Denver BPS-455 Manuel utilisateur

Rechargeable Party Speaker

Denver BPS-455

BASS

BOOM

POWER

COLORS

LIGHTS

Specification:

10"+10" woofer

2" tweeter

Power: 72 W RMS

USB/Micro SD Card input

Aux-in, FM Radio

Bluetooth Connect, Recording

EQ (Pop-Rock-Jazz-Classical-Flat)

TWS function: Wireless connection, up to 2pcs speakers playing

together to double the sound.

Built-in 4,500 mA rechargeable battery

Play time: 1.5 hours at 100% volume

Charging time: 5-6 hours

MIC input, Guitar Input

Microphone priority

Different modes Disco light (controlled by top panel and remote

control)

BASS/Treble/Microphone Volume control/Microphone Echo

Product size: 33 x 28 x 84 cm

Product weight: 11.15 kg

What you have in pack:

- User manual

- Remote control

- Power cable

Top panel operation

1. Power switch(AC play- Power off-DC play)

2. USB play back

3. Micro SD card play back

4. Aux-in (3.5mm PIN line cable)

5. MIC input

6. Guitar input

7. Short press for the previous song, long press for fast backward

8. Play/pause under USB/Micro SD/BT. Long press this button to enjoy TWS

function.

TWS connection spec:

When you are playing a speaker (host) under USB/Micro SD/AUX/BT mode, at this

time you want another speaker to share this song. You can turn on a new speaker,

Long press “Play/pause” button, the LED display will show “SLAU” and keep blinking,

now it is searching for the host. Once host found, this new speaker will connect

automatically to the host, and “SLAU” will not blink. At this time 2pcs speakers are

playing the same song.

The new joining speaker can operate: play/pause - previous song-next song- volume

control

9 Next song: short press for next song, long press for fast forward.

10 Volume control: long press volume+/- to increase/decrease the LED light

11 MENU (control BASS/Treble/MIC Volume), long press this button to restore

factory settings

12 Microphone volume control

13 Mode switch

14 Microphone Echo +

15 Microphone Echo –

16 REPEAT one song, Loop Playback.

17 Press to get super bass effect

18 Microphone priority (when playing USB/Micro SD, press this button, and the

microphone volume will override songs in USB/Micro SD)

19 Short press to record songs from microphone to USB/Micro SD,;long press to

play recordings, and long press again to delete recordings

20 EQ effect switch

21 Press to get various LED light effects, short press for color changing, long press

and hold this button to change light modes. Or turn off the light. Press it again to

turn on LED light.

Remote control

1. Mute

Available to be mute at any mode

2. Previous Song

Under USB/Micro SD card mode - previous song.

Under BT connection mode- previous song.

3. Mode

Press short to skip to Wireless BT/LINE IN/USB/Micro SD mode.

4. Record function

Under USB/Micro SD card mode, press “REC” button to record

5. Echo-

6. BASS+/-

7. EQ function

8. Microphone Volume+/-

9. Stand by

10. Pause & Play

11. Next song

Under USB/Micro SD card mode - next song.

Under BT connection mode- next song.

12. Light mode control

Short press to change light color, press and hold this button to change light

mode, or off the light, press it again to turn the light on.

13. Repeat function

14. Record play

15. Record delete

16. Echo+

17. Microphone priority

If you speak via microphone when playing music, your sound will override the

sound in USB/Micro SD card

18. Treble+/-

19. Main Volume

20. Number buttons

Under USB/Micro SD mode to choose songs

OPERATING INSTRUCTIONS

●Wireless BT Pairing Mode:

Press MODE or the Blue button on the unit or the remote control until BT is selected.

1. Put the cell phone within 20 meters;

2. Activate the BT features on your cell phone so that the cell phone starts to search for BT

device. Please refer to the user manual for details

3. Select the correct model no. (BPS-455)The device found by the cell phone;

4. Short press PLAY/PAUSE button to play or pause music. Short press the “ ” or “ ”

key to select the previous or next track.

●LINE IN MODE:

Press the MODE button on the unit or the remote control until the LINE is selected. Play the

music of the device connected to the LINE input. Short press the “ ” key to the next

song

●FM RADIO MODE:

Press the MODE button on the unit or the remote control until FM is selected.

Press the “ ”key and the speaker will auto search, then the speaker will read

signal from 87.5MHz till 108MHz, if any frequency has signal, the unit will

remember it and store it as a channel. After the searching is done, short press

the “ ” key to the previous channel and the “ ” key to the next channel.

●USB Mode:

1. After start up, press MODE to select “USB”and insert the USB device. The unit will

automatically read and play the music in the USB device.

2. Press the “ ” key short to pause or play.

3. Short press the “ ” key to the previous song.

4. Short press the “ ” key to the next song.

Please notice - All products are subject to change without any notice. We take reservations for

errors and omissions in the manual.

Electric and electronic equipment and included batteries contains materials, components and

substances that can be hazardous to your health and the environment, if the waste material

(discarded electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can symbol,

seen above. This symbol signifies that electric and electronic equipment and batteries should not

be disposed of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the appropriate and

designated facility. In this manner you make sure that the batteries are recycled in accordance

with legislature and will not harm the environment.

All cities have established collection points, where electric and electronic equipment and

batteries can either be submitted free of charge at recycling stations and other collection sites, or

be collected from the households. Additional information is available at the technical department

of your city.

Hereby, Inter Sales A/S declares that the radio equipment type BPS-455 is in compliance with

Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the

following internet address: www.denver-electronics.com and then click the search ICON on

topline of website. Write model number: BPS-455.Now enter product page, and RED directive is

found under downloads/other downloads.

Operating Frequency Range: 2402MHz~2480MHz FM:87.5-108MHz

Max Output Power:72W

DENVER ELECTRONICS A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark
