IV-18(ИВ-18)VFD Tube Clock Energy Pillar

Operation Instruction v1.2.0

Contents

Attention……..………….…………………………………………………………………………………………………………….…… 2

Functional features….…………………………………………………………………………….…………………………………… 2

Technical specifications………………………………………………………………………………………...……………….…… 2

Package content………………………………………………………………………………………...….…………………………… 3

Appearance layout………………………………………………………………………………..……….…………………………… 3

IR remote control introduction……………………………………………..…………………….……………………………… 3

Warning tone introduction….…………………………………..………………………...….…………………………………… 4

Display mode switch……………………………………………………..…………………………………………………………… 4

Power on/off…………………………………………………………….……………………..………………………………………… 4

Adjust brightness………………………………………………………………………….…………………………………………… 4

Temperature unit ℃/℉……………………………………………………………….……………………..……………………… 5

Set time……………………………………………………………………………………………………………………………………… 5

Set date……………………………………………………………………………………………………………………………………… 5

Set alarm……………………………………………………………………………………………….…………………………………… 5

Menu 1: Date format YY-MM-DD/YY-DD-MM/DD-MM-YY/MM-DD-YY…………………………….……… 6

Menu 2: Time format 12H/24H…………………………………………………………………………………………..……… 6

Menu 3: Set UTC………………………………………………………………………………………………………………………… 6

Menu 4: GPS Status……………………………………………………………………………………………………………….…… 7

Menu 5: Set GPS BAUD RATE………………………………………………………………………………………………………7

Menu 6: Set leader 0 mode…………………………………………………………………………………………………………7

Menu 7: Set Buzzer mode……………………………………………………………………………………………………..…… 8

Menu 8: Date interval of scrolling display……………………………………………………………………………..…… 8

Menu 9: Temp interval of scrolling display…………………………………………………………………………….…… 8

Menu 10: Set auto power off Time…………………………………………………………………………………………..…9

Menu 11: Set auto power on Time…………………………………………………………………………………………..…9

Timer function…………………………………………………………………………………………………………………………… 10

Special function …………………………………………………………………………………………………………………..…… 10

Announcements ………………………………………………………………………………………………………………….…… 10

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

Attention

◇Attention: In order to prevent damages, do not place this clock on uneven place.

◇W arning: The clock has an internal high voltage circuit, do not touch the circuit

board and components if the clock is working.

◇W arning: Exposing outdoor prohibited, using in moist or raining place prohibited.

◇Warning: Do not let the children touch the clock without adult.

Functional features

1. Eight digits IV-18 (ИВ-18) VFD tubes display. (1980-1090 made in USSR).

2. Display hour, minute and second (12 or 24 hours format optional).

3. Display year, month and day and Chinese lunar date (YY-MM-DD or

MM-DD-YY.DD-MM-YY.YY-DD-MM format optional).

4. Leader zero ON/OFF function.

5. GPS adjust, automatic adjust date and time in real time. GPS status display (GPS is

offered as an option).

6. GMT time zone functions, the clock will calculate the local time base on satellite.

7. Temperature display(℃or ℉temperature unit optional).

8. Two alarm clock(set on or off different alarm respectively).

9. Auto date and temperature circulating display. Also can set interval for circulation.

10. Timer function which can supply longest 99 hours 59 minutes and 59 seconds.

11. Power on/off timer, also can set the on/off time respectively. You can also check time

and date easily after auto power off.

12. 8 levels brightness adjustable, or auto brightness in different environment.

13. Button sound on/off.

14. Auto switch upright and upside-down mode, this function can display the right side

based on the position that you put the clock in.

15. IR remote controller operation supplied.

16. With extremely accurate RTC module, accuracy <1 minute in a year.

17. Built-in backup lithium battery, keep time more than 3 years without power supply.

Technical specifications

Input voltage DC5V

Working current Max 220mA

Tube type IV-18（ИB-18 1984-1992 made in USSR）

Size 200mm x 52mm x 64mm, tube length 115mm diameter 18mm

Working temp 0℃-60℃

Weight 350g

Shell material Aluminum alloy

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

③

④

②4

①

Package content

Name Quantity Name Quantity

VFD tube clock 1 Mini USB power line 1

IR remote controller 1 User manual 1

Appearance layout

Num Name Num Name

1 IV-18VFDtube 2 IRreceiver

3 GPS Receiver Socket 4 Mini USB Power Socket

IR remote control introduction

1.POWER 2.BACKLIGHT 3.SET

4.DATE 5.ALARM 6.TEMPERATURE

7.LEFT 8.RIGHT 9.FUNCTION

10.OK 11.CANCEL 12.NUM 0

13.NUM 1 14.NUM 2 15.NUM 3

16.NUM 4 17.NUM 5 18.NUM 6

19.NUM 7 20.NUM 8 21.NUM 9

Considered the battery are not allowed transport during air

transportation, if there’re no battery in controller, please put two AG10

cell (suit for double cell remote) or CR2025 cell (suit for single battery

remote control ) in it.

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

Warning tone introduction

Beep Description Meaning

Be 1 shot beep Normal operation

Be…1 long beep Confirm and saved

Bebebe 3 shot beep Sync with satellite time successfully

Bebebebe 4 shot beep Set error/cancel/alarm

Display mode switch

1. Display time Mode

After power on the clock, or press POWER button in shutdown state, it’ s display time

mode. Clock will display HOUR, MINUTE, SECOND (displayed as decimal point) on this

mode.

2. Display calendar date Mode

Press D AT E button enter display calendar date mode. Clock will display YEAR, MONTH,

DAY. Clock will return to display time mode after three seconds.

3. Display lunar date Mode

Press D A T E button twice or press D A T E button once under calendar date mode will

enter display lunar calendar date mode. Clock will display YEAR, MONTH, DAY of lunar date.

Clock will return to display time mode after three seconds.

4. Display alarm Mode

Press ALARM button, enter show alarm 1 mode. Press ALARM button again, it will

show alarm 2. Clock will return to display time mode after three seconds.

5. Display temperature Mode

Press TEMPERATURE button to enter display temperature mode. Clock will return to

display time mode after three seconds.

6. Timer Mode

Press ALARM button three times to enter timer mode. Then press CANCEL will return

to Display time Mode.

7. Menu Mode

Press FUNCTION button will enter menu mode, and then press CANCEL will exit.

Power ON/OFF

In display time mode, press POWER button can on/off the power of clock, and it will be

displayed as “HELLO”when power on, “POWER OFF”when power off.

Clock will cut off the filament supply and high voltage supply of the VFD tube in order to

extend VFD tube life-span.

Adjust brightness

In display time mode, press LIGHT button change brightness repeatedly, step 1-8. After

step 8, clock will show “Auto”mean clock will adjust brightness automatic according

environmental light. There was a high light at daytime and a low light at night which has no

effect to your sleep.

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

Temperature unit ℃/℉

In the display temperature mode, press FUNC button can switch temperature unit

repeatedly.

■This option stored in the clock and can’t lose when power off.

Set time

In display time mode, press SET button enter set time mode.

After enter set time mode, SECOND will blinking, means now is setting SECOND. Press LEFT

or RIGHT button change setting position.

Press button NUM0-NUM9 to change the number.

Press OK to save setting.

Press CANCEL abort setting and exit.

■After setting success, clock will beep for a long time, and return display time mode.

■If setting is illogical, clock will beep four times with short time, and abort save

setting then return display time mode.

■Please according to 24H format to set time.

Set date

In display date mode, press SET button enter set date mode.

After enter set date mode, D AY will blinking, means now is setting D AY . Press LEFT or

RIGHT button change setting position.

Press button NUM0-NUM9 to change the number.

Press OK to save setting.

Press CANCEL abort setting and exit.

■After setting success, clock will beep for a long time, and return display time mode.

■If setting is illogical, clock will beep four times with short time, and abort save

setting then return display time mode.

■The moon date don’t need set, clock will calculate automatic according Gregorian

calendar.

■T wo digit of YEAR means after 2000 year.

Set alarm

In display alarm 1/2 mode, press SET button enter set alarm mode.

After enter set alarm mode, HOUR will blinking, means now is setting HOUR of alarm. Press

LEFT or RIGHT button change setting position.

Left two digits will display witch alarm is setting now, A1 means now is setting alarm 1, A2

means now is setting alarm2.

Press button NUM0-NUM9 to change the number.

Press OK to save setting.

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

Press CANCEL abort setting and exit.

■After setting success, clock will beep for a long time, and return display time mode.

■If setting is illogical, clock will beep four times with short time, and abort save

setting then return display time mode.

■If want disable the alarm function, you should press FUNC button in alarm display

mode, then clock display OFF, means this alarm was disabled.

■If now is alarming, press any button to stop alarm, or clock will stop alarm after

60sec.

Menu 1: Date format YY-MM-DD/YY-DD-MM/DD-MM-YY/MM-DD-YY

Press FUNC button to enter the Menu, use RIGHT/LEFT key to switch the menu number,

menu 1 Date Format.

Press OK to enter settings screen, at this time will display the present date format. Press

RIGHT/LEFT key to change the four formats. (YY-MM-DD/YY-DD-MM/DD-MM-YY/

MM-DD-YY ).

Press OK to save and exit the settings, press CANCEL to cancel the settings and back to the

main screen.

■This setting stored in the clock and can’t lose when power off.

■The date format will only effective to date displaying. The setting should according

to YY-MM-DD format.

Menu 2: Time format 12H/24H

Press FUNC button to enter the menu and use the RIGHT/LEFT key to change the menu

number, then enter the menu 2 time format.

Press OK to enter settings screen, at this time will display the present time format. Press

RIGHT/LEFT will change the format. (12H/24H).

Press OK to save the present format and exit the menu, press CANCEL to cancel the settings

and back to the main screen.

■This setting stored in the clock and can’t lose when power off.

■The time format will only effective to time displaying. The setting should according

to 24H format.

Menu 3: Set UTC

Press FUNC to enter the menu, use RIGHT/LEFT key to change the number, then enter in

menu 3. Set UTC.

Press OK to enter the setting screen, at this time it will display the present UTC settings.

Press RIGHT/LEFT key to change the format between GMT-12 and GMT+12.

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

Press OK to save the settings and exit the menu, when you power on or cut off the power it

will remember what you set before.

■This setting stored in the clock and can’t lose when power off.

■After reset UTC, it will worked in the next time when GPS checking the time.

Menu 4: GPS status

Press the FUNC key to enter the menu, use RIGHT/LEFT key to change the number, and

then enter menu 4 GPS status screen.

Press OK to enter the settings screen, at this time will display the present GPS status.

Displaying NO GPS: no connect with GPS receiver or the BAUD setting was wrong.

Displaying SEARCH: now connected to the GPS receiver, but GPS receiver didn't connect to

satellite, and now it is searching for the satellite.

Displaying ONLINE: now connected to the GPS receiver and the satellite, and it is checking

the time.

■When the present time error reached 1 second to the satellite time, clock will check

the time and update the time immediately.

■After refresh successfully, clock will have three short beep.

Menu 5: Set GPS BAUD RATE

Press FUNC key to enter menu, use RIGHT/LEFT key to change the number, and then enter

menu 5 Set GPS baud rate.

Press OK to enter settings screen, at this time it will display the present GPS BAUD, use

RIGHT/LEFT key to change the BAUD.(4800bps/9600bps/19200bps/38400bps)

Press OK to save the settings and exit the menu 5, press CANCEL to cancel it.

■This setting stored in the clock and can’t lose when power off.

■The set should according to your GPS receiver user manual, if the BAUD was

mismatching the clock can’t check the right time.

Menu 6: Set leader 0 mode

Press FUNC key to enter the menu, use RIGHT/LEFT key to change the number, and then

enter in menu 6 Set leader 0 mode.

Press OK to enter the settings screen, at this time it will display the present settings. Press

RIGHT/LEFT will switch it between ON/OFF.

Displaying ON: when the first number is 0, 0 will display, eg: 8 am for 08:00:00

Displaying OFF: when the first number is 0, it will not display, eg: 8 am for 8:00:00

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

Press OK to save the settings and exit the menu 6, or you can cancel it.

■This setting stored in the clock and can’t lose when power off.

■The display mode only effective for displaying time, when you set the time, the

leader 0 will always display.

Menu 7: Set Buzzer mode

Press FUNC key to enter menu, use RIGHT/LEFT key to change the number, then enter the

menu 7 Set buzzer mode.

Press OK to enter settings screen, at this time it will display the present buzzer settings. Use

RIGHT/LEFT key to switch.

Displaying ON: operate to the clock, buzzer will have beep sound.

Displaying OFF: operate to the clock, buzzer will sound off.

Press OK to save the settings and exit the menu, also you can cancel it.

■This setting stored in the clock and can’t lose when power off.

■Even if the buzzer mode is OFF, the Alarm will always ringing.

Menu 8: Date interval of scrolling display

Press FUNC key to enter the menu, use RIGHT/LEFT key to change the number, and then

enter in menu 8 date interval of scrolling display.

Press OK to enter the settings screen, at this time it will display the present date interval of

scrolling display. Press digital number can set the time interval as 00-99 seconds.

Displaying 00 SEC, it means no alternate display for date.

Press OK to save the settings and exit the menu 8, and you also can cancel it.

■This setting stored in the clock and can’t lose when power off.

■If the time interval was beyond 0, the clock will displayed date for 3 seconds per N

seconds.

Menu 9: Temp interval of scrolling display

Press FUNC key to enter the menu, use RIGHT/LEFT key to change the numbers, and then

enter in menu 9 Temp interval of scrolling display.

Press OK to enter in settings screen, at this time it will display the temp interval settings.

Press digital number can set the temp interval as 00-99 seconds.

Displaying 00 SEC, it means no alternate display for temp.

Press OK to save the settings and exit the menu 9, and you also can cancel it.

■This setting stored in the clock and can’t lose when power off.

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

■If the time interval was beyond 0, the clock will displayed temp for 3 seconds per N

seconds.

Menu 10: Set auto power off Time

Press FUNC key to enter in menu, use RIGHT/LEFT key to change the number, and

then enter in menu 10 set auto power off time.

Press OK to enter settings screen, at this time it will display the time of auto power off, and

press digital number to set the time of auto power off.

Press OK to save the settings and exit the menu, press CANCEL to cancel it.

■This setting stored in the clock and can’t lose when power off.

■After settings, clock will have a long beep sound and back to the menu mode.

■When you set it, every number can be edit, but it will give up the settings only when

your set is not logical.

■When the time is reach off time, clock will display “ Auto OFF”three seconds, then

turn off automatically.

■When you want to see the time during the clock is in off time mode, please press

any digital number button, clock will display the time three seconds.

■In off time mode, you can set the time same as the power on mode.

Menu 11: Set auto power on Time

Press FUNC key to enter in menu, use RIGHT/LEFT key to change the number, and

then enter in menu 11 set auto power on time.

Press OK to enter settings screen, at this time it will display the time of auto power on, and

press digital number to set the time of auto power on.

Press OK to save the settings and exit the menu, press CANCEL to cancel it.

■This setting stored in the clock and can’t lose when power o f f.

■After settings, clock will have a long beep sound and back to the menu mode.

■When you set it, every number can be edit, but it will give up the settings only when

your set is not logical.

■When the time is reach on time, clock will display the time immediately

■When you want to close the auto power off function, you can set the time same as

the auto power on time

IV-18(ИВ-18)VFD Tube Clock Instructions Http://www.nixieclock.org

Timer Function

Under Display time mode, press ALARM key 3 times can enter in timer function.

When you enter in timer function, clock will adjust countdown time in acquiescent

condition for 1 hour. When the first character was ‘ o ’in the left side, it was stopped. Then you

can use the digital number to set the countdown time, it could be 00:00:01-99:59:59, that is 1

second to 99 hours 59 minutes and 59 seconds.

After settings successes, press OK, the clock will start the countdown function, at this time,

the first character in the left side will scrolling the icons.

When the time is over, clock will beep for four short times repeatly, at the same time the

screen flashes “00:00:00” , then you can press OK.

■When you set the countdown time, any number can be edit, but only when the

settings is logical the clock will be behave correctly, on the contrary it will have four

short beep.

■When the timer function working, the screen only display the countdown time, and

you can’t back to other display mode, unless you press OK to stop timer, then you

can back to other display mode, or you can press CANCEL to back to the main

screen.

Special function

In power off mode, press the following combination key will enter the special function.

8-3-7-7-OK check the present software version (present: v1.2.0)

4-6-4-8-OK restore the default settings but not the time and the date

8-3-7-8-OK test mode (you can press RIGHT/LEFT key to check the displaying of the

VFD tube is alright, and then press CANCEL to cancel it.)

Announcement

1. VFD tube is the product from 1980-1990, please don't compare its quality to modern

technology.

2. It is the normal situation when clock working it may produces heat.

3. Please check the Mini USB power line and the power supply when clock doesn't work.

■Any questions please contact me, it’ s my pleasure to answer your question

Table des matières

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

La Crosse Technology

La Crosse Technology WT-3141b Manuel

La Crosse Technology

La Crosse Technology W86531 Manuel utilisateur

Sharp

Sharp SPC900 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-50447 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur
