INSTALLATION GUIDE

DS3+ / DS4+

2009 Toyota RAV4. 933.TL11 1.12.193.2

This product is intended for installation by a professional installer only! Attempts to install this

product by a person other than a trained professional may result in severe damage to a vehicle’s

electrical system and components.

Introduction 4

Vehicle function compatibilities 4

Pre-installation and application warnings 5

Key type 5

Installation 6

Wiring diagram with T-Harness (THTON10) 6

Wiring diagram 7

Locating components in the vehicle 8

Vehicle connections 9

Connecting the module 12

Important! 12

8556T Temperature Sensor 12

8504D Combo Sensor 12

RF Systems 13

When used in conjunction with SmartStart 13

D2D port configuration 13

Module programming 14

With transponder and CAN 14

Without transponder with CAN 15

Module programming for security-only installations 16

LED diagnostics and troubleshooting 17

Soft reset 19

Hard reset 19

Learning the Tach (not needed with Virtual Tach) 20

Initializing Virtual Tach (not needed with hardwired or data tach applications) 20

Limited lifetime consumer warranty 21

Quick reference guide 22

Contents

3933.TL11 1.12.193.2 2009 Toyota RAV4

Warning! Safety ﬁrst

The following safety warnings must be observed at all times:

• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.

• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never

operate the system in an area that does not have adequate ventilation.

The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:

• Never use a test light or logic probe when installing this unit. Always use a multimeter.

• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).

• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.

ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE

STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.

Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or

death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with

the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the

neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.

This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product

installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to ﬁx the problem

immediately.

OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF

OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE

OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE

START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.

Remote starters for manual transmission pose signiﬁcant risks if not properly installed and operated. When testing to ensure the

installation is working properly, only remote start the vehicle in neutral gear, on a ﬂat surface and with a functional, fully engaged

parking brake. Do not allow anyone to stand in front of or behind the vehicle.

This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such

vehicles may pose certain risk.

4933.TL11 1.12.193.2 2009 Toyota RAV4

Introduction

DS3+ is a complete solution for remote start, security (when security features are enabled) and bypass. This guide provides

information on the installation of the module as a digital solution. Please refer to www.directechs.com for more information about

which conﬁguration is best for your application.

Warning! This module can be conﬁgured using the web tool located at www.directechs.com. The DS3/DS3+ module is not

equipped with Bluetooth, therefore the blue LED will not ﬂash during module programming or when performing a soft or hard reset.

DS4+ is a complete solution for remote start, security (when security features are enabled), bypass, and features

built in Bluetooth 4.0 allowing you to conﬁgure and control your system. This guide provides information on the

installation of the module as a digital solution. Please refer to the DirectLink application or www.directechs.com

for more information about which conﬁguration is best for your application.

Warning! This module is designed to be conﬁgured using the DirectLink application for mobile devices,

however it can also be conﬁgured using the web tool located at www.directechs.com. To download the DirectLink mobile

application, please visit the Google Play or Apple store.

Vehicle function compatibilities

This section lists all the functions compatible with this vehicle for the installation illustrated in this guide.

Parking Lights Control

Arm Factory Security

Disarm Factory Security

Door Lock Control

Door Unlock

Driver Priority Unlock

Trunk / Hatch Release

DS4+/DS3+ Only

Immobilizer Bypass-Data No Key Req'd

3x LOCK START (Start control using OEM Remote)

Accessory Activation

Ignition Activation

Remote Start Takeover

SmartStart

Start (Crank) Activation

Tach / RPM Output

Entry Monitoring ALL Door Pins

Entry Monitoring Hood Pin

Entry Monitoring Trunk/Hatch Pin

Factory Alarm Trigger Monitoring

Brake Status (foot brake)

E-Brake Status

Ignition Status

5933.TL11 1.12.193.2 2009 Toyota RAV4

Pre-installation and application warnings

Firmware notes: This section highlights important information for this speciﬁc ﬁrmware and will assist in

pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.

T-Harness

compatible THTON10 Keys required for

programming 1Keys required for

operation 0

Important: If your vehicle is NOT equipped with transponders or CANs, please ﬂash your module with an Analog ﬁrmware.

This guide will help you with the installation diagram and vehicle connections.

Some Toyota 2010+ models have different encryption types. Please look at your key blade and indentify the markings.

A dot "." means the vehicle is compatible with TL11 ﬁrmware. "G" or "H" indicates the vehicle is not compatible with this

ﬁrmware. Refer to "Key Types" for more information.

The optional Plug & Play THTON10 T-Harness is sold separately.

The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.

All T-Harness wires NOT listed in the diagram are NOT required for the installation.

Unless speciﬁed otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic

connector.

It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each

wiring diagram.

Refer to the "Vehicle connections" following the installation diagram.

General notes: This section highlights important information for this speciﬁc ﬁrmware.

[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.

[2] The siren is ONLY required when enabling the security features during module ﬂashing.

[3] The Green wire is ONLY required for starter disable and antigrind applications.

[4] Second starter connection may be required in some vehicles.

Key type

Some Toyota 2010+ models have different encryption types. Please look at your key blade and identify the markings.

G-stamped keys Standard Key

H-stamped keys

For vehicles with H-stamped keys, see

the TL10 firmware.

For vehicles with G-stamped keys, see

the TL5 & TL7 firmware.

For vehicles with dot-stamped keys,

see the TL11 firmware.

6933.TL11 1.12.193.2 2009 Toyota RAV4

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

Wiring diagram with T-Harness (THTON10)

(-) Parking Light Output: Lt.Green/Black

Siren

Hood Pin (-) Hood Input: Gray

(+) Siren Output: Brown/Red

Headlight Switch

(white 20-pin conn.)

12345678910

1112131415161720

19 18

(-) Parking Lights: Pin 18

Security Only

Mandatory Connections

Remote Start Only

Legend:

Remote Start + Security

22-pin White Connector

8-pin White Connector

12-pin Black Connector

10-pin White Connector

Ignition Connector

Diagnostic Connector OBDII

THTON10

(optional T-Harness)

NOT USED

Transponder Key Amplifier

(black conn. around ignition)

Cut the

Violet/White loop

labelled TACH.

Cut the

Yellow/Black loop

labelled SIL.

IMPORTANT:

Position the

fuses correctly!

Slide to open

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

7933.TL11 1.12.193.2 2009 Toyota RAV4

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).

Wiring diagram

(-) Ground: Black: 10

HS CAN Low: Tan : 1

(-) Parking Light Output: Lt.Green/Black: 1

HS CAN High: Tan/Black: 2

Data TX: Yellow/Black: 8

Data RX: Orange/Black: 7

Siren

Hood Pin

(+) 12V Input: Red: 6 & 12

(+) Starter 2 Output: Blue: 3

(+) 12V Input: Blue/Red: 2

(+) Ignition Input/Ouput: Pink: 10

(+) 12V Input: Red: 5

(+) 12V Input: Red/Black: 2

(+) Ignition 2 Output: Pink/White: 4

(+) 12V Input: Red/White: 9

(-) Hood Input: Gray: 21

(+) Siren Output: Brown/Red: 11

OBDII Plug

Black Connector

HS CAN High: Pin 6

HS CAN Low: Pin 14

Refer to Vehicle Connections for wire and connector details.

Refer to Vehicle Connections

for wire and connector details.

Ignition Switch

Headlight Switch

(white 20-pin conn.)

12345678910

1112131415161720

19 18

(-) Parking Lights: Pin 18

Dash Fuse Box

(white 1-pin conn.)

Transponder Key Amplifier

(black conn. around ignition)

(+) Starter Output (veh. side): Violet: 7

Starter Input (conn. side): Green: 6

CUT

Security Only

Mandatory Connections

Remote Start Only

Legend:

Remote Start + Security

(+)Accessory Output: Orange: 8

IMPORTANT:

Position the

fuses correctly!

Slide to open

MAIN (5A) (+)

(-) RLY3 PK LIGHT (15A) (+)

(-) ACC & START (30A) (+)

(-) FLEX RLY (20A) (+)

IGN (20A) (+)

8933.TL11 1.12.193.2 2009 Toyota RAV4

Locating components in the vehicle

9933.TL11 1.12.193.2 2009 Toyota RAV4

Vehicle connections

The connection information listed below is specific to the 2009 Toyota RAV4. Refer to “Pre-installation and application warnings” for a list of important notes.

Data harness, 8-pin white connector (H1)

Module Connects To

Conn./Pin Color Description Wire Location (+/-) Wire Color Connection

H1/1 Tan (Data) HS CAN Low OBD-data link connector, white 16 pin plug, pin 14 data white Mandatory

H1/2 Tan/Black (Data) HS CAN High OBD-data link connector, white 16 pin plug, pin 6 data black Mandatory

H1/3 Orange/Brown No Connection No Connection

H1/4 Orange/Green No Connection No Connection

H1/5 Lt. Green No Connection No Connection

H1/6 Violet/Brown No Connection No Connection

H1/7 Orange/Black (Data) Immo Data Transponder Key Amplifier on key switch, black 7 pin plug, pin

data pink Remote Start

Only

H1/8 Yellow/Black (Data) Immo Data Transponder Key Amplifier on key switch, black 7 pin plug, pin

data green Remote Start

Only

Analog input/output harness, 22-pin white connector (H2)

Module Connects To

Conn./Pin Color Description Wire Location (+/-) Wire Color Connection

H2/1 Lt. Green/Black (-) Pk Light Output headlight switch, white 20 pin plug, pin 18 - white Mandatory

H2/2 Blue/White No Connection No Connection

H2/3 Dk. Green/Black No Connection No Connection

H2/4 Red/White No Connection No Connection

H2/5 Brown/Black No Connection No Connection

H2/6 Brown/White No Connection No Connection

H2/7 White (+) No Connection No Connection

H2/8 Violet/Black No Connection No Connection

H2/9 Dk. Blue/Black No Connection No Connection

H2/10 Lt. Blue/Black No Connection No Connection

H2/11 Brown/Red (+) Siren Output [2] Security Only

H2/12 Pink No Connection No Connection

H2/13 Violet No Connection No Connection

H2/14 Brown No Connection No Connection

H2/15 White/Blue No Connection No Connection

H2/16 Red/Blue No Connection No Connection

H2/17 Black/White No Connection No Connection

H2/18 Orange/Black No Connection No Connection

H2/19 Blue No Connection No Connection

H2/20 Green No Connection No Connection

H2/21 Gray (-) Hood Switch Input [1] Not Applicable

10 933.TL11 1.12.193.2 2009 Toyota RAV4

Module Connects To

Conn./Pin Color Description Wire Location (+/-) Wire Color Connection

H2/22 Violet/White No Connection No Connection

Main harness, 12-pin black connector (H3)

Module Connects To

Conn./Pin Color Description Wire Location (+/-) Wire Color Connection

H3/1 Blue/White Relay N.C. No Connection No Connection

H3/2 Blue/Red Relay N.O. (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue (30A) Remote Start

Only

H3/3 Blue Relay COM (+) Start 2 Output ignition switch, white 8 pin plug, pin 1 + white Remote Start

Only

H3/4 White/Brown Relay N.C. No Connection No Connection

H3/5 White Relay COM No Connection No Connection

H3/6 Red (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue (30A) Mandatory

H3/7 Lt. Green/Red Relay N.O. No Connection No Connection

H3/8 Lt. Green Relay COM No Connection No Connection

H3/9 Lt. Green/White Relay N.C. No Connection No Connection

H3/10 Black (-) Ground (chassis ground) Mandatory

H3/11 White Relay COM No Connection No Connection

H3/12 Red (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue (30A) Mandatory

Relay harness, 10-pin white connector (H4)

Module Connects To

Conn./Pin Color Description Wire Location (+/-) Wire Color Connection

H4/1 N/A No Connection No Connection

H4/2 Red/Black (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue (30A) Remote Start

Only

H4/3 Pink/Black No Connection No Connection

H4/4 Pink/White (+) Ignition 2 Output ignition switch, white 8 pin plug, pin 4 + pink Remote Start

Only

H4/5 Red (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue (30A) Remote Start

Only

H4/6 Green Starter Input (conn. side) [3] ignition switch, white 8 pin plug, pin 8

Connection required for Starter Disable Only.

+ yellow Mandatory

H4/7 Violet (+) Starter Output (vehicle side) ignition switch, white 8 pin plug, pin 8 + yellow Mandatory

H4/8 Orange (+) Accessory Output ignition switch, white 8 pin plug, pin 3 + red Remote Start

Only

H4/9 Red/White (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue (30A) Remote Start

Only

H4/10 Pink (+) Ignition Input/Output ignition switch, white 8 pin plug, pin 6 + white Mandatory

Autres manuels pour DS3+

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Directed Accessoires automobiles

Directed

Directed XPRESSKIT solex DLCH-CHDL6+ Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed Xpresskit DBALL-NISS08EU Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed DS4+ Manuel utilisateur

Directed

Directed DS4+ Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed GM10 Manuel d'utilisation et d'entretien

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed DIRECTWIRE DIRECTECHS THGMN4 Manuel utilisateur

Directed

Directed DS3+ Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed Directechs DS3 Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed DS4+ Manuel utilisateur

Directed

Directed 933.TL7 Manuel utilisateur

Directed

Directed Directechs DB3 Manuel utilisateur

Directed

Directed Install Essentials CAN1 Manuel utilisateur

Directed

Directed XpressKit DBALL Manuel utilisateur

Directed

Directed 403.GM4 Manuel utilisateur

Directed

Directed Xpresskit DBALL2 Manuel utilisateur

Manuels Accessoires automobiles populaires d'autres marques

James Baroud

James Baroud Odyssey Manuel utilisateur

Motorola

Motorola i50sx Manuel utilisateur

Yakima

Yakima 9MM STANDARD BIKE MOUNT Manuel utilisateur

Feniex

Feniex T3 Manuel utilisateur

Renault

Renault 77 11 423 180 Manuel utilisateur

Kia

Kia E8300-4D000 Manuel utilisateur

Brink

Brink 756843 Manuel utilisateur

Whispbar

Whispbar K085W Manuel utilisateur

v.link

v.link CI-VL2-PC-HSD Manuel utilisateur

Viking

Viking Stack-Rack Guide de configuration rapide

Aries

Aries 203015 Manuel utilisateur

Choetech

Choetech AT0005 Manuel utilisateur

ZZ2

ZZ2 ZZAIR-PRO Manuel utilisateur

Holman

Holman 4A80L Manuel utilisateur

Thule

Thule 2075 Manuel utilisateur

Motorola

Motorola T325 Manuel utilisateur

TAUBENREUTHER

TAUBENREUTHER 16-3950 Guide d'installation

DV8

DV8 FBJL-02 Manuel utilisateur
