Digital Blue Disney Mix Max 512MB Manuel utilisateur
TABLE OF CONTENTS
1
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 2
FCC Declaration . . . . . . . . . . . . . . . . . . . . . . 3
EIA Guidelines. . . . . . . . . . . . . . . . . . . . . . . . 4
Location of Controls . . . . . . . . . . . . . . . . . . . 6
Charging the Battery . . . . . . . . . . . . . . . . . . . 7
Attaching the Wrist Strap . . . . . . . . . . . . . . . 8
Installing the Mix It Plug-In . . . . . . . . . . . . . . 9
Using the Mix It Plug-In. . . . . . . . . . . . . . . . 11
Installing the Windows 98 Driver. . . . . . . . . 13
Downloading & Transferring Files. . . . . . . . 16
Safely Remove Hardware . . . . . . . . . . . . . . 20
General Operation...................21
• Turning the Power On/Off. . . . . . . . . . . . 21
• Menu Button . . . . . . . . . . . . . . . . . . . . . . 21
• Inserting/Removing an External
Memory Card . . . . . . . . . . . . . . . . . . . . . 21
•HeadphonesJack..................22
• Volume Buttons . . . . . . . . . . . . . . . . . . . 22
•HoldSwitch.......................22
Operation–Music Playback Mode ......23
• To Listen to MP3s/WMAs. . . . . . . . . . . . 23
• High-Speed Music Search/Step . . . . . . . 24
•Forward/Reverse Skip . . . . . . . . . . . . . . 24
Operation–Video Playback Mode.......25
• To Watch Videos. . . . . . . . . . . . . . . . . . . 25
• High-Speed Video Search . . . . . . . . . . . 26
• Forward/Reverse Skip . . . . . . . . . . . . . . 26
• Pause Mode . . . . . . . . . . . . . . . . . . . . . . 27
Operation–Picture Playback Mode .....28
• To View Pictures. . . . . . . . . . . . . . . . . . . 28
• Thumbnail View . . . . . . . . . . . . . . . . . . . 29
• Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Settings Menu ......................30
• Setting the Brightness . . . . . . . . . . . . . . 30
• Setting the Backlight. . . . . . . . . . . . . . . . 31
• Setting the Power Savings . . . . . . . . . . . 32
• Setting the Equalizer . . . . . . . . . . . . . . . 33
•Setting the Audio Play Mode (Repeat). . 34
• Setting the Slideshow Interval . . . . . . . . 35
• Setting the Time Format. . . . . . . . . . . . . 36
• Setting the Time . . . . . . . . . . . . . . . . . . . 37
• To View the System Info. . . . . . . . . . . . . 38
Using the Mix It Feature ..............39
•Now Playing and Clearing a Playlist . . . 42
• Mix It FAQs. . . . . . . . . . . . . . . . . . . . . . . 43
Troubleshooting Guide...............44
Formatting the Player ................45
Resetting the Unit ...................46
Specifications ......................47
Welcome to Your Mix Max with Mix It Feature!
The Mix It button on your Mix Max offers an exciting, new way to enjoy your music! With just one
touch, your music instantly becomes more usable and fun, allowing you to make mixes on the
device itself, wherever and whenever you want!
Mix It makes it simple. Pick one song. Click one button. Get an amazing playlist that includes
perfect tracks from every corner of your collection—instantly. Mix It scan and Mix It instant playlist
functions will change the way you listen to music!
Refer to the Table of Contents above to learn where to find all of the instructions regarding the
Mix It feature in this owner’s manual.
COPYRIGHT:
• Distributing copies of MP3, WMA, WMA with DRM tracks and/or WMV files without
permission is a violation of international copyright laws.
SAFETY:
• Vibration experienced during walking or exercising will not affect the player.
However, dropping the player or dropping a heavy object on the player may result
in damage or sound distortion.
• Avoid spilling any liquid onto or into the player.
• Do not leave the player in a location near heat sources; in a location subject to direct
sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel
surface; or in a car with the windows closed during periods of excessive heat.
ROAD SAFETY:
• Do not use headphones while driving, cycling or operating any motorized vehicle. It
may create a traffic hazard and it is illegal in some areas. It can be potentially
dangerous to play your headset at a high volume while walking, especially at
pedestrian crossings. You should exercise extreme caution or discontinue use in
potentially hazardous situations.
FCC WARNING:
• This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual. The user could
lose the authority to operate this equipment if an unauthorized change or
modification is made.
PRECAUTIONS
2
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.
3
FCC DECLARATION
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: 1) This device may not cause harmful interference, and 2) This device must
accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shield cable must be used with this unit to ensure
compliance with class B FCC limits.
Dear Customer:
Selecting fine audio and video equipment such as the unit you’ve just purchased is
only the start of your musical enjoyment. Now it’s time to consider how you can
maximize the fun and excitement your equipment offers. This manufacturer and the
Electronic Industries Association’s Consumer Electronics Group want you to get the
most out of your equipment by playing it at a safe level. One that lets the sound come
through loud and clear without annoying blaring or distortion and, most importantly,
without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. So what sounds “normal” can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s Consumer Electronics Group
recommend you avoid prolonged exposure to excessive noise. This list of sound levels
is included for your protection.
4
Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
5
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You
LOCATION OF CONTROLS
6
1. Display
2. Strap Holder
3. Menu Button
4. Mix It Button
5. Navigation/Skip Up Button
6. Enter/Play/Pause ®p Button
7. Navigation/Search Right l
Button
8. SD/MMC Memory Card Slot
(under cover)
9. Navigation/Skip Down Button
10. Navigation/Search Left m
Button
11. Reset Button (bottom of unit)
12. USB Jack (under cover)
(bottom of unit)
13. Headphones Jack
(bottom of unit)
14. Volume Up Button
15. Volume Down/Mute Button
16. Power Button
17. Hold Switch
Front
Top
CHARGING THE BATTERY
7
This unit has a built-in Lithium Polymer rechargeable battery. When the bars
in the battery indicator (in the display) become low (see Figure 1), and
especially when the bars turn red (indicating a charge of 10% or less),
recharge the battery as follows.
1. Remove the USB jack cover and connect the USB cable to
this unit (as shown) and to the USB port on your computer;
the USB symbol will appear on the screen (as shown).
When charging, the battery indicator will flash between
empty and the current charge. Once the battery is fully
charged, the indicator will stop flashing.
If the Mix Max is OFF and being charged by the DDS8012,
DAC8001-USB or DAC8002-USB (all sold separately), the
screen will show an animated “Charging Battery” icon. Once the battery is fully charged,
the screen will show “Battery Full”.
NOTES:
• To disconnect this unit from your computer, make sure to follow the “Safely Remove
Hardware” instructions on page 20.
•It takes approx. three hours to charge the battery from empty to full. When fully charged,
the unit can playback for approx. 18 hours in Music Playback mode or approx. 2 hours
in Video Playback mode. (Actual playback times may vary.)
• For data transfer, please use the USB cable (included) or the model DDS8012 stereo
speaker (sold separately) to connect the Mix Max to your computer.
• If a computer with a USB port is not available, the Mix Max can be charged with the
model DAC8001-USB AC converter, DAC8002-USB AC converter or the DDS8012
stereo speaker (all sold separately). Refer to the instructions accompanying those
models for more information.
•"Low Battery Please Recharge" will appear in the display when the battery is empty.
Figure 1
ATTACHING THE WRIST STRAP
8
1
Insert the wrist strap through the rope’s loop
until snug.
2
See above for appearance of the wrist strap
when it is properly attached to the unit.
3
Insert the rope through the hole in the main
unit.
To install the Mix It Plug-In, your computer must
have Windows XP, Windows Media Player 10 (for
Windows Media Player 10, visit
www.windowsmediaplayer.com) and an Internet
connection.
Procedure to Install the Mix It Plug-In:
1. Insert the installation CD-Rom into the CD
Drive, then the installation screen will appear.
If the installation screen doesn't automatically
appear,double-click My Computer then
double-click on the CD drive, then the
installation screen will appear. Click “Install
Mix It Plug-In”.
2. At the first pop-up screen, click “Save” to save
“disneymixitplugin.msi” onto your computer.
Save in a convenient location, such as on your
Desktop.
3. Double-click on the “disneymixitplugin” icon
on your Desktop (if saved there) and the Setup
Wizard will appear. Click “Next”.
INSTALLING THE MIX IT PLUG-IN
9
10
INSTALLING THE MIX IT PLUG-IN (CONTINUED)
4. The “Select Installation Folder” screen will
appear. It is recommended to keep the folder
as is. On this screen, you can also authorize
just yourself or anyone using your computer to
use the Mix It Plug-In. Then click “Next”.
5. At the “Confirm Installation” screen, click
“Next” to start the installation.
A pop-up screen will appear during the
installation called “Disney Mix It Plug-In
Shortcuts”. Select (check) “Create a desktop
icon” or “Create a Quick Launch icon”, as
desired, and then click “OK”.
(You can double-click the desktop icon or go to
the bottom of the Windows and click "Start" c
"All Programs" c"Disney" c"Disney Mix It
Plug-in" c"Disney Mix It Plug-in" to activate
the Mix It Plug-In program if you checked, as
described above.)
6. When successfully completed, the “Installation
Complete” screen will appear. Click “Close” to
exit the Setup Wizard.
For more information on using the Mix It Plug-In,
refer to the “MusicIP Windows Media Player Plug-
In.chm” document located in "C:\Program
Files\Disney\Disney Mix It Plug-in\" (if you did not
change the folder in Step 4).
Autres manuels pour Disney Mix Max 512MB
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Digital Blue Lecteur MP3
Manuels Lecteur MP3 populaires d'autres marques
Blaupunkt
Blaupunkt Compact Drive MP3 Manuel utilisateur
Memorex
Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur
Meizu Electronic Technology
Meizu Electronic Technology E5 Manuel utilisateur
Naxa
Naxa NMV-173NX Manuel utilisateur
Philips
Philips PSA250 Manuel utilisateur
Zipy
Zipy go! Waving Manuel utilisateur
