DIG LEIT 4000 Series Manuel utilisateur

LEIT®4000

Ambient Light Powered

Irrigation Controllers

Instruction Manual

INSTRUCTION MANUAL

TABLE OF CONTENTS

A. Introduction ………………………………………………………………………… 1

B. About the LEIT 4000 Controller ……………………………………………………… 1

C. Technical Assistance ………………………………………………………………… 1

D. Copyright and Compliance …………………………………………………………… 1

E. Features …………………………………………………………………………… 1

1. System …………………………………………………………………………………… 2

1.1 Models available …………………………………………………………………… 2

1.2 Parts identification ………………………………………………………………… 2

1.3 USB updater ……………………………………………………………………… 2

1.4 Required system components ……………………………………………………… 3

1.5 Tools and supply requirements ……………………………………………………… 4

2. Installation ……………………………………………………………………………… 4

2.1 Valve installation model 160HE-XXX (2-WAY) ………………………………………… 4

2.2 LEMA Solenoid actuator installation model 1600HE (2-WAY) ………………………… 4

2.3 Wire installation and distance ……………………………………………………… 5

2.4 Controller installation ……………………………………………………………… 5

3. Sensor installation………………………………………………………………………… 5

3.1 Sensor connection to unused station ………………………………………………… 6

3.2 Sensor connection if station is not available ………………………………………… 6

3.3 Compatible sensors ………………………………………………………………… 7

4. Pump or any electrical equipment installation …………………………………………… 7

4.1 RKIT installation to the MV/Pump terminal …………………………………………… 7

4.2 RKIT installation to one of the valve station terminal connectors ……………………… 7

5. Programming …………………………………………………………………………… 10

5.1 Manual run ………………………………………………………………………… 11

5.2 Rain stop/restart …………………………………………………………………… 12

5.3 Monthly budget …………………………………………………………………… 13

5.4 Check status ……………………………………………………………………… 13

5.5 Setup schedule …………………………………………………………………… 14

5.6 Setup system ……………………………………………………………………… 16

6. Troubleshooting ………………………………………………………………………… 19

6.1 LEIT key …………………………………………………………………………… 19

6.2 LEIT controller ……………………………………………………………………… 19

6.3 LEMA solenoid actuator …………………………………………………………… 19

6.4 Hydraulic valves …………………………………………………………………… 20

6.5 Field control wires ………………………………………………………………… 20

7. Warranty ………………………………………………………………………………… 21

8. LEIT control programming quick reference chart …………………………………………… 22

9. USB Updater ……………………………………………………………………………… 24

A. INTRODUCTION

Thank you for purchasing a DIG LEIT®4000 series controller.

This manual describes how to get the LEIT 4000 controller up and running quickly. After reading this manual and

having been familiarized with the basic functionality of the controller, the manual can be used as a reference for

less common tasks in the future.

Please take the time to read through the enclosed instructions and follow them step-by-step.

B. ABOUT THE LEIT 4000 CONTROLLER

The LEIT 4000 Series Controller is an advanced ambient light powered water management irrigation controller that

uses a time tested photovoltaic module which harnesses light energy to generate electricity that is stored and used

to power the controller day and night in any kind of weather.

DIG LEIT irrigation controllers are available in two other models: LEIT X (without radio) or LEIT XRC (with radio

control capability).

The LEIT 4000 irrigation controller has an improved menu base with straightforward programming that allows

for a wide range of irrigation programs. Features include four programs with three start times per valve, manual

runs (both temporary or stored), rain delays for up to 99 days, budgeting up to 200 percent, status checks, history

reports, program setting modification, and more.

C. TECHNICAL ASSISTANCE

Should you encounter any problem(s) with this product or if you do not understand its many features, please refer

to this operating manual first. If further assistance is required, DIG offers the following customer support:

Technical Service USA

• DIG’s Technical Service Team is available to answer questions from 8:00 AM to 5:00 PM (PST) Monday-Friday

(except holidays) at 800-322-9146.

• Questions can be emailed to [email protected] or faxed to 760-727-0282.

• Specification documents and manuals are available for download at www.digcorp.com.

Customer Assistance Outside the USA

Contact your local distributor.

D. COPYRIGHT AND COMPLIANCE

& XRC, LEIT Link Master and LEIT Link Multi-Pro are each trademarks of DIG Corporation.

Patent #: 5,229,649 and 5,661,349

FCC, CE, Canada and Australia compliance

Warning: The user should make no field changes or modifications to the LEIT 4000 controller.

All adjustments and changes must be made at DIG’s facility under the specific guidelines set forth in

our manufacturing process. Any change or modification to the equipment will void the users authority

to operate the unit, and render the equipment in violation of FCC part 15 subpart C, 15.247.

Any tampering with this product will void the warranty.

E. FEATURES

• Operates 4-8 stations and a master valve or pump start without AC power hookup, batteries or conventional

solar panels

• Software in English, Spanish, Italian or French

• 4 programs with 3 start times per program

• Budgeting feature for a yearly watering schedule can be set by month

°Increase or decrease irrigation from 10-200% in 10% increments

• Review status and history reports

• Built to the highest quality control standard (ISO 9002)

°Controller functions and operations are 100% tested

°Controller waterproofing is 100% tested

• Non-volatile memory holds programs indefinitely without batteries

• All power is provided by an internal photovoltaic module and microelectronic energy management system

fueled by ambient light

°Functions day or night in all weather conditions and in most outdoor locations

• 365 day calendar with leap year

• Assign-rain, moisture or freeze sensors to an individual valve or to the entire system using

SKIT 8821-4 connector

• Manual watering by station or program

• Environmentally friendly - uses clean power

°No batteries or AC power needed

1. SYSTEM

This chapter explains the components and installation of the LEIT 4000 controller. The LEIT controller must be

installed according to the manufacturer’s recommendations; failure to do so will void the manufacturer’s warranty.

The LEIT 4000 can operate with all discontinued solenoids, such as LEMA 1500-4 and 1500S. DIG recommends all

new installations be done using the 160HE series valves and 1600HE solenoid actuator.

1.1 Models Available

1.1 The LEIT 4000 irrigation controller is available in three models:

• LEIT 4004 4 stations plus MV/Pump

• LEIT 4006 6 stations plus MV/Pump

• LEIT 4008 8 stations including MV/Pump

1.2 If you have purchased a LEIT 4004 or 4006, you have the option of connecting an additional master valve

to your controllers.

1.3 If you have purchased a LEIT 4008, you have the option to configure station 8 as a master valve when you

install a master valve on your system.

1.4 All LEIT 4000 series controllers are fitted with a wiring connector strip that has a maximum of 8 connector

ports for hot wires (stations) and 2 connector ports for common wires.

1.2 Parts Identification

qPVM – Photovoltaic module harnesses light energy and uses it to generate electricity to power the unit day

and night in any kind of weather condition.

wLCD Display – Displays the application stored in the controller.

e Programming Buttons – Use these 4 buttons to program,

modify and review the status of a LEIT 4000 controller.

r Location to insert the LEIT Key – To begin, insert the LEIT

Key to enter the LEIT controller’s programming screens (use 1,

9-volt battery). The LEIT Key is not included.

t Terminal Strip – Up to 11 terminals are available, depending on

model, to connect the valves wires, sensors via the SKIT and the

MV/P.

y USB Connection – for software updates.

LEIT Door and key – To enter the controller use the key (included) to unlock the door and remove it.

1.3 USB Updater

The LEIT 4000 is now supplied with a convenient USB port in order to keep the controller up to date

with new software versions.

If you have a laptop that is running Windows 7 you will be able to make updates in the field without removing

the controller from the pole. If your computer is running Windows Vista, XP or 2000 you will need to remove your

LEIT 4000 and bring it to a computer that has a viable internet connection. Please note that if you are removing the

controller, be sure all valve wires are marked clearly to simplify re-installation.

*At this time Apple OSX is not supported.

Step 1 With a computer that has a viable internet connection, download the LEIT 4000 USB Updater.zip file from

www.digcorp.com/LEIT-4000-software-update.

STATION 1

STATION 2

STATION 3

STATION 4

STATION 5

STATION 6

COMMON

S/N:

STATION MV/P

Step 2 After the file has completed downloading, unzip it by double clicking on file.

Step 3 Next plug the USB type B into the LEIT 4000 and the USB type A into your computer. If running Windows

7, please skip to step 5.

Step 4 For computers running Windows Vista, XP or 2000, the computer auto-detects that a device has been

connected and will ask you to install the proper drivers in order to establish a connection with the LEIT

4000 controller. Once the necessary drivers have been installed, proceed to the next step.

Step 5 Open up the unzipped 4000 USB Updater folder and double-click to run the LEIT 4000 USB Updater 1XX.

exe file.

Step 6 Follow all instructions on screen to complete the update process of your LEIT 4000 controller.

If you have any questions please call us at 1-800-322-9146 or 760-727-0914.

1.4 Required System Components

To properly install the LEIT controller, the following components will be needed:

1. Control unit: LEIT series controllers programmed with bilingual software versions SW Ver 1.23 and later EE

Ver 1.02 and later (LEIT Key not included).

2. LEIT Key: Programming tool required to enter and program the controller (uses 1, 9-volt alkaline battery).

3. Mounting column: model MCO4000 (short) 32” (81 cm) or MCO4000L (long) 48” (124

cm) steel pipe including mounting tool kit (1 screw, 1 spacing bolt, 1 hex-key 3/16”).

4. Actuator with in-line valve: each solenoid actuator comes complete with in-line

valve (160HE- 075 for 3/4”, 100 for 1”, 150 for 1-1/2” and 200 for 2”).

For drip systems, use a drip zone assembly model P52-075 that includes a

160HE-075 3/4” valve, 155 mesh screen filter and 30 PSI preset pressure regulator.

5. LEMA actuator only: (1600HE) one for each valve being used (see available

adapters for mounting on any brand name valves).

6. 7-solenoid adapters are available to fit most valves:

a. Model 30-920 use with BERMAD 200, HIT 500 and DOROT series 80, GRISWOLD 2000

and DW, BUCKNER VB series

b. Model 30-921, use with RAIN BIRD DV, DVF, PGA, PEB (3/4” and 1” only), GB, EFB-CP,

BPE, PESB (3/4” and 1” only) and ASVF series

c. Model 30-922, use with HUNTER ASV, HPV, ICV, PGV, SRV, IBV and AS VF series

d. Model 30-923, use with WEATHERMATIC 12000 and 21000 series

e. Model 30-924, use with IRRITROL 100, 200B, 205, 217B, 700, 2400, 2500, 2600 series,

TORO 220, P220

f. Model 30-925, use with SUPERIOR 950, HUNTER HBV, TORO 252 (1.5” and larger)

g. Model 30-926, use with RAINBIRD 1 1/2” and 2” PEB and PESB series

7. Optional: Model SKIT 8821-4 connector: if any sensors are used, an

SKIT 8821-4 adapter is required.

8. Optional: Model RKIT 8810S relay: if pumps or any electrical equipment

are used, an RKIT 8810S adapter is required.

E1 O-ring

200-014

model #30-494

Short sleeve

model #30-422

F1 O-ring

200-014

model #30-494

D1 O-ring

200-015

model #30-494

D2 Sleeve

model #30-424

C1 O-ring

200-012

model #30-495

Long sleeve

model #30-423

B1 O-ring

200-021

model #03-077

A1 O-ring

200-014

model #30-494

A2 Sleeve

model #30-424

G1 O-ring

200-021

model #30-926

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

STATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

STATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

LEIT Key

M-Kit

1.5 Tools and Supply Requirement

1. Battery: 9-volt alkaline battery for the LEIT Key

2. Standard wire stripper

3. Flathead screwdriver (9/64” or smaller)

4. Concrete: approximately three 60 lb (27 kg) bags

5. Conventional waterproof wire connectors

2. INSTALLATION

Select the optimum location for the LEIT 4000 controller. If possible locate the controller in open area not adjacent

to a wall or building. We recommend installing a rain sensor with each controller with the use of adapter model

SKIT 8821-4.

2.1 Valve Installation Model 160HE-XXX (2-WAY)

Recommended version is a complete valve assembly including LEMA solenoid actuator with

plastic in-line valve (globe), sizes from 3/4” to 2”.

Maximum static operating pressure is up to 150 PSI.

1. Shut off the mainline to the valve.

2. Install series 160HE-xxx valves with a solenoid actuator according to a valve standard

installation specification (see Figure A on page 7).

3. After installation is completed, turn the water supply on and pressurize the mainline.

The valves will open momentarily and then shut off. Test each valve in manual operation by moving the holder/

handle from left to right to open and right to left to close the valve, making sure that the valve is operating

correctly. The valve should open momentarily and then shut off.

4. Splice the solenoid actuator hot wires (red) to one of the color-coded wires. Splice the solenoid actuator white

wire to the single incoming white (common) wire. Use 2 conventional dry-splice waterproof connectors. Leave

the wires slightly loose on each side so that repairs, if needed, can be carried out easily. Make sure not to

exceed the maximum run recommendation of wire distance (see page 7).

2.2 LEMA Solenoid Actuator Installation Model 1600HE (2-WAY)

Select the appropriate adapter for the valve(s) that will be used (see list on page 5).

The LEMA solenoid actuator operates only with 2-way normally closed valves.

Maximum static operating pressure is up to 150 PSI.

1. Shut off the mainline to the valve.

2. Unscrew the conventional solenoid from the valve and remove the solenoid housing,

solenoid stem, plunger, spring, and O-ring (if necessary).

3. Select the appropriate conversion adapters for the valve(s) then thread and tighten the

conversion adapter clockwise to the compatible valve port, do not over tighten.

4. Make sure that the solenoid holder/handle is not inserted into the solenoid housing,

and then, screw the LEMA 1600HE assembly into the correct adapter. Firmly tighten the

solenoid by hand, but do not over tighten.

5. Slip the LEMA 1600HE sleeve/handle into the solenoid housing. Positioning the solenoid

handle at a 40-45° angel towards the valve creates a manual lever; helpful for manual

on/off.

6. After installation is completed, turn the water supply on and pressurize the mainline.

The valves will open momentarily and then shut off. Test each valve in manual operation

by moving the holder/handle from left to right to open and right to left to close the valve,

making sure that the valve is operating correctly. The valve should open momentarily and

then shut off. If the valve remains open in manual operation, examine the adapter and the

sleeve to see that it is installed correctly and the adapter is firmly secured. Do not over

tighten the LEMA solenoid actuator to the valve and do not cross thread the adapter into

the solenoid cavity

NOTE: For all brand name valves with internal manual bleed lever, make sure the lever is in closed

position. Do not move the lever after installing the solenoid with the valve adapter. If the manual lever

on the valve is used, it can damage the adapter or the sleeve causing the valve to

stay open.

7. Splice the solenoid actuator hot wires (red) to one of the color-coded field wires. Splice

the solenoid actuator white wire to the incoming white (common) wire. Use 2 conventional

DRY-SPLICE WATERPROOF CONNECTORS. Leave the wires slightly loose on each

side so that repairs, if needed, can be carried out easily. Make sure not to exceed the

maximum run recommendation of the wire distance (see A1 below).

WARNING: The LEMA solenoid actuators must not be tested with any AC valve tester or DC tester

over 9-volts. If you do so, it will cause irreparable damage to the LEMA solenoid actuator and the

controller unit. Testing the solenoids with equipment rated higher than 9-volts will void the warranty.

2.3 Wire Installation and Distance

Run all direct burial wires along their respective trenches from each valve box to the controller location. Use

selection of color-coded direct burial wires to connect to each solenoid red (hot) wire. Use white (common) wire to

connect to the solenoid’s white (common) wire. Make sure to label each color-coded wire inside the irrigation box

with the designated station number.

MAXIMUM WIRE DISTANCE

Wire gauge recommendation LEMA 1500S SOLENOIDS LEMA 1600 HE SOLENOIDS

14 AWG (2.5 mm2) 1500 feet (300 m) 4,500 feet (1365 m)

12 AWG (4 mm2) 2400 feet (700 m) 7,500 feet (2272 m)

2.4 Controller Installation

1. To install the mounting column, set the curved bottom of the mounting column in a

12” x 12” x 12” (30 x 30 x 30 cm) frame and pour in the three 60 lb (27 kg) bags of

cement (see Figure A). Make sure the column is vertical and the opening in the curved

bottom is accessible and unclogged. All wires should route to the controller through

the bottom of the mounting column (see A1).

NOTE: Make sure the cement pad is dry before continuing with

the installation.

LEGEND

qDRY SPLICE CONNECTORS

w18” VALVE BOX WITH COVER

eFINISH GRADE TOP

rDIG REMOTE CONTROL VALVE WITH FLOW

CONTROL AND LEIT DC SOLENOID

MODEL: 160HE-150 1-1/2”

MODEL: 160HE-200 2”

tPVC SCH 40 MALE ADAPTER

yPVC MAIN LINE

uBRICK SUPPORT AT EACH CORNER

iPEA GRAVEL SUMP MINIMUM 3”

oCONTROL WIRE TO OTHER VALVE

1) SWIVEL FITTING FOR EASY CONNECTION

MODEL: 23-152 1-1/2”

MODEL: 23-202 2”

1! PVC SCH 40-45° ELL

160HE-150 1-1/2” and 160HE-200 2” REMOTE CONTROL

VALVE FOR LEIT CONTROLLER ASSEMBLY

Figure A

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

STATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

STATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

Figure A1

LEIT X, XR and XRC Controller Speciﬁcations

Section 02810

moc.procgid.www2820-727-067XAF•6419-223-008:enohP

LIGHT ENERGIZED IRRIGATION CONTROLLER

LEIT CONTROL X, XR AND XRC

160HE-160 1-1/2" and 160HE-200 2" REMOTE CONTROL

VALVE FOR LEIT CONTROLLER ASSEMBLY

RAIN SENSOR ASSEMBLY

COLUMN MOUNTED

160HE-075 3/4" AND 160HE-100 1" REMOTE CONTROL

VALVE FOR LEIT CONTROLLER ASSEMBLY

LEGEND

1DRY SPLICE CONNECTORS

2VALVE BOX WITH COVER 12" SIZE

3FINISH GRADE TOP

4DIG REMOTE CONTROL VALVE WITH FLOW

CONTROL AND LEIT DC SOLENOID

MODEL:160HE-150 1-1/2"

MODEL:160HE-200 2"

5PVC SCH 40 MALE ADAPTER

6PVC MAIN LINE

7BRICK SUPPORT AT EACH CORNER

8PEA GRAVEL SUMP MINIMUM 3"

9CONTROL WIRE TO OTHER VALVE

!º SWIVEL FITTING FOR EASY CONNECTION

MODEL:23-152 1-1/2"

MODEL:23-202 2"

!¡ PVC SCH 40-45°ELL

LEGEND

1VALVE BOX WITH COVER 18" SIZE

2DRY SPLICE CONNECTORS

3FINISH GRADE TOP

4DIG VALVE MODEL

3/4" 160HE-075

1" 160HE-100

5SWIVEL FITTING DIG MODEL

3/4" 23-004,1" 23-003

6PVC SCH 40 MALE ADAPTER

7PVC LATERAL LINE

8BRICK SUPPORT AT EACH CORNER

9PEA GRAVEL SUMP – MINIMUM 3"

!º 12 OR 14 GAUGE WIRE

!¡ BACK-UP NPT PVC BALL VALVE

!™ PVC SCH 40 90°ELL

!£ SCH 40 TEE

LEGEND

1"MINI CLIK" RAIN SENSOR

2DIG PLASTIC PIPE CAP

1" PART #23-001 OR 1-1/2" #23-053

WITH HOLE FOR WIRES

3DRILL TWO 3/16" HOLES IN PIPE FOR

SENSOR BRACKET

4(2) #8-32 MACHINE SCREWS WITH

WASHER,LOCK WASHER AND NUT

51" OR 1-1/2" GALVANIZED PIPE

6-10 FEET HIGH

612" X 12" CONCRETE BASE,8" DEEP

MINIMUM

71" OR 1-1/2" PIPE ELBOW

8FINISH GRADE

96" ROUND VALVE BOX

!º SKIT ADAPTER PART #8821-4

USE WITH EACH SENSOR

!¡ TO CONTROLLER OR VALVE

!™ (4) DRY SPLICE CONNECTORS

!£ NORMALLY CLOSED WIRE FROM SENSOR

!¢ COMMON WIRE FROM SENSOR

!∞1" OR 1-1/2" NIPPLE

!§ GRAVEL

LEGEND

1AMBIENT LIGHT POWERED

IRRIGATION CONTROLLER.

MODEL X:10-28 STATIONS

MODEL XR (WITH OPTIONAL RADIO):

4-28 STATIONS

MODEL XRC WITH RADIO REMOTE:

4-28 STATIONS

2TERMINAL STRIP

312 OR 14 GAUGE WIRE

4PROGRAMMING KEY

MODEL #LEIT KEY

535" STEEL MOUNTING COLUMN

MODEL #MCOLXS (SHORT) OR

50" STEEL MOUNTING COLUMN

MODEL #MCOLXL (LONG)

6FINISH GRADE

76-1/2" OF BACKFILL SOIL

8POURED CONCRETE BASE –

1-1/2" CU.FT. INSTALL PER

MANUFACTURER'S INSTALL GUIDE

9DIRECT BURIAL CONTROL WIRES TO

CONTROL VALVES

Part 1 Introduction

1.1LEIT X, XR and XRC controllers are advanced water-management irrigation controllers. The controllers utilize ambient light as the source of energy to

operate up to 28 valves using a low voltage, high efﬁciency, watertight, 2-way magnetic solenoid actuator that operates at 5-volts. Built to the highest

quality standards (ISO 9002), the LEIT X, XR and XRC controllers have a menu base program with straightforward programming that allows for a wide

range of irrigation programs such as valve grouping, 4 programs with 3 start times, run times up to 6 hours, budget, rain delay, status reports, history

reports, manual runs and more. The controller design uses the most advanced time-tested photovoltaic module, which provides more power to harness

light energy day and night, anytime, anyplace. Used for sprinkler or drip systems, the LEIT X, XR and XRC controllers are commercial quality water

management controllers for any type of environment and for a wide range of uses.

Part 2 Typical Installation

2.1Drawing File no.: LEITX.exe

2. Run the field wires along their respective trenches from the valve

box up to the bottom end of the mounting column. Make sure not

to exceed the maximum recommended wire distance (see chart

for maximum wire distance above). Push the wires up through the

column until at least 12” (30 cm) of wire extends from the top of

the mounting column (see B1).

3. Remove the door from the LEIT controller using the door key

(included) and slide the controller into place on top of the mounting

column. Make sure that 12” (30 cm) of wires are now inside the

controller and cannot slip back down into the column (see C1).

4. Insert the clamp spacer and the screw (included with the mounting

column) into the hole located on the lower left end of the controller.

Tighten the screw with the hex-key (included) until the controller

does not turn or twist and cannot be pulled off of the mounting

column (see D1).

5. Connect the station wires to the controller using a standard wire

stripper. Strip 3/10” of insulation from the tip of each of the station

colored (labeled) wires. Connect the color-coded (hot) wires into

the connector strip labeled with the station number and tighten

the connector screw using a screwdriver. Connect the white

(common) wire into either of the two common wire connectors

labeled “common” located at the lower part of the connector strip

and tighten the connector screw using a screwdriver. If using a

master valve, connect the hot wire from the master valve into the

station labeled “MV/P” (see Figure E1). For pump or other electrical

equipment, see detailed installations on page 10.

3. SENSOR INSTALLATION

The SKIT switch-type, weatherproof sensor adapter provides a quick, reliable way to connect a compatible rain,

freeze, moisture or other normally closed, switch-type sensor. The connection can be made either directly to the

LEIT series irrigation controllers or to one of the micro-powered solenoid actuators.

3.1 Sensor connection to unused station

If there is an unused station on the LEIT controller, connect the sensor directly using a SKIT 8821-4.

a. Run a red (hot) wire from the unused station connector position on the LEIT controller to the red (hot) wire

on the SKIT 8821-4. Then run a white (common) wire from the common connector station position on the

LEIT controller to the white (common) wire on the SKIT. Finally, splice the two SKIT black wires to the

sensor’s two normally closed (N/C) wires (see Figure B, Option 1).

3.2 Sensor connection if station is not available

If station is unavailable, or the controller is too far from the sensor, connect the SKIT 8821-4 to LEMA actuators at

a valve closest to the desired sensor location. This method can be used to minimize excessive wire runs (see Figure

B, Option 2).

b. Choose a valve that is closest to the sensor location. On the installed LEMA series actuator, splice the

red (hot) wire to the SKIT’s red (hot) wire AND to the red (hot) field wire creating a 3-wire connection.

Next, splice the LEMA’s white (common) wire to the SKIT’s white (common) wire and connect both onto

the common field wire. Again, a 3-wire connection should have been created. Finally, splice the two SKIT

black wires to the sensor’s two normally closed (N/C) wires.

Figure E1

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

ATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

STATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

Figure C1

STATION 1

STATION 2

STATION 3

STATION 4

STATION 5

STATION 6

STATION MV/P

COMMON

S/N:

Spacing

Bolt

Screw

3/16” Hex Key

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

STATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

STATION 1/9

STATION 2/10

STATION 3/11

STATION 4/12

STATION 5/13

STATION 6/14

STATION 7/15

COMMON

S/N:

STATION 8 AND 16 OR MV/P

Figure B1

Figure D1

3.3 Sensors compatible with LEIT controllers

Rain sensors are the HUNTER MINI-CLIK®and the RAIN BIRD RSD.

Moisture sensors are the IRROMETER, and WEM-B (battery).

Freeze sensor is the HUNTER FREEZE-CLIK®or RAINCLIK™ RFC (rain-freeze combo).

NOTE: Wireless sensors are not compatible with LEIT controllers.

4. PUMP OR ANY ELECTRICAL EQUIPMENT INSTALLATION

If it is required to switch ON a pump, fertilizer injector, fountain or light, two connection options are available using

the RKIT 8810S relay interface module.

The RKIT 8810S units are used to switch 10 amp electrical circuits to a voltage up to 250V AC or 30V DC.

NOTE: RKIT 8810S can be used with LEIT Series 4000, X and XRC.

4.1 RKIT Installation to the MV/Pump Terminal

To operate all the valves with the unit connected to (e.g. pump), connect the RKIT to the MV/Pump terminal

(see Figure C).

4.2 RKIT Installation to One of the Valve Station Terminal Connectors

Operate only the valve number that RKIT has been installed to (e.g. Fountain will turn on/off by only the station

that is using the RKIT).

To install the RKIT, run a red (hot) wire from the RKIT to any of the controller station terminals. Then, run

a white (common) wire from the RKIT to the common terminal connector or if not available, splice it to the

common field wire using a WATERPROOF CONNECTOR. Run the two black wires from the RKIT to the

AC/DC equipment and connect them to the corresponding circuit to be switched (e.g. pump start relay).

Make sure to use WATERPROOF DRY-SPLICE CONNECTORS for all connections.

Figure B

OPTION 1

Sensor connected to

controller using SKIT

adapter

OPTION 2

Sensor connected to

a valve using SKIT

adapter

CONTROLLER INSTALLATION

Figure C

ELECTRICAL EQUIPMENT RELAY INTERFACE CONNECTION

LEGEND

1. FINISH GRADE

2. 6” ROUND VALVE BOX

3. RKIT ADAPTER PART NO. 8810-S. USE WITH EACH SENSOR

4. RED WIRE TO THE MV/PUMP TERMINAL OR ANY STATION

TERMINAL

5. WHITE WIRE TO THE COMMON TERMINAL

6. DRY SPLICE CONNECTORS (4)

7. TO AC/DC EQUIPMENT OR PUMP START RELAY

NOTE: If the RKIT is connected to any circuit higher than 24-volts, it must be located in its own high

voltage junction box in accordance with local electrical code.

If a pump start relay coil current is greater than 2A (Model 8810S 2A up to August 2007) or 10A (Model 8810S 10A

after August 2007) use a pilot rotary.

WARNING: RKIT cannot be housed in the same box with any low voltage equipment.

Do not connect the RKIT to a circuit higher than 380 VAC, 125 VDC.

Ce manuel convient aux modèles suivants

Table des matières

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
