Denver WCS-5020 Manuel utilisateur
Infrared Trail Camera
User's Manual
WCS-5020
Package List:
*Camera
*M unting Strap
*USB Cable
*User Manual
1
Parts Of The Camera
1. Display screen
2. IR lamps
3. Lens
4. Up/Vide Butt n
5. D wn/Capture Butt n
2
6. M ti n sens r
7. OK/Sh t butt n
8. Menu Butt n
9. Right butt n
10. Playback butt n
11. DC adapter p rt
12. Trip d Sl t
13. Micr SD card sl t
3
13. Battery c mpartment
14. ON-TEST-OFF butt n
15. USB jack
Power Supply
Please install batteries bef re using the camera. Unl ck the camera
and y u will find the battery c mpartment. Install 4 pieces f 1.5V
AA batteries. Please make sure the battery p larity is c rrect.
Inserting the Memory Card
•Please prepare a Micro SD card and insert it into the
camera for saving files. Before recording, please
format the memory card first.
•You are suggested to use a micro SD card up to 32 B
with class 6 or above high speed.
•To avoid malfunction, the memory card should be far
away from water, strong vibration, dust, hot source and
direct sunlight.
•Do not insert the memory card forcibly. Please refer to
the marking on the camera.
4
•For the first time of use, please wait for the memory
card temperature reach the ambient temperature. The
camera will be short-circuited by environment
temperature and humidity. Please protect the camera
when using it outdoor.
•If the capacity of memory card is full, the camera will
stop recording automatically.
•Press the edge of the card gently to pop-up the TF
card.
Basic Operation
Turn On / Off the Camera
•Switch the Mode Button to “Test /On” to turn on the
camera.
•Switch the Mode Button to “Off” to turn off the camera.
System Setup
Switch M de Butt n t “Test”, then y u can set the system
parameters.
1. Press Menu butt n t pen the setup menu.
5
2. Press Up/D wn butt n t scan all menus. Then press
OK butt n t enter the pti ns interface.
3. Press Up/D wn butt n t scan all pti ns. And press
OK butt n t c nfirm pti ns.
4. Press Menu butt n again t turn back t last menu r
exit the setup menu.
F ll wing bel w instructi ns t set up the menus and functi ns:
Mode
Set the w rking m de. In ph t m de, the camera just takes
pictures. In Vide m de, the camera just rec rds vide s. In
ph t & vide m de, the camera will take a ph t first, and then
rec rd a vide .
Opti ns: [Ph t ]/[Vide ]/[Ph t & Vide ].
Photo Resolution
Set the res luti n f a still image.
Opti ns: [12MP (4000x3000P)]/[8MP (3264x2448P)]/[5MP
(2592x1944P)]/[3MP (2048x1536P)]/[1MP (1280x960P)].
Photo Series
Set the ph t number f c ntinu us sh tings. In ph t m de,
the camera will take ph t s c ntinu usly. Opti ns: [1 ph t ]/[2
ph t s in series]/[3 ph t s in series].
6
Video Resolution
Set the vide res luti n. The larger the res luti n is, the
l nger the vide time will be st red.
Opti ns: [1920x1080P]/[1280x720P]/[720x480P]/[640x480P]/
[320x240P].
T Video Resolution
Set the res luti n f a time-lapse vide .
Opti ns:[2592x1944P]/[2048x1536P].
Video ength
Set the durati n f rec rding a vide clip. The sh rtest time can
be set is 3 sec nds and the l ngest time is 10 minutes.
Opti ns: 3 sec nds~10 minutes.
Audio Recording
Access this functi n, the camera will rec rd audi when rec rd
a vide at the same time.
Opti ns: [On]/[Off].
Shot ag
Set the time f delay sh ting when the camera detects a
m ti n. In the selected time, the camera will n t rec rd any
image r vide . This functi n can av id st ring t many same
events and waste f mem ry.
7
Opti ns: 5 sec nds~60 minutes.
IR Distance
Set the distance f infrared inducti n.
Opti ns: [Near]/[Middle]/[Far].
Sensitivity Motion Sensors
•Set the sensitivity level of the sensor. Normally the
environmental impact is small in indoors, you can
choose “Low” sensitivity. In normal condition of
outdoor, choose “Middle”. Choose “High” if the
environment impact is huge in outdoors.
•The temperature can also impact the sensor sensitivity.
“High Sensitivity” should be applied to mild
environment while “Low Sensitivity” should be applied
to cold environment.
Opti ns: [L w]/[Middle]/[High].
Target Recording Time
Set the target rec rding time. As sh wn in bel w picture, y u
can set the start and st p time. The camera will w rk just in the
stated time sl t. In ther time, the camera will keep in standby
state.
Opti ns: [On]/[Off].
8
Time-lapse
In Time-lapse menu, there are three pti ns as bel w:
[Normal]: The camera will take pictures aut matically as per
set time interval. F r example, set the interval time t 1 h ur, the
camera will take a ph t each h ur. If y u want t bserve a
plant bl ms, the camera will take 24 ph t s in 24 h urs t
rec rd the wh le pr cess f bl ming.
[T Video]: Y u can set the interval time within a time range
t take ph t s and c nvert these ph t s int a vide . The time
range is fr m 1 sec nd t 24 h urs. F r example, set the interval
t 1 h ur, the camera will take a ph t each h ur. If the camera
w rks f r 24 h urs, there will be 24 ph t s. These ph t s will
be c nverted int a vide .
9
[Off]: Cl se the time-lapse functi n.
anguage
Set the language display n screen.
Opti ns: [English]/[German]/[Danish]/[Finnish]/[Swedish]
[Spanish]/[French]/[Italian]/[Dutch]/[P rtuguese]/[Simplified
Chinese]/[Japanese].
Endless Capture
Set the camera t rec rd vide in l p.
Opti ns: [On]/[Off].
Time & Date
Set the date and time f camera. Press Right butt n t ch se an
item and press Up / D wn butt n t adjust the value. And then
press OK butt n t c nfirm.
10
