)&& TEST REPORT

Report No.: EMC-)&&-R0149

User manual

EMCcompliance Ltd. Page: 1 of 1

480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea

82 31 336 9919 (Main) 82 31 336 4767 (Fax)

This test report shall not be reproduced except in full, Without the written approval.

Appendix

TroubleshootingPlaybackConnectionsPreparation

Contents

Index

DSB-200

WIRELESS MUSIC SYSTEM

Owner’s Manual

You can print more than one page of a PDF onto a single sheet of paper.

Envaya

Appendix

TroubleshootingPlaybackConnectionsPreparation

Index

Contents

Preparation

Accessories························································································ 4

Features······························································································ 5

High Sound Quality ·········································································· 5

Good Design ···················································································· 5

Simple Operation ············································································· 5

Part names and functions ····························································· 6

Opening the Stand·········································································· 8

Charging····························································································· 9

Charging this Unit············································································· 9

Using this unit's power supply to charge a smartphone················ 12

Turn the power on ········································································ 13

Switching the power to standby ···················································· 13

Connections

Bluetooth Connection·································································· 14

Pairing ···························································································· 14

Three Bluetooth Connection Methods··········································· 14

Case 1: Pairing with this unit for the ﬁrst time······························· 15

Case 2: Connecting to a Bluetooth device

that has already been paired ·························································· 17

Case 3: NFC connection to a Bluetooth device equipped with

the NFC function ············································································ 18

Simultaneously connecting Bluetooth devices

(Multipoint function) ······································································· 19

Playback

Adjusting the volume··································································· 20

Turning o the sound temporarily (muting)···································· 20

Listening to music using a wired connection ······················· 21

Appendix

TroubleshootingPlaybackConnectionsPreparation

Index

Contents

Troubleshooting

Contents··························································································· 22

Tips································································································· 23

Troubleshooting ··········································································· 24

Restarting the unit ········································································ 27

Appendix

Replacing the grill net ····································································· 28

Explanation of Terms ······································································ 29

Trademark information···································································· 30

Speciﬁcations ··················································································· 31

Index ·································································································· 33

Appendix

TroubleshootingPlaybackConnections

Contents

Index

Preparation

Accessories

Check the following parts before use.

qQuick Start Guide wSafety Instructions eAC adapter rReplacement plug for AC adapter

For Europe For U.K.

For North America/

Japan

tInterchangeable nets

(3 colors)

Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Appendix

TroubleshootingPlaybackConnections

Contents

Index

Preparation

High Sound Quality

•Despite its compact size, this unit is equipped with two high sound

quality full range speakers, and a passive radiator that utilizes

double suspension to provide sound with a broad, overﬂowing

presence and deep base tones.

•Compatible with the high sound quality aptX codec

This unit is compatible with a wide range of codecs, including the high

sound quality aptX, AAC and SBC. This unit automatically selects the

optimum compatible codec for your smartphone or tablet so you can

enjoy high-grade wireless sound.

Good Design

•This unit is available in two colors. The white model features a high

gloss ﬁnish that brings a touch of class to the room, and the black

model features a soft feel ﬁnish that has a smooth, gentle texture.

•The speaker grill can be removed and the inside net changed

between any of the four provided colors (orange, pink, blue or

gray). This means you can color coordinate this unit with the decor

in your room.

Simple Operation

•Smartphones that are equipped with the NFC function can be

smoothly paired and connected with this unit simply by touching

this unit with the smartphone.

•The power supply to this unit can be switched on by operating

the smartphone or tablet. For example, you can switch the power

supply to the unit on and listen to music straight after waking up and

without getting out of bed, simply by operating your smartphone.

Features

Appendix

TroubleshootingPlaybackConnections

Contents

Index

Preparation

wq e r uyt i

Part names and functions

qBattery Indicator (vpage11)

wPower operation button (X)

Turns the power supply to on/standby (vpage13).

eAUX button

Switches input to a portable music player or other such devices

connected by a cable.

rBluetooth button

Switches input to Bluetooth. Also, press this button when pairing with

a device.

tIllumination LED

This lights in the following way according to the power supply status.

•Power on (using the AC adapter): Lit

•Power on (using batteries): Lit

(turns o 5 seconds after the power is

turned on.)

•Normal standby: O

•Eco standby: O

•Muted: Blinking

yN mark

When pairing (registering) a Bluetooth device that is equipped with the

NFC function, touch the Bluetooth device to this mark.

uMute button

Mutes the volume (vpage20).

iVolume adjustment button (-,+)

Adjusts the volume.

Appendix

TroubleshootingPlaybackConnections

Contents

Index

Preparation

oCharging port

Connect using a USB cable (sold separately) to recharge the smartphone

or portable music player.

Q0 Reset button

Restarts this unit (vpage27).

Q1 AUX Input connector

Use a stereo mini cable (sold separately) to connect to the headphones

jack of a portable music player, etc.

Q2 DC IN connector

Connect the supplied AC adapter.

Q3 Stand

Appendix

TroubleshootingPlaybackConnections

Contents

Index

Preparation

While holding this unit with both hands, use one hand to squeeze the indentations in the stand to open it.

Note

•When standing this unit up for use, be sure to place it on a ﬂat surface. Placing it on an unstable surface is dangerous because this unit may fall.

Opening the Stand

Appendix

TroubleshootingPlaybackConnections

Contents

Index

Preparation

Charging this Unit

This unit can be charged for use. It can also be used with the supplied AC adapter connected to a wall socket.

Before using for the ﬁrst time, be sure to fully charge this unit.

•It takes approximately Ohours to fully charge the battery when it is completely discharged.

•This unit can be used for approximately Ohours when the battery is fully charged.

2Replacing the AC Adapter Plug

Attach the adapter plug that ﬁts the power socket in your region as shown in the ﬁgure.

[Removing a replacement AC adapter plug]

While pressing the q button, slide in the direction of the arrow to

remove.

[Attaching a replacement AC adapter plug]

Push in the direction of the arrow until a “click” sound is heard.

Charging
