Devolo Magic 2 LAN1-1 Manuel utilisateur

Manual

devolo Magic 2 LAN 1-1

devolo Magic 2 LAN1-1

While the information in this manual has been compiled with great care, it may not be deemed an assurance of product characteristics. devolo shall be liable only

to the degree specified in the terms of sale and delivery.

The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is subject to written authorization from

devolo. We reserve the right to make any alterations that arise as the result of technical development.

Trademarks

Android TM is a registered trademark of Open Handset Alliance.

Linux®is a registered trademark of Linus Torvalds.

Ubuntu®is a registered trademark of Canonical Ltd.

Mac®and Mac OS X®are registered trademarks of Apple Computer, Inc.

iPhone®,iPad® and iPod®are registered trademarks of Apple Computer, Inc.

Windows®and Microsoft®are registered trademarks of Microsoft, Corp.

devolo, dLAN®and the devolo logo are registered trademarks of devolo AG.

All other names mentioned may be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability for technical errors

or omissions.

devolo AG

Charlottenburger Allee 67

52068 Aachen

Germany

www.devolo.com

Aachen, September 2018

Version 1.0

devolo Magic 2 LAN

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.3 CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.4 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.5 devolo on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.1 devolo Magic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2.2 The devolo Magic 2 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.3 Pairing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.3.1 Reading the indicator light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.3.2 Network connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.3.3 Integrated electrical socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3 Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.1 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.2 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3 Connecting the devolo Magic 2 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.3.1 Starter Kit – Automatic set-up for a new devolo Magic network . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.3.2 Addition – Expanding an existing network by adding another devolo Magic adapter . . . . . . . . . . 19

3.3.3 Changing the network password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.4 Installation of devolo software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.5 Removing the devolo Magic adapter from a network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

devolo Magic 2 LAN

4 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.1 Calling up the built-in web interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.2 Menu description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.2.2 PLC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.2.3 LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.2.4 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.2.5 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

5 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5.1 Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5.2 Bandwidth optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

5.3 Disposal of old devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

5.4 Warranty conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Preface 6

devolo Magic 2 LAN

1Preface

Welcome to the fantastic world of devolo Magic!

In no time at all, devolo Magic transforms your house into a

multimedia home that is ready for the future today.

devolo Magic gives you noticeably higher speeds, more stabi-

lity and greater range, providing the perfect Internet experien-

ce as a result!

1.1 About this manual

Carefully read all instructions before setting up the device and

store the manual and/or installation guide for later reference.

After a brief introduction to „devolo Magic“ and to the

devolo Magic 2 LAN in Chapter 2, Chapter 3 tells you how to

successfully start using the adapter in your network.

Chapter 4 describes in detail the setting options of the built-in

configuration interface.

Tips for bandwidth optimisation, information about environmen-

tal compatibility of the device, as well as our warranty terms, can

be found in Chapter 5 at the end of the manual.

Description of the icons

This section contains a brief description of the icons used in this

manual and/or on the rating plate, the device connector, as well

as the icons used on the package:

Icon Description

Very important safety symbol that warns

you of imminent electrical voltage which if

not observed can result in serious injury or

death.

An important safety symbol that warns you

of a potentially dangerous situation involv-

ing a burn hazard which can result in minor

injuries or damage to property.

An important note that should be observed

which can potentially lead to material dam-

ages.

The device may only be used indoors in dry

conditions.

7 Preface

devolo Magic 2 LAN

1.2 Intended use

Use devolo products, devolo software and the provided accesso-

ries as described to prevent damage and injury.

Products

devolo products are communication devices designed for in-

doors.* Depending on the product, they are equipped with a

PLC-(PowerLine Communication) and/or a Wi-Fi module. Com-

puters, laptops, smartphones, tablets, smart TVs and other de-

vices connected this way are integrated into a home network over

the existing electrical wiring and/or Wi-Fi without any complica-

ted wiring. devolo devices must never be used outdoors because

the high temperature fluctuations and moisture can damage both

the product and the power line. devolo products may not be in-

stalled at a height above two metres unless an additional fas-

tening mechanism is available. The products are intended for

operation in the EU, Switzerland and Norway.

* The only exceptions are devolo outdoor products, which are sui-

ted for the outdoor use thanks to their IP certification.

Software

devolo devices can be used only with the free, downloadable

programs approved and available on devolo AG's website

(www.devolo.com) and in app stores (iOS and Google Play). Any

modifications to the product-specific firmware or software could

damage the products and, in the worst-case scenario, render

them unusable and negatively affect conformity.

Always use the most up-to-date software version to make sure

you have the latest security functions and device updates. The in-

stalled devolo software notifies you automatically if a new soft-

ware version is available.

The manufacturer/distributing company

uses the CE marking to declare that the

product meets all applicable European reg-

ulations and has been subjected to the pre-

scribed conformity assessment procedures.

It is used to prevent the occurrence of waste

electrical and electronic equipment and to

reduce this type of waste through reuse,

recycling and other forms of utilisation. The

European Community WEEE Directive estab-

lishes minimum standards for handling

waste electrical and electronic equipment in

the EU.

Additional information, background mate-

rial and configuration tips for your device.

Indicates a completed course of action

Icon Description

Preface 8

devolo Magic 2 LAN

Accessories

Use only the provided accessories:

쎲Network cable: RJ45-RJ45 Cat-5e UTP

1.3 CE Conformity

This product complies with the technical requirements

of the directives 2014/35/EU, 2014/30/EU, 2011/65/

EU und 2009/125/EC.

This product is designed for use in the EU,

Switzerland and Norway.

A printout of the simplified CE declaration of this product is sepa-

rately included and can also be found under

www.devolo.com/support/ce.

1.4 Safety notes

It is essential to have read and understood all safety and opera-

ting instructions before the devolo device is used for the first time;

keep them safe for future reference.

DANGER!

Electrical shock caused by electricity

Do not reach into the electrical socket, do not open

the device and do not insert any objects into the

electrical socket or into the ventilation openings

Users do not need to carry out any maintenance on devolo de-

vices. In the event of damage, disconnect the devolo device from

the mains supply by pulling it or its plug out of the electrical soc-

ket. Then contact qualified specialist personnel (after-sales ser-

vice) exclusively. Damage is deemed to have occurred, for

example,

쎲if the power plug is damaged.

쎲if the devolo device has been showered with liquid (such as

rain or other water).

쎲if the devolo device is inoperable.

쎲if the housing of the devolo device is damaged.

Do not plug devolo devices directly into each other. De-

vices that are plugged into each other can experience a

decrease in transmission rate.

DANGER!

Electric shock caused by electricity

Device must be plugged into a power socket with a

connected earth wire

devolo devices may be operated only on a mains power supply

as described on the rating plate.

To disconnect devolo devices from the mains supply, unplug the

device from the electrical socket.

The power socket and all connected network devices should be

easily accessible so that you can pull the power plug quickly if

needed.

9 Preface

devolo Magic 2 LAN

CAUTION!

Heat development during operation

Certain housing components can become very hot in

certain situations. Attach device so that it is touch-

proof, observing optimal positioning

devolo devices should only be installed at locations that

guarantee adequate ventilation. Slots and openings on

the housing are used for ventilation:

쎲Do not cover devolo devices during operation.

쎲Do not place any objects on devolo devices.

쎲Do not insert any objects into the openings of devolo

devices.

쎲devolo devices must not be placed directly next to a naked

flame (such as fire or candles).

쎲devolo devices must not be exposed to direct heat

radiation (e.g. radiator, direct sunlight).

CAUTION!

Damage to housing from cleaning agents

containing solvents

Clean only electroless and with dry cloth

1.5 devolo on the Internet

For detailed information on our products and devolo Magic, visit

www.devolo.com.

There you will find product descriptions and documentation, and

also updates of devolo software and your device's firmware.

If you have any further ideas or suggestions related to our prod-

ucts, please don't hesitate to contact us at [email protected]!

Introduction 10

devolo Magic 2 LAN

2Introduction

2.1 devolo Magic

Home is where devolo Magic is – in no time at all,

devolo Magic transforms your house or flat into a multimedia

home of the future with noticeably higher speed, more stability

and greater range, providing the perfect Internet experience as a

result!

Be inspired by products that are astonishingly easy to install, with

impressive, innovative technology and unbeatable performance.

The product name concept

The devolo Magic 2 LAN 1-1 name concept has the following

structure:

Be ready for the technology of the future today

devolo Magic embodies the new generation of the tried-and-test-

ed Powerline technology (PLC) based on the cutting-edge G.hn

architecture. G.hn was developed by the International Telecom-

munication Union (ITU) with ongoing development provided pri-

marily by the HomeGrid Forum industry association.

devolo Magic products are certified according to HomeGrid

standards and are compatible with other HomeGrid-certified

products.

Like the HomePlug AV technology used in established devolo

dLAN devices, devolo Magic uses the household mains supply for

data transmission and secures ideal performance and stability in

locations where network cables are not viable or desired and/or

the WiFi frequently falls short due to ceilings and walls.

Fig. 1 devolo Magic throughout the home

Product family devolo Magic

Performance category 2

Transmission type LAN (Ethernet)

Number of sockets 1

Integrated electrical socket 1 (= yes)

Autres manuels pour Magic 2 LAN1-1

Table des matières

Autres manuels Devolo Contrôleurs

Devolo

Devolo Magic 1 LAN1-1 Manuel utilisateur

Manuels Contrôleurs populaires d'autres marques

Digiplex

Digiplex DGP-848 Mode d'emploi

YASKAWA

YASKAWA SGM series Manuel utilisateur

Sinope

Sinope Calypso RM3500ZB Manuel utilisateur

Isimet

Isimet DLA Series Style 2 Manuel d'installation

LSIS

LSIS sv-ip5a Manuel utilisateur

Rockwell Automation

Rockwell Automation 1769-L31 Manuel utilisateur

Airflow

Airflow Uno hab Manuel utilisateur

ABB

ABB ACS580-01 drives Manuel utilisateur

Panasonic

Panasonic GM1 Series Manuel utilisateur

Emerson

Emerson SW93 Manuel utilisateur

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuel utilisateur

Panasonic

Panasonic FP? Positioning Unit RTEX Manuel utilisateur

Samson

Samson Type 5824 Manuel de service

Alpha IP

Alpha IP MIOB 21001 Manuel utilisateur

Siemens

Siemens OpenAir GMA 1 Series Manuel utilisateur

Surecom

Surecom SR-629 Manuel utilisateur

Fishman

Fishman TriplePlay Manuel utilisateur

Regulus

Regulus SRS1 T Manuel utilisateur
