Directed Electronics Soloist Manuel utilisateur
Universal Sound System
Owner’s Guide
//
/
/
/
Desktop Docking Statio
n
© Directed Electronics, all rights reserved. 3
Soloist Universal Sound System
Table of Contents
Safety Precautions and FCC Statement 5
Congratulations 6
How to Use this Guide 6
Box Contents 7
Unpacking and Setting up your Soloist
Battery Installation 8
Front View 9
Rear View 10
Remote Control 11
Docking Cradle Types 12
Before inserting the Stiletto Cradle 13
Inserting Docking Cradle 14
Setting the Clock 15
LCD Contrast Setting 16
Installing the Windowsill Antenna 17
Using your Soloist
Switching Soloist On and Off 18
Selecting a Source 18
Volume Control 19
Equalization Settings 19
Dynamic Bass Boost 19
Mute 20
Display Option 20
Using the Headphone Jack 20
Using Specific Sources
Sirius Satellite Radio 20
iPod Music Players 23
Line In/Aux In 24
Alarms and Timers
Alarm Clock 24
Music Timer 26
Sleep Timer 29
USB Communication 30
Specifications 31
Warranty 33
Desktop Docking Statio
n
© Directed Electronics, all rights reserved. 5
Soloist Universal Sound System
Safety Precautions
Take the following precautions to keep Soloist in proper working order:
❍Set up must be performed according to this manual. Directed Electronics is not responsible for issues arising from set
up not performed according to the procedures in this manual.
❍Do not use any power supply other than the one included. This will damage or cause Soloist to be inoperable.
❍Do not use Soloist where it will be exposed to high levels of humidity, moisture, or dust.
FCC NOTICE:
This device complies with Part 15 of FCC rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation. Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this device.
Directed Electronics is not responsible for any radio or TV interference caused by unauthorized modifica-
tions to this equipment. Such modifications could void the User’s authority to operate the equipment.
© Directed Electronics, all rights reserved.
6
Congratulations
Thanks for purchasing Soloist Universal Sound System. This elegant powered speaker system with its unique interchange-
able cradle system will allow you to enjoy high quality audio from SIRIUS Satellite Radio, the ubiquitous iPod portable media
player, and many other popular digital audio and video devices. Be sure to save your sales receipt. It is your best record of
the date of purchase, which is required for warranty service. Read and follow all cautions, warnings and notes. For the lat-
est information about this and other products, visit www.directedsirius.com. For technical help regarding this product please
contact Directed Electronics at 1-800-753-0800.
How to Use this Guide
Button icons:
Soloist has buttons that are used to control the features
and functions of the system. In addition, an infrared remote
control is provided to control Soloist. Some buttons exist
only on Soloist or the remote, while some buttons exist in
both places.
In order to make this guide easy to understand, icons that
look just like the buttons on Soloist and the remote control
are used in the text.
An icon like this SNOOZE refers to a button on Soloist.
An icon like this
PROG/
CLOCK
refers to a button on the remote
control.
When you see both icons like this
VOL
or _you can
use either the button on Soloist or the remote control.
Note: Since the volume up and down buttons exist on both
Soloist and the remote control, only Soloist's button will be
used in this guide.
Liquid Crystal Display (LCD) messages:
In most cases in this guide, pictures of the LCD are used to
indicate what you will see on the LCD. In cases where no
picture is provided bold text in quotations is used.
“HELLO” means this message will appear on the LCD.
Soloist features:
The name of Soloist features or modes are capitalized in
this guide.
Clock Set refers to the clock setting mode of Soloist.
Desktop Docking Statio
n
© Directed Electronics, all rights reserved. 7
Soloist Universal Sound System
Box Contents
Unpack your Soloist universal sound system carefully and
make sure that everything listed below is present:
• Soloist Universal Sound System
• AC/DC Power Adapter and Line Cord
• Remote Control and battery
• Sportster 4 Docking Cradle
• Starmate 4 /Stratus cradle adapter
• Stiletto 10 and 100 Docking Cradle
• iPod Docking Cradle
• Sirius Home Antenna
• Owner's Guide
• Clock Battery
• Sirius Cradle Screw
Trademark of New Transducers Limited. All Patent Rights Reserved.
"SIRIUS" and the SIRIUS dog logo are registered trademarks of Sirius Satellite Radio Inc.
iPod is a registered trademark and the property of Apple Computer, Inc.
© Directed Electronics, all rights reserved.
8
Battery Installation:
Soloist Internal Battery
The battery inside Soloist is used to keep the clock run-
ning in the event of a power loss. It should be replaced
every 2 years. The battery holder is located in the bottom
panel of Soloist dock. It has a slot on one side. Press
in from the side near the slot with your thumb nail to
release the battery cover. Once cover is removed battery
can be installed or replaced. To reinstall battery cover,
insert tabs on opposite side of cover into slots and snap
in place. The battery is a CR2025.
Inserting the Batteries
1. Open the battery compartment cover.
2. Insert the new battery. Make sure that the positive
and negative terminals of the battery are oriented as
shown in diagram.
3. Close the cover.
Remote Control Battery
The instructions for opening the battery compartment
are located on the back of the remote. The battery is a
CR2032.
Precautions
1. Properly dispose of used battery.
2. Do not misuse battery by shorting the positive “+” and
negative “-” terminals or put it into fire. Overheating
may cause the battery to explode and cause a fire
hazard.
3. To avoid accidents, prevent children from playing with
the battery.
+
Partial bottom view of Soloist
Battery cover
Battery
UNPACKING AND SETTING UP YOUR SOLOIST
Desktop Docking Statio
n
© Directed Electronics, all rights reserved. 9
Soloist Universal Sound System
Soloist - Front View
1 Music Timer Button
2SNOOZE Snooze/Clock Set Button
3Alarm Clock Button
4 SLEEP Sleep Timer Button
5 IR sensor
6 Liquid Crystal Display
7 panel
8 Docking Cradle
9 _Volume Down Button
10 Power/Source Button
11 +Volume Up Button
12 Headphone Output Jack
13 AUX Auxiliary Input Jack
NOTE: The panel is rugged, but can be damaged
if punctured or pushed too hard. If anything is touching
the panel while playing the sound can be noisy and/or
distorted.
1 2 3 4 5
910 11 12 13
6
7 8
© Directed Electronics, all rights reserved.
10
Soloist - Rear View
1 Line Input Jack
2 Line Out Jack
3 DC 12V Input Jack
4 Sirius Antenna Jack
5 MINI USB Connector
1 2 3 4 5
