Devolo BPL Modem MV Manuel utilisateur
devolo
BPL Modem MV
BPL Modem MV
© 2017 devolo AG Aachen (Germany)
While the information in this manual has been compiled with great care, it may not be deemed an assurance of product characteristics. devolo
shall be liable only to the degree specified in the terms of sale and delivery.
The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is subject to written
authorization from devolo. We reserve the right to make any alterations that arise as the result of technical development.
Trademarks
devolo and the devolo logo are registered trademarks of devolo AG.
EICHHOFF and the EICHHOFF logo are registered trademarks of EICHHOFF Kondensatoren GmbH.
All other names mentioned may be trademarks or registered trademarks of their respective owners. Subject to change without notice. No liability
for technical errors or omissions.
devolo AG
Charlottenburger Allee 60
52068 Aachen
Germany
www.devolo.com/smart
Aachen, May 2017
Version 1.0_May 2017
devolo BPL Modem MV
Contents
1 Intended use............................................................................................................................................ 5
2 Important safety notes ............................................................................................................................ 6
3 Installation .............................................................................................................................................. 6
4 Description of the connections ............................................................................................................... 7
5 Broadband Powerline communication (BPL) .......................................................................................... 8
6 Package contents .................................................................................................................................... 8
7 Basic structure of a BPL network in the medium-voltage infrastructure area ...................................... 9
8 Using the modems in the factory defaults ............................................................................................ 11
9 Management software properties ........................................................................................................ 13
10 Example application .............................................................................................................................. 14
11 Setting up the modem ........................................................................................................................... 17
12 Medium-voltage signal coupler installation ......................................................................................... 26
devolo BPL Modem MV
5
This manual describes the properties,handling and basic installation steps. Carefully read all in-
structions before initial use of the device and store the manual for later reference.
Icons
This section contains a brief description of the icons used in this manual.
Very important note. Failure to observe this note may result in damage.
Important note that should be observed.
1 Intended use
Ensure that the BPL Modem MV is used according to its intended use in order to prevent damage
to this or other devices:
The intended use of the BPL Modem MV is the implementation of a PLC network of SMART GRID
devices in the medium-voltage grid in combination with inductive or capacitive medium-voltage sig-
nal couplers.
The BPL Modem MV is intended for installation on the DIN rail. The device is intended for blackout-
safe operation using a (network buffered) 24V DC nominal accumulator.
1.1 CE conformity
The product conforms to the requirements from the directives
쎲2014/35/EU
The product is intended for operation in the EU, Switzerland and Norway.
This product is a Class A device.
쎲RoHS 2011/65/EU
쎲ErP 2009/125/EC and the other relevant provisions of the Radio and Telecommunications Ter-
minal Equipment Act (FTEG).
You can find the CE declaration for the product online at www.devolo.com/smart.
1.2 Disposal of old devices
The WEEE Directive 2012/19/EU is used to prevent the occurrence of waste electrical and
electronic equipment and to reduce this type of waste through reuse, recycling and other
forms of utilisation. It establishes minimum standards for handling waste electrical and
electronic equipment in the EU.
devolo BPL Modem MV
6
1.3 devolo on the Internet
For detailed information on our products, visit www.devolo.com/smart.
The download area provides you not only with product descriptions and documentation, but also
updates for devolo software.
If you have any further ideas or suggestions related to our products, please don't hesitate to contact
2 Important safety notes
It is essential to have read and understood all safety and operating instructions before the device is
used for the first time; these should then be kept safe for future reference.
Installation may only be carried out upon instruction of the respective pow-
er company and by an installation company registered in the power compa-
ny's installation directory.
If possible, install the device when it is de-energised. Be aware of the rele-
vant safety instructions, otherwise there is risk of electric shock or electric
arcing (risk of burns).
The line properties and cross-sections for connecting the BPL Modem MV
must be selected based on the fuse protection. The current value of the fuse
protection should be 2A.
Additional restrictions on installation authorisation may apply at the in-
tended installation location. This requires co-ordination with the associat-
ed power company.
3 Installation
Install the BPL Modem MV properly on the top-hat rails. Take into account the vertical installation
alignment of the BPL Modem MV so that the mains power supply comes from below and the label
is legible in an upright position.
devolo BPL Modem MV
7
4 Description of the connections
ASupply voltage connection – Connect the terminals to the corresponding DC current power
supply conductors here.
BA Part modem A BNC connection – Connect the BNC connections to the corresponding BNC
feed line to the medium-voltage signal couplers.
BB Part modem B BNC connection: Connect the BNC connections to the corresponding BNC
feed line to the medium-voltage signal couplers.
DA RJ45 Ethernet jack of part modem A – RJ45 Ethernet jack part modem A for the connec-
tion of compatible Ethernet devices over an RJ45 Ethernet cable.
DB RJ45 Ethernet jack of part modem B – RJ45 Ethernet jack part modem B for the connec-
tion of a compatible Ethernet device over an RJ45 Ethernet cable.
CA Back-To-Back connection of modem A – connect the BPL Modem MV to CB using the
included RJ45 patch cable.
CB Back-To-Back connection of part modem B – connect the BPL Modem MV to CA using
the included RJ45 patch cable.
EA Part modem A control display – is illuminated steady GREEN as soon as part modem A
has a PLC data connection.
EBPart modem B control display – is illuminated steady GREEN as soon as part modem B has
a PLC data connection.
Fig. 1: Description of the connections
devolo BPL Modem MV
8
5 Broadband Powerline communication (BPL)
Broadband Powerline communication (BPL) for low-voltage and medium-voltage power line infra-
structure is a reliable and secure technology for smart grids. It enables data connections for auto-
mation, control and monitoring in almost real time using the electrical wiring without the need to
route data cables.
The BPL Modem MV works with a data transmission method in accordance with the international
data transmission standard IEEE1901 and was specifically developed for the interference-resistant
inductive EICHHOFF signal coupler technology.
For this purpose, high-frequency currents with a smaller amplitude for data transmission are mod-
ulated directly onto the operating company mains.
The possible transmission paths between medium-voltage switchgear are up to approximately
800 m in conjunction with interference-suppressing, inductive EICHHOFF signal couplers and can
be expanded at any time by bridging the BPL Modem MV.
Data connections can be run so that they are blackout-safe via the BPL Modem MV thanks to the
provided (network buffered) DC power supply from the accumulators of 24V DC nominal.
6 Package contents
The following components are contained within the devolo BPL Modem MV scope of delivery:
쎲devolo BPL Modem MV
쎲slim RJ45 patch cable, 10 cm
쎲Installation flyer
Fig. 2: BPL medium-voltage ring
devolo BPL Modem MV
9
7 Basic structure of a BPL network in the medium-volt-
age infrastructure area
A BPL network in the infrastructure area is always set up as a point-to-point data connection be-
tween switchgear and cable distribution points. This is fundamentally different than the PLC net-
works in the low-voltage area.
The primary goal of a BPL network in the medium-voltage infrastructure area is the maximum reli-
ability of the data connection between switchgear and cable distribution points. A particularly high
transmission rate is only of secondary importance.
The basic structure of a BPL network designed for the reliability of the data connection in the
infrastructure area is to be illustrated based on a typical example from the medium-voltage
infrastructure area:
An open switch in the medium-voltage switchgear interrupts the Powerline
communication on the corresponding strand.
The BPL overall network is divided into route-related subnets in order to arrive at a clearly defined
structure:
The great advantage of splitting the overall BPL network into route-related subnets is that each
route-related subnet receives exactly one transmission task that can accurately be defined physically
and solved optimally on an individual basis.
Route-related subnet A connects the medium-voltage switchgear 4 and 1.
Route-related subnet B connects the medium-voltage switchgear 2 and 3.
Additional route-related subnets where the number is not limited.
The subnets are technically coupled to each other for data transmission using
RJ45 patch cables.
Fig. 3: BPL network
A
B
C
D
devolo BPL Modem MV
10
This is the only network architecture that makes it possible to fully utilize the inductive power cou-
pling with EICHHOFF signal couplers, which bundle the modem transmitting energy precisely to this
cable connection using a type of directional antenna.
The maximum reliability and range of BPL data connection is reached in combination with the si-
multaneously very high levels of suppression of interference signals via the EICHHOFF signal cou-
plers developed specifically for BPL.
The technical implementation of the data connection of individual subnets takes place
using what is known as bridging with a short RJ45 patch cable (see scope of delivery):
Fig. 4: Bridging
