Detecto DL Series Manuel utilisateur

8529-0637-2M Rev A DL Series Operation Manual

DL Series

Price Computing Scale

with Integral Printer

Operation Manual

8529-0637-2M Rev A

203 E. Daugherty, Webb City, MO 64870 USA

11/15

Ph: 417-673-4631 Fax: 417-673-5001

www.detecto.com

Technical Support: Ph: 866-254-8261 [email protected]

8529-0637-2M Rev A DL Series Operation Manual

INTRODUCTION

Thank you for purchasing our Detecto DL Series Price Computing Scale with Integral Printer.

Your scale has been designed to operate from 115 VAC 50/60 Hz.

This manual will guide you through setup and operation of your scale. Please read it

thoroughly before attempting to operate this scale and keep it handy for future reference.

pictorial content, in any manner, is prohibited. No patent liability is assumed with respect to the

use of the information contained herein.

DISCLAIMER

While every precaution has been taken in the preparation of this manual, the Seller assumes

no responsibility for errors or omissions. Neither is any liability assumed for damages resulting

from use of the information contained herein. All instructions and diagrams have been checked

for accuracy and ease of application; however, success and safety in working with tools

depend to a great extent upon the individual accuracy, skill and caution. For this reason the

Seller is not able to guarantee the result of any procedure contained herein. Nor can they

assume responsibility for any damage to property or injury to persons occasioned from the

procedures. Persons engaging the procedures do so entirely at their own risk.

SERIAL NUMBER _____________________

DATE OF PURCHASE _________________

PURCHASED FROM __________________

____________________________________

RETAIN THIS INFORMATION FOR FUTURE USE

PRECAUTIONS

Before using this product, read this manual and pay special attention to all

"NOTIFICATION" symbols:

IMPORTANT

ELECTRICAL

WARNING

STATIC

SENSITVE

8529-0637-2M Rev A DL Series Operation Manual

PROPER DISPOSAL

When this device reaches the end of its useful life, it must be properly disposed of. It must not

be disposed of as unsorted municipal waste. Within the European Union, this device should

be returned to the distributor from where it was purchased for proper disposal. This is in

accordance with EU Directive 2002/96/EC. Within North America, the device should be

disposed of in accordance with the local laws regarding the disposal of waste electrical and

electronic equipment.

It is everyone’s responsibility to help maintain the environment and to reduce

the effects of hazardous substances contained in electrical and electronic

equipment on human health. Please do your part by making certain that the

device is properly disposed of. The symbol shown to the right indicates that

this device must not be disposed of in unsorted municipal waste programs.

FCC COMPLIANCE STATEMENT

This equipment generates, uses and can radiate radio frequency and if not installed and used

in accordance with the instruction manual, may cause interference to radio communications. It

has been designed within the limits for a Class A computing device pursuant to Subpart J of

Part 15 of FCC rules to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area may

cause interference in which case the user will be responsible to take whatever measures

necessary to correct the interference.

You may find the booklet "How to Identify and Resolve Radio TV Interference Problems"

prepared by the Federal Communications Commission helpful. It is available from the U.S.

Government Printing Office, Washington, D.C. 20402. Request stock No. 001-000-00315-4.

8529-0637-2M Rev A DL Series Operation Manual

TABLE OF CONTENTS

SPECIFICATIONS 

ABREVIATIONS AND GLOSSARY 

INSTALLATION 

Attachment of Tower Display 

Placement 

Level Adjustment 

Power Connection 

PRINTER 

Install Gap Labels 

Gap Paper Mounts Recycle 

Install Plain Paper 

Operations Concerning Paper 

Abnormity of Gap Paper Print 

KEYPAD FUNCTIONS 

DISPLAY ANNUNCIATORS 

Tare (lb) Window 

Weight (lb)/Pcs Window 

Change ($)/Unit $/lb Window 

Total Price ($) Window 

Dot Matrix Display 

OPERATION INDICATORS 

SET DATE, TIME AND STORE NAME 

FAST PLU PROGRAMMING 

QUICK KEY PROGRAMMING 

OPERATION 

Basic PLU Transaction 

By Weight 

By Count 

Tare 

Weight Tare 

Keypad Tare 

Lock and Unlock Tare 

Batch Print Mode (only for piece count PLU) 

Pre-Pack Mode (only for weight PLU) 

Temporary-Sale by Weight 

Temporary-Sale by Count 

Price Discount by Subtraction 

III

8529-0637-2M Rev A DL Series Operation Manual

TABLE OF CONTENTS, CONT.

REPORT PRINTING OPERATION 

Print Total Report 

Print PLU Report 

Clear Report Information Manually 

Clear All Reports and Records Information 

PRINT FORMAT 

BARCODE PRINTING 

ERROR CODES 

CARE AND CLEANING 

8529-0637-2M Rev A DL Series Operation Manual

SPECIFICATIONS

Models:

DL1030, DL1030P

Capacity

30 lb (15kg)

Division Value:

0 –30 lb x .01 lb (0 –15 kg x .005 kg)

Platform Size:

L x W = 12.8 x 8.9 in (324 x 226 mm)

Scale Size:

Integrated Rear Display

With Tower Display

L x W x H = 15.6 x 13.8 x 6.2 in (396 x 351 x 158 mm)

L x W x H = 17.6 x 13.8 x 18.3 in (448 x 351 x 464 mm)

Display:

4 Window LED display 1 Dot matrix Text screen

LED Display:

4 digits for tare

5 digit for weight,

6 digit for unit price

6 digit for total price

Power:

20VDC, 4A with positive center, AC adaptor

Operating Temperature:

32 ~ 104°F (0° ~ 40°C)

Printer:

Thermal Print

Print Media:

58mm x 40mm and 40mm x 30mm gap thermal paper

58mm and 40mm width plain thermal paper

PLU:

5990

8529-0637-2M Rev A DL Series Operation Manual

ABREVIATIONS AND GLOSSARY

PLU

Price or Product Look Up. e.g. Identification number affixed to produce

and other products

Weight PLU

By Weight PLU

Count PLU

By Count PLU

Dept.

Department

U. Price

Unit price

T. Price

Total Price

Prog

Program key or menu

F Prog

Fast program key or menu

Spec

Specification. Parameter that control the behavior of the scale

T-Sale

Temporarily Sale

Amount

The quantity of the goods, weight or count. It means weight (lb) for

weight PLU and count (pcs) for count PLU

8529-0637-2M Rev A DL Series Operation Manual

INSTALLATION

Included in carton find:

Scale

Tray - 2 pcs: plastic tray & metal top

Display pole and screw pack (DL1030P only)

Operation Manual

DL Series Setup Utility CD

Four (4) overlays for shortcut PLU

Power Cord

Attachment of Tower Display

Remove cover tower bracket on bottom of base. Place the tower display in close proximity to

the base. Connect tower cable to circuit board in base. Gently slide the tower post into the

bracket. Fasten the tower to base with two bolts provided. Replace bracket cover.

Placement

Place the scale in an environment free of excessive dust and moisture and on a stable,

vibration-free level surface away from direct sunlight and any rapidly moving air source

(heating/cooling vents, fans, etc.). This will prevent sudden temperature changes and air

currents that may result in unstable weight readings.

WARNING! DO NOT place the scale on any unstable cart, stand or table. The scale

may fall causing injury to the operator, and damage the unit, or proper operation of

the scale may be inhibited.

Level Adjustment

Check to make certain the scale is level. The level indicator is located at the front of the scale.

If the scale is not level (the bubble will not be centered), adjust the mounting feet as required to

center the bubble and attain a level scale.

Power Connection

The scale uses an external AC power cord that is to be used in a standard 110/120 VAC

50/60Hz grounded wall outlet.

8529-0637-2M Rev A DL Series Operation Manual

PRINTER

Install Gap Labels

1.Open Upper door

Step 1 - Open door of scale printer

Step 2 - Remove paper retainer

Step 3 - Paper through
