Dirt Devil 360 REACH DDU03-E01 Manuel utilisateur

Cyclonic Vacuum

360°REACH™

USER GUIDE

DDU03-E01

WARNING

BASIC SAFETY PRECAUTIONS

• This vacuum cleaner is intended for

household use only and NOT for

commercial or industrial use.

• This vacuum cleaner does not stay

upright without constant support, in

 betweenuseslieatontheoor.

• Only use the vacuum cleaner

indoors on dry surfaces and keep

the area you’re cleaning well lit.

•Keepngers,hairandloose

clothing away from moving parts

and openings whilst using the

vacuum cleaner.

• This vacuum cleaner can be used

by children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the vacuum

cleaner in a safe way and

understand the hazards involved.

Children shall not play with the

vacuum cleaner. Cleaning and

user maintenance shall not be

made by children without

supervision.

• Only Dirt Devil recommended

tools should be used with the

vacuum cleaner, use of non-

branded Dirt Devil accessories/

tools will invalidate your guarantee.

• Don’t use the vacuum cleaner

if it has been dropped,

damage or left outdoors.

• Don’t run over the power cord or

use vacuum cleaner if the power

cord or plug is damaged. Please

contact our Customer Care Line

on: 0330 026 2626 (Mon-Fri

9:00am-5:00pm).

• Don’t handle the plug or use the

vacuum cleaner with wet hands.

• Don’t pull or carry the vacuum

cleaner by the power cord.

• Don’t use the power cord as a

handle, pull the power cord around

corners, sharp edges or close a

door over the power cord.

• Don’t unplug the vacuum cleaner

by pulling on the power cord.

•Don’tvacuumupanyammableor

 combustiblematerials(lighteruid,

petrol, kerosene etc) or use the

vacuum cleaner in an area with

explosive vapours or liquid.

• Don’t vacuum up hot coals,

cigarette butts, matches or

smoking hot burning items or use

in an area where there may be

 harmfuluids(chlorine,bleach,and

ammonia drain cleaner).

• Don’t vacuum up hard or sharp

objects such as glass, nails,

screws or coins etc.

DON'TS

WARNING

• Don’t attempt to remove blockages

with sharp objects as this may

cause damage to the vacuum

cleaner, remove blockages only as

instructed in this guide.

• Don’t use the vacuum cleaner with

incorrect voltage as this may result

in damage or injury to the user.

The correct voltage is listed on the

ratings label.

DON'TS CONTINUED...

• Turn off all controls on the vacuum

cleaner before disconnecting or

connecting the plug from the

mains socket.

• Always keep the power cord away

from brushes during use.

• Always make sure both the

 pre-motor/post-motorltersare

in place before use.

• Take extra care when using the

vacuum cleaner on the stairs.

• Always switch off the vacuum

cleaner before disconnecting or

connecting the reach wand and

accessories.

• Keep all openings clear and free

from debris as this may affect the

 airow/suction.

• Always replace the fuse in the plug

with a British 13amp fuse.

• Always protect the power cable

from heated surfaces and open

 ames.

• Use only CE approved 13amp

extension cords, non-approved

extension cords may overheat.

Care should be taken to arrange

the extension cord as it can be a

trip hazard.

• Store the vacuum cleaner in a cool,

 dryarea.Iftheltershavebeen

cleaned as per user the guide

instructions ensure they are

thoroughly dry before storing away.

• Take extra care when using the

vacuum cleaner on the stairs

• Use only CE approved 13amp

extension cords, non-approved

extension cords may overheat.

Care should be taken to arrange

the extension cord as it can be a

trip hazard.

PLEASE KEEP INSTRUCTIONS

FOR FURTHER USE.

DO'S

HI. WELCOME.

PRODUCT

REGISTRATION

For quick reference, please record your product information below.

Model #:

Serial number :

(serial number located on the back or bottom of product)

Guarantee Registration

Be sure to register your product online at www.DirtDevil.co.uk

Hint: Attach your sales receipt to this User Guide. Veriﬁcation of date of purchase may be

required for warranty service of your Dirt Devil®product.

Congrats on purchasing your new 360° REACH™

cyclonic vacuum. Inside, you’ll ﬁnd everything

you want to know from tools to how to.

So what are you waiting for? LET’S GO.™

This product uses the following parts:

POST-MOTOR FILTER

PRE-MOTOR FILTER

Find GENUINE Replacement Parts at www.DirtDevil.co.uk

TABLE OF

CONTENTS

Quick Start Assembly 6

How to 8

Tools 16

Troubleshooting 18

Limited Guarantee 19

Push the reach wand

down onto the powered

head until it clicks

into place.

Slide the crevice tool

into the crevice tool

holder inside the

handheld handle.

Push the handheld

down onto the reach

wand until it clicks

into place.

QUICK START

YOUR 360º REACH™

CYCLONIC VACUUM

IS READY TO CLEAN! NEED HELP?

Go to www.DirtDevil.co.uk or

contact our Customer Service

Department at 0330 026 2626

(Mon-Fri 9:00am to 5:00pm)

The upright stick vacuum cleaner is

not free standing, in between uses

lie ﬂat on the ﬂoor.

Push the handle forward to lock the

reach wand and powered head into

the upright position.

2. The reach wand and powered

head are not free standing. Place

safely and securely to one side.

1. Press the handheld release clip.

Pull and separate the handheld

from the reach wand.

3. Pull and slide the crevice tool out

of the crevice tool holder, if you

need it.

5. Plug into mains and slide the

On/Off and brushbar control

forward once (I).

4. Push the crevice or upholstery

tool into the handheld until it

clicks into place.

6. The crevice tool can be turned to

a desired angle for easier

cleaning.

USE AS A HANDHELD VACUUM CLEANER

IMPORTANT: Always switch off the vacuum cleaner before attaching/detaching the accessories.

Always take extra care when using the vacuum cleaner on the stairs.

This vacuum cleaner has a constantly rotating brushbar when

carpet mode (II) has been selected . When turned on never leave

the vacuum cleaner in one spot for an extended period of time as

this may damage the ﬂoor surface. The power head brush should

be ON (II) for carpets and OFF (I) for hard ﬂoors.

CAUTION

TOOLS

USE AS A STICK VACUUM CLEANER

2. Slide the On/Off and

brushbar control -

0= Off

I = The brush on the powered

head will NOT spin - for hard

ﬂoor cleaning

II = The brush will spin and a

green light on the powered

head will illuminate - for

carpet cleaning

1. Plug into the mains and place

your foot on the powered head.

Pull the handle backwards

to recline.

3. Slide the air vent open on

the reach wand to reduce

suction if required.

LOCK THE POWERED HEAD

INTO POSITON OPTIONAL

Position the wand and powered

head to the preferred cleaning

angle. Push the eco lock towards

the neck of the powered head to

lock position. This will make the

neck of the powered head less

ﬂexible.

TIP: For most efﬁcient results, the air

vent should be closed.

Unplug and switch off the vacuum cleaner before performing

maintenance or troubleshooting checks.

CAUTION

EMPTY AND CLEAN THE DIRT CONTAINER…

1. Press the handheld release clip.

Pull and separate the handheld

from the reach wand/crevice/

upholstery tool.

2. Place the reach wand and

powered head safely and securely

to one side, lie ﬂat on the ﬂoor.

3. Hold the handheld over a bin,

press the dirt release button

allowing dirt/debris to fall out.

TIP: Don’t over ﬁll the dirt container to avoid blocking the air ﬂow through the vacuum

cleaner and replace ﬁlters every 6-9 months.

PRESS

CLICK
