Devolo MicroLink 56k PCI Manuel utilisateur

MicroLink

56k PCI

While the information in this manual has been compiled with great care, it may not be deemed an assurance of product

characteristics. devolo shall be liable only to the degree specified in the terms of sale and delivery.

The reproduction and distribution of the documentation and software supplied with this product and the use of its contents

is subject to written authorization from devolo. We reserve the right to make any alterations that arise as the result of

technical development.

You can find declarations and certifications of compliance for the products, as long as they were available at the time of

publication, in the appendix of this documentation.

Trademarks

Windows®and Microsoft®are registered trademarks of Microsoft, Corp.

The devolo logo is a registered trademark of devolo AG. All other names mentioned may be trademarks or registered trade-

marks of their respective owners.

Subject to change without notice. No liability for technical errors or omissions.

devolo AG

Sonnenweg 11

52070 Aachen

Germany

www.devolo.de

Aachen, April 2003

|devolo MicroLink 56k PCI |

Preface

Thank you for placing your trust in this devolo product.

With the MicroLink 56k PCI, you will be able to access the Internet and take

advantage of a variety of other data communications applications by using

the included software package.

Exacting manufacturing standards and stringent quality control are the basis

for high product standards and consistent quality to ensure your fullest satis-

faction with this modem.

About this manual

This manual will inform you about all aspects of your MicroLink 56k PCI and

help you get it operating. In addition, you will find some answers to fre-

quently asked questions in this manual.

This documentation was compiled by several members of our staff from a

variety of departments in order to ensure you the best possible support when

using your devolo product

Additional information in the Internet at 'www.devolo.de'.

Our online services www.devolo.de are available to you around the clock

should you have any queries regarding the MicroLink 56k PCI.

Package contents

Please ensure that the delivery is complete before beginning with the instal-

lation of your MicroLink 56k PCI:

MicroLink 56k PCI

Country-specific telephone connection cable

CD-ROM including manual, drivers, Norman firewall and virus scanner*

and BVRP communications software*

Installation guide (in print)*

devolo reserves the right to change the package contents without prior

notice.

* Additional software and the printed installation guide are only supplied with the retail product.

|devolo MicroLink 56k PCI |

CE conformity

This product meets the requirements of the 1999/5/EG Directive R&TTE and

is designed for connection to public telecommunications networks in the EU

and Switzerland.

The declaration of conformity can be found in the appendix of this manual.

|devolo MicroLink 56k PCI |

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1.1 V.92 standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.2 Communications software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.3 Firewall and virus scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.1 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2 Installation of the MicroLink 56k PCI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.3 Installation of drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.3.1 Installation under Windows 98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.3.2 Installation under Windows Me . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.3.3 Installation under Windows 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.3.4 Installation under Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3.2 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.3 Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

4 Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Introduction |

|devolo MicroLink 56k PCI |

1 Introduction

This chapter is intended to present you the MicroLink 56k PCI and its most

important features. It also includes a brief description of the communications

software Classic PhoneTools of BVRP* and the firewall and anti-virus soft-

ware Norman Internet Control*.

1.1 Features

The MicroLink 56k PCI card for the PCI bus supports all modern data commu-

nications applications: Internet downloads at up to 56,000 bps, sending and

receiving faxes and home banking are just as easy to use as e-mail or home

shopping. The use of the PCI bus ensures ease of installation with true

plug&play.

1.1.1 V.92 standard

Your MicroLink 56k PCI card also supports the following features of the V.92

standard:

Much faster initiation of dial-up connections

The dial-up sequences to the Internet Service Provider (ISP) are tempora-

rily saved in quick connect to speed up the establishment of a new con-

nection.

V.44 data compression

Data throughput can be increased by a factor of six, e. g. when downloa-

ding web sites.

Please note that your telcommunications and Internet service provider must

offer the V.92 standard before you can use these features with your

MicroLink 56k PCI!

|Introduction 7

|devolo MicroLink 56k PCI |

1.2 Communications software*

The MicroLink 56k PCI is supplied with the BVRP software package Classic

PhoneTools. Classic PhoneTools is a communications program which pro-

vides you with the most important data communications applications in a

convenient, easy-to-use package.

The included software Classic PhoneTools provides the following features in

conjunction with your modem:

fax operation: send and receive up to 14,400 bps

answering machine

address book (e.g. fax and telephone numbers)

1.3 Firewall and virus scanner*

The MicroLink 56k PCI is supplied with the Norman Internet Control software.

Norman Internet Control is a firewall and anti-virus program that monitors

your PC for malicious software, also referred to as malware. The most com-

mon types of malware are viruses, worms, and trojans. For the sake of sim-

plicity, we often use the term virus as a collective description.

Norman Internet Control can detect and remove known and unknown viruses

from hard disks, floppy disks, e-mail attachments, etc. Norman Internet Con-

trol checks files when they are accessed, and possible viruses are removed

automatically. If Norman Internet Control is unable to clean an infected file,

you will receive a warning and instructions on how to proceed.

*Additional software is only supplied with the retail product.

Installation |

|devolo MicroLink 56k PCI |

2 Installation

This chapter is intended to help you activate your MicroLink 56k PCI. You will

find a brief description of the installation procedure under Windows 98, Win-

dows Me, Windows 2000 and Windows XP.

2.1 System requirements

Your computer must meet the following requirements to operate with your

MicroLink 56k PCI:

Operating systems: Windows 98, Windows Me, Windows 2000 or

Windows XP

Free PCI slot

2.2 Installation of the MicroLink 56k PCI

Disconnect the AC power cable and the connection to the telephone

network before opening your computer. This is necessary to ensure that

the device is no longer live.

Do not touch any electronic parts! Static charges could destroy the elec-

tronics. You should, therefore, briefly touch the computer housing to

discharge any static electric charge built up on your body.

햲The first step

Safety First! Disconnect the power cord from the PC before removing the

housing. The PC card may only be installed or removed if the PC has been

disconnected from the AC power supply.

햳Loosen the screws

Loosen the retaining screws on the housing and remove it.

햴Remove the blind bracket

Remove the blind bracket of a free PCI slot.

햵Insert the MicroLink 56k PCI card

Plug your PCI card into the slot. Ensure that the PCI card is correctly sea-

ted in its slot and tighten the screw of the mounting plate.

햶Replace PC housing

Replace the housing and screw it tight.

|Installation 9

|devolo MicroLink 56k PCI |

Close the PC before connecting it to the telephone network! Make

sure that the case of the PC has been closed properly before connecting it to

the telephone network.

햷Connection to the telephone network

Connect the included connection cable to the socket on the mounting

bracket and the appropriate telephone line socket.

햸Connection to AC power

Reconnect the power cord to your computer and switch the computer on.

햹Installing the drivers

Continue by installing the drivers as described for the corresponding ope-

rating system.

Deinstallation is performed in the reverse order.

2.3 Installation of drivers

Plug&play installation

The MicroLink 56k PCI supports plug&play. Plug&play simplifies the installa-

tion considerably. Windows wizards will guide you through the installation

and asked you for required data.

There are differences between the installation procedures for the described

Windows versions. The driver installation will be described separately for

each version for the sake of clarity.

2.3.1 Installation under Windows 98

햲Restart your computer after inserting the PC card.

햳Insert the supplied devolo product CD into your CD-ROM drive.

햴Windows starts the hardware wizard and reports that new hardware has

been detected. Confirm this message with Next.

햵Windows offers you two different ways of searching for drivers. Select

the 'Search for the best driver for your device (Recommended)' option and

click Next.

햶The suitable driver can be found on the devolo product CD. Activate the

'CD-ROM drive' option and deactivate all other boxes. Confirm with

Next.

Installation |

|devolo MicroLink 56k PCI |

햷When the driver 'PCI Modem Enumerator' has been found, confirm by

clicking Next in order to initiate installation.

햸In the subsequent dialog box, click Finish.

햹Windows detects the MicroLink 56k PCI card. Confirm this message with

Next.

햺Windows offers you two different ways of searching for drivers. Select

the 'Search for the best driver for your device (Recommended)' option and

click Next.

햻The suitable driver can be found on the devolo product CD. Activate the

'CD-ROM drive' option and deactivate all other boxes. Confirm with

Next.

햽Confirm the search results with Next. Windows will install the driver.

햾When the wizard is ready, click Finish.

햿Windows detects the 'Wave Device for Voice Modem'. Confirm this mes-

sage with Next.

The modem is entered in the Device Manager as 'MicroLink 56k PCI' and as

audio device with the 'Voice Modem Serial Wave Device' hardware compo-

nent to ensure voice functionality.

헀Windows offers you two different ways of searching for drivers. Select

the 'Search for the best driver for your device (Recommended)' option and

click Next.

헁The suitable driver can be found on the devolo product CD. Activate the

'CD-ROM drive' option and deactivate all other boxes. Confirm with

Next.

헂Finally, exit the installation by clicking Finish.

2.3.2 Installation under Windows Me

햲Restart your computer after inserting the PC card.

햳Insert the supplied devolo product CD into your CD-ROM drive.

햴Windows starts the hardware wizard and reports that new hardware has

been detected. The wizard offers you two different ways of searching for

Autres manuels pour MicroLink 56k PCI

Table des matières

Autres manuels Devolo Carte PCI

Devolo

Devolo ADSL PCI Manuel utilisateur

Manuels Carte PCI populaires d'autres marques

ERMA

ERMA SSI 1417 Manuel utilisateur

SIIG

SIIG CyberSerial Dual PCI Instructions de montage

Moxa Technologies

Moxa Technologies CP-102E Manuel utilisateur

I-Bus

I-Bus IBC2602 Manuel utilisateur

Exsys

Exsys EX-60102 Manuel utilisateur

Chelsio Communications

Chelsio Communications T5 Series Manuel utilisateur

Conrad Electronic

Conrad Electronic 97 46 71 Manuel utilisateur

Micro Innovations

Micro Innovations USB650A Manuel utilisateur

KTI Networks

KTI Networks KF-310 Manuel utilisateur

Asus

Asus SpaceLink WL230 Manuel utilisateur

SIIG

SIIG SC2475 Manuel utilisateur

TRENDnet

TRENDnet TEW-703PI Manuel utilisateur

Belkin

Belkin F5D7000F Manuel utilisateur

Pericom

Pericom PI7C7100 Manuel utilisateur

ADLINK Technology

ADLINK Technology cPCI-3548 Manuel utilisateur

Digium

Digium TE200 Series Manuel utilisateur

Allo.com

Allo.com 2nd Gen E1/T1/J1 Manuel utilisateur

Western Digital

Western Digital FireWire PCI Adapter Manuel utilisateur
