DirekTronik ZXT-120 Manuel utilisateur

ZXT-120

(Z-Wave-to-AC IR Extender)

USER MANUAL

Table of Contents

Introduction 2

Controller and Gateway Requirements 3

Built-in IR code library 3

Glossary 3

Product Overview 5

Setup and Operations 6

Listening Mode 6

Inclusion/Exclusion 7

IR Code Selection 8

IR Code Learning 9

Reset ZXT-120 to factory default 14

ZXT-120 Information 14

Z-Wave Configuration Parameters 15

Installation 18

Mounting the ZXT-120 to a wall 18

Wireless Information 21

Maintenance 21

Frequently Asked Questions 22

Technical Specifications 24

Checking Accessories 25

FCC Notice 25

Warnings 26

Caution 26

Z-Extender ZXT-120

(Z-Wave-to-AC IR Extender)

Introduction

The ZXT-120 is a Z-Wave to IR extender for air-conditioner (AC), (Figure 1), it works with

any Z-Wave compliant gateway or controller by translating Z-Wave Thermostat

Commands to AC IR control code. User can select the IR code from the built-in code

library of ZXT-120, or use learning function, by using Z-Wave Configuration Commands

according to the parameter table. ZXT-120 is also with built-in temperature sensor which

allows gateway or controller to get the current room temperature.

ZXT-120 can be configured as either "Frequently Listening Routing Slaves" FLiRS (if

you are using battery) or "Always Listening" (if you are using 5Vdc adaptor) before

inclusion process. Refer to Glossary for definition of "FLiRS" and "Always Listening"

mode.

ZXT-120 supports Network Wide Inclusion (NWI) and Explore Frames. It also supports Z-

]Wave networks with multiple gateways and controllers. Once the configuration and setup

is complete, the gateway or controller can use Z-Wave "Thermostat commands class" to

control their IR-controlled air-conditioner through the ZXT-120.

Figure 1 ZXT-120

Controller and Gateway Requirements

The ZXT-120 can work with any Z-Wave compliant controller or gateway supporting the

following Z-Wave commands.

- Configuration Command Class

- Multilevel Sensor Command Class

- Thermostat Command Class

> Thermostat Mode Command Class

> Thermostat Fan Mode Command Class

> Thermostat Set-point Command Class

Built-in IR code library

The Built-in IR code library supports most of the popular air conditioner brands in the

market. Z-Wave gateway and controller does not need to have any IR control code

knowledge. User can use Z-Wave controller or gateway to select the IR code according to

the ZXT-120 code list separately provided through Z-Wave configuration command.

Glossary

Device or Node Devices and nodes are all terms to describe an individual Z-

Wave device. These are all interchangeable when setting up

your Z-Wave network.

Inclusion Add a Z-Wave device to the network.

Exclusion Delete a Z-Wave device to the network.

Remove To take a device out of a group, scene or association group

while that device still exists in the same Z-Wave network.

Z-Wave Network A collection of Z-Wave devices is controlled by primary and

secondary controllers operating on the same system. A Z-Wave

network has its own unique ID code so that controllers not in the

network cannot control the system.

Primary

Controller

The first controller is used to set up your devices and network.

Only the Primary Controller can be used to include or delete

devices from a network. It is recommended that you mark the

primary controller for each network for ease in modifying your

network.

Network Wide

Inclusion (NWI)

Network Wide Inclusion (NWI) enables both end-user friendly,

Plug and Play like Z-Wave network installation as well as

professional installation scenario where the inclusion process in

terms of time will be reduced significantly. NWI is a feature

supported by a new frame type named Explorer which enables

the Z-Wave protocol to implement Adaptive Source Routing.

FLiRS Mode FLiRS is abbreviation for "Frequently Listening Routing Slave".

FLiRS mode is targeted for battery operated applications and

will enter sleep mode frequently in order to conserve battery

consumption. The response to Z-Wave command is not as

quick as Always Listening Device. Normally there is 1-2

seconds latency.

Always Listening

Mode

Always Listening mode is targeted for AC power operated

applications and it can act as a repeater, which will re-transmit

the RF signal to ensure that the signal is received by its

intended destination by routing the signal around obstacle and

radio dead spots. The response to Z-Wave command is

immediate.

Product Overview

1. "PROG" Button, Learning and LED Indication

2. Temperature sensor

3. External IR Port

4. USB Power 5V DC

5. Battery chassis

Surround IR Output for top and 4-directions

Figure 2

PROG Key and IR Port of ZXT-120

1 2

3 4

Setup and Operations

Before using the ZXT-120, please read the [INSTALLATION] if you need to mount the

ZXT-120 to a wall. Power up the ZXT-120 by the USB Power 5Vdc or Dry battery AAA x

3pcs.

- Plug-in 5Vdc power into the USB socket if operated at Always Listening mode. Or

- Install 3xAAA batteries if operated at FLiRS mode.

- Please refer to the section of [MOUNTING PROCEDURE].

- Remove the battery cover on the back of your ZXT-120 battery chassis.

- Mount the battery cover into the main unit with 2 screws.

- Check the polarity of the batteries and the "+/-" marks inside the battery compartment.

- Insert the batteries.

- Push the battery cover and main unit back in place.

(Please carefully read through the following then store the manual for future reference.)

Listening Mode (default mode is FLiRS)

ZXT-120 can be configured as either "Frequently Listening Routing Slaves" FLiRS (if

you are using battery) or "Always Listening" (if you are using 5Vdc adaptor) before

inclusion process. Refer to Glossary for definition of "FLIRS" and "Always Listening"

mode.

Important:

It is not allowed to changing ZXT-120 listening mode without exclusion process (do not

change ZXT-120 listening mode while ZXT-120 is included in a network).

ƒ{- Use new batteries of the recommended type and size only.

ƒ{- Never mix used and new batteries together.

ƒ{- To avoid chemical leaks, remove batteries from the ZXT-120 if you do not intend to

use the remote for an extended period of time.

- Dispose of used batteries properly; do not burn or bury them.

CAUTION (battery and power adaptor safety)

How to switch ZXT-120 listening mode from "Always Listening" to

"FLiRS" (or vice verse)

Inclusion/Exclusion

The primary controller should indicate that the action was successful. If the controller

indicates the action was unsuccessful, please repeat the procedure.

Step

1Press and hold the PROG button on

the ZXT-120 for around 5 seconds

Setup Key LED Indication Status on ZXT-120

- LED turns ON after PROG key

hold for 5seconds

2Release the button and then press the

PROG button 3 times within 2 seconds

-LED flashes twice then stay off

(ZXT-120 set in FLiRS mode)

- LED flashes four times then stay

off (ZXT-120 set in Always

Listening mode)

Step

1Refer to your primary controller

instructions to process the inclusion/

exclusion setup procedure.

Setup Key LED Indication Status on ZXT-120

2When prompted by your primary

controller, click once on the PROG

button

- LED flashes once then stay off

(ZXT-120 will report the

supported command class)

IR Code Selection

ZXT-120 is with built-in IR AC code library, user may select the IR code using

Configuration Command Class.

Step

1After included ZXT-120 to Z-Wave

controller or Gateway, go to device

setup for configuration on gateway or

controller.

Setup Key LED Indication Status on ZXT-120

2Input parameter number "27" and

parameter value (please look up the

code list of ZXT-120 according to your

AC brand). Then complete the

configuration process.

-LED flashes twice when ZXT-120

receives the configuration setting

3Press the PROG button on the ZXT-

120. (this step apply when using ZRC-

100 or other portable controller for set

up, if using gateway, user can skip this

step)

-LED flashes twice when ZXT-120

receives the configuration setting

4Go back to the control page of ZXT-

120 on the gateway and try the

function such as (cool, temperature set).

If the air conditioner does not respond

to the command you set on Gateway

(Cool, Heat, Auto, Temperature set etc.),

repeat step 2 and 3 to select the next

code on code list.

-LED flashes once every time it

receives a command from

gateway

IR Code Learning

In case none of the code on the code list works for the targeted air conditioner, user can

use IR code learning function using configuration according to below steps:

- Different brand or model of air conditioner has different function. For example,

o o

some air conditioner only support temperature set from 18 C - 30 C, if user set

17 C on gateway, ZXT-120 will not respond.

- There are more than 1 code for each brand, some does not support heat, if user

selected a code that does not support heat but the original air conditioner supports

heat function, please continue to try next code until the correct one is selected.

- You can record down your device code for future reference after setting up the

ZXT-120 correctly.

AC device programmed to your ZXT-120

Code no.:

- If none of the code works on the target air conditioner, or the air conditioner brand

is not shown on the code list, please select code "000" for IR code learning (refer

to instruction of IR Code Learning)

Important Information

Step

1Go to configuration setting page on the

gateway or ZRC-100 and input parameter

number "27" and parameter value "000" to

select the dedicated AC code number "000"

for learning.

Setup Key LED Indication Status

on ZXT-120

- LED flashes twice when

ZXT-120 receives the

configuration setting.
