dexPro TH18W Fiche technique
4
PRODUCT INSTRUCTION MANUAL
1
SPECIFICATION:
Voltage rating: 110-130V, 220-240V / 50HZ
Power rating: 1.8kW
Temperature of wind: 60 C + 20 C
Weight: 3.0 KG
Velocity of wind: >15m / sec
Activating distance: >140 mm
DEXPRO LTD
Main telephone line 01244 631370
AUTOMATIC HAND DRYER
TH18W/TH18S
Warranty
This hand dryer has a 1 year warranty from the date of purchase for any manufacturing defect.
It covers replacement of defective parts, except when caused by improper use.
Before taking any action in the event of a fault, contact our customer service team who will assist
you. The products serial number and proof of purchase must be provided. In the event of a faulty
product, deXpro will replace faulty parts or at its sole discretion replace the product.
Labour costs and consequential losses are excluded.
Fig. 1
PLEASE READ ALL INSTRUCTIONS BEFORE USING
2
Thank you for purchasing the hand dryer. With greater emphasis on air flow and reduced
heat, the unit has high efficiency, with powerful concentrated air giving a short hand-dry me.
Please carefully read and understand these instrucons before commencing installaon and
leave them with the user when installaon is complete. It is an ideal choice for hotels,
household and public places.
APPLICATION:
1. Aer installaon of the hand dryer, connect the unit to power source and it will be in standby status.
2. When a hand reaches within 15cm range to the air outlet, the dryer will sense the hand and automacally
start to blow warm air. (The lamp will also be on at the same me). Blow your hands with the warm air
unl they are dry. The unit will stop working aer connuous operaon for 1 minute. To restart the unit,
put your hands again within the sensing range.
Important safety points
ŸThe Electrical installaon must be carried out by a qualified electrician in accordance with the current
edion of the I.E.E. Wiring Regulaons.
ŸThis appliance must be earthed.
ŸMeans for electrical disconnecon must be incorporated in the fixed wiring in accordance with the
wiring rules.
ŸAvoid spaering the product with water.
ŸThe hand dryer must be fixed out of reach of a person taking a bath or shower.
ŸThis appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilies or lack of experience and knowledge if they have been given supervision
or instrucon concerning use of the appliance in safe way and understand the hazard involved.
Children shall not play with the appliance. Cleaning and us1er maintenance shall not be made by
children without supervision.
ŸDo not cover the air inlet or outlet.
INSTALLATION:
Recommended installaon height (measured from air outlet to the floor): for man 1.2m, for woman
Ÿ
1.1m, for child 0.9m.
A 2-pole switch with contact gap >3mm must be installed before connecon to power source.
Grounding wire must be connected to the unit.
Hand
Dryer
Fig. 2
Fig. 4Fig. 3 An-the
screw hole
110~130V / 220 ~ 240V
Connector
Blower fan
Capacitance
Master
control plate
Temperature
control switch Heang wire
POWER SCHEME
OVERHEAT PROTECTION
The heater is protected with an overheat protector that switches off the heater automacally in case of
overheat. e.g. due to the total or paral obstrucon of the grills. In this case, unplug the appliance, wait
about 30 minutes for it to cool and remove the object which is obstrucng the grills. Then switch it back on
as described above.
MAINTENANCE
Always isolate the appliance from the power supply before commencing any maintenance.
Never use abrasive chemicals or materials when cleaning the unit.
Use a vacuum cleaner to clear the inlet and outlet vents of any dust or debris.
3
