DELTA MCS-1800 Power Shelf

Installation, Operation and

Maintenance Manual

Delta MCS 1800 3U

Power Shelf

Installation, Operations and

Maintenance Manual

DELTA ELECTRONICS, INC.

DELTA MCS 1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

INDEX i

1. General ---------------------------------------------- 1-1

1.1 Using This Manual ---------------------------------------------- 1-1

1.2 Safety Notice ---------------------------------------------- 1-1

2. Product Description ---------------------------------------------- 2-1

2.1 Product Description ---------------------------------------------- 2-1

2.2 Product Main Features ---------------------------------------------- 2-1

2.3 System Specifications ---------------------------------------------- 2-1

3. Power Supply Unit (PSU) ---------------------------------------------- 3-1

3.1 Description ---------------------------------------------- 3-1

3.2 Specifications ---------------------------------------------- 3-1

3.3 Operation and Adjustment ---------------------------------------------- 3-4

3.4 System Alarm ---------------------------------------------- 3-5

3.5 PSU Block Diagram ---------------------------------------------- 3-5

3.6 PSU Operating Principle ---------------------------------------------- 3-5

4. Alarm Control Unit ---------------------------------------------- 4-1

4.1 Description ---------------------------------------------- 4-1

4.2 Specifications ---------------------------------------------- 4-1

4.3 Alarm Control Unit Block Diagram ---------------------------------------------- 4-4

4.4 Settings and Control ---------------------------------------------- 4-4

5. DC Distribution ---------------------------------------------- 5-1

5.1 DC Cabling ---------------------------------------------- 5-1

5.2 Low Voltage Battery Disconnect (System

equipped with PDU) ---------------------------------------------- 5-1

5.3 Battery Connections (System equipped with

PDU) ---------------------------------------------- 5-1

5.4 Battery Temperature Probe Connection (System

equipped with PDU) ---------------------------------------------- 5-1

6. Installation ---------------------------------------------- 6-1

6.1 Preliminary Inspection ---------------------------------------------- 6-1

6.2 System Mounting ---------------------------------------------- 6-1

6.3 Module Installation ---------------------------------------------- 6-1

6.4 Shelf Wiring ---------------------------------------------- 6-1

6.5 AC Input Connections ---------------------------------------------- 6-1

DELTA MCS 1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

INDEX ii

6.6 Battery String Connections (System equipped

with PDU) ---------------------------------------------- 6-1

6.7 Temperature and Alarm Connections ---------------------------------------------- 6-2

6.8 EXT. Breaker trip signal I/P Connector Wiring ---------------------------------------------- 6-2

6.9 AC High Voltage Aux. RelayOutput Wiring---------------------------------------------- 6-2

7. System Start –Up Procedure ---------------------------------------------- 7-1

7.1 Initial Start-Up Preparation ---------------------------------------------- 7-1

7.3 Basic Functional Verification 7.2 No Load

Start-Up ---------------------------------------------- 7-1

7.4 DC Load Connections ---------------------------------------------- 7-1

7.5 System Functionality Check ---------------------------------------------- 7-1

7.6 System Operation ---------------------------------------------- 7-1

8. System Alarms and Troubleshooting ---------------------------------------------- 8-1

8.1 AC Fail Voltage Alarm Description ---------------------------------------------- 8-1

8.2 High Voltage Shutdown Alarm ---------------------------------------------- 8-1

8.3 High Voltage Alarm Description ---------------------------------------------- 8-1

8.4 Low Voltage Alarm ---------------------------------------------- 8-2

8.5 Low Voltage Disconnect Alarm (System

equipped with PDU) ---------------------------------------------- 8-2

8.6 Fuse Fail Alarm (System equipped with PDU) ---------------------------------------------- 8-2

8.7 Alarm Unit Fail ---------------------------------------------- 8-3

8.8 Rectifier Fail Alarm ---------------------------------------------- 8-3

9. Maintenance ---------------------------------------------- 9-1

9.1 Cleaning and Maintenance ---------------------------------------------- 9-1

9.2 Removing and Replacing a Rectifier Unit ---------------------------------------------- 9-1

10. Acronyms and Abbreviations ---------------------------------------------- 10-1 ~3

ATTACHMENT

DELTA MCS-1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

1-1

1 General

1.1 Using This Manual

This manual contains specifications and instructions to properly install and maintain the power supply system.

Component specifications and drawings are also included.

This manual contains information related to the operation and maintenance of the Alarm Control Unit (ALU),

the –48V/+24V Power Supply Unit (PSU), and the Distribution Module. Additional information is provided

on system status and alarms, troubleshooting, and system maintenance. Appendix figures of this manual

contains drawings, simple block diagram for different functional blocks and systems schematic.

Step-by-step procedures required for the installation and turn-up are detailed. All equipment parameter

setting, adjustments, and confirmation, as well as system monitoring, operations, and maintenance procedures,

are included.

Warnings are printed in bold, italic lettering. They alert the installation or maintenance craftsperson of a

potential hazard to either the equipment or the craftsperson if the warning is not followed.

1.2 Safety Notice

Delta Energy Systems is not liable for any hazards incurred by not following proper safety procedures.

Installation, operation, and maintenance personnel should always follow these safety rules:

1. Before installing the system, verify the AC input voltage and frequency, the AC breaker rating and type,

and other environmental conditions as noted in the specifications.

2. The system has passed stringent system testing prior to shipment. To avoid electrical shock. The

rectifier system requires a single ground point permanently connected to earth ground.

3. An AC breaker must provide adequate isolation between the system input and commercial AC main.

4. The environment should be dust free and controlled by an AC system. The area must be free of any

flammable vapors or fluids.

5. To avoid electrical hazard, the covers must not be removed on any component, including the ALU and

the rectifier.

6. Circuit breakers or fuses must be replaced with approved replacement circuit breakers meeting the

original design specification.

7. All connections must be made per the latest issue of the applicable national and local codes.

DELTA MCS-1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

2-1

2 Product Description

2.1 Product Description

This power Shelf consists of modular rectifiers, an Alarm Control Unit (ALU), and a DC distribution

module. Up to four rectifiers and an alarm unit can be equipped on a shelf containing an integrated distribution

module. The rectifiers can operate from a universal range of AC line voltages. The High Line (HL)

operations are defined at an AC line input range of 165VAC~ 264VAC. The Low Line (LL) operations are

defined at an AC line input range of 90 VAC-130 VAC.

The system is controlled and monitored by the ALU. System level rectifier voltage settings, system

status, and alarms are displayed on the ALU. The system float voltage, equalize voltage, and alarm thresholds

are set from RMS. The ALU also provides automatic derating of the output power over the whole operating

line voltages. Figure 1 shows different functional blocks of the system.

2.2 Product Main Features

The Power Shelf has the following main features:

 -48 VDC/120 Amps, or +24VDC/200Amps, N+1 redundancy

 Modular design for scalable, cost effective expansion

 Front access for simple installation and maintenance

 High power density

 Active Power Factor Correction (>. 99PFC)

 High efficiency

 Temperature compensated float voltage control

 Alarm Control Unit

 Low Voltage Battery Disconnect (LVBD) (System equipped with PDU)

 Remote Monitoring and control

2.3 System Specifications

The system specifications are provided in the following sections.

2.3.1 -48V Standard Power Shelf Configuration(MODUL NAME: ES48/120-JAAxx)

(1) AC Input: 175VAC ~ 275VAC, 48Amps. Max

(2) System Capacity: 120Amps. Max.

(3) Rectifier: -48V/30A×1~4

(4) Control and Supervisory Unit

Figure 1 shows a front view of shelf.

DELTA MCS-1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

2-2

Environmental Data

System Environmental Data

Specification Value

Operating temperature 0℃to +50℃

Storage temperature -40℃to +70℃

Humidity 0% to 95% RH

Altitude -300 ft. to 10,000 ft.

Weight Approximately 48 lbs.

EMI/FRI FCC Part 15, Class B and CISPR 22, Class B

Lightning/surge ANSI/IEEE C62.41-1, and IEC 1000-4-5

Seismic Bellcore GR-63-CORE, Zone 4

Safety CUL and UL Listed and Marked

2.3.2 +24V Standard Power Shelf Configuration(MODUL NAME: ES24/200-JAAxx)

(1) AC Input: 175VAC ~ 275VAC, 48Amps. Max

(2) System Capacity: 200Amps. Max.

(3) Rectifier: +24V/50A×1~4

(4) Control and Supervisory

Figure 1 shows a front view of shelf.

Environmental Data

System Environmental Data

Specification Value

Operating temperature 0℃to +50℃

Storage temperature -40℃to +70℃

Humidity 0% to 95% RH

Altitude -300 ft. to 10,000 ft.

Weight Approximately 48 lbs.

Lightning/surge ANSI/IEEE C62.41-1, and IEC 1000-4-5

Seismic Bellcore GR-63-CORE, Zone 4

Safety CUL and UL Listed and Marked

2.3.3 -48V System with Power Distribution and Rectifiers(MODUL NAME: ES48/90-JBAxx)

(1) AC Input: 175VAC ~ 275VAC, 36Amps. Max

(2) System Capacity: 90Amps. Max.

(3) Rectifier: -48V/30A×1~3

(4) Control and Supervisory

(5) Load Distribution: 30A Breaker×5 @ Single Pole

(6) Low Voltage Disconnect Switch: 100A×1 @ Single Pole at Battery Side

(7) Battery Breaker: 100A×1

(8) AC Breaker

DELTA MCS-1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

2-3

Figure 1-1 shows a front view of shelf.

Environmental Data

System Environmental Data

Specification Value

Operating temperature 0℃to +50℃

Storage temperature -40℃to +70℃

Humidity 0% to 95% RH

Altitude -300 ft. to 10,000 ft.

Weight Approximately 48 lbs.

Lightning/surge ANSI/IEEE C62.41-1, and IEC 1000-4-5

Seismic Bellcore GR-63-CORE, Zone 4

2.3.4 -48V System with Power Distribution and Rectifiers(MODUL NAME: ES48/90-JFAxx)

(1) AC Input: 175VAC ~ 275VAC, 36Amps. Max

(2) System Capacity: 90Amps. Max.

(3) Rectifier: -48V/30A×1~3

(4) Control and Supervisory

(5) Load Distribution: 100A Breaker×4 @ Single Pole

(6) Low Voltage Disconnect Switch: 100A×1 @ Single Pole at Battery Side

Figure 1-1 shows a front view of shelf.

Environmental Data

System Environmental Data

Specification Value

Operating temperature 0℃to +50℃

Storage temperature -40℃to +70℃

Humidity 0% to 95% RH

Altitude -300 ft. to 10,000 ft.

Weight Approximately 48 lbs.

EMI/FRI FCC Part 15, Class B and CISPR 22, Class B

Lightning/surge ANSI/IEEE C62.41-1, and IEC 1000-4-5

Seismic Bellcore GR-63-CORE, Zone 4

Safety CUL and UL Listed and Marked

2.4 Electrical Data

The system electrical data is provided in the following tables.

2.4.1 Input

DELTA MCS-1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

2-4

Table 1 displays the system input specifications.

Table 1 System Input Specifications

Specification Value

Nominal range 175 ~ 275VAC

Operational range

90 ~ 275VAC Full Load

150V ~ 175Vac de-rating to 80% Load

90V ~ 150Vac de-rating to 50% Load

50℃~ 65℃de-rating 1500W

Frequency 45 ~ 65Hz

Power Factor >0.99 @ 220VAC, Full Load

THD <5% @ 220VAC, Full Load

Efficiency >90% @ 220VAC, Full Load

2.4.2 Output

Table 2 displays the system output specifications.

Table 2 System Output Specifications

Specification Value

DC Volts 38~60 VDC (-48V Version)

20~30 VDC (+24V Version)

Load regulation <1%

Line regulation <0.2%

Current Limit 110%

Current share <5%

Noise:

Audio band

Wide band

Acoustic

<2mv

<10 mVrms

<55 dBA

2.4.3 Status/Alarm Indicators

The Power Shelf has the following status/alarm indicators:

 Load Current

 AC ON

 Rectifier Fail Alarm (RFA)

 Current Limit (CL)

 Float/Equalize (FL/EQU)

 Major Alarm (MAJ)

 Minor Alarm (MIN)

 High Voltage Alarm (HV)

 High Voltage Shutdown (HVSD)

 Low Voltage Alarm (LV)

 Low Voltage Disconnect Open (LVDS OPEN)

 Fuse Blown (FUSE ALM)

 AC Fail (AC FAIL)

DELTA MCS-1800 3U Power Shelf

Installation, Operations and

Maintenance Manual

2-5

2.4.4 Mechanical Data

Dimension Value

Height 5.2 in. (132mm)

Depth 10.35 in. (263mm)

Width 3.3 in. (83.6mm)

Table des matières

Autres manuels Delta Electronics Alimentation

Delta Electronics

Delta Electronics DPS-350TB series Manuel utilisateur

Delta Electronics

Delta Electronics DPS-350AB-4 Manuel utilisateur

Delta Electronics

Delta Electronics Q48SB Manuel utilisateur

Delta Electronics

Delta Electronics 4.5V~ 5.5V Manuel utilisateur

Delta Electronics

Delta Electronics PMC-24V050W1AA Manuel utilisateur

Delta Electronics

Delta Electronics Delphi DNQ12 Manuel utilisateur

Delta Electronics

Delta Electronics DPS-220AB Manuel utilisateur

Delta Electronics

Delta Electronics LNE V320W Series Guide de l'utilisateur

Delta Electronics

Delta Electronics 33W Family Manuel utilisateur

Delta Electronics

Delta Electronics Delphi S36SE Manuel utilisateur

Delta Electronics

Delta Electronics GPS-230GB-1 Manuel utilisateur

Delta Electronics

Delta Electronics DPS-350QB Manuel utilisateur

Delta Electronics

Delta Electronics DPS-250WB Manuel utilisateur

Delta Electronics

Delta Electronics GPS-450EB EA22 Manuel utilisateur

Delta Electronics

Delta Electronics H48SN Manuel utilisateur

Delta Electronics

Delta Electronics Delphi S48SP Manuel utilisateur

Delta Electronics

Delta Electronics TAP-CP01 Manuel utilisateur

Delta Electronics

Delta Electronics VFD-M Manuel utilisateur

Delta Electronics

Delta Electronics Delphi NC Series Manuel utilisateur

Delta Electronics

Delta Electronics DRP024V060W1BA Manuel utilisateur

Delta Electronics

Delta Electronics Delphi Q48DR Manuel utilisateur

Delta Electronics

Delta Electronics Delphi NE Series Manuel utilisateur

Delta Electronics

Delta Electronics DPS-180KB-4 Series Manuel utilisateur

Delta Electronics

Delta Electronics DPS-300PB-2 Manuel utilisateur

Manuels Alimentation populaires d'autres marques

Monacor

Monacor PS-12CCD Manuel utilisateur

VOLTIMA

VOLTIMA MagicBox 15 Manuel utilisateur

Agilent Technologies

Agilent Technologies 6032A Manuel utilisateur

Miller

Miller Auto Deltaweld 452 Manuel utilisateur

BCP

BCP PUOUBK Feuille d'instructions

HC 2210 Manuel utilisateur

Puls

Puls CT5.241 Manuel utilisateur

OCZ

OCZ ZX1250W Manuel utilisateur

iseg

iseg ECH 238 Manuel utilisateur

Power

Power XXL A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 6631B Manuel utilisateur

Renogy

Renogy PHOENIX 300 Manuel utilisateur

HP 6200B Manuel de service

Epson

Epson Stylus Scan 2500 Manuel d'utilisation

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuel utilisateur

Puls

Puls MiniLine ML50.100 Manuel utilisateur

Puls

Puls AS-Interface SLA4.100 Manuel utilisateur

Kenwood

Kenwood PS-60 Manuel utilisateur
