Dickinson Caribbean Fiche technique
Caribbean/Mediterannean
2 Burner Stove 3 Burner Stove
Propane Galley Range
Operating and Installation Manual
This instruction manual contains important information
necessary for the assembly, installation and safe operation
of this stove
Form#7.2-247 Issue#1
Mar 15th 2016
Serial #
____________
3
Table of Contents
4................................................................................................General Warnings
6...............................................................LP Gas Cylinder Specs and Installation
7....................................................................................About our Dickinson Stove
8..............................................................................................Stove Specifications
9...........................................................................................................Accessories
10................................................................................Standard Cutout Installation
11...................................................................................Gimbal Cutout Installation
12..............................................................................Built In Kit Cutout Installation
13...........................................................................................................Installation
14......................................................................................................Fuel Systems
15............................................................................................................Operation
.
17.......................................................................................................Maintenance
19.............................................................................Caribbean Exploded Diagram
20.....................................................................Mediterannean Exploded Diagram
21.................................................................................Caribbean Wiring Diagram
22...........................................................................Mediterranean Wiring Diagram
23..................................................................................................Troubleshooting
24.............................................................................................Replacement Parts
25...................................................................................................Warranty Policy
26....................................................................................................Warranty Form
4
ŸLeak test all connections before 1st use
ŸLeak test all connections after each tank refill
ŸNever check for leaks using an open flame. Use soapy water on the
connections and look for bubbles being produced.
ŸAlways check the stove, tank and hose connections prior to each use
ŸThis stove is configured for propane. Do not use natural gas.
ŸNever use charcoal, lava rocks or any other source of solid fuel in this
stove
ŸEnsure that flames are coming out the entire circumference of the
burners or length of the broiler. Occasionally insects can enter the
unit when not in use and create blockages which can lead to fires.
ŸNever use or store gasoline or any other flammable products in or
near your heater
ŸKeep children and pets away from a hot appliance. DO NOT allow
children to operate
ŸDo not leave this stove unattended when in use
ŸKeep any electrical cords away from the stove when it is in use
ŸDO NOT operate under the influence of alcohol or drugs
ŸDo not use any other regulator than ones supplied or recommended
by Dickinson Marine
ŸThis stove becomes hot when in use. To avoid burns
- DO NOT attempt to move
- Wear protective equipment
- DO NOT touch any hot surface
- Do not wear loose clothing while operating
ŸThis stove is not intended for commercial use
ŸAdhere to all clearances listed in this manual
ŸFor recreational vehicle installation, the Standard for Recreational
Vehicles, ANSI A119.2, or the Standard for Gas Equipped
Recreational Vehicles and Mobile Housing CSA Z240.4
5
ŸA manufactured home (USA only) or mobile home OEM installation
must confirm with the Manufactured Home Construction and Safety
Standard, Title 24 CFR, Part 3280,or, when such standard is not
applicable, the Standards for Manufactured Home Installations, ANSI
A225.1/NFPA 501A, or Standard for Gas Equipped Recreational
Vehicles and Mobile Housing, CSA Z240.4
ŸToddlers, young children, and others may be susceptible to accidental
contact burns. A physical barrier is recommended if there are at risk
individuals in the house. To restrict access to a fireplace or stove,
install an adjustable safety gate to keep toddlers, young children and
other at risk individuals out of the room and away from hot surfaces
ŸClothing or other flammable material should not be placed on or near
the appliance
ŸAny safety screen, guard or barrier removed for servicing the
appliance must be replaced prior to usage
ŸLabel all wires prior to disconnecting when servicing controls. Wiring
errors can cause improper and dangerous operation after service.
Verify proper operation after service prior to firing.
ŸInstallation and repair should be done by a qualified service person.
The appliance should be inspected before use and at least annually
by a professional service person. More frequent cleaning might be
required due to excessive lint from carpeting, bedding material etc. It
is imperative that control compartments, burners and circulating air
passageways of the appliance be kept clean.
*** FAILURE TO ADHERE TO THE SAFETY WARNINGS LISTED IN
THIS MANUAL COULD RESULT IN DAMAGE TO PROPERTY OR
SEVERE PERSONAL INJURY***
6
LP GAS CYLINDER SPECS AND INSTALLATION
ŸThe stove and its individual shutoff valve must be disconnected from
the gas supply piping system during any pressure testing of that
system at test pressures in excess of 1/2 PSI (3.5kPa)
ŸThe appliance must be isolated from the gas supply piping system by
closing it’s individual manual shut-off valve during any pressure testing
of the gas supply piping system in equal or less than 1/2 PSI (3.5kPa)
ŸThe LP gas supply cylinder to be used MUST be constructed and
marked in accordance with the specifications for LP gas cylinders,
U.S. Department of Transportation (DOT) or the standard for cylinders,
spheres and tubes for the Transportation of Dangerous Goods,
CAN/CSA-B339
ŸThe propane supply cylinder system must be installed with proper
vapor withdrawal capabilities
ŸA pressure regulator must be used in the operation of this unit which
will emit the propane at a pressure of 11”W/C
ŸAny replacement regulators must be of those specified by the
appliance manufacturer
7
About our Propane Galley Stoves
One of our newer appliances, our Dickinson propane galley ranges are clean burning
appliances designed for use in marine environment but are adaptable to many applications.
With a large range of setting they are ideal for all cooking situations and are great to have
in any galley. Made out of attractive stainless steel our stoves are durable and beautiful.
The stainless design is resistant to corrosion and will keep its shine for many years. The
burners have porcelain capping for a nice glossy black look which looks great with grained
finish of the stove. Paired with the laser cut lettering, the propane galley ranges are a must
have.
Each Dickinson range comes standard with one set of polished pot holders, a
stainless cooking rack, a finished wood cutting board as well as a stainless steel potholder
rail. The stoves are designed to sit in a standard cut out and can be mounted three
different ways. Straight into a cut out, built in with stainless steel accent pieces or gimbal
mounted for use in light chop. Any way it is mounted, your propane range will offer
dependable service for years to come. When not in use, place the cutting board into the
stove top and you have increased counter space.
These stoves operate on 11” W/C pressure and require a dedicated regulator or a 2
stage regulator for a multiple appliance set up. All burners are equipped with thermocouple
controlled flame out protection as well as automatic spark ignition for ease of use and the
oven is thermostatically controlled and maintains a nice even temperature. All around the
stoves are easy to use and reliable.
8
Galley Specifications
Galley Dimensions
Height
Width
Depth
Weight
Burner BTU Range
Small Top
Large Top
Broiler
Oven
Oven Temperature Range
Oven Size (Usable)
Height
Width
Depth
Gimbal Point
Height
From Front
From Rear
Mediterranean
21”
20.5”
20”
80lbs
2300 - 7000 (x2)
4300 - 11000
4500
7000
9”
16”
12.5”
18”
7.5”
11.5”
Caribbean
21”
20.5”
14.75”
70lbs
2300 - 7000
4300 - 11000
4500
7000
9”
16”
12.5”
18”
7.5”
7”
Automatic Spark Ignition - Each burner is equipped with an automatic spark ignitor which is engaged as
soon as the burner knob is pressed down to allow gas. This does not allow for any build up of propane gas
that could create a potentially dangerous situation.
Thermocouple Controlled Flame Out Prevention - Each burner is equipped with flame out protection. In
the event that a burner is accidentally blown out, the thermocouple will sense the lack of heat and disengage
the valve and prevent any gas build up.
Thermostatically Controlled Oven - The oven in our propane galley range is controlled thermostatically
with a probe located inside the oven that regulates the cooking temperature. With a cooking range from 250
to 450 degrees your oven is capable of cooking a variety of items
Triple Burner - The large burner is a patented triple burner design which allows the Dickinson propane
galley range to boast the most powerful marine stove burner (11000 BTUs). The Burner can be turned
down to a third of the BTU’s for slower cooking.
Product Features
9
Included Accessories
Cutting Board - The cutting board is a nice addition
to the propane galley. It sits flush in the sink cutout
creating more counter space and has cut outs in the
back eliminating the need to remove the pot holder
rail.
Mediterranean - 26-011
Caribbean - 26-010
Cooking Grate - The cooking grate is made of
beautifully polished stainless steel and sits tight on
four anti-rattle pins. It is equipped with locking slides
on the front and back for your pot holder rail as well
as 4 adjustable leveling points for your cutting board.
Mediterranean - 26-031
Caribbean - 26-030
Pot Holders - Your propane galley comes with a set of
pot holders. They can be adjusted to fit any sized pot
as they are placed individually on the pot holder rail
and once in place will not move.
Mediterranean - 20-020A
Caribbean - 20-020
Pot Holder Rail - The pot holder rail serves the dual
purpose of holding the pot holders and offering a small
raised barrier against sliding pots in small chop.
26-021
Tie Down Bar - This is used to secure the stove
underneath at the back where it is inaccessible
10
Standard Cutout
If installing your Mediterranean or Caribbean propane stove into a cutout, the cutout needs to be a
minimum of 20.5” wide for either stove and 22” deep for the Mediterranean or 16.5” for the Caribbean. A
cutout is not necessary as the stove can be freestanding. Once mounted the stove needs to be secured
with the tie down bar and two screws in the front below the door.
