Delta Electronics Delphi NE Series Manuel utilisateur

OPTION

 Vertical or horizontal versions

Delphi NE Series Non-Isolated Point of Load

DC/DC Modules: 4.5~13.8Vin, 0.59V-5.1Vout, 20A

The Delphi NE 20A Series, 4.5V to 13.8V wide input, wide trim single

output, non-isolated point of load (POL) DC/DC converters are the

latest offering from a world leader in power systems technology and

manufacturing —Delta Electronics, Inc. The ND/NE product family is

the second generation, non-isolated point-of-load DC/DC power

modules for the datacom applications which cut the module size by

almost 50% in most of the cases compared to the first generation NC

series POL modules. The NE 20A product family provides an ultra

wide input range to support 5V, 8V, 9.6V, and 12V bus voltage

point-of-load applications and it offers 20A of output current in a

vertically or horizontally mounted through-hole miniature package and

the output can be resistor trimmed from 0.59Vdc to 5.1Vdc. It

provides a very cost effective, high efficiency, and high density point

of load solution. With creative design technology and optimization of

component placement, these converters possess outstanding

electrical and thermal performance, as well as extremely high

reliability under highly stressful operating conditions.

APPLICATIONS

 DataCom

 Distributed power architectures

 Servers and workstations

 LAN/WAN applications

 Data processing applications

FEATURES

 High Efficiency:

94.0% @ 12Vin, 5V/20A out

 Size:

Vertical: 30.5x15.5x12.0mm

(1.20”x0.61”x0.47”)

Horizontal: 30.5x15.5x12.9mm

(1.20”x0.61”x0.51”)

 Wide input range: 4.5V~13.8V

 Output voltage programmable from

0.59Vdc to 5.1Vdc via external resistors

 Voltage and resistor-based trim

 No minimum load required

 Fixed frequency operation

 Input UVLO, output OCP, SCP

 Remote ON/OFF (Positive)

 ISO 9001, TL 9000, ISO 14001, QS9000,

OHSAS18001 certified manufacturing

facility

 UL/cUL 60950 (US & Canada), TUV

(EN60950) -- pending

PRELIMINARY DATABRIEF

DB_NE12S20A_07272007

SPECIFICATIONS

GENERAL SPECIFICATIONS OUTPUT SPECIFICATIONS

Input Voltage 4.5V~13.8V Output Programmable 0.59V ~ 5.1V

Switching Frequency Typical 500KHz

olta

e Typical ±1.5% of Vo

Operating Temperature Horizontal 0°C ~ + 130°C Output Current Maximum 20A

MTBF TBD M hours Ripple & Noise 12Vin, 2.5Vout 25 mVp-p

Size (Vertical) (1.20”x0.61”x0.47”) 30.5x15.5x12.0mm Weight 8.8 g

Size (Horizontal) (1.20”x0.61”x0.51”) 30.5x15.5x12.9mm

PART NUMBERING SYSTEM

NE 12 S 0A0 V 20 P N F A

Product

Series Input Voltage Number of

outputs Output

Voltage Mounting Output

Current ON/OFF

Logic Pin

Length Option

Code

NE-

Non-isolated

Series

12- 4.5V~13.8V

S - Single

output

0A0-

programmable V- Vertical

H- Horizontal

20 - 20A

P - Positive

N - 0.150”

F - RoHS 6/6

(Lead Free) A-standard

MODEL LIST

Model Name Packaging Input Voltage Output Voltage Output Current Efficiency 12Vin/5Vo @

100% load

NE12S0A0V20PNFA Vertical 4.5V ~ 13.8Vdc 0.59 V ~ 5.1Vdc 20A 94%

NE12S0A0H20PNFA Horizontal 4.5V ~ 13.8Vdc 0.59 V ~ 5.1Vdc 20A 94%

MECHANICAL DRAWING

VERTICAL HORIZONTAL

CONTACT: www.delta.com.tw/dcdc

USA:

Telephone:

East Coast: (888) 335 8201

West Coast: (888) 335 8208

Fax: (978) 656 3964

Email: [email protected]

Europe:

Telephone: +41 31 998 53 11

Fax: +41 31 998 53 53

Email: [email protected]

Asia & the rest of world:

Telephone: +886 3 4526107 ext. 6220

Fax: +886 3 4513485

Email: [email protected]

WARRANTY

Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.

Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor for any

infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any

patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
