUT LED will turn on.
On recall, the clip will play to the OUT point then stop.
To delete an IN or OUT point, press and hold [DEL], then press [IN]or [OUT].
The IN/OUT LED will turn off.
If no IN point is marked, the current location of the clip will be learned as the IN
point.
4) For GANGs, repeat steps 1 and 2 for each channel.
Then, press the [GANG] softkey.
Press VTR [1], [2], [3], [4], [5], or [6] to add it to the GANG. The VTR LED
will turn on.
Press the VTR key again to remove it from the gang. The VTR LED will turn
off.
Press [ESC] to exit GANG mode. The LEDs of all GANGed VTRs will turn on.
b. ON THE SHOT BOX
1. Press [LEARN]. The LEARN indicator will turn on.
2. Select the desired BANK by pressing BANK [1], [2], [3], [4], [5], [6], [7], [8],
[9] or [0].
3. Press the desired Shotkey to complete the learn process.
The learned CLIP ID is displayed on the Shotkey.
4. Press [ESC] at anytime to escape without LEARNing.
