Dimplex DEP Series Manuel utilisateur

7216010000R00

Panel Convector Heater

DEP/DNP Series

Digital Weekly Timer Programming

1. Set day and time

Press + and simultaneously.

2. Temperature

d1: Monday

d2: Tuesday

d3: Wednesday

d4: Thursday

d5: Friday

d6: Saturday

d7: Sunday

A. Select 12H/24H (press +)

B. Conrm (press )

C. Set the hour (press + or -)

D. Conrm (press )

E. Set the minutes (press + or -)

F. Conrm (press )

G. Set the day (press + or -)

H. Conrm (press )

30˚C

7˚C

.... ....

30˚C

7˚C

OFF

.... ....

˚C ˚F

Red = Comfort

Adjust Comfort

temperature by

pressing + or -

Green = Eco

Adjust Eco

temperature by

pressing + or -

A centre dot in the numerical

display will ash when the

heater is heating

Do not cover

the heater.

08/90289/0 Issue 0

1-888-346-7539 | www.dimplex.com

In keeping with our policy of continuous product improvement,

we reserve the right to make changes without notice.

3. Optional settings

Programme daily settings

Override

Key lock

This heater has nine 24hour programs. Select one program

for each day of the week.

Pr. 1

Pr. 2

Pr. 3

Pr. 4

Pr. 5

Pr. 6

Pr. 7

Pr. 8

Pr. 9

0600 2300

0700 2400

1500 2300

150008000600 2300

170008000600 2300

0600 1600

0600 2000

0000 2400

0000

2400

Press and + simultaneously.

A. Select from above

programmes for day 1

(Monday) (press + or -)

B. Conrm (press )

C. Now select from above

programmes for day 2

(Tuesday) (press + or -)

D. Conrm (press )

Repeat for each day (d1 to d7)

d1: Monday

d2: Tuesday

Adaptive start allows the heater to learn what time it needs

to start heating so that the room is at the set temperature

by the time of the programmed setting. For example, if the

programming is set to 20 degrees Celsius at 6am, the heater

will start heating up before 6am so that by 6am, the room will

be 20 degrees Celsius. Many factors impact on room heat up

times (e.g. size of the room and insulation) and initially the

heater may start too early or too late. However it will learn

and recalibrate itself over several days optimising itself to the

best time to start heating.

Pressing overrides the status from Comfort to Eco or vice

versa.

The override is terminated automatically upon the next event

in the program, or at 03:00.

Press and - simultaneously to lock or unlock
