DK2 Power OPC505AE Manuel utilisateur
CHIPPER ASSEMBLY GUIDE
MODEL: OPC505AE
5 INCH AUTO FEED CHIPPER
DETAIL K2 INC.
DK2 POWER USA
4301 S Valley View Blvd STE 10-11
Las Vegas, NV 89103
1-702-331-5353
AUTO FEED
DOT TOWABLE
KOHLER ENGINE
5IN AUTO FEED CHIPPER
REV 1 –9-19-2019
DETAIL K2, INC.
1080 Clay Avenue Unit 2
Burlington, Ontario, Canada L7L0A1
DK2 USA EAST
6245 Industrial Parkway
Whitehouse, OH 43571
PARTS AND SERVICE 702-331-5353 OR WWW.DK2POWER.COM CONTACT US
OPC505AE 5 INCH
AUTO FEED CHIPPER
STEP 1:
Open and unpack all items. Leave lots of working space.
Inspect all parts.
The CHIPPER is shipped in a crate. Remove all sides before
you begin.
1. Assemble the main feed chute with the hinges and
hardware provided.
2. Connect the wiring as shown.
NOTE: UPON INSPECTION OF PARTS IF YOU FIND ANY DAMAGE OR MISSING
PARTS PLEASE CALL DK2 POWER AT 702-331-5353 OR CONTACT US VIA
OUR WEBSITE WWW.DK2POWER.COM
WE WILL REPLACE ANY MISSING PARTS TO YOU FREE
PLEASE DO NOT RETURN TO THE STORE
REV 1 –9-19-2019
STEP 2:
1. Install the roller valve under the chute
2. Use 2 bolt hardware included.
2 BOLTS AND NUTS
REV 1 –9-19-2019
STEP 3:
1. Install the feed roller speed control to side of chute.
2. TAKE CARE TO NOT DROP ANY HARDWARE INTO THE FEED
CHUTE AND INTO THE CUTTING CHAMBER.
REV 1 –9-19-2019
2 BOLTS AND NUTS
STEP 4:
1. INSTALL THE CHIP CHUTE
2. BOLT 4 PLACES
4 BOLTS on base
REV 1 –9-19-2019
STEP 5:
1. INSTALL ENGINE GUARD
2. Use 4 bolts provided.
Use 4 bolts provided
REV 1 –9-19-2019
STEP 6
1. Install the TOW BAR
2. Use 2 bolts and hardware provide and secure tightly
Use 2 bolts provided
REV 1 –9-19-2019
REV 1 –9-19-2019
REV 1 –9-19-2019
Ref. Description Ref. Description
1
Penta
-blade rod 41
Wheel
16*8.0-7
2
Triangle
blade 42
Flange
3
Φ
8 washer 43
Seal
Φ25*47*7
4
M
10*25 thinhead screw 44
Bearing
6205
5
Bearing
1507 45
Wheel
pipe axle
6
Pulley
Φ200 46
Battery
box
7
B
-belt 940 47
Baseframe
plate
8
Engine
48
Mouth
frame
9
Adjust
plate 4-0 49
Feed
rubber
10
Adjust
plat 8-0 50
Foot
angle plate
11
Tow
bar 51
Feed
hopper
12
Belt
cover 52
Switch
valve
13
Clutch
Φ125 53
Speed
valve
14
Washer
2-0 54
Spring
15
M
8*25 screw 55
Cover
16
Bearing
6306-2RS 56
Short
blade spacer
17
Lock
nut M35*1-5 57
Interval
rod
18
Blade
push-plate 58
Main
axle
19
Key
way 8*7*60 59
Plate
blade
20
Long
blade spacer 60
Bearing
FL206
21
Bearing
base 61
Pulley
AΦ90
22
Fan
plate 62
Belt
AΦ500
23
Blade
plate 63
Pin
8*7*30
24
Anvil
64
Rubber
seal
25
Bottom
frame 65
Emergency
stop
26
Switch
66
Hopper
block plate
27
Battery
67
Push
bar
28
Cover
fixing plate 68
Pump
joint
29
Rear
frame 69
Pump
30
Rubber
pad 70
Pump
fixing plate
31
Oil
bean cover 71
Pump
pulley
32
Oil
feed filter 72
Ratchet
& motor
33
Chain
73
Top
cover
34
Tank
74
Top
body
35
Oil
outlet filter 75
Screw
hook
36
1
.5inch interface 76
Bottom
discharge
37
Oil
outlet interface 77
Top
discharge
38
Pin
Φ3.5*40 78
Fasten
handle
39
Nut
M24 79
Reflect
cover
40
Φ
25 washer
READ THE KOHLER ENGINE MANUAL SUPPLIED WITH YOUR
UNIT FOR FULL ENGINE OPERATION, SAFETY, AND
MAINTENANCE.
YOUR UNIT HAS A COMMERCIAL KOHLER ENGINE WITH A 3YR
PARTS AND SERVICE WARRANTY. FOR WARRANTY IN YOUR
AREA CONTACT THE NEAREST KOHLER DEALER.
VISIT WWW.KOHLERENGINES.COM FOR PARTS, SERVICE,
MANUALS, AND DEALER LOCATIONS.
REV 1 –9-19-2019
