INSTRUCTION MANUAL
Thank you for purchasing PORTABLE DIGITAL AUDIO
PLAYER from DIASONIC TECHNOLOGY Co. LTD. Please
carefully read the Instruction manual for safe use of the
product. We recommend you to keep this instruction
manual for future reference.
PORTABLE DIGITAL AUDIO PLAYER
MODEL : DMP-105/DMP-115
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지1 (1,1)
DIASONIC TECHNOLOGY Co. LTD. has all the copyrights for this
instruction manual.
It is against the copyright law to make unauthorized copies, translate
and publish material without prior authorization from DIASONIC
TECHNOLOGY Co. LTD. All the information written in this instruction
manual was produced with our company's careful caution, but they
can be changed without any prior notification. Any differences
between product and manual due to the cause of change the
responsibility will not fall under our company.
COPYRIGHT
WARNING
Changes or modifications not expressly approved by the
manufacturer could void the user's authority to operate the
equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operations.
INFORMATION TO THE USER
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지2 (1,1)
CONTENTS
-2-
1. DMP-105/DMP-115 SERIES
1) Notes for using ······················3
2) About DMP-105/DMP-115 SERIES ············ 4
3) Function and Feature ·················· 5
4) Name of each part and LCD display ············ 6
5) Use of battery and component of package. ········· 7
6) Use of basic functions ·················· 9
7) Folder and File Management Method ···········12
8) Use of buttons ·····················16
9) Operating dial menu ···················18
10) Recording from voice record property ···········21
11) Deleting ························23
12) Connecting to a exterior devices ·············24
13) Receiving FM radio function ···············25
2. DIGITAL AUDIO MANAGER AND MAIL MANAGER
1) USB Driver Installation Method ··············26
2) MANAGING FOLDER ··················28
3) File Download······················30
4) File Deletion ······················31
5) File Format ·······················32
6) What is DIGITAL AUDIO MANAGER? ···········35
7) Mail Manager ······················36
3. Standard Product ····················40
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지3 (1,1)
Before use (notes for using)
-3-
●Do not drop or give a hard impact. It could cause malfunction.
●Do not use or place it at following places.
- Highly temperate area(above 60℃)
- Under direct light beam or anywhere close to heater
- Car with closed windows. (Especially summer)
- Where lots of moisture exist ex) bathroom.
- Where lots of electricity occurs
●If too much force is pressed on LCD Display window it becomes the
reason of malfunction. And it can cause problem due to LCD
Display windows' specificity.
●If you place any kind of magnetic card; cash card, or commutation
ticket close to a speaker, it will affect magnetic part of cash card,
and commutation tickets and make the card useless.
●Please make sure no dust goes into insertion of this product.
●You should not shake or give impact to the product or remove it
from USB port when it is reading or writing data. At situation like
this, data could be lost or damaged.
●Please understand that our company will not be responsible for any
harm caused by this product or compensation request made by
third party
●Please understand that our company will not be responsible for lose
of memory other than by damage or repair.
●Please do not repair, disassemble, or remodel on users own will.
●Please do not operate where use of electric device is prohibited.
●Please do not operate while driving.
●Please do not overheat the body of the product or the battery, also
do not short the battery.
●Users using assistant equipment please do not use the main
product fasten so closely to assistant equipment's slot.
●There is a chance that stored memories might change, or disappear
due to situation where the customer or the third party misuses the
product or static electricity, and electric shock is given to product or
when repairing the damage or replacing the batteries.
Please record important information on a memo or note.
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지4 (1,1)
About DMP-105/DMP-115 SERIES
-4-
DMP-105/DMP-115 series are Multi-Function Next-Generation
Portable Digital Audio Player that integrated technology and quality
from DIASONIC TECHNOLOGY Co. LTD. It's a high performance
portable digital audio player which plays digitally compressed audio
file MP3 and WMA file in various ways. It can record high-quality
voice and also has function to record by connecting it to exterior
devices and listening and recording of FM radio broadcast is also
possible.
●Voice and Exterior Device Record
It enables to record voice and record through exterior device; it has
adopted a various voice record function of MP3 player, and it can also
be used as portable data storing device which has portable hard disk
function.
●Listening and Recording of FM Radio
DMP-105/DMP-115 SERIES has function to receive FM Radio
frequency, so you can listen to FM broadcast and at same time you can
record the broadcast that you are listening and re-listen at anytime.
●Graphic LCD Display and Back-Light Function
DMP-105/DMP-115 SERIES uses graphic LCD that supports not
just a Korean, but also English, Chinese, and Japanese, so you can
easily notify the name of the song and playtime, and the back-light
of dark-blue LCD makes it possible for users to configure the menu
at night time.
●Provide DIGITAL AUDIO MANAGER/ Mail Manager
You can freely transmit the data recorded form PC or receive MP3 files
from a PC, and the comfort support of playing and managing stored
data and transmitting record data on e-mail is possible.
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지5 (1,1)
-5-
Function and Feature
●DMP-105 is MP3 player that stores music file or data only with
connection to the USB port of the computer and can be accessed
relatively rapidly.
●Adopted USB interface for convenient computer storage.
●Plays MP3 file, voice record, receiving and recording of FM radio
broadcast.
●Graphic LCD with back-light (indicates file title, play time, battery
condition, etc)
●Hold function to prevent actions from miss-pressed buttons.
●Repeat play function (normal, 1 track, all, random, section repeat,
album repeat)
●Supports Korean, English, Japanese, Chinese.
●Play/ intro play/stop/ power off/record.
●Next track/ previous track/ Fast forward/ Rewind.
●Volume up/down(digital volume: 30level)
●Storing/Managing Folder function.
●Various equalizer mode (NORMAL, CLASSIC, LIVE, POP, ROCK.
●Adjust back-light time, adjust scroll speed time.
●Delete function (ONE, ALL)
●Display function to change display while MP3 file is being played
(NORMAL, REMAIN, TITLE)
●
Software : DIGITAL AUDIO MANAGER [ File transfer, MP3/WAV/Audio
CD Play,MP3 Encoding (Option) 〕
Mail Manager (DMF play, record, voice mail, voice memo)
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지6 (1,1)
Name of each part and LCD Display
-6-
EARPHONE
JACK
PLAY/STOP
LINE IN
REW/MENU/FF
REC/STOP
VOL+ / VOL-
HOLD
ON/OFF
HOLD
VOL
REPEAT
REC TIME/PLAY TIME/EL/
VOLUME REC/PLAY/USB DISK
EQ
BATTERY
USB
JACK
RADIO
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지7 (1,1)
1. Open the battery cover.
2. Insert 1 LR 03 type battery to product matching the (+) (-)polar
signs and close the cover.
[Battery : LR 03 or equal product (SIZE"AAA" or UM-4)
3. Press play/stop button to check the battery.
Battery full Consumed 1/3 of the Battery .
Consumed 2/3 of battery. Battery needs exchange.
※Notice
If LCD doesn't appear after new battery has been inserted,
immediately check the polar signs of battery. Even after checking the
polar signs of the battery and if LCD still doesn't appear, take the
battery out and request for repair.
Use of Battery and Component of Package
-7-
OPEN
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지8 (1,1)
-8-
4. Use time of battery
5. Attention when using battery
●Take the battery out if it's not going to be used for long period of
time.
●When using rechargeable battery, use it properly after reading the
instruction manual.
6. Package Components
STEREO EARPHONE, USB DRIVER INSTALL CD for WINDOWS 98 SE,
LINE/IN CABLE, USB CABLE(10Cm), INSTRUCTION MANUAL,
BATTERY, NECK STRAP, WIRED CONTROLLER
Battery used When recording
Approx. 7hour Approx. 7hour
When played with
earphone
( volume : medium )
Alkaline battery
SIZE"AAA" LR-03
DMP-105/115pdf용 2003.11.3 2:36 PM 페이지9 (1,1)
●Power ON/OFF
●Using hold switch
If the hold switch is upward switch will not be operated.
Keep the switch upward when it's not being used or if you wish to
maintain the recording condition. Before turning the power on,
make sure hold switch is disabled.
Basic use
-9-
HOLD disabled HOLD
Switch will not be enabled.
Press play button for over 1seconds to turn the
power on and LCD display screen will appear
like picture on the side. While power is on,
press play button again for over 1second to turn
the power off.
If none of the buttons are pressed over 1minute
power will turn off automatically.
※If power is turned on while the hold switch is at ON it will indicate
"HOLD ON", and power will shut off automatically. So, disable
hold and turn the power on.
