Digital Watchdog D2362DIR Manuel utilisateur

5436 W Crenshaw St. Tampa, FL 33634

Tel: 866-446-3595 / 813-888-9555

Fax: 813-888-9262

www.Digital-Watchdog.com

[email protected]

Technical Support Hours: Monday-Friday

8:30am to 8:00pm Eastern Time

Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for future reference.

ABOUT MANUAL

01302012

User Manual

D2362DIR, D2363D, D2363TIR

D2367WD, D2367WTIR

D2382TIR, D2365T

Indoor Dome Camera

■ Do not open or modify.

■ Do not open the case except during maintenance and installation,

for it may be dangerous and can cause damages.

■ Do not put objects into the unit.

■

Keep metal objects and ammable substances from entering the camera. It can cause re, short- circuits,

or other damages.

■ Be careful when handling the unit.

■To prevent damages, do not drop the camera or subject it to shock or vibration.

■Do not install near electric or magnetic elds.

■Protect from humidity and dust.

■Protect from high temperature.

■

Be careful when installing near the ceiling of a kitchen or a boiler room, as the temperature may rise to

high levels.

■Cleaning

■To remove dirt from the case, moisten a soft cloth with a soft detergent solution and wipe.

■Mounting Surface

■The material of the mounting surface must be strong enough to support the camera.

PRECAUTIONS

Before sending your camera for repair, check the following or contact our technical specialist.

No VIDEO

Check the coaxial cable and make sure it is connected securely.

Check the lens’iris adjustment at the menu setup of the camera.

Check the power supply and make sure the camera has the proper voltage and current.

Out-of-Focus VIDEO

Check the clear dome cover and the lens for dirt or ngerprints. Use a soft cloth and gently clean.

Check the lens manual focal and zoom adjustment. Field test monitor is recommended.

TROUBSHOOTING

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC rules. These limits are designed to Provide reasonable protection against harmful

interference .when the equipment is operated in a residential environment.This equipment generates, uses,

and radiates radio frequency energy; and if it is not installed and used in accordance with the instruction

manual, it may cause harmful interference to radio communications.

WARNING :Changes or modications are not expressly approved by the manufacture.

FCC COMPLIANCE

■1/3”High Resolution CCD

■540 TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■100ft Range IR with Intelligent Camera Sync

■Electronic Day and Night

■DRC (Dynamic Range Compressor)

■HME (Highlight Masking Exposure)

■SLC (Side Light Compensation)

■AGC / BLC / AWB

■Negative Imaging

■Mirror Image Control

■RS485 Built-In

■Programmable Privacy Zone (4) & Motion Detection

■Easy Icon Driven OSD Menu with Built-In Joystick

■Secondary Video-BNC Output

■1/3”High Resolution CCD

■High Resolution 560 TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■Electronic Day and Night

■Star-Light (Super Low LightTechnology)

■DRC (Dynamic Range Compressor)

■3D-DNR (3D Digital Noise Reduction)

■HME (Highlight Masking Exposure)

■Negative Imaging

■AGC / BLC / AWB

■Programmable Privacy Zone (6) & Motion Detection

■Easy Icon Driven OSD Menu with Built-In Joystick

■Auto Sensing 12VDC or 24VAC with Line Lock

■Secondary Video-BNC Output

FEATURES*-D2362DIR FEATURES*-D2363D

■1/3”High Resolution CCD

■High Resolution 560 TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■Electronic Day and Night

■100ft Range IR with Intelligent Camera Sync

■True Day and Night / TDN5

■Star-Light (Super Low LightTechnology)

■DRC (Dynamic Range Compressor)

■3D-DNR (3D Digital Noise Reduction)

■HME (Highlight Masking Exposure)

■Negative Imaging

■AGC / BLC / AWB

■Programmable Privacy Zone (6) & Motion Detection

■Easy Icon Driven OSD Menu with Built-In Joystick

■Auto Sensing 12VDC or 24VAC with Line Lock

■Secondary Video-BNC Output

FEATURES*-D2363TIR FEATURES*-D2367WD

■1/3”Sony Super HAD II CCD

■560 TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■Electronic Day and Night

■EWDR (Electronic Wide Dynamic Range)

■Star-Light (Super Low LightTechnology)

■DSS (Digital Slow Shutter)

■3D-DNR (3D Digital Noise Reduction)

■DIS (Digital Image Stabilizer)

■HME (Highlight Masking Exposure)

■AGC / BLC / AWB

■Programmable Privacy Zone (6) & Motion Detection

■Easy Icon Driven OSD Menu with Built-in Joystick

■Auto Sensing 12VDC/24VAC with Line Lock

■Secondary Video-BNC Output

FEATURES*-D2367WTIR

■1/3”Sony Super HAD II CCD

■560 TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■100ft Range IR with Intelligent Camera Sync

■True Day and Night / TDN5

■EWDR (Electronic Wide Dynamic Range)

■Star-Light (Super Low LightTechnology)

■DSS (Digital Slow Shutter)

■3D-DNR (3D Digital Noise Reduction)

■DIS (Digital Image Stabilizer)

■HME (Highlight Masking Exposure)

■AGC / BLC / AWB

■Programmable Privacy Zone (6) & Motion Detection

■Easy Icon Driven OSD Menu with Built-in Joystick

■Auto Sensing 12VDC/24VAC with Line Lock

■Secondary Video-BNC Output

FEATURES*-D2382TIR

■1/3”Sony Super HAD II CCD

■High Resolution 560TV Lines

■OMNI-Focus 2.9~8.5mm 3X Motorized Zoom, Auto Iris 70ft Range IR with Intelligent Camera Sync

■True Day & Night / TDN5 (Electro Magnetic Mechanism)

■Max-DR (Electronic Wide Dynamic Range)

Enables the camera to capture perfect images in both bright and dark environments simultaneously.

■3D-DNR (3D Digital Noise Reduction)

Produces less noise and more color during low-light application.

■HME (Highlight Mask Exposure)

Masks overly exposed light to produce a true video image of any environment.

■SLC (Side Light Compensation)

■DIS (Digital Image Stabilizer)

■Programmable Privacy Zone (6) & Motion Detection Easy Icon Driven OSD Menu with Built-In Joystick

■Auto Sensing 12VDC or 24VAC with Line Lock

■No Fog or Condensation under AnyWeather Condition

DIMENSION (mm)*

109.6

103.1

41.3

6.5



145

117.0

125.0



5.0



4.5

91.0

85.0

L= 300mm

RS485 (Black+ & White -)

VIDEO(yellow)

BNC JACK

DC 12V or AC24V

5mm TWIST SOLDERING

RED

BLACK

FEATURES*-D2365T

1110

■1/3" Pixim Seawolf CMOS Sensor

■690 Horizontal TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■TDN (True Day and Night/IR Cut Filter)

■3D-DNR (3D Digital Noise Reduction)

■Powerful Wide Dynamic Range

■Smear Canceling Circuit

■AGC / BLC / AWB

■DIS (Digital Image Stabilizer)

■HME (Highlight Masking Exposure)

■AGC / BLC / AWB

■Programmable Privacy Zone (6) & Motion Detection

■Easy Icon Driven OSD Menu with Built-in Joystick

■Low Power Consumption

■Auto Sensing 24VAC/12VDC with Line Lock

■Secondary Video-BNC Output

1312

Power Requirement *

Power Wire Maximum Distance

Wire Gauge 12VDC 24VAC

24 AWG 80feet 323feet

22 AWG 128feet 513feet

20 AWG 203feet 815feet

18 AWG 323feet 1295feet

16 AWG 514feet 2056feet

14 AWG 816feet 3264feet

12 AWG 1295feet 5183feet

10 AWG 2057feet 8228feet

Coaxial Cable Type Maximum Distance

RG59/U 750feet

RG6/U 1,000feet

RG11/U 1,500feet

Power Requirement

12VDC at 1A

24VAC at 500mA

INSTALLATION*

Included with Digital Watchdog Camera:

1. User Manual

2. Mounting Template

3. Security L-Key

4. Single Sided Hex Key

5. Secondary BNC Cable for a Field Monitor

6. Four (4) Screws and Four (4) Dry Wall

Anchors

Camera Installation

Use the Mounting Template when mounting the camera.

Use the Security L-Key to loosen the Four Screws that secure the vandal-proof dome cover.

Remove the cover; then, remove the inner screw holes to mount the camera.

NOTE: Keep the lens and the vandal proof cover free from dust or ngerprint.

INSTALLATION*

A. Loosen the Screws (A) with the Security L-Key

included with your camera.

B. Separate the Upper Case (B) from the Base (F).

C. Cut a hole in the ceiling for routing the cables.

D. Use the Mounting Template to drill the four

screw holes on the surface of the ceiling.

E. Pass the Power Cable (C) and the Video Cable (E)

from the camera unit through the hole in the

ceiling.

F. Align the screw holes of the camera unit with

the holes in the ceiling. Secure the four screws.

G. Install and adjust the camera unit.

H. Assemble the Upper Case (B) and the Baes (F).

I. Put the upper case and the base together.

J. Tighten the outer Screws (A) using the Security

L-Key.

INSTALLATION AND ADJUSTMENT*-D2382TIR

Included with DW Indoor Dome Camera:

1. User Manual

2. Mounting Template

3. One Security L-Key

4. One Single Sided Hex Key

5. Secondary BNC Cable for a Field Monitor

6. Two (2) Screws andTwo (2) Dry Wall

Anchors

7. IR Remote Controller

Camera Installation

Use the mounting template to mount the camera.

Using the security L-key to loosen the four screws that secure

the vandal proof dome cover, Remove the vandal proof dome

cover to access the screw holes to mount the camera.

NOTE: Keep the lens and the vandal proof cover free from dust

or ngerprint.

3-Axis Gimbal Adjustment

1514

CONNECTION*

Video Output BNC Cable

Main Monitor

Field Test Monitor

Spot Monitor Cable

DC12V / AC24V

CAMERA OSD & IR REMOTE CONTROLLER*

NOTE:

Press [KEY] + [ID] (Default is “001”for ID=1)

Press [ENT] to access the Menu

Note: The camera ID is a 3-digitnumber.

Key Button

Menu Access and Control

Zoom Function Control

ID Buttons

Motion Alarm On &OFF

Field Test Monitor Video Output

RS485 Connector

Dip Switch for the IR Remote Controller

Mini Joystick for the Menu Setup

LEFT

UP DOWN

RIGHT

-D2382TIR

1716

1918

LENS ADJUSTMENT*

A. Move the Zoom Lever until you get the desired position.

B. Move the Focus Lever until you get the desired focus.

A. Zoom Lever

B.Focus Lever

: D2362DIR, D2363D, D2363TIR, D2367WD, D2367WTIR, D2382TIR, D2365T

CAMERA SETTING & ON-SCREEN DISPLAY*

Field Test Monitor Video Output

RS485 Connector

Dip Switch for the IR Remote Controller

Mini Joystick for the Menu Setup

LEFT

UP DOWN

RIGHT

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Digital Watchdog Caméra de sécurité

Digital Watchdog

Digital Watchdog Megapix DWC-MV72I4V Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGAPIX DWC-MT95Wi36TW Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MV84WiA Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MB44WiA Manuel utilisateur

Digital Watchdog

Digital Watchdog V2262D Series Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DW-MV82WiA Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MVT4Wi28 Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light DWC-B6263TIR Manuel utilisateur

Digital Watchdog

Digital Watchdog STAR-LIGHT Universal HD over Coax... Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-light Plus DWC-B6883WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-B6853WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-MB44iALPR Manuel utilisateur

Digital Watchdog

Digital Watchdog STAR-LIGHT DWC-B7753TIR Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGAPIX DWC-MV95WiATW Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-D362D Manuel utilisateur

Digital Watchdog

Digital Watchdog MegaPix Pano DWC-PVF5M1TIRC6 Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MPA20M Manuel utilisateur

Digital Watchdog

Digital Watchdog B2372TIR Manuel utilisateur

Digital Watchdog

Digital Watchdog STAR-LIGHT PLUS DWC-D3853WTIRW Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-V1CMW Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-MVH2I4WV Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MB82i4V Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MPVA5WiAT Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGAPIX DWC-MT94WI36T Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
