INSTRUCTION MANUAL
Federico
8705
2
DIR
www.dirgroup.co.uk
CONTENTS
Please read the operation manual before using the product.
Please put the operation manual in the place easy for you to read and you can read it at any time.
Product Introduction
Maintenance
3
5
Product Information
4
6
Troubleshooting Guide
Operation Instructions
Contact Us
14
15
Warranty
12
13
Aftercare instructions
3
DIR
www.dirgroup.co.uk
PRODUCT INTRODUCTION
Product Name: Federico
Product Code: 8705
Thank you for placing your order with the DIR . Our materials inc. faux leather etc,are
specially sourced to provide quality and performance, as well as meeting UK/EUsafety
regulations to ensure customer satisfaction.
All of our facial beauty bed are produced with strong resilient faux leather, tested by our
manu-facturer to ensure strength, memory, heat resistance and stain proofing. We also fit
ourfacial beauty bed with fire-retardant, pre-moulded memory foam to ensure continual use
andsustained durability which we offer a one year warranty to ensure customer confidencein
our products and our company.
4
DIR
www.dirgroup.co.uk
WARRANTY
66 Rea Street South
Birmingham
B5 6LR
UK
-----------------------------
Tel:
+44(0)121 6433877
-----------------------------
Email:
DIR BIRMINGHAM
Unit 1 River Road
Business Park
33 River Road, Barking
Greater London
IG11 0DA
UK
------------------- ----------
Tel:
+44(0)20 8591 9310
--------- --------------------
Email:
sales.london@dirgroup.co.uk
DIR LONDON
24 Woodward Ave.
Suite C
Queens, NY 11385
USA
------------------- ----------
Tel:
+1 (718)628-6668
+1 (800)728-2008
-------- ---------------------
Email:
sales@dirsalonfurniture.com
DIR NEW YORK
Konrad-Adenauer-Straße 25
50996 Köln
Germany
------------------------------
Tel:
+ 49 (0) 221/88888.128
------------------------------
Email:
DIR COLOGNE
Unit 5 Block E,
Riverview Business Park,
Nangor Road, Dublin 12
Republic of Ireland
------------------------------
Tel:
+353 (01) 429 7969
------------------------------
Email:
sales.ireland@dirgroup.ie
DIR IRELAND
The warranty period is one year. DIR warrants to you, the original buyer, that goods shall be free of
defects in material and/or workmanship attributable to manufacture for one year from date of buyer′s
receipt of product. Damage resulting from improper handling after merchandise is received, or from
exposure to weather or extreme atmospheric conditions is not covered by the warranty.
For any other information please contact our support team:
5
DIR
www.dirgroup.co.uk
ASSEMBLY INSTRUCTIONS
Measurement: L1880*W800*H720(mm)
Hydraulic Height:720 - 890 mm
Net weight:75 KG
Gross weight:100 KG
Maximum load: 150 KG
590mm
800mm
1880mm
720-890mm
6
DIR
www.dirgroup.co.uk
ASSEMBLY INSTRUCTIONS
Press down or can adjust the bed go up or dropdown
720mm
890mm
7
DIR
www.dirgroup.co.uk
ASSEMBLY INSTRUCTIONS
Tools Necessary
Step the backrest controller toward the arrowhead direction.Push the backrest backwards
at the same time,It can let backrest tilt. Let slip the backrest when adjust it to meet your need,
and the backrest can adjust from 0 to 110 degree.
Backrest can come back when step on the backrest controller the second time.
underframe cover
backrest controller
step down
1100
Push backwards
8
DIR
www.dirgroup.co.uk
ASSEMBLY INSTRUCTIONS
Step the controller of the seating washer toward the arrowhead direction.
Push the backrest backwards.It can let seating washer tilt.Let slip the seating
washer when adjust it to meet your need .Seating washer can come back
when step on controller the second time
seating washer controller
underframe cover
step down
Push backwards
9
DIR
www.dirgroup.co.uk
ASSEMBLY INSTRUCTIONS
Pull the leg mat controller upward and let it dropdown slowly by
hand.Stop pull controller of the leg mat can let the leg mat fix up
when adjust to meet your need.
Leg mat can adjust from 0 to 77 degree,Push the opposite side.
The leg mat go up or come back
leg mat controller
77°
.
10
DIR
www.dirgroup.co.uk
ASSEMBLY INSTRUCTIONS
Armrest can adjust from 0 to 104 degree for the customer to get
on or get off the bed freely (Just like the picture show)
1040
