Detectortesters Testifire XTR2 Manuel utilisateur

Testire XTR2

USER

MANUAL

detectortesters.com

EU: shift-consult Hubert Scherzinger

Hessenweier 9,79108 Freiburg, DE

Tel: +49 (0) 7665 91 21 74

No Climb Products Ltd.

163 Dixons Hill Road, Welham

Green. Hertfordshire, AL9 7JE,

United Kingdom

Tel +44 (0)1707 282 760

Testire XTR2

This product is intended to be used at height.

Exercise great care and always wear appropriate PPE

(personal protective equipment) when operating above

head height in order to avoid the risk of injury.

DO NOT OVER REACH. Keep proper footing and

balance at all times. Proper footing and balance

enables better control of the equipment in

unexpected situations.

Pay particular attention to avoid contact with overhead

items such as light ttings, overhead power cables and

any other objects that could be accidentally dislodged

which might cause danger to the operator or anyone

else in the vicinity.

Avoid prolonged, direct exposure to the vapour

generated by Testire XTR2. Safety Data Sheets for

the Testire XTR2 battery pack and Testire XTR2

Smoke Cartridge are available. It is recommended to

review the safety data sheets for Testire XTR2

Battery Pack and Testire XTR2 Smoke Cartridge

before use (see detectortesters.com).

This product contains hot parts.

DO NOT TOUCH the heat element. It may be very hot

immediately after use and may burn if touched.

Contains precision parts which may be easily damaged

and cause injury. DO NOT TOUCH the smoke uid

intake pipe in the smoke cartridge area or the heat

element in the tester cup.

Contains Lithium Ion rechargeable batteries:

• Do not dismantle, open, shred or incinerate

batteries.

• Do not expose batteries to heat or re. Avoid

storage in direct sunlight.

• Do not short-circuit a battery. Do not store bat-

teries loose in a box or drawer where they may

short-circuit each other or be short-circuited by

other metal objects.

• Do not subject batteries to mechanical shock.

• Keep batteries clean and dry.

• Do not use any charger other than that speci-

cally provided for use with the equipment. Refer

to the manufacturer’s instructions or equipment

manual for proper charging instructions.

• Do not leave a battery on prolonged charge when

not in use.

• Do not use any battery which is not designed for

use with this equipment.

• Do not use the battery in any other application.

• Keep batteries out of the reach of children.

• Dispose of properly.

CAUTIONS & WARNINGS

Warning Caution

Testire XTR2

• Read this User Manual completely before using your

Testire XTR2

• Keep this User Manual - save all safety and operational

instructions for future reference.

• Take note of the Warnings - Read carefully and follow all

warning labels on the product and those described in this

User Manual.

• Testire XTR2 is electronic test equipment and care

should be taken when handling and storing. Dropping the

unit on to a hard surface could damage it. Please look after

it, treat it with care for lasting use.

• This product is designed for indoor use only and should

not be subject to harsh environments. It is not designed

for use in hazardous areas (those containing explosive

vapour or dust). Do not use the equipment in places where

temperatures and/or humidity are high or go through

rapid changes including:

◦Direct sunlight

◦Near heat sources (stoves, radiators, etc.)

◦Sandy or dusty environments

◦In the presence of strong magnetic elds

◦Places prone to strong vibration

◦Restrictions detailed in the Technical Information (see

Section 12).

• Testire XTR2 may be used in ceiling and oor voids but

care must be taken to ensure that the unit and cup can

pass through gaps in both directions.

• Stop using Testire XTR2 immediately if you notice any

damage or unusual odours, liquids or sounds coming from

the unit. Turn the power off immediately and consult tech-

nical support and troubleshooting (see section 11).

• Use only approved accessories as described in this manual

that are recommended by the manufacturer for your Testi-

re XTR2 (see section 7).

• Testire XTR2 x1

• Testire smoke generator x1

• TES3 smoke cartridge x1

• Testire battery pack x1

• Battery charge cradle x1

• Mains power supply x1

• Car power adaptor x1

• Charger lead (USB-C to USB-C) x1

• Programming cable (USB-C to USB-A) x1

• Quick start guide

IMPORTANT

INFORMATION

KIT CONTENTS

WHAT’S IN THE BOX?

Testire XTR2

Cautions and warnings 2

Important information 2

Kit Contents – What’s in the box? 3

1. General Instructions 6

1.1 Warranty 6

1.1 Acknowledgement 6

1.2 Recycling 6

1.3 Declarations & Certications 6

1.4 Privacy Policy 6

2.  TestireXTR2Introduction       7

3.  Preparationforrstuse        8

3.1 Charging the Battery 8

3.2 Installing the Generator 8

3.3 Inserting the smoke cartridge 9

3.4 Inserting the Battery 9

4.  UsingTestireXTR2        10

4.1 Attaching Testire XTR2 to Solo Access Poles 10

4.2 Powering on Testire XTR2 10

4.3 LED Indicator Reference Chart 11

4.4 Adjusting the Head Unit Angle 11

5. Performing a Test 12

5.1 Default Smoke Test 12

5.2 Heat Test 13

5.3 Combined Test 14

5.4 Sequential Test 15

5.5 Clearing a Detector 16

5.6 Delayed Start 16

5.7 Using the LED Torch 16

5.8 Manual Purge 17

5.9 Device Settings 17

6.  ASDAdaptor–TestingASDSystemsandFlatDetectors    18

6.1 Testing an ASD System or Flat Detector 18

6.2 Installing the ASD Adaptor 18

6.3 Testing with the ASD Adaptor 18

7.  RemovingandReplacingConsumables      19

7.1 Removing the Smoke Cartridge 19

7.2 Replacing the Smoke Cartridge 19

7.3 Removing the Smoke Generator 19

7.4 Replacing the Smoke Generator 20

7.5 Removing the Battery for Charging 20

7.6 Replacing the Battery 20

7.7 Removing and Replacing the Membrane 20

8.  DetectortestersCloudPortal       21

8.1 Registering a New Account 21

8.2 Verifying Your New Account 21

8.3 Registering and Purchasing a Subscription for Testire XTR2 22

8.3.1 Registering Testire XTR2 22

8.3.2 Purchasing a Subscription for Testire XTR2 22

8.3.3 Cancelling a Subscription 23

8.4 Managing Test Reports 23

8.5 Managing Technicians 23

8.6 Settings Menu 24

8.6.1 Uploading a Company Logo 24

8.6.2 Company Details 24

8.6.3 Prole Details 25

8.6.4 Changing Password 25

9.  DetectortestersConnectApp       26

9.1 Downloading the App 26

9.2 Signing In 26

9.3 Pairing your Testire XTR2 28

9.4 Creating a New Test Job 29

9.5 Performing a Test 30

CONTENTS

Testire XTR2

9.5.1 Aborted Tests 31

9.5.2 Changing Test Mode 32

9.5.3 Changing Alarm Signal Mode 33

9.5.4 Manual Clearing 33

9.5.5 Using the Delayed Start mode 34

9.6 Closing a Test Job 36

9.7 Sharing a Test Report 38

9.8 App Settings Menu 40

9.8.1 Edit Prole 40

9.8.2 My Companies 40

9.8.3 Change Email Address 40

9.8.4 Change Password 40

9.8.5 Error History 40

9.8.6 Push Notications 40

9.8.7 Vibration/Sound 40

9.8.8 Help 40

9.8.9 Give Feedback 41

9.8.10 Terms & Conditions 41

9.8.11 Privacy Policy 41

9.8.12 Deactivate Account 41

10.  ConsumablesandAccessories       42

11.  Troubleshooting         43

11.1 Device Error Codes 44

12.  Support&Technical        45

12.1 Maintenance 45

12.2 Technical Information 46

12.3 Support Contact 47

Testire XTR2

In addition to any other express warranty given in writing by

the Company in relation to the Goods, the Company warrants

that the Goods supplied under these terms and conditions will

be in accordance with the specication (if any) contained in the

Purchase Order, and will be free from defects in workmanship

and material for a period of 24 months from the date of deliv-

ery to the Buyer, or for a period of 24 months after the date

of sale by the Buyer to the nal customer, or for a period of 24

months from the date of rst registration with Detectortesters

Connect, whichever period is the shorter.

Testire™ is a registered trademark of No Climb Products Ltd.

All other brand names mentioned are trademarks or

registered marks of their respective holders, and are

hereby acknowledged.

Testire XTR2 and Detectortesters Connect are covered by the

Detectortesters (No Climb Products) privacy policy. Full details

of the policy can be found on the Detectortesters website.

https://www.detectortesters.com/privacy-policy/

This product and its associated components are fully compliant

with the following:

• CE (including EMC, LVD and RoHS)

• UKCA

• UL / ULC

Further details regarding declarations and certications are

available upon request. Please contact support@detectortest-

ers.com for more information.

The packaging can be easily separated into the following

materials:

• Cardboard (outer box)

• Cardboard (inner buffers, boxes)

• Polyethylene

• Plastic

Please dispose in line with local environmental requirements.

WEEE (Waste Electrical & Electronic Equipment) Regulations

Testire XTR2, accessories and batteries are suitably marked

to be recycled in accordance with your local environmental

requirements. Alternatively, these items may be returned to the

manufacturer via your reseller for disposal in compliance with

WEEE (Waste Electrical & Electronic Equipment) Regulations.

GENERAL INSTRUCTIONS

1.1 Warranty

1.1 Acknowledgement

1.4PrivacyPolicy

1.3Declarations&Certications

1.2 Recycling

Testire XTR2

TESTIFIRE XT2

INTRODUCTION

ThankyouforpurchasingtheTestireXTR2

multifunction Smoke-Heat Detector Tester.

This manual is designed to assist you to get the best

and most efcient use of the Testire XTR2 and

provides all the information required to perform

routine service and maintenance tasks with ease.

Testire XTR2 includes advanced technology that

simplies functional testing of smoke, heat and

multi-function detectors in the eld.

Design Features

1. Tester cup

2. Cup membrane

3. Standoff plate

4. Smoke outlet

5. Heater element

6. Proximity sensor

7. Optical LED reader

8. LED torch

9. Air inlet

10. Power button

11. LCD touch display

12. Status LED’s

13. Locking button

14. Battery pack

15. Smoke cartridge

16. Smoke generator

16 3

Testire XTR2

The battery is charged by tting the battery pack into the

charge cradle and connecting to a mains socket using the

supplied power adaptor (Fig. 1)

• Ensure the battery is fully charged before use.

• Do not charge the battery outside of the specied

operating temperature range (5-45°C).

• At low ambient temperatures (5-10°C), the battery

may not charge completely but may continue to indi-

cate that charging is in progress.

• If the battery pack detects that the temperature is

outside of the operational temperature range for

charging, a fault will be indicated by a red ashing LED.

• In the event of a battery charging fault, remove the

battery from the charging cradle, ensure the battery

is within the operational temperature range and retry

charging the battery.

• Open the back cover

• Remove protective packaging of generator. Do not

touch exposed electrical contacts.

• Insert generator rmly into recess, engaging clips 1 and

2 (see Fig.2)

• Once the generator is inserted, do not remove it until

indicated that a replacement is necessary.

• When replacing a generator, any dust or debris within

the Testire XTR2 housing can be removed using an air

duster. Any condensation can be removed by wiping

with a lint-free cloth.

• Empty generators may be returned to the manufacturer

via the reseller for environmentally friendly disposal

to comply with WEEE (Waste Electrical & Electronic

Equipment) Regulations.

PREPARATION FOR

FIRST USE

Priortorstuse:

3.1ChargingtheBattery

3.2InstallingtheGenerator

Figure 1

Figure 2

Read cautions on lithium Ion rechargeable

batteries before use (see page 2)

WARNING

Testire XTR2

• Remove the cartridge from bag.

• Do not insert the cartridge until the generator has been

fully tted to the main unit. See installing the Generator

section 3.2.

• Slide cartridge completely into the generator housing

following the guide rails (see Fig. 3)

• Once the cartridge is inserted do not remove it until

indicated that a replacement is necessary. Do not re-use

old cartridges.

• Empty cartridges may be returned to the manufacturer

via the reseller for environmentally friendly disposal

to comply with WEEE (Waste Electrical & Electronic

Equipment) Regulations.

• Once the battery is charged clip the battery pack into

the battery compartment (Fig. 4).

• Do not force the battery into place

• Do not install the battery before the Smoke Generator

and Smoke Cartridge

• Close the back cover before powering on

3.3Insertingthesmokecartridge 3.4InsertingtheBattery

Do not touch the contacts on the PCB on the

cartridge. Static electricity may cause damage and

contamination of the contacts must be avoided.

Do not touch the contacts on the battery. Static

electricity may cause damage and contamination

of the contacts must be avoided.

WARNING

Figure 3

Figure 4

Testire XTR2

Testire XTR2 is designed for use with the Solo range of access

poles (purchased separately). The product is not compatible

with alternative poles.

Take the Solo access pole and press down the locking button on

Testire XTR2. Align it with the location hole and push the

Testire XTR2 handle further into the pole until the button

springs up through the hole. Twist to lock (Fig. 5)

USING TESTIFIRE XTR2

4.1AttachingTestireXTR2toSoloAccessPoles

Figure 5

No more than three Solo 101 extension poles

should be used at the same time.

CAUTION

When working at height it is recommended that a

competent person carries out a suitable risk

assessment. This will identify any risk to the user

and/or the environment and hence any need for

Personal Protective Equipment.

WARNING

NOTE:

A Solo 101 extension pole can extend the Solo 100 and 108

telescopic poles, or may be used separately.

For further information on the correct use of poles, see

“instructions for Solo Poles” document in the support section

of detectortesters.com

https://www.detectortesters.com/manuals/

NOTE:

If Testire XTR2 has been left unused for a period of time

then a manual purge may be required.

With the generator, cartridge and battery securely tted and

the back cover closed, the unit can now be powered on. Power

the unit on by holding down the power button for 3 seconds.

NOTE:

After replacing a generator and powering on, a ‘purge cycle’ will

run. During this the sound of the pump operating may be heard.

This will last for approximately a few seconds after which, the

unit will be ready for use. If no smoke is observed during a test

a manual purge may be required (see section 5.8 for more detail

on how to perform a manual purge).

The unit is functioning correctly if the status indicator LED’s

are solid blue and a Smoke test is selected on the LCD display

(Fig. 6). If the status indicator LED’s are not solid blue refer to

the LED Reference Chart in section 4.3.

4.2PoweringonTestireXTR2

Figure 6

Smoke

Autres manuels pour testifire XTR2

Table des matières

Autres manuels Detectortesters Équipement de test

Detectortesters

Detectortesters Testifire 1001 Manuel utilisateur

Detectortesters

Detectortesters solo 365 Manuel d'utilisation et d'entretien

Detectortesters

Detectortesters Testifire 1000 Manuel

Detectortesters

Detectortesters testifie XTR2 Manuel utilisateur

Detectortesters

Detectortesters testifire XTR2 Manuel utilisateur

Manuels Équipement de test populaires d'autres marques

SMART

SMART KANAAD SBT XTREME 3G Series Manuel utilisateur

Agilent Technologies

Agilent Technologies BERT Serial Manuel utilisateur

Agilent Technologies

Agilent Technologies N3280A Manuel utilisateur

Vernier

Vernier Go Direct Voltage Manuel utilisateur

Lifeloc

Lifeloc R.A.D.A.R. Manuel utilisateur

Fluke

Fluke T5-600 Instructions d'utilisation et d'installation

Mercury

Mercury TSL01 Manuel utilisateur

MAHA

MAHA MBT Series Manuel utilisateur

Fuji Electric

Fuji Electric P-61 Manuel utilisateur

ETC

ETC SealerAtor Manuel utilisateur

Skyfine

Skyfine ETHYWAY V2 Manuel utilisateur

Appion

Appion G5 Twin Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 8159-0112A Manuel utilisateur

BW Technologies

BW Technologies MicroDock II Manuel utilisateur

Sun Nuclear

Sun Nuclear 1027 Manuel utilisateur

Biomark

Biomark HPR LITE READER Manuel utilisateur

Hioki

Hioki 3169-20 Manuel utilisateur

Ashcroft

Ashcroft ATE-100 Manuel utilisateur
