CORDLESS SCREWDRIVER
EN
Battery charge
ATTENTION!
The charger should only be connected to a single phase ac power the voltage of which
corresponds to the voltage indicated on the label.
Insert the charger into a power outlet and plug its plug into the socket ставьте 5 (рiс. 1). On indicator 2 (pic. 1), the
red segment will turn on, which indicates the ongoing charging process. When the battery reaches full charge,
indicator 2 (pic. 1) will light completely (three segments). During battery charging, no power is supplied to the
engine switch.
Installation and removal of the tooling
Installation of bit nozzles and an additional magnetic adapter on the output shaft of a screwdriver is performed
without any additional action. The socket is equipped with a magnet to prevent the tooling from falling out of the
socket.
Reversal of rotation
The direction of rotation of the spindle is changed by a switch 8 (рiс. 1). The switch has 3 xed positions. When
you press the switch on the right until it stops– right-hand spindle rotation is activated, when press to the left
- left-hand. Corresponding symbols are printed on the movable switch bar. The middle position of the switch
corresponds to the lock of the engine switch.
Speed adjustment
The cordless screwdriver is not equipped with a spindle speed control system. Work is carried out at a constant
speed indicated in the "Specications" section.
Illumination of the working area
LED backlight work area turns on simultaneously with the engine when you press the switch key. The backlight
turns o when you release the key.
Handle adjustment
For convenience during operation, the position of the main handle of the screwdriver can be changed. To do this,
press button 4 (pic. 1) and turn the handle 180 degrees. When you release the button, the handle is locked in one
of the two extreme positions.
NOISE AND VIBRATION
Noise and vibration characteristics are given in the table №1.
The noise and vibration levels specied in this manual is measured by measurement method, prescribed in the
standard, and can be used to compare. However, if the Electrical Rotary Hammer will be used for other work with
the use of working tools, not provided by the manufacturer, or maintenance will not meet the requirements, then
the vibration level may be dierent.
MAINTENANCE
- If you have noticed a decrease in the eciency of the tool, extraneous noise or smell then you must contact the
service center for timely diagnosis and repair.
- Tooling maintenance. The use of the worn working tool reduces the eectiveness of the work and may result
in motor or gearbox failure, so you need to sharpen periodically or replace worn removable tools, as soon as there
is a need.
