Delta Electronics EFB0812HHB Manuel

* Function type is optional.

* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.

* Noise is measured in anechoic chamber in free air, one meter from intake side.

* All readings are typical values at rated voltage.

* Specifications are subject to change without notice.

* Both of the ball bearing and the 1 ball + 1 Sleeve type are available.

80 x 80 x 15 MM SERIES

EFB

DIMENSIONS DRAWING

P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT

(INCH)

UNIT:

OUTLET SIDE INLET SIDE

Bearing Type

Ball Bearings

Material

Impeller & Frame : Plastic(UL 94V-0)

Lead Wires :

UL 1007 AWG #24 OR Equivalent

Red Wire Positive(+)

Black Wire Negative(-)

Weight : 67g (2.36 OZ)

Rib Type Only

Operating

Voltage

Range

MODEL Rated

Voltage

Maximum

Air Flow

Speed

Maximum

Air Pressure

Noise

PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A

EFB0812LB -R00 / -F00 12 5.0 to 13.8 0.10 1.20 2300 0.839 29.62 1.71 0.067 30.0

EFB0824LB -R00 / -F00 24 14.0 to 27.6 0.08 1.92

EFB0812MB -R00 / -F00 12 5.0 to 13.8 0.13 1.56 2800 1.020 36.02 2.51 0.099 33.0

EFB0824MB -R00 / -F00 24 14.0 to 27.6 0.11 2.64

EFB0812HB -R00 / -F00 12 5.0 to 13.8 0.21 2.52 3300 1.200 42.37 3.42 0.134 37.0

EFB0824HB -R00 / -F00 24 14.0 to 27.6 0.14 3.36

EFB0812HHB -R00 / -F00 12 5.0 to 13.2 0.33 3.96 3800 1.382 48.80 4.35 0.171 41.0

EFB0824HHB -R00 / -F00 24 14.0 to 27.6 0.20 4.80

http://www.deltaww.com

Air Pressure

(mm H O)

(IN H O)

Air Flow

0 12.0 36.024.0 48.0

2.0

1.0

0.06

0.03

0 0.3

5.0

3.0

4.0

0.12

0.09

0.15

0.6 0.9 1.2 1.5

(CFM)

(M /MIN)

EFB812/24XB

6.0

0.18

Input

Power

Input

Current
