Denon AVR-X8500H Guide de démarrage rapide
AVR-X8500H/AVC-X8500H
HDMI 8K Upgrade
Information
Read Me First
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
1.SPK610-611_RMF_ENG_00A_210408.indd 11.SPK610-611_RMF_ENG_00A_210408.indd 1 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
1
Contents
Read me first2
Upgraded Features2
Important post-upgrade notes5
Packing the product (US and Canada only)6
1.SPK610-611_RMF_ENG_00A_210408.indd 11.SPK610-611_RMF_ENG_00A_210408.indd 1 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
2
Read me first
This document describes the details and important notes about the upgrade service.
Upgraded Features
2One HDMI input connector (HDMI IN 7) and two HDMI output connectors
(HDMI OUT MONITOR 1 and 2) support 8K 60/50 Hz and 4K 120/100 Hz
pass-through.
2 DVD 3 Blu-ray 6 CD 7 AUX2(8K)4 GAME5 MEDIA PLAYER
eARC
ARC
MONITOR1 MONITOR2
1 CBL/SAT 4K ZONE2
NOTE
• The HDMI input 7 can not be selected for ZONE 2.
2All HDMI input/output connectors support the HDR10+, Dynamic HDR, VRR
(Variable Refresh Rate), QMS (Quick Media Switching), and QFT (Quick Frame
Transport) functions.
2The copy protection standard HDCP 2.3 is supported.
8K support
1.SPK610-611_RMF_ENG_00A_210408.indd 21.SPK610-611_RMF_ENG_00A_210408.indd 2 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
3
2The HDMI input 7 will be assigned to “AUX2 (8K)” as a default input source.
NOTE
• Along with the above, the unassigned HDMI input connector is changed from HDMI 7 to HDMI 6.
2The following information will be displayed when “HDMI Signal Info.” or
“HDMI Monitor 1 / HDMI Monitor 2” is selected in the setup menu.
8K signal / HDR10+ / Dynamic HDR / ALLM (All Low Latency Mode) /
VRR (Variable Refresh Rate) / QMS (Quick Media Switching) /
QFT (Quick Frame Transport) / eARC (Enhanced Audio Return Channel)
2The “4K Signal Format” in the setup menu will be renamed as “4K/8K Signal
Format” and “8K Enhanced” mode will be newly added. Select “8K Enhanced”
mode to allow 8K or 4K 120Hz pass-through.
NOTE
• The default setting after the upgrade is changed from “Standard” to “Enhanced”.
1.SPK610-611_RMF_ENG_00A_210408.indd 31.SPK610-611_RMF_ENG_00A_210408.indd 3 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
4
2In the “Resolution” setting for i/p Scaler of the setup menu, the “8K” setting
for 8K upscaling is added.
NOTE
• The “4K(60/50)” setting is integrated into the “4K” setting, the “1080p:24Hz” setting is integrated
into the “1080p” setting, and the frame rate conversion function is removed.
2When powered ON, the front panel display shows “AVR-X8500HA” or “AVC-
X8500HA”, instead of “AVR-X8500H” or “AVC-X8500H”. The added “A” means
the product has been upgraded.
%
•Press INFO button on the remote control unit twice to display information about video input and output
signals at the screen.
1.SPK610-611_RMF_ENG_00A_210408.indd 41.SPK610-611_RMF_ENG_00A_210408.indd 4 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
5
Important post-upgrade notes
2Once the upgrade is performed, the following settings will reset to factory
default settings. The backup memory such as volume level will be erased
as well. It is necessary to setup the product once again when the product is
returned.
• Audyssey®Setup
• Speaker Config.
• Changing the “Quick Select Names”
• Network connection
• Last function memory
• Various settings using the custom installer
• All the other settings in the backup memory
NOTE
• The “Save & Load” function does not work. The saved settings can not be restored once the upgrade
is performed on the product.
2The warranty period of the product is the same as before the upgrade.
2If the upgrade is performed, the product cannot be returned to the state before
the upgrade.
1.SPK610-611_RMF_ENG_00A_210408.indd 51.SPK610-611_RMF_ENG_00A_210408.indd 5 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
6
Packing the product (US and Canada only)
Once you received an empty box, follow the instructions below to pack the product. It will help
prevent damages during shipment.
2Preparation
①Remove the left and right antennas
on the rear panel.
Keep the antennas at home and attach
them again to the product once the product
is returned after the upgrade.
NOTE
• If the product is packed with the antennas
attached, the antennas will be damaged.
• Also keep other accessories such as the
remote control unit at home. They do not need
to be shipped with the product.
② To protect the door during shipment,
insert the provided door cushion into
the door as shown in the diagram,
close the door, and then fix the door
in place with tape.
To tape up the door, use the blue tape affixed
to the provided product packing sheet.
1.SPK610-611_RMF_ENG_00A_210408.indd 61.SPK610-611_RMF_ENG_00A_210408.indd 6 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
7
2Packing
①
Wrap the product with the provided
sheet as shown in the diagram.
To tape up the product, use the yellow tape
affixed to the provided product packing
sheet.
SHEET
FRONT PANEL
②
Set the bottom cushions (front/
back) in the cardboard box in the
orientation as shown in the diagram.
“BOTTOM”,
“REAR”
indication
“BOTTOM”,
“FRONT”
indication
1.SPK610-611_RMF_ENG_00A_210408.indd 71.SPK610-611_RMF_ENG_00A_210408.indd 7 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
8
④
Set the top cushions (front/back) in
the correct orientation.
“TOP”,
“FRONT”
indication
“TOP”,
“REAR”
indication
FRONT PANEL side
⑤
Close and tape the cardboard box
for shipment. Follow the instructions
from the servicer for shipment.
③
Place the product in the box with
the front panel facing the “FRONT”
cushion.
FRONT PANEL side
1.SPK610-611_RMF_ENG_00A_210408.indd 81.SPK610-611_RMF_ENG_00A_210408.indd 8 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black
1
Inhalt
Bitte zuerst lesen2
Verbesserte Funktionen 2
Wichtige Hinweise nach dem Upgrade5
Verpacken des Produkts (nur USA und Kanada)6
2.SPK610-611_RMF_DEU_00A_210408.indd 12.SPK610-611_RMF_DEU_00A_210408.indd 1 2021/04/08 11:13:382021/04/08 11:13:38
