Owner’s Manual

DLS D-series

Audio for Life

The information contained in this manual is subject to

change without prior notice. The most current version of

this manual is available on our official website at:

www.dls.se

This product must be returned to the separate col lec tion system for electronic

products. Do not dis po se this product together with general household waste.

Marking by the ”CE” symbol indicates compliance of this device with the EMC

(Electromagnetic Compatibility) and LVD (Low Voltage Directive) standards of

the European Community

Introduction!

Please read this manual fully before unpacking and installing the product. It will help you to opti-

mise the performance of your speakers.

Unpacking and maintenance

Your speaker should be treated with the same care you would treat a piece of furniture. Use only

a piece of soft cloth and a small quantity of warm soapy water to clean the loudspeakers. Avoid

touching the cone of the bass unit or treble dome since this may leave a finger mark or even

damage the dome and spoil its performance. After unpacking, we suggest you retain all packing

material for future transports.

Running-in period

The performance of the speaker will change subtly during the listening period.

Please allow your new speakers to play about 50 hours of music at normal listening level before

doing any critical listening.

Room positioning

2-Channel stereo

The performance of a loudspeaker system in a

room varies with placement. Ideal positioning of

the speakers are 3-4 m apart and preferably at

least 0.5-1m away from side and rear walls, se

fig. 1. Avoid distances from walls that correspond

to 1/2, 1/4, 1/6 etc., of the room dimensions.

Seek instead odd fractions; 1/3, 1/5, 1/7 etc.to

minimize effects of room related resonances.You

will perceive the most accurate sound picture if

you listen from a position halfway between the

loudspeakers, and three to four metres away

Avoid corner placement as it leads to colouration

and an over-emphasise of the lower frequen-

cies. Image stability and stereo perception is

increased if the two speakers are turned slightly

towards the listening position. Try this out and

listen for best stereo image and centre focus.

Objects in the direct sound path can disturb the

coherence of the sound picture. Try out different

positions before deciding on a final arrangement.

Fig.1

Surround system

Centre speaker positions:

For a front centre speaker, position it directly above or below the screen, depending on screen

height. Optimum is in the same height as the front speaker sound centre (0.8-1m for

floor standing

models) For wall mounting, there are two holes on the backside of the speaker for wall mounting

with brackets. One hole for each bracket Front right and left speaker: Place the speaker 0.5-1m

from the TV. For large projection screens, space speaker 0.1- 0.5m from screen. Try to follow the

2-channel position as close as possible in room for best sound image.

Surround speaker “rear speaker”:

Depending on where you sit in the room there are two ways of presenting the sound image.

Direct or diffuse surround effect.

Direct is when the speaker point at the listening positions from rear or side walls, in the same

height as front and centre speaker.

For diffuse sound effect, mount the speaker higher and point them along rear or side wall.

Side panels

DLS D-series speaker are designed to be used with

side panels that are avalible in different finishes.

The panels and the speakers have internal hidden

magnets that automatically places the panels in correct position.

When adding the side panels on D3, put the panel bottom on the

small edge in the lower part of the D3, and then adjust the upper

side of panel to correct position.

Front cloth panel

The front cloth panels are attached in the same way using hidden magnets.

Connections

Make sure to turn off all amplifiers before connecting your new speaker to your system.

Connect the cable to the terminal. Use the marking of the cable to ensure that the red or ”+” mark

of the amplifier is connected to the ”+” side of the terminal, also marked with red.

We recommend high quality cables, not to thin, to avoide losses to reduce the effect the cable has

on the speaker. At high frequency the inductive component of the cables impedance can dominate

over the DC resistance and will affect the tonal balance. Minimum cable size should be 2 x 2,5 sq

mm. Ask your dealer for the best cable for your needs.

Power handling

DLS recommends using amplifiers within a specific power range. However, the most important

thing is that the amplifier has sufficient power reserves for handling peaks and transients in the

music signal. The power rating figure of a loudspeaker is a very inprecise figure. Since the energy

in the music signal varies, neither peak nor average value is relevant. A power rating of e.g. 100W

RMS says only that you can play a continuous tone of 1kHz at this output. It does not mean that

you can turn the volume all the way up on a 100W amplifier and expect clear sound and healthy

speakers. The greatest danger to a loudspeaker is distorded signal. Distorsion in the low frequen-

cy range produces overtones in the entire spectrum, with an energy that can easily damage the

tweeter units. And since a more powerful amplifier can play louder without distorsion, we have the

paradox that it is a greater risk to damage speakers by playing loud with a smaller amplifier.

Caution!

If you hear distortion when you increase the volume this is normally a sign of overloading the amp-

lifier and you should immediately reduce the output level.

Use of loudness, bass or treble boost

increases the risk for harmful distortion inthe amplifier. We recommend that you use these controls

with care.

Place the side panel bottom

on this edge

Service

Should your DLS loudspeaker system require service, or if you have difficulty in achieving the

fine performance of which your DLS loudspeaker system is capable, consult the DLS dealer from

whom the system was purchased. Your dealer has the knowledge required to provide expert

advice and assistance. In case the DLS dealer is unable to assist you, you are welcome to contact

the DLS Technical Department.

Warranty

This DLS loudspeaker is warranted to the original purchaser, against factory defect in material or

workmanship, for a period of one (1) year from the date of original purchase. This warranty is valid

only in the country of purchase, to the original purchaser and is non-transferable.

DLS loudspeakers are music listening devices and should be used for listening purposes only

They must not be connected to any other equipment than amplifiers within the specified power

range.

DLS cannot be held responsible for damage or injuries caused by improper use, or use in violation

with the recommendations in this leaflet.

Contact:

DLS Svenska AB

P.O Box 13029

SE-402 51 Göteborg

SWEDEN

Phone: +46 31 840060

Fax: +46 31 844021

e-mail: [email protected]

www.dls.se
