ELECTRIC OIL FILLED RADIATOR

INSTRUCTIONS FOR USE

SAVE THESE INSTRUCTIONS

RADIATEURS À BAIN D’HUILE

CONSIGNES D'UTILISATION

CONSERVER CES CONSIGNES

RADIADORES ELÉCTRICOS DE ACEITE

INSTRUCCIONES PARA EL USO

REPASE Y GUARDE ESTAS INSTRUCCIONES

LEA CUIDADOSAMENTE ESTE INSTRUCTIVO

ANTES DE USAR SU APARATO

TYPE/MODELO: EW7507EB/EW7507EBL

Illustrated. Visit www.delonghiregistration.com.

Visit www.delonghi.com for a list of service centers near you. (U.S.

Only)

Enregistrez ce produit en ligne et recevez un numéro gratuit de Cook's

Illustrated. Visitez www.delonghiregistration.com.

Visitez www.delonghi.com pour y voir une liste des centres de répa-

ration proches de chez vous. (É.-U. uniquement)

Registre este producto en línea y reciba un ejemplar gratis de Cook's

Illustrated. Visite www.delonghiregistration.com.

Visite www.delonghi.com para ver la lista de centros de servicios cer-

canos a usted. (Solamente en los Estados Unidos)

ELECTRIC CHARACTERISTICS/ CARACTÉRISTIQUES ÉLECTRO-

NIQUES/CARACTERISTICAS ELECTRICAS

120V˜60Hz 1500W

Service Questions: Contact DeLonghi at 1-866-528-8323

Sales Inquiries: Contact Sylvane at 1-800-934-9194 or visit

sylvane.com

IMPORTANT SAFEGUARDS

When using electrical appliances, basic precautions should always be taken to

avoid the risk of fire, electric shock and personal injury, including the following:

1. Read all instructions before using this heater.

2. If your radiator is equipped with a polythene tape used as carry handle,

remove it before connecting appliance to the outlet.

3. This heater is hot when in use. To avoid burns, do not let bare skin touch hot

surfaces. Use handle when moving this heater. Keep combustible materials,

such as furniture, pillows, bedding, papers, clothes, and curtains at least 3

feet (0,9 m) from the front and top of the heater and keep them away from

the sides and rear.

4. Extreme caution is necessary when any heater is used by or near children or

invalids and whenever the heater is left operating and unattended.

5. Always unplug heater when not in use.

6. Check that neither the appliance nor the power cable have been damaged in

any way during transportation.

7. Do not operate any heater with a damaged cord or plug or after the hea-

ter malfunctions, has been dropped or damaged in any manner. If heater

has leaked any oil, discontinue using the heater and contact the service

center as indicated in the instruction leaflet. Return heater to authorized

service facility for examination, electrical or mechanical adjustment, or

repair.

8. Do not use outdoors. Household use only.

9. This heater is not intended for use in bathrooms, laundry areas and similar

indoor locations. Never locate heater where it may fall into a bathtub or

other water container.

10.Do not run cord under carpeting. Do not cover cord with throw rugs, run-

ners, or similar coverings. Do not route cord under furniture or appliances.

Arrange cord away from traffic area and where it will not be tripped over.

11.To disconnect heater, turn controls to off, then remove plug from outlet.

12. Connect to properly polarized outlets only.

13.Do not insert or allow foreign objects to enter any ventilation or exhaust ope-

ning as this may cause an electric shock, fire, or damage the heater.

14.To prevent a possible fire, do not block air intakes or exhaust in any manner.

Do not use on soft surfaces, like a bed, where openings may become

blocked.

15.A heater has hot and arcing or sparking parts inside. Do not use in areas

where gasoline, paint, or flammable liquids are used or stored.

16.Use this heater only as described in this manual. Any other use not recom-

mended by the manufacturer may cause fire, electric shock, or injury to per-

sons.

17.To prevent overload and blown fuses, be sure that no other appliance is

plugged into the same outlet (receptacle) or into another outlet (receptacle)

wired into the same circuit.

18.It is normal for the heater’s plug and cord to feel warm to the touch. A plug

or cord which becomes hot to the touch or becomes distorted in shape may

be a result of a worn electrical outlet. Worn outlets or receptacles should be

replaced prior to further use of the heater. Plugging heater into a worn

outlet /receptacle/ may result in overheating of the power cord or fire.

19.Always plug heaters directly into a wall outlet/receptacle. Never use with an

extension cord or relocatable power tap (outlet/power strip).

20.Be sure that the plug is fully inserted into an appropriate outlet. Please

remember that outlets also deteriorate due to aging and continuous use:

check periodically if signs overheating or deformations are evidenced by the

plug. Do not use the outlet and CALL your electrician.

21.Make sure that no pieces of polystyrene or other packaging material have

been left between one element of the appliance and another. It may be

necessary to pass over the appliance with a vacuum cleaner.

22.When switching on the appliance for the first time, allow it to run at full

power for about two hours to get rid of the unpleasant smell Make sure

that the room in which the appliance is located is well ventilated during

this operation. It is normal for the appliance to emit small cracking sounds

when you turn it on for the first time.

23.Do not cover the appliance while it is functioning in order to avoid overhea-

ting with the attendant risk of fire.

SAVE THESE INSTRUCTIONS

HOW TO USE YOUR HEATER

"EASY WHEEL" SYSTEM

Turn the radiator upside-down on a rug or a soft surface in order to prevent damaging

the paint finish. Fully unfold the castors by turning them outwards (Fig. 1).

Turn the radiator back to its upright position.

LOCATION

Place the radiator on the floor beneath coldest window in the room or any desired loca-

tion. Your heater will minimize the effect of cold drafts. The heater must not be placed

immediately below a power-outlet. Do not use this radiator in rooms having a surface

area of less than 43 square feet (4 sq.m.).

POWER CONNECTION

The radiator must be connected to a properly polarized A/C 110/120 V household

outlet in perfect working condition.

Keep loose clothing or bedding, furniture and flammable material away from the power

outlet where the heater is plugged into.

Your product is equipped with a polarized alternating current line plug (a plug having one blade

wider than the other). This plug will fit into the power outlet only one way. This is a safety feature.

If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should

still fail to fit, contact your electrician to replace your obsolete outlet.

Do not attempt to modify the plug to bypass this safety feature.

fig. 1

OPERATION AND USE

1) SETTING THE CLOCK

For the first time, set the clock to the correct time, proceeding as follows:

• Press the button “h” until the display shows the correct hour setting.

• Press the button “min” until the display shows the correct minute setting.

When setting the clock time, the numbers will flash on the display.

The flashing numbers will continue for a few seconds until the adjustment has finished.

Once the numbers stop flashing the clock will start working.

To change the time, press and hold the “h” or “min” button for at least 5 seconds or

until the numbers are flashing. Then proceed as above to modify both hours and minu-

tes.

2) MANUAL OPERATION

To operate the appliance in “manual” mode, press the “ON MODE” button.

To set the required power level: press the “ON MODE" button, and then press again one or

more times within 5 seconds to select the power level, as per the following sequence:

Maximum power

Medium power

Minimum power

Off

If Maximum power has been selected, adjust the “ +” or ” -” button to the desired comfort

temperature, from 42 to 95°F (5 to 35°C). By pushing once the “ +” or “ -” button the desi-

red temperature (shown on the right side of the display) will increase or decrease of 1°F.

Press and hold the button to move through the temperature mode quickly.

correct time Set temperature

set temperature

correct time

ELECTRONIC CLIMATE CONTROL

This heater has Electronic Climate Control (ECC) which automatically monitors and

selects the ideal power setting to maintain your chosen temperature.

If the selected temperature is higher than the actual room temperature, the appliance

will start automatically and rapidly heat the room until it reaches the selected tempera-

ture. The unit will automatically maintain the temperature at a constant level, by swit-

ching between maximum, medium, minimum power and OFF.

If medium power level has been selected using the “ON MODE” button, the appliance

will cycle between medium, minimum power and OFF to maintain a selected tempera-

ture.

ANTI-FREEZE SETTING

Press the “ON MODE” button and select the maximum power level. Set the temperatu-

re to 42°F (5°C) with the “ -” button. When set in this way, the appliance will turn

on automatically only if the room temperature falls below 42°F (5°C), to prevent free-

zing conditions.

Note: This function is not guaranteed in the event of power failures, lasting more than

2 minutes.

TIMER OPERATION

The timer allows you to set two programs in a 24-hour period.

To program the timer:

Press the Timer button A (see Figure 2), this the following is displayed:

- The flashing message “--:--“;

- The message “ON” at the bottom left (ON time setting);

- The symbol “A” at the right indicating that the first program controlling is being set;

To set the “START” time press the “h” button to set the hour and “min” button to set the

minutes, then confirm the “START” time by pressing the “Timer button A” again.

The words “OFF” and “12:00” appear on the display.

Set the time you want the appliance to go OFF using the “h” button and “min” button,

then confirm the OFF time by pressing the “Timer button A” again.

At this point, the word “AUTO” appears at the top of the display and the “ ”

indicator light comes on to indicate that the appliance is ready to operate at the

programmed time maintaining the preset comfort temperature (fig.2).

fig. 2

- To set the program Bpress “Timer button B” and follow the same procedure as

described for the program A.

- Use the “ +” or “ -” buttons to set the desired comfort tempera-

ture, as described above.

- When set in this way the heater will automatically switch on at the set

time for the designated time period and automatically maintain the

preset comfort temperature.

To cancel a preset program, press the timer button A or Bonce and then press the

hour button until the display shows “--:--“ (fig.3).

TIMER OVERRIDE

To operate the appliance without using the programs (timer), press the “ON MODE” button

(Fig.2). The yellow lamp “ “ will go off.

IMPORTANT:

If the heater looses its electricity supply for more than 2 minutes the appliance does not switch

on. The display shows the blinking numbers. To switch it on, repeat the above described ope-

rations.

Remote Control

The appliance can be completely controlled with the remote control. Two AAA 1.5V batteries

are required (not included):

• remove the cover located on the back side of the remote control;

• insert the two AAA 1.5V batteries positioning them correctly (see the instructions in the

batteries compartment);

• replace the cover.

Remote Control Operation

- When you press the frost protection push button, the radiator will set the temperature to

42°F (5°C) and will switch on automatically only if the room temperature falls below 42°F

(5°C), thereby preventing freezing, at minimum energy consumption.

The “ “ light on the control panel will flash.

- Press the increase/decrease temperature button (+/-) to adjust the temperature from 42°F

(5°C) to 95°F (35°C).

- The “Off” button switches off the appliance.

Every time you press a button, the appliance will confirm the selection with a “beep” and

the pilot light on the remote control will illuminate.

fig. 3

WARNINGS

You must leave the heater plugged into the outlet to keep the timer

memory programmed.

If the heater loses its power supply for more than 2 minutes, (e.g. switched off at the outlet or

in the event of a power failure), the heater’s programs will be lost, and the heater will not

work until reset.

SAFETY DEVICE

Asafety device switches the heater off in the event of everheating. To restart the heater,

call the nearest service center.

Note: when the safety device intervenes, the heater doesn’t

heat but the display works.

MAINTENANCE AND SERVICE

Always remove the plug from the power outlet and allow the radiator to cool. Wipe radiator

with a soft damp cloth, do not use detergents and abrasives. Should the radiator not be in use

over a certain length of time, wind the cable round the holder and store it in a dry place. This

appliance has been built to give many years of trouble free service. In case of malfunction or

doubt, do not try to repair the heater by yourself: it may result in a fire hazard or electric

shock. Call the nearest Service Center (see attached list of Service Centers) or call customer

support at 1-800-322-3848.

NOTE: This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful interfer-

ence to radio communications. However, there is no guarantee that interference will

not occur in a particular installation. lf this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

Modifications not approved by the party responsible for compliance could void user’s

authority to operate the equipment.

This warranty applies to all products with De’Longhi or Kenwood brand names.

Limited Warranty

What does the warranty cover?

We warrant each appliance to be free from defects in material and workmanship. Our obliga-

tion under this warranty is limited to repair at our factory or authorized service center of any

defective parts or part thereof, other than parts damaged in transit. In the event of a products

replacement or return, the unit must be returned transportation prepaid. The repaired or new

model will be returned at the company expense. This warranty shall apply only if the appliance

is used in accordance with the factory directions, which accompany it, and on an Alternating

current ( AC ) circuit.

How long does the coverage last?

This warranty runs for one year ( 1 ) from the purchase date found on your receipt and applies

only to the original purchaser for use.

What is not covered by the warranty?

The warranty does not cover defects or damage of the appliance, which result from repairs or

alterations to the appliance outside our factory or authorized service centers, nor shall it apply

to any appliance, which has been subject to abuse, misuse, negligence or accidents. Also, con-

sequential and incidental damage resulting from the use of this product or arising out of any

breach of contract or breach of this warranty are not recoverable under this warranty. Some

states do not allow the exclusion or limitation of incidental or consequential damage, so the

above limitation may not apply to you.

How do you get service?

If repairs become necessary, see contact information below:

U.S. Residents:

Please contact our toll free hotline at 1-800-322-3848 or log onto our website at

www.delonghiusa.com. For all accessories, spare parts or replacement parts, please contact our

parts division at 1-800-865-6330.

Residents of Canada: Please contact our toll free hotline at 1-888-335-6644 or log onto our

website at www.delonghi.com.

Residents of Mexico: Please refer to the Limited Warranty statement for Mexico.

Please refer to the back page of the manual for De’Longhi addresses.

The above warranty is in lieu of all other express warranties and representations. All implied

warranties are limited to the applicable warranty period set forth above. This limitation does not

apply if you enter into an extended warranty with De’Longhi. Some states do not allow limita-

tions on how long an implied warranty lasts, so the above exclusions may not apply to you.

De’Longhi does not authorize any other person or company to assume for it any liability in con-

nection with the sale or use of its appliance.

How does state law apply?

This warranty gives you specific legal rights, and you may also have other rights, which vary

from state to state.

Service Questions: Contact DeLonghi at 1-866-528-8323

Sales Inquiries: Contact Sylvane at 1-800-934-9194 or visit

sylvane.com

Autres manuels pour EW7507EB

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels DeLonghi Chauffage

DeLonghi

DeLonghi HVE333 Manuel utilisateur

DeLonghi

DeLonghi DRAGON 3 Manuel utilisateur

DeLonghi

DeLonghi TRN Manuel utilisateur

DeLonghi

DeLonghi ELECTRIC PANEL HEATER Manuel utilisateur

DeLonghi

DeLonghi FAN HEATER Manuel utilisateur

DeLonghi

DeLonghi HSX Series Manuel utilisateur

DeLonghi

DeLonghi Dragon4 Pro Fiche technique

DeLonghi

DeLonghi TRV Series Manuel utilisateur

DeLonghi

DeLonghi CERAMIC FAN HEATER Manuel utilisateur

DeLonghi

DeLonghi Holmo Fluid Manuel utilisateur

DeLonghi

DeLonghi TRD40615T-6A Manuel utilisateur

DeLonghi

DeLonghi TRRS0715E Manuel utilisateur

DeLonghi

DeLonghi HEX60 Series Manuel utilisateur

DeLonghi

DeLonghi TRD40820 Manuel utilisateur

DeLonghi

DeLonghi HCM2030 Manuel utilisateur

DeLonghi

DeLonghi Radia R 030715 Manuel utilisateur

DeLonghi

DeLonghi TRD40615ECA Manuel utilisateur

DeLonghi

DeLonghi MCH 710T Manuel utilisateur

DeLonghi

DeLonghi DCH4120 Manuel utilisateur

DeLonghi

DeLonghi HCS Manuel utilisateur

DeLonghi

DeLonghi PALACE 1800/2 Manuel d'installation et d'exploitation

DeLonghi

DeLonghi DRAGON HM3 Manuel utilisateur

DeLonghi

DeLonghi TRRS0715.B Manuel utilisateur

DeLonghi

DeLonghi HMP1500 Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
