Denver PFF-1042W Manuel utilisateur

PFF-1042W

denver.eu

Jul , 2022

À DÉPOSER

EN MAGASIN À DÉPOSER

EN DÉCHÈTERIE

FRFR

Cet appareil et

ses cordons sont

recyclables

Language

English

German

Danish

Dutch

French

Spanish

Italian

Portuguese

Swedish

Finnish

Norwegian

Polish

Abbrevation

ENG

GER

DEN

NED

FRA

ESP

ITA

POR

SWE

FIN

NOR

POL

Order

10.

11.

12.

ENG

Important safety information

WARNING: Please read the safety instructions carefully before using the product for

the first time and keep the instructions for future reference. Read all the safety

information below before using this Frameo product.

1. This product is not atoy. Keep it out of reach of children. If operated by

children, please always make adult supervision.

2. Please keep the product away from pets.

3. Do not try to open the Frameo product! The device may contain parts with deadly

voltage.

4. Do not expose to heat, water, moisture, direct sunlight!

5. Only charge with the original adapter supplied with this product!

6. Repairs or service should only be performed by qualified personnel.

7. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or

moisture.

The apparatus shall not be exposed to dripping or splashing and that objects filled with

liquids, such as vases, shall not be placed on apparatus.

8. The direct plug-in adapter is used as disconnect device, the disconnect device shall

remain readily operable. So make sure there is space around the power outlet for

easy access.

9. Product operating and storage temperature is from -10 degree Celsius to 40 degree

Celsius.

Under and over this temperature might affect the function.

1. POWER

After connecting power adapter, please press and hold power button for

approximately 5 seconds (until screen turns on).

When it is on, press and hold power button for approximately 3 seconds to

access reboot or power off menu. Short press on power button will turn off/

onscreen (but leave the photo frame in on position).

2. USB

Connect a USB flash drive. USB is for service use only.

3. RESET

Use a needle or paper clip to reset unit.

4. MicroSD card

Load external max 32GB microSD memory card here.

5. DC

Connect DC adapter to power on the device.

ENG 2

1 4

DC-5V

User Manual

Version: 1.11.10

ENG

Getting started

Congratulations on your brand new Frameo photo frame!

If you are new to using Frameo then start by following the Frameo quick setup or follow the

on-screen guide when powering it on for the first time.

Once you have set up your Frameo frame, you can start connecting it to your friends and family.

Frameo app

To send photos to your frame, use the Frameo app for iOS or Android.

Find the Frameo app by scanning this code:

For Android:

Search for “Frameo” on Google Play.

For iOS:

Search for “Frameo” on App Store.

ENG

Frameo quick setup

When starting your frame for the first time, you will need to set up the frame.

●Select a language. This will be the language used on the Frameo.

●Connect your frame to the internet by connecting it to Wi-Fi.

●Verify or correct the date and time.

●Frameo may ask you to update to the latest version. It is recommended to update

your frame before continuing if asked to.

●Enter your name, and the location where you have placed your frame e.g. “John Doe”

and “Living room”, “Kitchen” or “Office”. Finally set the timezone if not already correct.

ENG

Start using Frameo

Next step is to connect Frameo with your friends and family by providing them with a code from

your frame.

If you want to be able to send photos to the frame yourself, start by downloading the app for iOS

or Android on App Store or Google Play. Then use the code to connect your frame and app as

described below.

Connecting a new friend

Make sure that your friend has downloaded and installed the Frameo app.

Click the add friend icon on your frame . A dialog will appear showing a connection code,

which is valid for 12 hours.

Now share this code in whatever fashion you prefer e.g. SMS, E-Mail, IM, phone call, to your

friend.

Once your friends have added the code in their Frameo app, they will automatically appear on

your frame and be able to send you photos.

Read chapter Change options for a friend to allow connected friends, to retrieve and share the

connection code via the smartphone app.

ENG

Navigating your Frameo

Swipe left or right to go through your photos.

To access the menu, simply tap once on the screen.

In the menu you will find the most used features.

Add friend

This will generate a code that you can share with your friends and family so they can connect and

send photos to your frame.

Settings

Opens the Settings.

Power menu

Opens the Power menu.

React

Opens the React menu.

NB. The React menu can also be accessed by double-tapping on the screen.

Hide photo

Hides the current photo. This means that the photo will no longer be shown in the slideshow. If

needed the photo can be shown again through the settings menu.

Gallery

Opens a gallery which allows for easy and fast navigation through your photos.

Fit to frame/Fill frame

This toggles how the photo is shown.

ENG

The Fill frame option is the default. The photo is scaled so that it fills the whole screen. It will be

centered around what is selected as the most important part. See the first picture below.

Fit to frame will make sure that the entire photo is shown on the screen. See the second picture

below.

Adjust photo

Allows you to adjust the position of the photo in the frame for an even better fit. Here you can also

use to rotate your photo.

Interacting with videos

When a video is shown two additional controls are shown. One for play/pause of the video and

one to control the volume level for video sounds.

Press to start the video playback. Pressing will pause the video playback.

Press to open the volume slider. Use the slider to adjust the volume level for video sounds.

Pressing will mute the video while pressing will unmute the video.

ENG
