Division-Furtive Type 50 Manuel utilisateur
1
ENGLISH
OPERATING INSTRUCTIONS
TYPE 50
2 3
© 2011-2015 Division Furtive All Rights Reserved
20150427
www.division-furtive.com
3
ENGLISH
Content
Quick start
Basic operation
Setting the watch
Advanced features
Travel mode
Troubleshooting
4
5
6
11
14
17
4 5
Quick start
For a quick start, take a few minutes to read and master
the instructions on the card provided with the watch.
5
ENGLISH
The watch responds to movement and time is only displayed
when it detects that your wrist has been rotated to place
the watch in front of you.
The hours are displayed on the top cursor and minutes on
the bottom cursor. When minutes are not an even multiple
of 5 minutes, the bottom cursor will pulse once or twice
and right or left to display minutes precisely. One pulse left
means that you need to subtract one minute, two pulses left
means that you need to subtract two minutes, one pulse
right means that you need to add one minute and two pulse
right means that you need to add two minutes.
When the watch is left a 45º for more than 15 seconds, it
automatically deactivates the display to prevent battery
drainage. In order to allow display to turn on again, you
must put the watch’s dial downward for a one second.
Basic operation
IMPORTANT
6 7
Setting the watch
The watch can only be set by the light from your
smartphone or computer display. Programming device
must be a recent smartphone or LCD screen (some screen
calibration/adjustment may be required and must be web-
enabled. Because of this, the watch can support advanced
calendar features like moon phases and automatic date
change (including leap-year calculation).
The watch will always be set to the time of your
programming device (the program fetches time from the
programming device). During this procedure, the travel
“west” and “east” time shifts are also programmed (see
more info about in the “Travel Mode” section below). If
after setting the time, it does not match the time on the
programming device, please move the “Setting the Watch
(Troubleshooting)” section.
7
ENGLISH
1) Set your programming device to maximum brightness.
2) Put the watch is “programming mode”. At any moment
during the procedure below you can put the watch
downward to turn off the display and start over.
2.1) Display time by putting the watch at 45º in front of you.
The cursor will then move to current time. At this moment,
if the bottom cursor is blinking steadily (do not confuse
with left/right bottom cursor pulses for precise minute
reading), you are currently in some advanced feature (you
could have tapped the watch by mistake)….put the watch
downward and start over.
2.2) Then double-tap: bottom cursor goes to 5/calendar
icon and blinks slowly (it will be explained later why bottom
cursor blinks rapidly or slowly). Don’t pay attention to the
top cursor at the moment.
2.3) Then single-tap: bottom cursor goes to 15/travel mode
icon and blinks rapidly. Don’t pay attention to the top cursor
8 9
at the moment.
2.4) Then single-tap again: bottom cursor goes to 25/moon
phase icon and blinks slowly. Don’t pay attention to the top
cursor at the moment.
2.5) Then single-tap again: bottom cursor goes to 35/
chronometer icon and blinks rapidly. Don’t pay attention to
the top cursor at the moment.
2.6) Then single-tap again: bottom cursor goes to 45/
battery level icon and blinks slowly. Don’t pay attention to
the top cursor at the moment.
2.7) Then single-tap again: bottom cursor goes to 55/set
mode icon and blinks rapidly. Don’t pay attention to the top
cursor at the moment.
2.8) At this point, as soon as you double-tap, the watch
will put itself in”programming mode”. In this mode, the
top cursor displays the light intensity received by the light
9
ENGLISH
sensor on the back of the watch (on the 0-------1 scale)
and the bottom cursor is static at 55/wrench. The watch
remains in the state until programming is completed or
until it times out. Time out occurs if no valid data has been
sent to the watch after two minutes, at which point the top
and bottom cursor will blink multiple times at 0 (or 12h00).
3) Visit http://a.djust.me for the web-app (PC/Mac/iOS/
others) or to download the app for Android on the Google
Play store. You can also click “Set Watch” from Division
Furtive’s website top menu.
4) Put the back of the watch in direct contact over the
programming device’s screen and make sure the small
glass window (this is were the light enters the watch) is
in the center of the black and white ashing rectangle. As
soon as the programming is completed (at least one full
attempt, that is the orange progress bar going from 0%
to 100%), the cursors will move to current time (then
turn off if the watch is not at about 45º). The program will
attempt sending the programming data ve times (that
10 11
IMPORTANT
corresponds to the ve white bars on top of the orange
progress bar). Depending on the quality of the light signal
received, it may take more than one attempt.
If using a programming device that has a touchscreen,
make sure the watch contact with the touchscreen is
not interpreted as a user input and does not disturb the
programming sequence. A good way to avoid this is leaving
the programming device on a at surface with the watch
on top of it.
If your programming device has a very bright screen, you
must prevent the light sensor from becoming saturated
(when top cursor reaches 1 during programming) by moving
the watch away from the light source. It is important that
the brightness remains at the maximum setting since lower
settings may interfere with the programming sequence.
IMPORTANT
