Dimplex CFS60E Manuel utilisateur

08/82609/0 ISSUE: 5

INSTRUCTION MANUAL

Installation and Operating

CFSE Commercial Fan Heater

Model: CFS60E

This product is supplied and operated with a Wireless Remote Control handset

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR

FUTURE REFERENCE. Note also the information presented on the appliance

IMPORTANT SAFETY ADVICE

DO NOT COVER OR OBSTRUCT the air inlet or outlet grille.

IMPORTANT – Disconnect from the mains supply before carrying out maintenance

work.

THIS APPLIANCE MUST BE EARTHED

This heater must not be located immediately above or below a ﬁxed socket outlet

or connection box.

Keep combustible materials such as drapes and other furnishings clear from the front,

sides and rear of the heater.

DO NOT use this heater in the immediate surrounding of a bath, a shower or a

swimming pool.

DO NOT use this heater in areas where excessive dust exists.

DO NOT store or use any ﬂammable materials or sprays in the vicinity of the appliance

– FIRE HAZARD.

DO NOT insert any foreign objects into the appliance openings. Risk of injury, electric

shock or damage to the appliance may occur.

This product should be mounted safely to a solid wall.

Ensure the supply cables are of adequate current carrying capacity and are protected

by a suitable fuse.

This appliance should only be connected to the ﬁxed wiring of the premises by means

of conduit.

This product must not be subjected to water spray or immersion.

If the appliance is mounted in a toilet or washroom, the appliance should be mounted

such that no part of it can be touched by a person using a ﬁxed bath or shower.

If the appliance is mounted in a toilet or washroom an isolating switch must be

provided outside the washroom adjacent to the entrance door.

DO NOT use heater to dry your laundry.

DO NOT operate the heater with the mains lead overhanging the front outlet grille.

This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall not be made by children

without supervision.

Children of less than 3 years should be kept away unless continuously supervised.

Children aged from 3 years and less than 8 years shall only switch on/o the appliance

provided that it has been placed or installed in its intended normal operating position

and they have been given supervision or instruction concerning use of the appliance

in a safe way and understand the hazards involved. Children aged from 3 years and

less than 8 years shall not plug in, regulate and clean the appliance or perform user

maintenance.

CAUTION — Some parts of this product can become very hot and cause burns.

Particular attention has to be given where children and vulnerable people are present.

The instruction leaﬂet belongs to the appliance and must be kept in a safe place. If

changing owners, the leaﬂet must be surrendered to the new owner. Ensure proper

manual handling procedures are observed at all times.

CAUTION – In order to avoid a hazard due to inadvertent resetting of the thermal

cut-out, this appliance MUST NOT be supplied through an external switching device,

such as a timer, or connected to a circuit that is regularly switched on and o by the

utility.

WARNING -Do not use this heater in small rooms where they are occupied by persons

not capable of leaving the room on their own, unless constant supervision is provided.

WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN

• Swallowing may lead to serious injury in as little as 2 hours or death, due to

chemical burns and potential perforation of the oesophagus.

• If you suspect your child has swallowed or inserted a battery go straight to a

hospital emergency room.

• Examine devices and make sure the battery compartment is correctly

secured, i.e. that the battery cover is ﬁtted securely. Do not use if the

compartment is not secure.

• Dispose of used batteries immediately and safely. Flat batteries can still be

dangerous.

Model Identiﬁer(s): CFS60E

Nominal heat output Pnom 6.0 kW

Height (mm) 360

Width (mm) 386

Depth (mm) 630

Minimum heat

output (indicative) Pmin N.A.

Maximum continuous heat output Pmax,c 6.0

Auxiliary electricity Consumption

At nominal heat output elmax 0.00

At minimum heat output elmin 0.00

In standby mode elSB <0.0005

This product meets the Ecodesign requirements for an electric ﬁxed local space

heater Commission Regulation (EU) 2015/1188.

Energy Related Product Directive

Technical Details

Type of heat output/ room temperature control

Electronic room temperature control plus week timer Yes

With open window detection No

With adaptive start control Yes

Customer Helpline: 0344 879 3588

aftersales@dimplex.co.uk

www.dimplex.co.uk

Glen Dimplex Heating and Ventilation

Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF

All Models

Controls

Digitally controlled, Electronic Thermostat

Timer modes:

7 Day Programmable User Timer

Continuous heat modes:

Manual, Runback, Fan Only, O

Controller UI

O-board control only. Requires pairing with Wireless remote.

Controller Functions

• Heat Selection: High, Low, Fan Only

• Adaptive-Start

• Advance time period

• Adjustable SP range (7-30°C)

• Wireless for control

Construction Steel case with plastic mouldings

Fan Type

Centrifugal

Element Finned metal sheathed

Installation Supplied with wall mounting bracket

Safety Manual reset cut-out (114°C)

Automatic cut-out (86°C)

Battery Backup

None. Time and date must be re-programmed in event of power loss to

the product

Supply

Requires: 3 core for fused spur installation, 1/N/PE ~230-240 V, 50Hz

Class I, with earth wire

Colour / Finish Trac White (RAL 9016) with black grille and bracket

Approvals UKCA & CE

IP Rating IPX4

Guarantee 2 years

Country of Origin British Isles

Manufacturer Glen Dimplex Heating & Ventilation (Glen Dimplex UK Limited.)

Fig. 1 Fig. 2

Fig. 3

Fig. 4 Fig. 5

500 mm

Min.

500 mm

Min.

1000 mm

Min. 1000 mm

Min.

2.1 m MIN

45° Max

70 mm

3a. 3b.

General

A robust, durable wall mounting fan heater designed to coordinate with the Dimplex

range of Air Curtains, providing environmental heating in commercial and light

industrial environments.

The heater works by gradually raising the air temperature in the building and should

be positioned so as best to achieve an even temperature distribution. The product

has an output of 6kW

Wall Mounting

Remove the wall mounting bracket from the back of the heater and using it as a

guide (see Fig. 2) mark o the hole positions on a suitable wall (a minimum height

of 2.1 metres is required from the ﬂoor level to the bottom of the bracket). Solid

brick or concrete block walls must be drilled and plugged. Fix the wall mounting

bracket to the wall and assemble the heater to the extension tube using a bolt and

wing nut ﬁtted into hole 1 shown in Fig. 3a. Rotate the heater as shown in Fig. 3b,

and ﬁx the heater into position using the remaining bolt and wing nut in hole 2. Pivot

and rotate the heater into the desired position and tighten all three wing nuts. A

6mm Allen key can be used as an aid to tightening the bolts.

Model

Heat

Output

(kW)

Electrical Sup-

ply

Electrical Load

(per phase)

(A)

Weight (kg) Min installed

Height (M)

CFS60E 3 / 6 16.5 2.1220-240V ~1PN 26.0

Electrical Connections

The installation of this appliance should be carried out by a competent electrician

and be in accordance with the current IEE wiring regulations.

Only cable with a minimum CSA (cross sectional area) of 4.0mm must be used on

this appliance.

Electrical power and control connections are made by removing the control housing.

The control housing (‘Y’ in Fig 4) is detached by removing the two screws and

hinging the housing as shown (see step 1 in Fig 4). The bottom panel (‘x’ in Fig 4) is

detached by removing two screws and lifting o as shown (see steps 2 & 3 in Fig. 4).

NOTE:

A suitable local isolating switch must be provided in the electrical

supply circuit as close as possible to the heater with at least 3mm

clearance on each pole

Feed appropriate supply cable (see ‘a’ in Fig 5) to terminal blocks ‘c’. Make electrical

connections as shown in Fig 7 and ﬁx cable in back panel using cable gland.

Thermal Safety Cut-Out

The power supply to the heating elements will be interrupted if one or a

combination of the following abnormal events occurs:

1. Air inlet grilles are obstructed.

2. Internal ventilation is impaired due to build up of dust and ﬂu.

3. Blower unit stalls.

To reset the thermal safety cut-out, access reset button by removing the panel

shown in Fig 6 and push the reset tab in direction of arrow.

Fig. 6

Wiring Diagram

Fig. 7

The product is supplied with a Wireless remote control, the remote control should be con-

tained in the carrier bag along with these instructions. This remote control is required to

operate the appliance. When paired with the remote control various operational modes

and features can be accessed.

IMPORTANT NOTE:

The remote control is required to operate the appliance. It is important

that the remote control remains near the appliance at all times.

Remote Control

1Display Screen

2‘Menu’ Button

3‘Back’ Button

4‘Advance’ Button

5‘Up and Down’ Arrows

6‘Enter’ Button
