DL-HD70LS Quick Install Guide

Important noce:

• Do not aempt to disassemble or alter the housing. There are no user-serviceable parts

inside the unit. Doing so will void your warranty.

• To minimize the possibility of equipment damage from electrostac discharge (ESD), all source and desnaon

equipment must be powered o during installaon.

• Do not connect the device to a telecommunicaon outlet wired to unrelated equipment. Doing so may

damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through (point-

to-point).

• Allow proper venlaon to reduce the risk of thermal failure.

This guide is for quick installaon only.

For complete owners manual go to www.libav.com or use a QR reader to access the

manual via QR code below.

Scan QR Code with your Smart-phone or Tablet

The DigitaLinx DL-HD70LS extender set transmits HDMI (1080p, 4Kx2K (UHD/HDR) & 3D), including

HDCP 2.2, and bidireconal IR up to 70 meters away using a single solid core, shielded Category 6 twisted

pair cable.

Built-in surge protecon helps ensure hassle-free and robust installaons. The 12 volt power supply is

secured with a screw-on connector to prevent the power from being accidentally disconnected.

The DL-HD70LS is sold only as a set. The individual transmier and receiver are not compable with

other HDBaseT devices due to proprietary PoE circuitry.

Product Overview

Package Contents

• DL-HD70LS Transmier and Receiver Set

• (1) Quick Install Guide

• (1) IR Receiver (Eye)

• (1) IR Transmier (Emier)

• (1) DC12v US Power Supply with four adapter plugs (US, EU, AU, UK)

• (4) Mounng Brackets with screws

• (8) Rubber feet

Transmier View

1 2

4 5 6

HDMI INPUT SIDE TWISTED PAIR OUTPUT SIDE

1. HDMI IN

•HDMI input port for connecons to video sources

2. IR IN

•3.5mm IR input port for connecon to IR receiver or IR system

3. IR OUT

•3.5mm IR input port for connecon to IR receiver or IR system

4. Power Indicator

•Indicates power for transmier

5. 12V DC

•Locking power port, connect DC12V power adapter (either power port can power enre set)

6. Twisted Pair Output with Link and HDCP Status Indicators

•RJ45 HDBaseT connecon. Connect Cat6 cable to receiver

LED States

Solid Link - Link established between transmier and receiver

Flashing HDCP - HDMI signal is not encrypted

Solid HDCP - HDMI signal is encrypted

Receiver View

1 2

4 5 6

HDMI OUTPUT SIDE TWISTED PAIR INPUT SIDE

1. HDMI OUT

•HDMI output port for connecons to display devices

2. IR IN

•3.5mm IR input port for connecon to IR receiver or IR system

3. IR OUT

•3.5mm IR input port for connecon to IR receiver or IR system

4. Power Indicator

•Indicates power for transmier

5. 12V DC

•Locking power port, connect DC12V power adapter (either power port can power enre set)

6. Twisted Pair Input with Link and HDCP Status Indicators

•RJ45 HDBaseT connecon. Connect Cat6 cable to transmier

LED States

Solid Link - Link established between transmier and receiver

Flashing HDCP - HDMI signal is not encrypted

Solid HDCP - HDMI signal is encrypted

1. Verify all components included with the extender set are present before

installaon.

2. If the extenders are going to be permanently mounted to a surface, aach the

included mounng brackets with the supplied screws.

3. Turn o power and disconnect the audio/video equipment by following the

manufacturer’s instrucons.

4. Connect Category 6 or greater twisted pair cable with RJ45 connectors between

the transmier (DL-HD70LS-TX) and the receiver (DL-HD70LS-RX). TIA/EIA-568B

straight-through wiring connecons must be used with all HDBaseT extenders.

5. Connect an HDMI cable and any desired control accessories between the

display and the receiver (DL-HD70LS-RX).

6. Connect an HDMI cable and any desired control accessories between the source

and the transmier (DL-HD70LS-TX).

7. Connect the included power supply to the transmier or receiver and lock the

power supply to the power connector by twisng the locking collar clockwise.

8. Power on aached audio/video devices.

Connecvity Instrucons

Passing IR Signals:

The DL-HD70LS is capable of passing IR signals between 33 and 55 KHz. To

prevent damage to any of the electronics, the extenders should be powered

o while inserng or removing any IR components. Inserng an IR transmier

into the IR IN port may damage the IR circuit for that extender.

IR OUT: The IR transmier (IR emier) must be plugged into the IR OUT port.

IR IN: The IR receiver (IR eye) must be plugged into the IR IN port.

To pass 3rd party IR system signals through the DL-HD70LS, such as a control

system, connect the TS connector of the IR-AC coupling cable (provided) to

the IR output port of the control system and connect the TRS connector of the

IR-AC cable to the IR IN to either transmier or receiver of the DL-HD70LS

To control system / 3rd party IR output

To Extender IR IN on either TX or RX

TIA/EIA-568B

Orange/White

Orange

Green/White

Blue

Blue/White

Green

Brown/White

Brown

Pin 1

Pin 2

Pin 3

Pin 4

Pin 5

Pin 6

Pin 7

Pin 8

1 8 Twisted Pair Wiring

Use TIA/EIA-568B wiring for Category 6

connecon between send and receive

units.

Cabling Requirements

HDBaseT Cabling

To ensure proper performance of the DL-HD70LS, it is recommended that you use solid core,

shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may perform well but

may not support power over HDBaseT reliably.

For opmized HDBaseT performance use the following Liberty Wire and Cable branded

cabling;

Category 6 plenum; 24-4P-P-L6SH

Category 6A plenum; 24-4P-P-L6ASH

Category 6 NON-plenum; 24-4P-L6SH

Category 6A NON -plenum; 24-4P-L6ASH

When using shielded category cabling A LWAY S ...

....use shielded connectors

....properly ground the category cable

REV 171211

Intelix

11675 Ridgeline Drive

Colorado Springs, CO 80918

800-530-8998

supportlibav@libav.com

Technical Specicaons

Supported Audio and Video

Maximum Video Compability 70 m: Deep Color 36/30/24 Bit at 1080p

40 m: Deep Color 48 Bit at 1080p, 3D, and 4k x 2k (UHD)

Video Compliance HDMI, HDCP, and CEC (Consumer Electronics Control)

Embedded Audio Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio

IR Carrier Frequency Range 33-55kHz at 5 volts

HDBaseT Signal Characteriscs

Maximum Distance 70 m

Cable Requirements Solid core shielded Category 5e, Category 6 or greater with TIA/EIA-568B

crimp paern

Bandwidth 10.2 Gbps

Chassis and Environmental

Dimensions (H x W x D) 18 mm x 120 mm x 74 mm (0.71 in x 4.72 in x 2.91 in)

Operang Temperature (Environment) 0° to +40° C (+32° to +104° F)

Operang Temperature (Chassis) 31° C (88° F) (S); 38° C (100° F) (R)

Operang Humidity (Environment) 20% to 90%, Non-condensing

Power

Maximum Power Consumpon 12 was

Power Supply Input Voltage 100-240V AC at 50-60 Hz

Power Supply Output Voltage 12V DC

Regulatory CE, RoHS

Other

Standard Warranty 2 Years

Included Items Quick Guide, Power Supply, Adapter Plugs (US, EU, AU, UK), Mounng

Brackets (4 ea), Mounng Screws (4 ea), (8) Rubber Feet, (1) IR Emier, (1)

IR Receiver

IR Transmier DIGIB-EMT

IR Receiver DIGIB-EYE, IR-AC

Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF

and electrical interference, and cable patches.

Thank you for your purchase.

For Technical Support please call our toll free number at

800-530-8898 or email us at supportlibav@libav.com

www.intelix.com

www.libav.com

is a brand of:

11675 Ridgeline Drive

Colorado Springs, Colorado

80921 USA

Phone: 719-260-0061

Fax: 719-260-0075

Toll-Free: 800-530-8998
