DIAMOND MULTIMEDIA - SPECIFICATION SHEET

SKU 4870PE5512DTXOC

BRAND HD 4800

February 4, 2011 - 6:26 am

ENG APVD - LK 2008-09-08

MRKTG APVD - LL 2008-11-19

SKU 4870PE5512DTXOC

PRODUCT DIAMOND AMD ATI Radeon™ HD 4870 512MB GDDR5 Video Card

PRODUCT SHORT DESCRIPTION INTERFACE PCI Express x16

GPU HD 4870

CORE CLOCK 795 Mhz

MEMORY CLOCK 1100 Mhz x 2

MEMORY CONFIGURATION 16Mx32

MEMORY TYPE GDDR5

MEMORY BANDWIDTH 161 GB/Sec

MEMORY SIZE 512MB

MEMORY CONTROLLER INTERFACE 256-bit

PORTS 2 Dual-Link DVI,Video Out [S-Video, Composite, HDTV]

DUAL LINK DVI Hydravision 4

PRODUCT DETAILED DESCRIPTION Redefine HD Gaming The ATI Radeon™ HD 4800 Series Graphics Cards GPUs deliver a cinematic gaming experience

with unprecedented performance. The powerful new TeraScale graphics will propel you deep into your gameplay with

seamless frame rates and high resolutions. Enhanced anti-aliasing (AA) and anisotropic filtering create striking graphics

with unparalleled realism so you can max out the settings of the most demanding next-generation games or revitalize your

favorite titles. Play today while preparing for tomorrow with tessellation, support for DirectX® 10.1 and scalable ATI

CrossFireX™ technology.

PRODUCT FEATURES ●GPU: Radeon™ HD4870

●Bus Type: PCI-Express 2.0

●Stream Processors: 800

●Core Clock: 750 Mhz

●Memory Size: 512MB

●Memory Configuration: 16Mx32 GDDR5

●Memory Interface: 256-Bit

●Memory Speed: 900 MHz

●Two Dual Link DVI + HDTV-Out (HDMI support VIA Adapter)

SYSTEM REQUIREMENT EXTERNAL POWER REQUIREMENT 2 x 6-pin

CPU Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or

higher

CPU SPEED 2.0 Ghz or faster

MEMORY 1024MB

HARD DISK 400 MB

SYSTEM BUS PCI Express x16

SLOT DOUBLE

CHASSIS ATX

MONITOR Digital flat-panel (DFP) displays or DVI-I Compatilbe or

digital CRT display or High-resolution VGA monitor

INTERNET ACCESS

USB

CD DVD YES

POWER SUPPLY 450 Watt or greater power supply with 75 Watt 2 x 6-pin PCI

Express® power connector recommended.

OPERATING SYSTEM WINXP WINXP64 WINVISTA32 WINVISTA64 MCE

FORM FACTOR Standard Profile Full-Height

DIMENSIONS [PRODUCT] : 11.75 X 9.5 X 3 inches [RETAIL BOX] : 11.75 X 9.5 X 3 inches [S BUILDER] : 11.75 X 7.25 X 2 inches

WEIGHT [PRODUCT WEIGHT] : 2.75 LBS [PRODUCT WITH CONTENT WEIGHT] : 3.55 LBS

UPC RETAIL PACKAGE UPC : 757448006780

PACKAGE CONTENT

●DIAMOND RADEON HD 4870 PCIE 512MB GDDR5

VIDEO CARD

PRODUCT WEBPAGE http://www.diamondmm.com/4870PE5512DTXOC.php

PRODUCT NOTES California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth

defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if

heating the solder.

The information presented in this document is for information purposes only. The information contained herein is subject to change and may be rendered inaccurate for many reasons, including, but not limited to product and specification

changes, new model and/or product releases, product differences between differing manufacturers, software changes, BIOS flashes, firmware upgrades, or the like. Diamond Multimedia assumes no obligation to update or otherwise correct or

revise this information. Diamond Multimedia makes no representations or warranties with respect to the contents hereof and assumes no responsibility for any inaccuracies, errors or omissions that may appear in this information. However,

Diamond Multimedia reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of Diamond Multimedia to notify any person of such revisions or changes. Please see your Diamond

Multimedia sales representative for any questions regarding this product information.

Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.

ATI, Graphics by ATI, and Radeon are trademarks of ATI Technologies, Inc.

All other trademarks are property of their respective owners.

Diamond Multimedia

20740 Plummer St. Chatsworth, CA 91311

Tel: (818) 534-1414 Fax: (818) 773-9619

http://www.diamondmm.com
