Denon AVR-2803 Guide de l'administrateur

DENON AVR2803 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS(C1〜C5) : ０１０００ , EXTENSION BIT(C12,C13):１１

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

0 ００００００ 16 ００００１０ FR LEVEL DOWN

1 １０００００ POWER 17 １０００１０

2 ０１００００ FL LEVEL UP 18 ０１００１０ CDR/TAPE

3 １１００００ PHONO 19 １１００１０ TAPE-2

4 ００１０００ CD 20 ００１０１０

5 １０１０００ TUNER 21 １０１０１０ CINEMA EQ ON

6 ０１１０００ 22 ０１１０１０ SR LEVEL UP

7 １１１０００ FL LEVEL DOWN 23 １１１０１０ SR LEVEL DOWN

8 ０００１００ DBS 24 ０００１１０ VIDEO SELECT

9 １００１００ TV 25 １００１１０ CINEMA EQ OFF

10 ０１０１００ VDP 26 ０１０１１０

11 １１０１００ FR LEVEL UP 27 １１０１１０ MULTI

12 ００１１００ V.AUX 28 ００１１１０ INPUT MODE ANALOG

13 １０１１００ VCR-1 29 １０１１１０ CURSOR RIGHT

14 ０１１１００ VCR-2 30 ０１１１１０ STATUS

15 １１１１００ VCR-3 31 １１１１１０ ON SCREEN

SYSTEM ADDRESS(C1〜C5) : ０１０００ , EXTENSION BIT(C12,C13) : １１

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

32 ０００００１ ENTER 48 ００００１１ MUTING

33 １００００１ POWER ON 49 １０００１１ MASTER VOLUME UP

34 ０１０００１ POWER OFF 50 ０１００１１ MASTER VOLUME DOWN

35 １１０００１ DVD 51 １１００１１ SL LEVEL UP

36 ００１００１ DOLBY / DTS SURROUND 52 ００１０１１ SL LEVEL DOWN

37 １０１００１ SW LEVEL DOWN 53 １０１０１１ CENTER LEVEL UP

38 ０１１００１ DSP SIMULATION 54 ０１１０１１ CENTER LEVEL DOWN

39 １１１００１ SB/SBL LEVEL UP 55 １１１０１１ SBR LEVEL UP

40 ０００１０１ 56 ０００１１１ SBR LEVEL DOWN

41 １００１０１ 57 １００１１１ TONE DEFEAT ON

42 ０１０１０１ TEST TONE 58 ０１０１１１ TONE DEFEAT OFF

43 １１０１０１ SB/SBL LEVEL DOWN 59 １１０１１１ SB:MATRIX ON

44 ００１１０１ SW LEVEL UP 60 ００１１１１ SB:NON MATRIX

45 １０１１０１ SPEAKER 61 １０１１１１ SB:OFF

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

DENON AVR2803 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS(C1〜C5) : ００１１０ , EXTENSION BIT (C12,C13) : ０１

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

0 ００００００ ALL BASS DOWN 16 ００００１０ ZONE2 CD

1 １０００００ DTS SURROUND 17 １０００１０ ZONE2 TUNER

2 ０１００００ SURROUND BACK ON/OFF 18 ０１００１０ ZONE2 VDP

3 １１００００ MASTER VOL. PRESET1(0dB) 19 １１００１０ ZONE2 V.AUX

4 ００１０００ 20 ００１０１０ ZONE2 VCR-1

5 １０１０００ MASTER VOL. PRESET2(-20dB) 21 １０１０１０ ZONE2 TAPE-2

6 ０１１０００ MASTER VOL. PRESET3(-40dB) 22 ０１１０１０ MULTI PRESET UP

7 １１１０００ ZONE2 VOL. PRESET1(0dB) 23 １１１０１０ MULTI PRESET DOWN

8 ０００１００ ZONE2 VOL. PRESET2(-20dB) 24 ０００１１０

9 １００１００ ZONE2 VOL. PRESET3(-40dB) 25 １００１１０ ZONE2 VCR-2

10 ０１０１００ ZONE2 DBS 26 ０１０１１０ ZONE2 VCR-3

11 １１０１００ HOME THX CINEMA 27 １１０１１０ ZONE2 TV

12 ００１１００ 28 ００１１１０ ZONE2 CDR/TAPE

13 １０１１００ ZONE2 VOLUME UP 29 １０１１１０ STEREO

14 ０１１１００ ZONE2 VOLUME DOWN 30 ０１１１１０ DIRECT

15 １１１１００ ZONE2 PHONO 31 １１１１１０

SYSTEM ADDRESS(C1〜C5) : ００１１０ , EXTENSION BIT (C12,C13):０１

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

32 ０００００１ SYSTEM SET UP 48 ００００１１ CH VOLUME UP

33 １００００１ SURROUND PARAMETER 49 １０００１１ CH VOLUME DOWN

34 ０１０００１ 50 ０１００１１

35 １１０００１ CURSOR UP 51 １１００１１

36 ００１００１ CURSOR DOWN 52 ００１０１１

37 １０１００１ 53 １０１０１１ INPUT MODE EXT.IN

38 ０１１００１ 54 ０１１０１１ INPUT MODE

39 １１１００１ 55 １１１０１１ ALL TREBLE UP

40 ０００１０１ 5CH/7CH STEREO 56 ０００１１１ ALL TREBLE DOWN

41 １００１０１ 2CH PLAY(INPUT CH) 57 １００１１１ TUNER SHIFT A

42 ０１０１０１ MULTI CH PLAY (INPUT CH) 58 ０１０１１１ TUNER SHIFT B

43 １１０１０１ 59 １１０１１１ TUNER SHIFT C

44 ００１１０１ AUDIO FUNCTION 60 ００１１１１ TUNER SHIFT D

45 １０１１０１ VIDEO FUNCTION 61 １０１１１１ TUNER SHIFT E

46 ０１１１０１ 62 ０１１１１１ ZONE2 DVD

47 １１１１０１ CH SELECT 63 １１１１１１ ALL BASS DOWN

DENON AVR2803 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS(C1〜C5) : ００１１０ , EXTENSION BIT (C12,C13) : １０

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１ CURSOR LEFT

SYSTEM ADDRESS(C1〜C5) : ００１１０ , EXTENSION BIT (C12,C13) : １１

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

0 ００００００ 16 ００００１０

1 １０００００ TUNER PRESET CH 1 17 １０００１０

2 ０１００００ TUNER PRESET CH 2 18 ０１００１０

3 １１００００ TUNER PRESET CH 3 19 １１００１０

4 ００１０００ TUNER PRESET CH 4 20 ００１０１０

5 １０１０００ TUNER PRESET CH 5 21 １０１０１０ TUNER PRESET DOWN

6 ０１１０００ TUNER PRESET CH 6 22 ０１１０１０ TUNER PRESET UP

7 １１１０００ TUNER PRESET CH 7 23 １１１０１０ TUNER BAND

8 ０００１００ TUNER PRESET CH 8 24 ０００１１０ TUNING MODE(AUTO/MANUAL)

9 １００１００ 25 １００１１０ TUNER TUNING UP

10 ０１０１００ 26 ０１０１１０ TUNER TUNING DOWN

11 １１０１００ 27 １１０１１０

12 ００１１００ TUNER MEMORY 28 ００１１１０

13 １０１１００ TUNER SHIFT 29 １０１１１０

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０ DIMMER

DENON AVR2803 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS (C1〜C5) : ０１０００ , EXTENSION BIT (C12,C13) : １０

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

0 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０ ZONE1 TV

3 １１００００ 19 １１００１０ ZONE1 DBS/SAT

4 ００１０００ 20 ００１０１０ ZONE1 VCR-1

5 １０１０００ 21 １０１０１０ ZONE1 VCR-2

6 ０１１０００ 22 ０１１０１０ ZONE1 VCR-3

7 １１１０００ 23 １１１０１０ ZONE1 V.AUX

8 ０００１００ ZONE1 TUNER 24 ０００１１０

9 １００１００ ZONE1 PHONO 25 １００１１０

10 ０１０１００ ZONE1 CD 26 ０１０１１０

11 １１０１００ 27 １１０１１０ ZONE1 TAPE-1

12 ００１１００ 28 ００１１１０ ZONE1 TAPE-2

13 １０１１００ 29 １０１１１０ MULTI ZONE ON/OFF

14 ０１１１００ ZONE1 DVD 30 ０１１１１０

15 １１１１００ ZONE1 VDP 31 １１１１１０

SYSTEM ADDRESS (C1〜C5) : ０１０００ , EXTENSION BIT (C12,C13) : １０

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１ MAIN ZONE ON

42 ０１０１０１ PURE DIRECT 58 ０１０１１１ MAIN ZONE OFF

43 １１０１０１ 59 １１０１１１ MULTI ZONE2 ON

44 ００１１０１ 60 ００１１１１ MULTI ZONE2 OFF

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

DENON AVR2803 RC CODE

FORMAT SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

SYSTEM ADDRESS (C1〜C5) : ００１００ , EXTENSION BIT (C12,C13) : ０１

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

0 ００００００ 16 ００００１０ DOLBY PL II MUSIC

1 １０００００ WIDE SCREEN 17 １０００１０ DOLBY PL

2 ０１００００ SUPER STADIUM 18 ０１００１０

3 １１００００ ROCK ARENA 19 １１００１０ DTS ES MATRIX

4 ００１０００ JAZZ CLUB 20 ００１０１０ DOLBY DIGITAL EX

5 １０１０００ CLASSIC CONCERT 21 １０１０１０ CINEMA MODE

6 ０１１０００ MONO MOVIE 22 ０１１０１０ MUSIC MODE

7 １１１０００ MATRIX 23 １１１０１０

8 ０００１００ VIDEO GAME 24 ０００１１０

9 １００１００ VIRTUAL 25 １００１１０

10 ０１０１００ THX ULTRA2 CINEMA 26 ０１０１１０

11 １１０１００ THX MUSIC MODE 27 １１０１１０

12 ００１１００ THX SURROUND EX 28 ００１１１０

13 １０１１００ DTS NEO:6 CINEMA 29 １０１１１０

14 ０１１１００ DTS NEO:6 MUSIC 30 ０１１１１０

15 １１１１００ DOLBY PL II CINEMA 31 １１１１１０

SYSTEM ADDRESS (C1〜C5) : ００１００ , EXTENSION BIT (C12,C13):０１

No. Data (C6〜C11) Key Name No. Data (C6〜C11) Key Name

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１ INPUT MODE AUTO

36 ００１００１ 52 ００１０１１ INPUT MODE PCM

37 １０１００１ 53 １０１０１１ INPUT MODE DTS

38 ０１１００１ 54 ０１１０１１ INPUT MODE RF

39 １１１００１ 55 １１１０１１ INPUT MODE EXT.IN

40 ０００１０１ 56 ０００１１１ INPUT MODE EXT.IN2

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１
