DGSHAPE DWX-53DC Instructions de montage

Congratulations on your purchase of this product this time.

•

To ensure safe and correct use of this product and to gain a thorough understanding of its performance, please read this manual

carefully and retain it for future reference.

•

Unauthorized copying or copying of all or part of the contents of this manual is prohibited.

•

The specifications of this product and the contents of this manual are subject to change without notice.

•

We assume no responsibility for any direct or indirect damage caused by the use of this product, whether or not it is faulty.

•

We shall not be liable for any direct or indirect damages caused to the product manufactured by this product.

R1-220907

https://www.dgshape.com/

Installer Guide


Introduction ............................................................................................................................................................... 2
ABOUT THE MACHINE..................................................................................................................................................
3

Unique features ........................................................................................................................................................3

Pre-installation check.........................................................................................................................................................
4

Installation and Installation .......................................................................................................................4

Installation location...................................................................................................................................................
5

Temperature and humidity ........................................................................................................................6

Installation space.......................................................................................................................................7

What's in the Box ...............................................................................................................................................................
9

Installation........................................................................................................................................................11

PREPARATION TO USE THE MACHINE ................................................................................................................
12

Check before operation ...........................................................................................................................12

Install the aircraft............................................................................................................................................................
15

Remove the fasteners ..............................................................................................................................15

Connect the power cord........................................................................................................................ 19

Turn on the power................................................................................................................................. 21

Retighten the screws of the air nozzle. ......................................................................................22

Attach the dust collector..........................................................................................................................24

Install the regulator...................................................................................................................25

Connect to a computer......................................................................................................................................................
29

System requirements ...............................................................................................................................29

Software to be installed ...........................................................................................................30

Install software.................................................................................................................. 31

Connect to a computer.............................................................................................................32

Show VPanel......................................................................................................................................... 39

Exiting VPanel...................................................................................................................................... 40

Connect multiple units....................................................................................................................................................
41

Registering another aircraft .....................................................................................................................41

Switching the Aircraft Operated by VPanel......................................................................................... 44

Changing the Name and Images of the Aircraft Displayed on VPanel.....................................................45

Before starting work .......................................................................................................................................................
47

Selecting the Aircraft to Use with VPanel for DWX ...............................................................................47

Running in the disc changer ....................................................................................................48

Perform spindle habituation operations .....................................................................................50

Correcting the cutting position automatically ..........................................................................................52

Turn off ....................................................................................................................................58

Appendix...........................................................................................................................................................59

Specifications.................................................................................................................................................
60

Expansion terminal..................................................................................................................................60

Coordinate...............................................................................................................................................61

Dimensions .............................................................................................................................................62

List of specifications ...............................................................................................................................66

System-Requirements for USB Connectivity...........................................................................................67

1

Tabl
e of
Con
tent
s

Introducti

Introduction

ABOUT THE MACHINE ............................................................................................................

Unique features...................................................................................................................3

Pre-installation check....................................................................................................................

Installation and Installation......................................................................................4

Installation location..............................................................................................................

Temperature and humidity.......................................................................................6

Installation space.....................................................................................................7

What's in the Box..........................................................................................................................

Introducti

Relevant

informatio

Unique features

This machine is a dental cutting machine that uses dental cutting ceramics, resin materials for dental cutting, dental casting

wax, or dental non-cast cobalt-chromium alloy to make prostheses such as crowns, copings, and bridges.

You can create high-quality prostheses by installing special software on your computer and connecting the instrument.

The machine's disc changer automatically manages and switches up to six cutting materials. Continuous machining is

possible while using materials in use without waste.

Please refer to our site for the latest information on this machine.

•

https://www.dgshape.com/

ABOUT THE MACHINE

Introducti

Note

Loading/unloading and installation shall be carried out by at least four persons.

Forcible work with a small number of persons may injure your body. If it falls, it may cause injury.

Note

Hold the projector by the parts shown in the illustration when lifting it.

Important

Do not have milling area covers, adaptor area covers, tool area covers and dust harvesting hose

attachments.

Installation and Installation

The weight of the main unit alone is 120 kg . Take care when loading/unloading and installing.

Pre-installation check

Pre-

installation

check

Introducti

Warning

Install the unit in a place that is level, stable, and capable of withstanding the weight of the unit.

The total weight of the instrument is more than 120 kg . Failure to do so may result in a serious accident such as a fall,

fall or collapse.

Warning

Do not install the product in a place exposed to fire.

Otherwise, it may ignite the machining scrap. Powdery things are very combustible and can burn even if they are

metal.

Warning

Do not install the product near flammable materials or in a place filled with gas.

Failure to do so may result in a fire or explosion.

Warning

Do not install the product outdoors, in a place exposed to water, or in a place with high humidity.

Electric leakage may cause electric shock or fire.

Warning

Keep the power plug easily accessible at all times.

This is for quick disconnection of the power plug in case of emergency. Install the equipment near the power

outlet. Also, leave enough space for the power cord to be brought into close proximity to the outlet.

Installation location

•

Do not install the product in a location subject to large changes in temperature and humidity.

•

Do not install the product in a place subject to shaking or vibration.

•

Do not install the product in a dusty location.

•

Do not install the product in direct sunlight or near heating and cooling equipment.

•

Do not install the product in a location where there is a lot of electrical or magnetic noise, such as electromagnetic

waves.

•

Do not install the product in an atmosphere containing silicone-based substances (oil, grease, spray, etc.).

Failure to do so may cause contact failure of the switch or malfunction of the ionizer.

Pre-

installation

check

Introducti

Important

Use the machine in an environment where the temperature is kept as constant as possible. Large changes in the

temperature of the installation environment may affect the machining quality.

Temperature and humidity

Install the product in a place with specified conditions (temperature, humidity, etc.). Failure to observe this precaution

may result in damage to the unit.

•

Temperature : 5

～

40 ℃

•

Humidity: 35 to 80% RH (no condensation)

Pre-

installation

check

Introducti

Relevant

informatio

Installation space

Allow at least the following space for installation.

Installation space

Working space

800 mm

900 mm

1,800 mm

1,900 mm

Secure sufficient space for the adapter area cover or tool area cover to be opened.

912 mm

•

P. 62 "External Dimensions"

Pre-

installation

check

Introducti

Height to be installed

Install the product at least 0.6 m from the work floor.

This unit is a tabletop-mounted device. Install the product so that it is easily accessible to the power switch and other operating

parts during operation.
