Derytech Shepherd Manuel utilisateur
Shepherd
User Guide
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 2
Contents
This user guide describes how to setup, install and operate the Shepherd. Please read it carefully before commencing
installation of the product.
Statement.............................................................................................4
FCC Interference Statement ........................................................................................4
FCC Radiation Exposure Statement ...........................................................................5
Manufacturer's Disclaimer Statement.........................................................................5
1. System Introduction........................................................................6
1.1 Features...................................................................................................................7
1.2 Configuration..........................................................................................................8
2. System Hardware..........................................................................10
2.1 Package Contents.................................................................................................10
2.2 Hardware Connections ........................................................................................ 11
2.3 LED Panel...............................................................................錯誤! 尚未定義書籤。
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 3
3. System Setup and Configuration ................................................15
3.1 Installing MagicLink ............................................................................................. 15
3.2 Configuring the WTX5800 Transmitter and WRX5800 Receiver.......................18
Re-configuring the WTX5800 Transmitter............................................................................... 18
Configuration Settings ............................................................................................................. 25
Re-configuring the WRX5800 Receiver................................................................................... 33
4. System Hardware Assembly and Installation.............................34
4.1 System Location...................................................................................................34
4.2 System Assembly.................................................................................................38
Before Commencing Installation .............................................................................................38
Pole Mounting ...........................................................................................................................39
Wall Mounting............................................................................................................................ 40
4.3 Aligning the Transmitter and Receiver...............................................................42
5. Trouble Shooting...........................................................................45
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 4
Statement
FCC Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
This 5.8GHz Wireless video system has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used according to the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which is found by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment or device.
zConnect the equipment to an outlet other than the Receiver's.
zConsult a dealer or an experienced radio/TV technician for assistance.
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 5
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 23cm between the radiator and your body.
Manufacturer's Disclaimer Statement
The information in this document is subject to change without notice and does not represent a commitment on the part
of vendor. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or
fitness for any particular purpose of this document. The manufacturer reserves the right to make change to the content
of this document and/or the products associated with it at any time without obligation to notify any person or
organization. In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential
damages arising out of the use or inability to use this product or documentation, even if advised of the possibility of
such damages. This document contains materials protected by copyright.All rights are reserved. No part of this
manual may be reproduced or transmitted in any form, by any means or for any purpose without express written
consent of its authors. Product names appearing in this document are mentioned for identification purposes only. All
trademarks, product names or brand names appearing in this document are registered property of their respective
owners.
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 6
1. System Introduction
The DeryTech Shepherd represents an all new, high performance, cost effective digital based wireless surveillance
camera transmission system. Offering exceptional bandwidth and serial data transmission, the Shepherd brings a
wireless capability to all traditional fixed cameras and supplies built-in remote control to PTZ dome cameras, providing
a first-rate solution for remote and hard-to-reach camera locations.
The Shepherd uses the latest digital wireless OFDM modulation in the less crowded (and unlicensed) 5GHz radio
band, providing transmission rates that significantly reduce signal interference and, being full-duplex, supplying a very
stable wireless link, which, combined with our image processing software, delivers hi-definition, full-motion, no-ripple
video up to 10 Km line-of-sight. Furthermore, the Shepherd offers considerably improved data security via either AES
or RC4 key encryption when used in conjunction with our proprietary MagicLink software, and it’s bi-directional,
full-duplex digital transmission allows the system to provide full joystick remote control of RS485 based PTZ cameras.
The Shepherd has also been designed for ease-of-use and flexibility. The MagicLink software makes configuring the
Shepherd a quick and simple task, allowing for the selection of personalized encryption keys, the setting-up of the PTZ
interface and a choice of transmission ranges for improved image quality. Where transmission of over 10 kilometers is
required or the signal path needs to change direction, two or more Shepherds can be connected in series using the
Repeater Mode. The Shepherd is also set-up to support Power over Ethernet (PoE), eliminating the need for an AC
power supply and associated cabling, making installation easier and cheaper.
Overall, the Shepherd provides a versatile, all-in-one wireless transmission solution for CCTV and traffic surveillance
needs, offering superb performance in all environments and weather conditions, and providing integrators and
installers with a system that is easy to set-up, simple to install and straight-forward to operate, whilst offering time and
money saving flexibility.
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 7
1.1 Features
zWireless transmission for real time video up to 10 Km
z5GHz OFDM for reduced interference
zData Rates of up to 54 Mbps
zFull Duplex provides a stable wireless link
zDigital Image Processing cuts out signal ripple and snow
zAdvanced security provided by either AES or RC4 key encryption
zProprietary serial data transmission mode for PTZ control
zUser-selectable transmission power and distance
zMagicLink software for system configuration
zSupports NTSC/PAL (D1 resolution at 30 fps)
zNo signal interference between cameras
zEasy installation and mounting
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 8
1.2 Configuration
Figure 1a A standard wireless configuration using the Shepherd.
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 9
DeryTech Shepherd -
Wireless Surveillance Camera Transmission System User Guide | 10
2. System Hardware
2.1 Package Contents
ShepherdTM Transmitter x 1, Receiver x 1
Antenna 23dBi panel antenna X 2
MagicLink CD-Rom
Power Adapter X 2
RCA/BNC Line Fully Assembled
User Manual Soft Copy
Warranty Card X 1
Mounting Brackets X 2 sets
NOTE: If any of the above items are damaged or missing,
please contact your dealer immediately.
