Upgrade Instructions

Part Number: EK–DS513–UP. A01

DECstation 5000

Model 1xx to DEC

3000 Model 300 AXP

MLO-010693

Can Cannot

Upgrade Upgrade

Drives: RZ23L, RZ24L RZ57

RZ24, RZ25 RX23

RZ26 RX33

RZ55 (e) TK50Z

RZ56 (e) RRD40

RZ58 (e) RW100

RRD42 (t)

TLZ04 (e)

TLZ06 (t)

TKZ081(e)

TKZ091(e)

TSZ071(e)

TZK101(e)

TZ30 (e)

Expansion

Boxes: PMTcE**

SZ03

SZ12

SZ16

Input

Devices: VSXXX-AA/AB LK501

VSXXX-GA/GB VSXXX-BB

VSXXX-FA/JA

VSXXX-XX

VSX10-AA/A3*

VSX20-AA/A3*

VSX30-AA/A3*

(e) Supported in external device only.

(t) Supported in external device including tabletop.

1Support planned.

*DEC Open3D required for software support.

**Minimum revision of host module must be D03.

Options You Can Upgrade

Can Cannot

Upgrade Upgrade

Graphics

Modules: PMAGB-BA/BB PMAG-AA/AB

PMAGB-BC/BD PMAG-DA/DB

PMAGB-JA/JB AV10U-AA/DA

PMAG-GB/HA PMAG-EA/EB

PMAGB-BE/BF PMAG-FA/FB

PMAGB-DA/DB* PMAGB-ED/EC

PMAGB-EA/EB* PMAGB-DC/DD

PMAGB-FA/FB2PMAG-CA/CB

PMAG-JA/JB

PMAG-BA/BB

Memory: None

Monitors: VR319-DxVR262-Ax

VR320-DxVR290-Dx

VRC16-Cx/HxVR297-Dx

VRM17-Ax/HxVR299-Dx

VRT16-HxVRT19-Dx

VRT19-HxVR319-Cx

VR320-Cx

VRT16-Dx

VRT13

TURBO-

channel

Devices: DEFZA-AA1DEFZA-CA

PMAD-AA/AB DSYT1-AB

PMAZ-AA/AB

Options You Can Upgrade

*DEC Open3D required for software support.

1Support planned.

2DEC Open3D and PMTcE required for support.

x=variable model number

Your shipment should contain the following

two kits:

Check the Components Shipped

Monitor

Video Cable

Antistatic

Wrist Strap

Monitor

Power Cord

System Power

Cord

Screwdriver

System Unit

Documentation

Modem Loopback

Connector

10BASE-T Loopback

Connector

SCSI

Terminator

Universal

Strain Relief

Strap

Keyboard/Mouse

Extension Cable

System Kit:

Accessory Kit:

MLO-010839

Network

Cable

Screws (8)

Mounting

Brackets (2)

xxxxxxx

xxxxxxxxxxx

xxx

Upgrade

Card

Return

Address

Label

Mouse

with Mousepad

Keyboard

External

SCSI Cable

If your DEC 3000 system has a factory-

installed drive, you may need to change the

SCSI ID setting on the drive you upgrade.

To display the SCSI ID settings of the drives

in your DECstation system:

1. Enter the following command to shut

down the software and put the system in

console mode: shutdown -h now

2. Enter the cnfg 3 command at the

console prompt (>>). A screen similar to

the following displays:

This example display shows an RZ24 drive

set to SCSI ID 2 and an RRD42 drive set to

SCSI ID 5.

Write down your system drive names and

SCSI ID settings here:

Record Your System SCSI IDs

>>cnfg 3

3: KN02 DEC Vn.n TCF0 (8 MB)

(enet: 08-00-2b-30-14-df)

(SCSI = 7)

----------------------------------------------

DEV PID VID REV SCSI ID

==============================================

rz2 RZ24 (C) DEC DEC 0700 DIR

rz5 RRD42 (C) DEC DEC 0700 CD-ROM

1. Turn off the DECstation system by

pressing O on the on/off switch on the

back of the system unit. Wait 15 seconds

for the monitor to discharge.

2. Disconnect all the cables from the back

of the system unit.

3. Loosen the cover-release screw on the

back of the system unit. This captive

screw can be loosened but not removed.

4. Grasp each side of the cover with your

hands, and pull the cover straight toward

the front about 2 inches (5.5 cm). Pull

the cover up and set it aside.

CAUTION: To avoid damage from static

discharge, always wear an antistatic wrist

strap when working inside the system unit.

Turn Off/Open the DECstation

PMAG-C

V~100-120 A 3.0

V~220-240 A 1.7

V~100-120/220-240

A 7.9/4.2

Hz 50-60

W 359

MLO-010006

Captive

Screw

1. Loosen the two captive screws that hold

the front drive panel in place.

2. Loosen the two captive screws on the

back of the drive bracket.

3. If there is a drive inside the bracket, dis-

connect the SCSI and power cables from

the drive.

4. Pull up carefully from the back of the

drive bracket. As you raise the end of the

bracket, you can pull the disconnected

ends of the cables through the cutout in

the bracket.

5. Release the cables from the cable clamps

on the inside of the front panel.

6. Set the front panel aside. Handle it

carefully if it contains a drive.

Remove the Front Drive Panel

MLO-010666

Captive

Screws

Captive

Screws

1. Press down on the disk drive and unlock

the sliding latch.

2. Lift the drive off the mounting post and

out of the chassis cutouts.

3. Unplug the power cable and SCSI cable

from the drive. Pull on the SCSI cable

connector flap to remove the connector.

4. Set the drives aside on an antistatic mat.

5. Put all the disconnected ends of the

cables back into the system unit.

Remove Fixed Disk Drives

MLO-010667

Note: TURBOchannel options can be up-

graded to the DEC 3000 Model 300 only.

TURBOchannel option modules and graphic

option modules can be single, double, or

triple width.

1. Remove the option slot screws and

the support post screws.

2. Release the module from the system

connector and lift the module out of the

option slot opening.

Remove Option Modules

Support

Post Screws Option

Slot Screws

MLO-010664

System

Connector

MLO-010663

Note: Remove all drive mounting brackets

by removing the four screws that secure the

drive to the mounting bracket.

If your DEC 3000 system has a factory-

installed disk drive, it is set to SCSI ID 3.

Check the SCSI ID settings you noted ear-

lier. If one of the drives you are upgrading

is also set to SCSI ID 3, change the setting.

The SCSI ID settings for drives not shown

here can be found in the DEC 3000 Model

300/300L AXP Hardware Reference Guide.

RZ23L Drive:

Set the SCSI IDs on the Drives

MLO-010587

SCSI

Settings:

E2 E1
