Deming Designs De-Bug Guide d'installation

DEMING DESIGNS

1090 Cobblestone Dr.

Pensacola, FL 32514

(850) 478-5765

(850) 476-3361 fax

www.beachwheelchair.com

kmdeming@aol.com

De-Bug Beach Wheelchair

ASSEMBLY, OPERATION,

SAFETY INSTRUCTIONS

AND

WARRANTY INFORMATION

Transfers

Footrest Operation

Recining Backrest and

Tlt N Space Operation

Ratchet Operation

Ratchet Assembly

ChairAssembly Instructions

Available Options

Maintenance Instructions

Warranty Information

Table of Contents

Transfers:

Because of the diameter and widthof the tires,

De-Bugmaybeslightly

higherfromthegroundthanaconventionallydesignedwheelchair.

Transferringfromoneelevationtoa lowerelevationminimizesthis

difference.

The elevation of De-Bug canbe lowered further

byreducing

the

air

pressure

in all tires from

5 to 2.5 PSI.

This also makes De-Bug

considerably

easier to propel in very soft sand

. On trails and more

compact surfaces, thetire airpressure should be adjusted back to 5

P.S.I.

Thearmrestsshouldbe removedbeforeperformingalateraltransfer

andthefrontwheelsshouldbelockedtostabilizethechair. Thearm-

restsarenotintendedtosupporttheweightof theuserduringtrans-

fers, or to beused as a seat themselves.

For most strongparaplegics,minimal stand-by assistance isre-

quired. We recommendthatlessableusershaveanassistantfamiliar

withtransfers

tainless Chair

With Elevating Legrest

Figure 1 To raise the leg rest, pull up

on the Notched regulator located on

each side of the chair.

Figure 2 While holding the notched

regulator up, raise the foot rest to the

desired position, and then release the

notched regulator, locking the footrest

iin postion

Figure 3 shows the legrest raised to

the first increment

Figure 4 demonstrates the leg exten-

sion fully elevated in the third postion.

To extend the length of the footrest,

loosentheblackknobslocatedon both

sides of the footrest, and firmly pull the

legrest out to the desired length

Figure 3

Figure 1

Figure 4

tainless Chair

With Reclining Backrest

Stainless Chair.

With Tilt N Space

Figure 1 Shows the chair in the

fully upright position.

Figure 2. To lower the backrest,

pull up on the cable located in the rear

of the chair until the locking mecha-

nism is released. At the same time,

lean the backrest slightly forward, then

gentlylowerthebackresttothedesired

position. To raise the backrest, pull up

on the backrest cable until the locking

mechanism is released, then raise the

backrest to the desired position. Re-

lease the cable when that position has

been reached.

Be sure the chair is in a stationary

position with the brakes locked

Figure 3. Shows the chair inthe fully

reclined position with the arm rests

removed

Figure 4. To tilt the chair on it’s axis,

pull up on the cable located in the rear

of the chair until the locking mechanism

is released. Then gently tilt the backrest

to the desired position.

Be sure the chair is in a stationarypo-

sition with the brakes locked

Figure 2

To disassemble the De-Bug

Loosen the Leg LengthAdjustment knobs and slide out the footplate.

Slide off the Leg Support Sling, and remove the two 1/4-20 nuts at the

point of rotation of the knees.

To remove theAnti tip Wheels, loosen the four attaching 1/4-20 bolts and

remove the wheelie bar.

To remove the Mid Axle, loosen the two attaching 1/4-20 bolts.

To remove the Backrest, remove the two attaching 1/4-20 bolts and slide up on the

Backrest.

The Rear Suspension Tension may be detached by removing the Rear

Suspension

Tension bolt. This bolt should be tight during use.

The chair may be further disassembled by removing the remaining 1/4-20 bolts as

required.

ToAssemble the De-Bug

Slide on the Leg Support Sling, and insert the two 1/4-20 nuts at the point of rotation

of the knees.

Slide on the foot plate, and tighten the Leg Length Adjustment knobs

Attach the Anti tip Wheels and then the wheelie bar. Tighten the four attaching 1/4-

20 bolts

Install the Mid Axle, tighten the two attaching 1/4-20 bolts.

To install the Backrest, slide the backrest down on the chair frame and

attach using the two 1/4-20 bolts

The Rear Suspension Tension may be attached by inserting the Rear

Suspension

Tension bolt. This bolt should be tight during use.

Assembly Instructions

*Anti-tipWheelsareonElevatinglegrestchairsonly!

Assembly Instructions

Please note the anti tip wheels are used with chairs that have the elevating legrests.

316L Stainless Steel

Beach Wheelchair with

seatbelts, removable,

swing away armrest and

castering rear wheels.

Ten year warranty on

frame included

Pool/Street Chair

shown with

elevating leg

rest, front

interchangeable

pool wheels, and

extra rear

suspe

nsion.

316L SS Beach

Wheelchair, with

Elevating Leg rest,

seatbelts, removable,

swing away armrest and

castering rear wheels,

Ten year warranty on

frame included *

Reclining chair

Shown with

headrest, and

powder coated

blue. The

armrests are in the

eversed position.

Tilt in Space Chair.

Shown with elevating

leg rest, head rest, and

powder

coated blue

Tilt N

Space

Reclining

Combination.

Shown with

elevating leg

rest, head rest,

and powder

coated blue

Interchangeable

front Pool/Street

Wheels

Umbrella with Stainless

Steel, Adjustabl

Swiveling holder

Extra Rear caster

Ring Chest Strap

Butterfly Chest

Strap

Concave, or Three

Piece Headrest

Removable,

Zippered,

Washable,

Cushion, with

UV and Anti

Milde

Inhibitor,

Wheeleez Wheels

We are a full distributor

of Wheeleez Wheels

and Products.

Stainless Steel

Quick Release

Pins

SPECIFICATION

De-Bug frame

is constructed using

#316L

Stainless Steel tubing which is a

higher grade

than

standard

“#304 marine grade”

stainless.

Weight capacity

350 pounds standard, weight capacities up to 600 pounds can be

accommodatedforanominalfee.

Casters

- rear wheels rotate 360 degrees . Wheel hubs are made from poly-nylon material

to eliminate salt water corrosion.

The rear suspension also articulates +/- ~20degrees, allowing all four wheels to remain in

contact with the ground when going across uneven terrain, making it much more stable than

standardoutdoorwheelchairs.

Swing away arm rests

are also easilyremovable for Lateral transfers.

Footrest-

Has Linear position telescopic length

adjustment

and four position angle adjust-

ment. The De-Bug also has a footrestfor proper foot support.

Wheel Lock

-Adjustable tension wheel brake can be actuated independantlyon each

side, uses all #316L stainless steel hardware.

* Chair weight

- Forty pounds for a standard adult chair

Chair width

is ~33.5 inches to access a 36 inch doorway and is ~27 inches wide with the

optionalinterchangeablepoolwheels.

Chair design

is patented in the U.S. #380,991

30 DAY Money Back Guarantee

Ten year warranty

Components & Frame

#316Lseries Stainless Steel “ the higher the higher the qualityof

Stainless”

Two year warranty

Seating - Material is Phifertex Nylon, anti-absorbant, U.V. resistant. Seating is removable and

machinewashable.

Two year warranty

Tires

- 3 ply poly urathene, low pressure, to specifically enable easy operation in grass,

gravel, sand, snow, & uneven terrain

MAINTENANCE

Because your De-BUG chair is built tough, maintenance is minimal, however, to keep your

chair in top shape for years to come, just follow these simple Maintenance procedures.

Cleaning Chair

After use, rinse off the chair to remove any dirt and debris. Amild detergent can be used

to remove any tough stains.

Sling Seats

Mild soap and water should remove anystains. If necessary, a diluted mixture of bleach

& warm water will remove anytough stains.

Cushions

Mild soap and water should remove anystains. If necessary, a diluted mixture of bleach

& water will remove anytough stains

LIMITEDWARRANTY

DEMINGDESIGNSWARRANTSIT’SPRODUCTS,OTHERTHANTIRESANDSLINGS, AGAINST

DEFECTSINMATERIALANDWORKMANSHIPFORAPERIODOF TEN(10)YEARS FROMTHEDATE

OFPURCHASE. THISWARRANTYISLIMITED,ATDEMINGDESIGN’SOPTION,TOTHEREPAIROR

REPLACEMENTOF,ORTHEISSUINGOFACREDITFOR,ANYDEFECTIVEEQUIPMENTORPARTCOV-

EREDBYTHISLIMITEDWARRANTY. DEMINGDESIGNSSHALLHAVETHERIGHTTOREQUIRETHAT

THEDEFECTIVEPRODUCT(S)BERETURNEDTODEMINGDESIGNSWITHTRANSPORTATIONBEING

PREPAIDBYTHEPERSONCLAIMINGUNDERTHEWARRANTY. DEMINGDESIGNSSHALLINVOICE

FORALLCHARGES,PARTS,LABORANDTRANSPORTATIONFORREPAIRSTOORREPLACEMENTOF

ANYPRODUCTSFOUNDNOTTOBEDEFECTIVEOROTHERWISENOTCOVEREDBYTHETERMSOF

THISWARRANTY. DEMINGDESIGN’SLIABILITYISLIMITEDTOTHEAMOUNTCHARGEDBYDEMING

DESIGNSFORTHEDEFECTIVEPRODUCTANDTHISWARRANTYDOES

NOT

INCLUDETRANSPOR-

TATIONCHARGESANDLABORCOSTFORREMOVALORRE-INSTALLATION.

NOTWITHSTANDINGTHEABOVELIMITEDWARRANTY,DEMINGDESIGNSWILLHAVENO

LIABILITYWHATSOEVER,IFANYDEFECTINAPRODUCTISFOUNDTOHAVERESULTEDFROMTHE

IMPROPERSTORAGE,USEORSERVICEOFTHEPRODUCT,INCLUDINGBUTNOTLIMITEDTOSTOR-

AGE,USEORSERVICE NOTCONSISTENTWITHDEMINGDESIGN’SWRITTENINSTRUCTIONSAND

RECOMMENDATIONS,IFANY. INADDITION,DEMINGDESIGNSSHALLBEWITHOUTLIABILITYFOR

ANYDEFECTINANYPRODUCTWHICHDEMINGDESIGNS,INITSOPINION,DETERMINESHASRE-

SULTEDFROMTHEPRODUCTBEINGINSTALLED,REPAIREDORALTEREDBYSOMEONEOTHER

THANDEMINGDESIGNSORHASRESULTEDFROMMISUSE,NEGLIGENCEORACCIDENTOTHER

THANBYDEMINGDESIGNS. DEMINGDESIGNSALSOWILLBEWITHOUTLIABILITYINTHEEFFECT

THEPERSONCLAIMINGUNDERTHISLIMITEDWARRANTYFAILSTODELIVERNOTICEOFTHE

ALLEGEDDEFECTTODEMINGDESIGNSWITHINSIXTYMONTHSFROMTHEDATEOFORIGINAL

PURCHASEFROMDEMINGDESIGNSORWITHINTHIRTYDAYSAFTERTHEDEFECTWASORREA-

SONABLYSHOULDHAVEBEENDISCOVERED,WHICHEVERISEARLIER.

DEMINGDESIGNSDOESNOTWARRANTTHEMERCHANTABILITYORFITNESSORANY

PARTICULARPURPOSEOFITSPRODUCTSANDDOESNOTMAKEANYWARRANTY,EXPRESSOR

IMPLIED,OTHERTHANTHELIMITEDWARRANTYCONTAINEDHEREIN.

DEMING DESIGNS SHALL IN NO EVENT BE LIABLE FOR ANY DAMAGES OR LOSSES

ARISING FROM THE LOSS OF USE OF THE PRODUCT, ANYCOMMERCIALLOSS, CONSEQUEN-

TIAL DAMAGES OR INCIDENTALDAMAGESARISING FROMADEFECT IN MATERIALAND/OR

WORKMANSHIP COVERED UNDER THIS WARRANTY.

DEMING DESIGNS RESERVES THE RIGHT TO MAKE CHANGES IN DESIGN OR IM-

PROVEMENTS IN ITS PRODUCTS WITHOUT NOTICEAND WITHOUT THE OBLIGATION TO IN-

CORPORATE THE SAME IN ANY PRODUCTS PREVIOUSLY MANUFACTURED.

DEMING DESIGNS HAS NOT AUTHORIZED ANYONE TO MAKE ANY REPRESENTA-

TION OR WARRANTY OTHER THAN THE WARRANTY CONTAINED HEREIN.

EXCEPT WHERE PROHIBITED BY LAW, THIS LIMITED WARRANTY REPRESENTS THE

TOTAL AGREEMENT BETWEEN YOU AND DEMING DESIGNS AS TO DEMING DESIGN’S LI-

ABILITY IN THE EFFECT OF DEFECTS IN WORKMANSHIP OR MATERIAL OF ANY DEMING

DESIGNS MANUFACTURED OR SUPPLIED PRODUCTS, AND YOU ACCEPT OR USE ANY SUCH

PRODUCTS SUBJECT TO THIS LIMITED WARRANTY, WAIVINGANYOTHER RIGHTSYOU MAY

HAVEAGAINST DEMINGDESIGNS FORANYCLAIMSARISING OUT OFANYDEFECT INWORK-

MANSHIP OR MATERIALS. TO THE EXTENT ANY ONE OR MORE PROVISIONS OF THIS LIM-

ITED WARRANTYARE HELD TO BE PROHIBITED BY LAW, THE REMAINING PROVISIONS OF

THIS LIMITED WARRANTY SHALL BE SEVERED AND GIVEN THE FULL FORCE AND EFFECT

PERMITTED BY LAW

Table des matières

Manuels Fauteuil roulant populaires d'autres marques

Otto Bock

Otto Bock Skippi plus Manuel utilisateur

Invacare

Invacare Action 4NG series Manuel utilisateur

SORG

SORG LoopSORG 802 Manuel utilisateur

Designability

Designability WizzyBug Instructions d'installation

Vermeiren

Vermeiren RAPIDO Manuel utilisateur

Excel

Excel G5 KIDS 0285 Manuel utilisateur

M. Bartels

M. Bartels SA-3 Manuel utilisateur

nino robotics

nino robotics NIno Manuel utilisateur

Vermeiren

Vermeiren Turios Manuel utilisateur

Invacare

Invacare MK5 EX Manuel utilisateur

Invacare

Invacare Solara Spree GT Manuel

Nova

Nova TKW-12 Manuel utilisateur

BCW

BCW Advantage Manuel utilisateur

You-Q

You-Q Luca Manuel utilisateur

interco

interco Ortolight Standard Mode d’emploi

Nova

Nova 7190L Manuel utilisateur

Vermeiren

Vermeiren EZ1 Manuel utilisateur

PaceSaver

PaceSaver Scout M-300 Manuel utilisateur
