DMXking EDMX1 MAX Manuel utilisateur

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

eDMX1 MAX

USER MANUAL

DMXking.com •JPK Systems Limited •New Zealand
0132-700-4.1
ii
TABLE OF CONTENTS
1. Introduction ............................................................................................................................................................................... 1
Hardware and Firmware versions................................................................................................................................................... 1
Main Features ................................................................................................................................................................................. 2
2. Exterior View.............................................................................................................................................................................. 3
Front View....................................................................................................................................................................................... 3
Rear View........................................................................................................................................................................................ 3
Status LED Table.............................................................................................................................................................................. 3
3. Default Configuration................................................................................................................................................................. 4
4. Configuration Utility................................................................................................................................................................... 5
Network Tab ................................................................................................................................................................................... 6
Port Tab........................................................................................................................................................................................... 7
DMX Display Function..................................................................................................................................................................... 9
Node Report.................................................................................................................................................................................. 10
Art-Net Node Name ...................................................................................................................................................................... 10
Factory Reset ................................................................................................................................................................................ 10
Summary of settings ..................................................................................................................................................................... 11
5. Ports, Merging, Priority And DMX Input .................................................................................................................................. 12
Ports and merging......................................................................................................................................................................... 12
Supported merging combinations ................................................................................................................................................ 12
sACN / E1.31 Priority..................................................................................................................................................................... 12
sACN / E1.31 Priority –DMX Receive............................................................................................................................................ 12
DMX512 In –Unicast / Broadcast / Multicast............................................................................................................................... 12
6. Compatible Software ............................................................................................................................................................... 13
7. Technical Specifications ........................................................................................................................................................... 14
8. Warranty .................................................................................................................................................................................. 14
DMXking Hardware Limited Warranty.......................................................................................................................................... 14

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

1. INTRODUCTION

Thanks for purchasing a DMXking product. Our aim is to bring you high quality products with great features we know you’ll

appreciate.

HARDWARE AND FIRMWARE VERSIONS

From time-to-time minor hardware changes occur in our products usually small feature additions or unseen optimizations. The

table below lists eDMX4 MAX DIN product variants. Check the product label for P/N details.

Part Number

Feature addition

0132-1.1-3/5

Initial product release

Firmware updates are released on a semi-regular basis. We recommend updating to the latest available firmware version so all

product features are available. Please take note the user manual reflects latest firmware version features unless otherwise

noted.

Firmware Version

Comments

V4.1

Initial release. RDM support disabled.

eDMX1 MAX requires eDMX Configuration Utility v1.27+

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

MAIN FEATURES

−Power from USB-C

−Tough aluminum enclosure

−Static or DHCP IPv4 network addressing

−Supported operating systems: Windows, MacOS, Linux, iOS, Android

−eDMX1 MAX - 1x DMX512 Out or DMX512 In with Art-Net, sACN E1.31 and E1.20 RDM support

−Art-Net broadcast, Art-Net II,3 & 4 unicast, sACN/E1.31 Multicast and sACN Unicast support

−Merge 2 incoming Art-Net/sACN streams per output channel with both HTP and LTP options

−sACN Priority takeover for multi-tier controller arrangements

−Mix and match ArtNet with sACN merge/priority sources

−DMX-IN and DMX-OUT channel offset re-mapping

−User configuration of Art-Net Node short and long names

−Fully compatible with all software and hardware that supports Art-Net I, II, 3 & 4 and sACN protocols

−Works with your existing console if Art-Net or sACN external nodes are supported

−Universe Sync Art-Net, sACN and Madrix Post Sync

−Configuration utility with basic Art-Net output/input test functionality

eDMX MAX translates Art-Net 00:0:0 to Universe 1 (i.e. offset by 1) so there is

an easy mapping between sACN/E1.31 and Art-Net.

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

2. EXTERIOR VIEW

FRONT VIEW

5pin and 3pin XLR socket variants. DMX port status indicator bottom left of XLR socket.

REAR VIEW

Network 10/100Mbps RJ45 socket. USB-C socket for DC power input.

STATUS LED TABLE

LED

Indication

Protocol

Protocol activity. Flash Yellow = Art-Net/sACN. Solid Yellow = Bootloader mode

Link/Act

Network activity. Green = Link, Flash = Traffic

Port A –Front XLR

DMX512 Port A TX/RX activity

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

3. DEFAULT CONFIGURATION

All eDMX4 MAX DIN units ship with default IP address settings. Please reconfigure network settings as required before use.

Parameter

Default Setting

IP Address

192.168.0.112

Subnet Mask

255.255.255.0

Default Gateway

192.168.0.254

IGMPv2 Unsolicited

Report

Unchecked

Network Mode

DHCP

DMX512 Port configuration parameter defaults.

Parameter

Default Setting

Async Update Rate

40 [DMX512 frames per second]. Universe Sync will override.

Port Operation Mode

DMX-OUT

Timeout all sources

Unchecked

Channel Offset

Fixed IP

0.0.0.0 [Only for DMX IN –Unicast to 1 IP address only]

Merge Mode

HTP

Full DMX Frame

Unchecked

*Broadcast Threshold

10 [Art-Net II/3/4 unicasting up to 10 nodes]. Set to 0 for Art-Net I

broadcast on DMX IN ports.

Unicast IP [DMX-IN]

0.0.0.0

sACN Priority [DMX-IN]

100

RDM Discovery Period [DMX-OUT]

0s / RDM Disabled

RDM Packet Spacing [DMX-OUT]

1/20s

DMX-OUT Failsafe Mode

Hold Last

Recall DMX Snapshot at startup

Unchecked

DMX512 Universe

1 [Net 00, Subnet 0, Universe 0-0]

Note: sACN Universe 1 = Art-Net 00:0:0

*Global threshold for all DMX-IN ports, configured only in Port A settings tab.

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

4. CONFIGURATION UTILITY

The eDMX Configuration utility provides a simple interface to all device parameters. Typically, these are set once during initial

configuration and left untouched.

eDMX Configuration functions with primary Art-Net UDP 6454 and an alternate UDP 16454 port for device configuration. This is

helpful when simultaneously running eDMX Configuration and a lighting control application. Automatic selection of alternate

port is performed upon utility startup if the primary Art-Net port is unavailable. It is also possible to lock eDMX Configuration to

the alternate port via the Advanced menu. Note that DMXking nodes are always listening on both primary and alternate ports so

there is no device configuration required to change.

eDMX Node configuration can be saved/loaded from a simple Key:Value YML file. Select the node and perform Load/Save

accessible in the File menu.

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

NETWORK TAB

eDMX Configuration can find and configure eDMX MAX hardware on different IP subnets from the computer network adapter.

There are some functions such as the Recorder that require both devices on the same IP subnet range e.g., Computer IP

192.168.0.100 Subnet 255.255.255.0 Gateway 192.168.0.254 when eDMX MAX is on default IP.

Upon startup eDMX nodes are automatically detected and displayed by IP address. To poll for new devices or just check the

communications is okay by clicking Search. Polling is automatic every 8 seconds but can be disabled through the Advanced |

Auto Device Poll menu option. Mute Responses option prevents any new nodes from being listed regardless of their status on

the network. With large node counts this can be helpful.

Click on the desired node’s entry and all Settings will be retrieved. Note that if no response is received the settings will be greyed

out and no additional tabs visible. An activity box shows both transmitted and received messages to help with diagnosing

communication issues. If your network configuration has multiple adapters and or IP addresses you should select the same

network range as the eDMX from the Network Adapter IP Address dropdown box and also ensure the subnet mask is

appropriate.

Settings Broadcast is suppored by eDMX MAX which allows node settings to be updated regardless of the network adapter

subnet range.

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

Unicast single node discovery and configuration is possible by selecting Advanced | Unicast Poll and entering the destination

IPv4 address then click Search. This will function over routed networks provided a Default Gateway has been specified in the

node Network Settings.

eDMX MAX nodes provide IGMPv2 Reports necessary to participate in a multicast environment as necessary for sACN/E1.31

protocol. Sometimes due to network infrastructure issues an IGMP querier is not present and in these situations, you can opt to

have the node generate ongoing unsolicited IGMPv2 Reports.

To change the node Network Settings make applicable changes then click Update Network Settings.

Selecting Firmware Update will prompt for an appropriate firmware file and upload upon confirmation. A built-in boot loader

permits updating of the eDMX firmware. We do not recommend performing firmware updates over routed networks. Note only

signed encrypted firmware files from DMXking.com can be successfully loaded to ensure you won’t brick your device by

accident. Future firmware releases for this product will be in the form 0126-500-VersionMajor.VersionMinor.enc

PORT TAB

Port Operation Mode: DMX-OUT

DMXking.com •JPK Systems Limited •New Zealand

0132-700-4.1

Port Operation Mode: DMX-IN sACN with sACN Priority 100

DMX512 ports can be individually configured as either DMX-OUT, with automatic dual sACN/Art-Net protocol support, or DMX-

IN, with manually selected sACN or Art-Net protocol. When configured as DMX-IN a single Unicast IP address destination may be

specified but in the majority of applications leaving this field at 0.0.0.0 is appropriate.

Timeout all sources can be used to override default ArtNet defined behavior of holding the last sent or received frame forever.

•DMX-OUT mode: Whenever 2 sources are present and being merged together a 2nd source will always timeout when

the stream stops. In DMX-OUT mode if Timeout all sources is unchecked and Hold Last mode selected the output will

hold last frame forever. Timeout all sources checked and Failsafe Mode other than Hold Last selected will cause the

output to change to Zero, Full or Snapshot Scene.

•DMX-IN mode: An ArtNet or sACN stream is generated upon receiving DMX512 on the port. Timeout all sources

checked will cause this stream to end a few seconds after the DMX512 signal stops.

Channel Offset provides simple re-mapping for both DMX-OUT and DMX-IN port configurations. Set to 0 for no re-mapping.

•DMX-OUT mode: Incoming ArtNet or sACN stream(s) are re-mapped so channel 1 is pushed up to channel 1+N. When

channel 1+N exceeds 512 the incoming stream channels are ignored/lost.

•DMX-IN mode: Incoming DMX512 is re-mapped so channel 1 is pushed up to channel 1+N on the outgoing ArtNet or

sACN stream. When incoming DMX512 channel 1+N exceeds 512 to channels are ignored/lost.

Make changes to the applicable Port settings then click Update. Changes on all port tabs are updated regardless of which tab the

Update button is clicked.
