Digitronic Digitaler Schaltbeschleuniger
Automationsanlagen GmbH DIGISPEEDDS1/V2
1. Introduction:
All magneticallyinfluenced switching linkse.g. magneticvalvesorrelaisundergo acertainswitching
delay. Thisdelayconsist ofthe following coefficients:
1. the time, needed to establish the magneticfield,
2. the time, needed to overcome invertia,
3. the time, needed to dismantle the magneticfield when switching off.
Toaccelerate the establishment ofthe magneticfieldand therebyto shorten the switching timeofa
switching linkduring the process off switching on, DIGISPEEDgivesan overload impulseup to
100 Voltonto the switching link'scoil.Bythisover-energizing the magneticfieldinthe coil will be
increased, whichcausesaquickerovercoming ofinvertia. During the process ofswitching of
flywheeling diodscauseadelyofthe decreasing magneticfield. It isnot possibleto renouncethemfor
reasonsofprotection againstmalfunctions.Thisincreasesthe timerequired forswitching of
essentially.DIFGISPEEDacceleratesthe dismantleling ofthe magneticfieldusing aflywheel-circleof-
26VDC and causesa decreasing switching-off time.
Result: Bytime-intervalcontrolled overload-impulsesin connection with the regulationofthe flywheel-
voltage to -56VDC the DIGISOFTcausesmagneticallyinfluenced switching linksto work
with tenth the speed.
2. Attributes:
* Microprocessorcontrolled perfomance-electricityforan excact reproducible switching behaviour.
*Version with two channels
*short circuit resistant
* two aditionalinputsforparametering the overload impulse
*LED Statusdisplayforin-and outputs
*Short recoverytimesforthe overload-impulse
*high overenergizing voltage ofup to 100VDC fora quickswiching on
* high flywheel-voltage of-56VDC forquickswitching off
*galvanicalsepartion ofthe inputs
*forswitching devicesup to 2 x24 Watt appropriated (2 x1 Ampere costantcurrent)
* 24VDC ±20%Powersupplywithout aditionalexternalpower.
*30mm lankcase made ofThermoplast-synthetics.
*Case with comfortable snap-on assembling.
*Simple adjusting ofthe casesin a row
Ausgabe: August 04 Seite: 4
